なぜdig正常に動作するのか、なぜ私の NetGear ルーターが直接動作しないのか (最初にそこにアクセスしますが、それは私の DNS なので、NetGear 自体が8.8.8.8プライマリ DNS として設定されています)。私の NetGear に192.168.1.1は LAN 上の IP があります。ここに完全なシナリオを添付しました。フレームの分析から、両方の要求がUDP 上の192.168.1.1ポートでルーター NetGear に届くことが IMO でわかります53。他に違いはありませんか、それとも何か違いがありますか? 助けてください。
フレーム番号の違いやその他の明らかな違いを除けば、私にとって目に見える唯一の違いは
[Coloring Rule Name: UDP]
[Coloring Rule String: udp]
OK フレームには存在し、失敗したパケットには存在しません (失敗 - つまり、192.168.1.1 からまったく応答がない)
dig cf16.eu
; <<>> DiG 9.9.2-P2 <<>> cf16.eu
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 24482
;; flags: qr rd ra; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 1
;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 512
;; QUESTION SECTION:
;cf16.eu. IN A
;; ANSWER SECTION:
cf16.eu. 3600 IN A 89.75.41.50
;; Query time: 10 msec
;; SERVER: 127.0.1.1#53(127.0.1.1)
;; WHEN: Wed May 8 17:47:05 2013
;; MSG SIZE rcvd: 52
しかし：
dig @192.168.1.1 cf16.eu
; <<>> DiG 9.9.2-P2 <<>> @192.168.1.1 cf16.eu
; (1 server found)
;; global options: +cmd
;; connection timed out; no servers could be reached
Wireshark パケット: dig cf16.eu [OK]
No. Time Source Destination Protocol Length Info
340 4.775113000 192.168.1.3 192.168.1.1 DNS 78 Standard query 0x5fa2 A cf16.eu
Frame 340: 78 bytes on wire (624 bits), 78 bytes captured (624 bits) on interface 0
Interface id: 0
WTAP_ENCAP: 1
Arrival Time: May 8, 2013 17:47:04.131360000 CEST
[Time shift for this packet: 0.000000000 seconds]
Epoch Time: 1368028024.131360000 seconds
[Time delta from previous captured frame: 0.005265000 seconds]
[Time delta from previous displayed frame: 0.005265000 seconds]
[Time since reference or first frame: 4.775113000 seconds]
Frame Number: 340
Frame Length: 78 bytes (624 bits)
Capture Length: 78 bytes (624 bits)
[Frame is marked: False]
[Frame is ignored: False]
[Protocols in frame: eth:ip:udp:dns]
[Coloring Rule Name: UDP]
[Coloring Rule String: udp]
Ethernet II, Src: Micro-St_4b:47:dc (d4:3d:7e:4b:47:dc), Dst: Netgear_bb:b7:2c (00:1b:2f:bb:b7:2c)
Destination: Netgear_bb:b7:2c (00:1b:2f:bb:b7:2c)
Address: Netgear_bb:b7:2c (00:1b:2f:bb:b7:2c)
.... ..0. .... .... .... .... = LG bit: Globally unique address (factory default)
.... ...0 .... .... .... .... = IG bit: Individual address (unicast)
Source: Micro-St_4b:47:dc (d4:3d:7e:4b:47:dc)
Address: Micro-St_4b:47:dc (d4:3d:7e:4b:47:dc)
.... ..0. .... .... .... .... = LG bit: Globally unique address (factory default)
.... ...0 .... .... .... .... = IG bit: Individual address (unicast)
Type: IP (0x0800)
Internet Protocol Version 4, Src: 192.168.1.3 (192.168.1.3), Dst: 192.168.1.1 (192.168.1.1)
Version: 4
Header length: 20 bytes
Differentiated Services Field: 0x00 (DSCP 0x00: Default; ECN: 0x00: Not-ECT (Not ECN-Capable Transport))
0000 00.. = Differentiated Services Codepoint: Default (0x00)
.... ..00 = Explicit Congestion Notification: Not-ECT (Not ECN-Capable Transport) (0x00)
Total Length: 64
Identification: 0xf650 (63056)
Flags: 0x00
0... .... = Reserved bit: Not set
.0.. .... = Don't fragment: Not set
..0. .... = More fragments: Not set
Fragment offset: 0
Time to live: 64
Protocol: UDP (17)
Header checksum: 0x0108 [correct]
[Good: True]
[Bad: False]
Source: 192.168.1.3 (192.168.1.3)
Destination: 192.168.1.1 (192.168.1.1)
[Source GeoIP: Unknown]
[Destination GeoIP: Unknown]
User Datagram Protocol, Src Port: 47841 (47841), Dst Port: domain (53)
Source port: 47841 (47841)
Destination port: domain (53)
Length: 44
Checksum: 0x4831 [validation disabled]
[Good Checksum: False]
[Bad Checksum: False]
Domain Name System (query)
Transaction ID: 0x5fa2
Flags: 0x0120 Standard query
0... .... .... .... = Response: Message is a query
.000 0... .... .... = Opcode: Standard query (0)
.... ..0. .... .... = Truncated: Message is not truncated
.... ...1 .... .... = Recursion desired: Do query recursively
.... .... .0.. .... = Z: reserved (0)
.... .... ..1. .... = AD bit: Set
[Expert Info (Warn/Security): AD bit set in DNS Query]
[Message: AD bit set in DNS Query]
[Severity level: Warn]
[Group: Security]
.... .... ...0 .... = Non-authenticated data: Unacceptable
Questions: 1
Answer RRs: 0
Authority RRs: 0
Additional RRs: 1
Queries
cf16.eu: type A, class IN
