新しいバージョンの libvirtd で LXC を起動しようとしていますが、次のエラーが発生して起動に失敗します。
$ virsh -c lxc: start textlxc
error: Failed to start domain testlxc
error: internal error: cannot load AppArmor profile 'libvirt-dfb2c573-05cb-4ca3-9e46-bea6cebf0f9f'
エラーメッセージログファイル
2015-06-23 12:13:12.306+0000: 14141: error : virCommandWait:2532 : internal error: Child process (/usr/lib/libvirt/virt-aa-helper -p 0 -c -u libvirt-dfb2c573-05cb-4ca3-9e46-bea6cebf0f9f) unexpected exit status 1: virt-aa-helper: error: /proc/meminfo
virt-aa-helper: error: skipped restricted file
virt-aa-helper: error: invalid VM definition
2015-06-23 12:13:12.306+0000: 14141: error : AppArmorGenSecurityLabel:468 : internal error: cannot load AppArmor profile 'libvirt-dfb2c573-05cb-4ca3-9e46-bea6cebf0f9f'
これは私のテストlxc.xmlファイル
<domain type='lxc'>
<name>testlxc</name>
<uuid>dfb2c573-05cb-4ca3-9e46-bea6cebf0f9f</uuid>
<memory unit='KiB'>4048292</memory>
<currentMemory unit='KiB'>4048292</currentMemory>
<vcpu placement='static'>2</vcpu>
<resource>
<partition>/machine</partition>
</resource>
<os>
<type arch='x86_64'>exe</type>
<init>/sbin/init</init>
</os>
<clock offset='utc'/>
<on_poweroff>destroy</on_poweroff>
<on_reboot>restart</on_reboot>
<on_crash>destroy</on_crash>
<devices>
<emulator>/usr/lib/libvirt/libvirt_lxc</emulator>
<filesystem type='mount' accessmode='passthrough'>
<source dir='/var/lib/libvirt/filesystems/testlxc'/>
<target dir='/'/>
</filesystem>
<filesystem type='mount' accessmode='passthrough'>
<source dir='/var/lib/libvirt/filesystems/testlxc-data'/>
<target dir='/mnt/data'/>
</filesystem>
<filesystem type='mount' accessmode='passthrough'>
<source dir='/var/run/testlxc/lxc'/>
<target dir='/mnt/run'/>
</filesystem>
<filesystem type='mount' accessmode='passthrough'>
<source dir='/proc/meminfo'/>
<target dir='/proc/meminfo'/>
</filesystem>
<console type='pty' tty='/dev/pts/1'>
<source path='/dev/pts/1'/>
<target type='lxc' port='0'/>
<alias name='console0'/>
</console>
</devices>
</domain>
実行中の Libvirt のバージョンは 1.2.12 です。以前はバージョン 1.2.2 で lxc を正常に実行していました。
$ libvirtd --version
libvirtd (libvirt) 1.2.12
答え1
問題はユーティリティのドメイン XML 検証にあることを突き止めました。これは、要求に応じて AppArmor プロファイルを生成するユーティリティです。失敗するのは XML の構造ではありませんが、報告されたエラーはこれが原因であることを示しているようです。関数function invirt-aa-helper
内の論理検証は、LXC コンテナーでは機能しません。virDomainDefParseXML
domain_conf.c
私は libvirt コードに十分精通していないため、この共有領域を変更できません。他の何かを壊してしまった可能性がありますが、次のパッチは機能するようです。
if (!(flags & VIR_DOMAIN_DEF_PARSE_SKIP_OSTYPE_CHECKS)) {
/* If the logic here seems fairly arbitrary, that's because it is :)
* This is duplicating how the code worked before
* CapabilitiesDomainDataLookup was added. We can simplify this,
* but it would take a bit of work because the test suite fails
* in numerous minor ways. */
bool use_virttype = ((def->os.arch == VIR_ARCH_NONE) ||
!def->os.machine);
virCapsDomainDataPtr capsdata = NULL;
読む
if (!(flags & VIR_DOMAIN_DEF_PARSE_SKIP_OSTYPE_CHECKS)) {
/* If the logic here seems fairly arbitrary, that's because it is :)
* This is duplicating how the code worked before
* CapabilitiesDomainDataLookup was added. We can simplify this,
* but it would take a bit of work because the test suite fails
* in numerous minor ways. */
bool use_virttype = (def->os.type != VIR_DOMAIN_OS_TYPE_EXE) &&
((def->os.arch == VIR_ARCH_NONE) ||
!def->os.machine);
virCapsDomainDataPtr capsdata = NULL;
残念ながら、再コンパイルせずにこれを修正する方法は見つかりませんでした。64ビットマシンを使用している場合は、ローカルでビルドしたパッケージを以下からダウンロードできます。このリンク(Microsoft アカウントで失礼します)。
注記: このバグの影響を受けているかどうかを確認するには、コマンドプロンプトで次のコマンドを入力します(このフォーラム投稿):
$ export VM=foo ; virsh -c lxc:// dumpxml $VM |\
sudo /usr/lib/libvirt/virt-aa-helper -c \
-u libvirt-`virsh -c lxc:// domuuid $VM`
foo
失敗したlxcコンテナの名前はどこにありますか。出力が表示された場合
virt-aa-helper: error: could not parse XML
virt-aa-helper: error: could not get VM definition
おそらく同じバグです。
