PC の背面にある緑色のポートに有線接続されたヘッドセットがあります。マイクが機能しません。PC の設定 > サウンドは次のとおりです。
出力デバイス: テストボタンでヘッドフォン-内蔵オーディオ。ライン出力-内蔵オーディオに変更するオプションがあります。
入力デバイス: フロント マイク - 内蔵オーディオ。テスト ボタンも変更オプションもありません。
ターミナルでの aplay コマンドの結果は次のとおりです。
$ aplay -l
**** List of PLAYBACK Hardware Devices ****
card 0: HDMI [HDA Intel HDMI], device 3: HDMI 0 [HDMI 0]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA Intel HDMI], device 7: HDMI 1 [HDMI 1]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA Intel HDMI], device 8: HDMI 2 [HDMI 2]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA Intel HDMI], device 9: HDMI 3 [HDMI 3]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 0: HDMI [HDA Intel HDMI], device 10: HDMI 4 [HDMI 4]
Subdevices: 1/1
Subdevice #0: subdevice #0
card 1: PCH [HDA Intel PCH], device 0: ALC662 rev1 Analog [ALC662 rev1 Analog]
Subdevices: 0/1
Subdevice #0: subdevice #0
ターミナルのミキサーの結果は次のとおりです。マイク コントロールは、オーディオ入力がヘッドセットとは別になっていることを示しているようです。ヘッドセット マイクを使用できる場合、どのような調整を行う必要がありますか?
$ amixer -c1
Simple mixer control 'Master',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 64
Mono: Playback 64 [100%] [0.00dB] [on]
Simple mixer control 'Headphone',0
Capabilities: pswitch
Playback channels: Front Left - Front Right
Mono:
Front Left: Playback [on]
Front Right: Playback [on]
Simple mixer control 'Headphone+LO',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 64
Mono:
Front Left: Playback 64 [100%] [0.00dB]
Front Right: Playback 64 [100%] [0.00dB]
Simple mixer control 'PCM',0
Capabilities: pvolume
Playback channels: Front Left - Front Right
Limits: Playback 0 - 255
Mono:
Front Left: Playback 255 [100%] [0.00dB]
Front Right: Playback 255 [100%] [0.00dB]
Simple mixer control 'Front',0
Capabilities: pswitch
Playback channels: Front Left - Front Right
Mono:
Front Left: Playback [on]
Front Right: Playback [on]
Simple mixer control 'Front Mic',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Front Mic Boost',0
Capabilities: volume
Playback channels: Front Left - Front Right
Capture channels: Front Left - Front Right
Limits: 0 - 3
Front Left: 3 [100%] [30.00dB]
Front Right: 3 [100%] [30.00dB]
Simple mixer control 'Surround',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 64
Mono:
Front Left: Playback 0 [0%] [-64.00dB] [off]
Front Right: Playback 0 [0%] [-64.00dB] [off]
Simple mixer control 'Center',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 64
Mono: Playback 0 [0%] [-64.00dB] [off]
Simple mixer control 'LFE',0
Capabilities: pvolume pvolume-joined pswitch pswitch-joined
Playback channels: Mono
Limits: Playback 0 - 64
Mono: Playback 0 [0%] [-64.00dB] [off]
Simple mixer control 'Line',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Capture',0
Capabilities: cvolume cswitch
Capture channels: Front Left - Front Right
Limits: Capture 0 - 31
Front Left: Capture 31 [100%] [33.00dB] [on]
Front Right: Capture 31 [100%] [33.00dB] [on]
Simple mixer control 'Capture',1
Capabilities: cvolume cswitch
Capture channels: Front Left - Front Right
Limits: Capture 0 - 31
Front Left: Capture 0 [0%] [-13.50dB] [off]
Front Right: Capture 0 [0%] [-13.50dB] [off]
Simple mixer control 'Channel Mode',0
Capabilities: enum
Items: '2ch' '4ch' '6ch'
Item0: '2ch'
Simple mixer control 'Input Source',0
Capabilities: cenum
Items: 'Front Mic' 'Rear Mic' 'Line'
Item0: 'Front Mic'
Simple mixer control 'Input Source',1
Capabilities: cenum
Items: 'Front Mic' 'Rear Mic' 'Line'
Item0: 'Front Mic'
Simple mixer control 'Loopback Mixing',0
Capabilities: enum
Items: 'Disabled' 'Enabled'
Item0: 'Disabled'
Simple mixer control 'Rear Mic',0
Capabilities: pvolume pswitch
Playback channels: Front Left - Front Right
Limits: Playback 0 - 31
Mono:
Front Left: Playback 0 [0%] [-34.50dB] [off]
Front Right: Playback 0 [0%] [-34.50dB] [off]
Simple mixer control 'Rear Mic Boost',0
Capabilities: volume
Playback channels: Front Left - Front Right
Capture channels: Front Left - Front Right
Limits: 0 - 3
Front Left: 0 [0%] [0.00dB]
Front Right: 0 [0%] [0.00dB]