Name: cf16.eu
Type: A (Host address)
Class: IN (0x0001)
Additional records
<Root>: type OPT
Name: <Root>
Type: OPT (EDNS0 option)
UDP payload size: 4096
Higher bits in extended RCODE: 0x0
EDNS0 version: 0
Z: 0x0
Data length: 0
192.168.1.1 cf16.eu を掘る [失敗]
No. Time Source Destination Protocol Length Info
603 7.972662000 192.168.1.3 192.168.1.1 DNS 78 Standard query 0xc755 A cf16.eu
Frame 603: 78 bytes on wire (624 bits), 78 bytes captured (624 bits) on interface 0
Interface id: 0
WTAP_ENCAP: 1
Arrival Time: May 8, 2013 17:49:36.816366000 CEST
[Time shift for this packet: 0.000000000 seconds]
Epoch Time: 1368028176.816366000 seconds
[Time delta from previous captured frame: 0.402535000 seconds]
[Time delta from previous displayed frame: 0.402535000 seconds]
[Time since reference or first frame: 7.972662000 seconds]
Frame Number: 603
Frame Length: 78 bytes (624 bits)
Capture Length: 78 bytes (624 bits)
[Frame is marked: False]
[Frame is ignored: False]
[Protocols in frame: eth:ip:udp:dns]
Ethernet II, Src: Micro-St_4b:47:dc (d4:3d:7e:4b:47:dc), Dst: Netgear_bb:b7:2c (00:1b:2f:bb:b7:2c)
Destination: Netgear_bb:b7:2c (00:1b:2f:bb:b7:2c)
Address: Netgear_bb:b7:2c (00:1b:2f:bb:b7:2c)
.... ..0. .... .... .... .... = LG bit: Globally unique address (factory default)
.... ...0 .... .... .... .... = IG bit: Individual address (unicast)
Source: Micro-St_4b:47:dc (d4:3d:7e:4b:47:dc)
Address: Micro-St_4b:47:dc (d4:3d:7e:4b:47:dc)
.... ..0. .... .... .... .... = LG bit: Globally unique address (factory default)
.... ...0 .... .... .... .... = IG bit: Individual address (unicast)
Type: IP (0x0800)
Internet Protocol Version 4, Src: 192.168.1.3 (192.168.1.3), Dst: 192.168.1.1 (192.168.1.1)
Version: 4
Header length: 20 bytes
Differentiated Services Field: 0x00 (DSCP 0x00: Default; ECN: 0x00: Not-ECT (Not ECN-Capable Transport))
0000 00.. = Differentiated Services Codepoint: Default (0x00)
.... ..00 = Explicit Congestion Notification: Not-ECT (Not ECN-Capable Transport) (0x00)
Total Length: 64
Identification: 0xf651 (63057)
Flags: 0x00
0... .... = Reserved bit: Not set
.0.. .... = Don't fragment: Not set
..0. .... = More fragments: Not set
Fragment offset: 0
Time to live: 64
Protocol: UDP (17)
Header checksum: 0x0107 [correct]
[Good: True]
[Bad: False]
Source: 192.168.1.3 (192.168.1.3)
Destination: 192.168.1.1 (192.168.1.1)
[Source GeoIP: Unknown]
[Destination GeoIP: Unknown]
User Datagram Protocol, Src Port: 37226 (37226), Dst Port: domain (53)
Source port: 37226 (37226)
Destination port: domain (53)
Length: 44
Checksum: 0x09f5 [validation disabled]
[Good Checksum: False]
[Bad Checksum: False]
Domain Name System (query)
Transaction ID: 0xc755
Flags: 0x0120 Standard query
0... .... .... .... = Response: Message is a query
.000 0... .... .... = Opcode: Standard query (0)
.... ..0. .... .... = Truncated: Message is not truncated
.... ...1 .... .... = Recursion desired: Do query recursively
.... .... .0.. .... = Z: reserved (0)
.... .... ..1. .... = AD bit: Set
[Expert Info (Warn/Security): AD bit set in DNS Query]
[Message: AD bit set in DNS Query]
[Severity level: Warn]
[Group: Security]
.... .... ...0 .... = Non-authenticated data: Unacceptable
Questions: 1
Answer RRs: 0
Authority RRs: 0
Additional RRs: 1
Queries
cf16.eu: type A, class IN
Name: cf16.eu
Type: A (Host address)
Class: IN (0x0001)
Additional records
<Root>: type OPT
Name: <Root>
Type: OPT (EDNS0 option)
UDP payload size: 4096
Higher bits in extended RCODE: 0x0
EDNS0 version: 0
Z: 0x0
Data length: 0
答え1
このシナリオでは、ルータはローカル要求に対して DNS サーバとして機能し、不明なアドレスに対してはフォワーダとして機能し、8.8.8.8 サーバに対してクエリを実行し、応答を処理し、結果を示すパケットを送り返します。サーバ参照なしで dig を使用すると、ルート ゾーンを使用して解決され、ルータは解決のためにルックアップをルート サーバに転送します。
dig でサーバーを指定する場合、通常は、作成/インポートしたばかりのゾーンがこのサーバー上で正常に動作しているかどうかを判断しようとしているため、転送を許可することはできません。転送すると、特にテストしようとしているサーバー上の潜在的な障害が隠れてしまいます。つまり、「このドメインに関する情報を提供してください」と言っているのではなく、「この特定のサーバーがこのドメインについて持っている情報を提供してください」と言っているのです。
問題のドメインはルーター上に実際に存在するゾーンに存在しないため、応答はありません。
詳細はこちらをご覧ください: http://en.wikipedia.org/wiki/Dig_%28command%29
コマンド呼び出しで特定のネーム サーバーが指定されていない場合は、通常は resolv.conf ファイルで設定されているオペレーティング システムのデフォルトのリゾルバが使用されます。引数を指定しないと、DNS ルート ゾーンが照会されます。
