私はDebianを搭載したRaspberry Piにowncloudサーバーをセットアップしています。大容量ストレージとして、Intenso 500 GB USBドライブこれはLogiLink USBハブRaspberry pi は USB ドライブ自体に電源を供給できないためです。Raspi を起動するとすべて正常に動作し、ファイルの同期が開始されますが、約 1 時間後に次のエラーが発生します。
Data directory (/media/usb1/owncloud/data) not writable by ownCloud
Permissions can usually be fixed by giving the webserver write access to the ownCloud directory
ssh経由でドライブにアクセスしようとすると
pi@raspberrypi ~ $ ls /media/usb1
ls: reading directory /media/usb1: Input/output error
また、ルートとして試すかどうかは問題ではありません。
syslogを調べたところ、ドライブが数回マウントおよびアンマウントされていたことが分かりました。
Dec 22 13:13:51 thecabbage kernel: [ 2.610218] usb 1-1: New USB device found, idVendor=0424, idProduct=9512
Dec 22 13:13:51 thecabbage kernel: [ 2.618633] usb 1-1: New USB device strings: Mfr=0, Product=0, SerialNumber=0
Dec 22 13:13:51 thecabbage kernel: [ 2.628570] hub 1-1:1.0: USB hub found
Dec 22 13:13:51 thecabbage kernel: [ 2.634990] hub 1-1:1.0: 3 ports detected
Dec 22 13:13:51 thecabbage kernel: [ 2.919641] usb 1-1.1: new high-speed USB device number 3 using dwc_otg
Dec 22 13:13:51 thecabbage kernel: [ 3.039878] usb 1-1.1: New USB device found, idVendor=0424, idProduct=ec00
Dec 22 13:13:51 thecabbage kernel: [ 3.048428] usb 1-1.1: New USB device strings: Mfr=0, Product=0, SerialNumber=0
Dec 22 13:13:51 thecabbage kernel: [ 3.062073] smsc95xx v1.0.4
Dec 22 13:13:51 thecabbage kernel: [ 3.125592] smsc95xx 1-1.1:1.0 eth0: register 'smsc95xx' at usb-bcm2708_usb-1.1, smsc95xx USB 2.0 Ethernet, b8:27:eb:b3:7a:73
Dec 22 13:13:51 thecabbage kernel: [ 3.249669] usb 1-1.2: new high-speed USB device number 4 using dwc_otg
Dec 22 13:13:51 thecabbage kernel: [ 3.381573] usb 1-1.2: New USB device found, idVendor=05e3, idProduct=0608
Dec 22 13:13:51 thecabbage kernel: [ 3.396388] usb 1-1.2: New USB device strings: Mfr=0, Product=1, SerialNumber=0
Dec 22 13:13:51 thecabbage kernel: [ 3.410539] usb 1-1.2: Product: USB2.0 Hub
Dec 22 13:13:51 thecabbage kernel: [ 3.422131] hub 1-1.2:1.0: USB hub found
Dec 22 13:13:51 thecabbage kernel: [ 3.430220] hub 1-1.2:1.0: 4 ports detected
Dec 22 13:13:51 thecabbage kernel: [ 3.719824] usb 1-1.2.1: new high-speed USB device number 5 using dwc_otg
Dec 22 13:13:51 thecabbage kernel: [ 3.841101] usb 1-1.2.1: New USB device found, idVendor=13fd, idProduct=1840
Dec 22 13:13:51 thecabbage kernel: [ 3.859642] usb 1-1.2.1: New USB device strings: Mfr=1, Product=2, SerialNumber=3
Dec 22 13:13:51 thecabbage kernel: [ 3.871457] usb 1-1.2.1: Product: USB 2.0 Drive
Dec 22 13:13:51 thecabbage kernel: [ 3.877793] usb 1-1.2.1: Manufacturer: PI-239
Dec 22 13:13:51 thecabbage kernel: [ 3.884178] usb 1-1.2.1: SerialNumber: 533252594A39434431313731
Dec 22 13:13:51 thecabbage kernel: [ 3.892819] usb-storage 1-1.2.1:1.0: USB Mass Storage device detected
Dec 22 13:13:51 thecabbage kernel: [ 3.901643] scsi0 : usb-storage 1-1.2.1:1.0
Dec 22 13:13:51 thecabbage kernel: [ 4.900648] scsi 0:0:0:0: Direct-Access PI-239 USB 2.0 Drive 1.08 PQ: 0 ANSI: 4
Dec 22 13:13:51 thecabbage kernel: [ 4.933311] sd 0:0:0:0: [sda] 976773168 512-byte logical blocks: (500 GB/465 GiB)
Dec 22 13:13:51 thecabbage kernel: [ 4.963305] sd 0:0:0:0: [sda] Write Protect is off
Dec 22 13:13:51 thecabbage kernel: [ 4.989392] sd 0:0:0:0: [sda] Mode Sense: 23 00 00 00
Dec 22 13:13:51 thecabbage kernel: [ 4.990187] sd 0:0:0:0: [sda] No Caching mode page found
Dec 22 13:13:51 thecabbage kernel: [ 4.997069] sd 0:0:0:0: [sda] Assuming drive cache: write through
Dec 22 13:13:51 thecabbage kernel: [ 5.035068] sd 0:0:0:0: [sda] No Caching mode page found
Dec 22 13:13:51 thecabbage kernel: [ 5.059342] sd 0:0:0:0: [sda] Assuming drive cache: write through
Dec 22 13:13:51 thecabbage kernel: [ 5.089366] sda: sda1
Dec 22 13:13:51 thecabbage kernel: [ 5.096949] sd 0:0:0:0: [sda] No Caching mode page found
Dec 22 13:13:51 thecabbage kernel: [ 5.113466] sd 0:0:0:0: [sda] Assuming drive cache: write through
Dec 22 13:13:51 thecabbage kernel: [ 5.140575] sd 0:0:0:0: [sda] Attached SCSI disk
Dec 22 13:13:51 thecabbage kernel: [ 6.302336] bcm2708-i2s bcm2708-i2s.0: Failed to create debugfs directory
Dec 22 13:13:51 thecabbage kernel: [ 15.139041] EXT4-fs (mmcblk0p2): re-mounted. Opts: (null)
Dec 22 13:13:51 thecabbage kernel: [ 15.627170] EXT4-fs (mmcblk0p2): re-mounted. Opts: (null)
Dec 22 13:13:51 thecabbage kernel: [ 24.054213] EXT4-fs (sda1): recovery complete
Dec 22 13:13:51 thecabbage kernel: [ 24.063171] EXT4-fs (sda1): mounted filesystem with ordered data mode. Opts: (null)
しかし、その時はまだ動作していました。約 1 時間後、次のエラーが発生しました。
Dec 22 14:33:12 thecabbage kernel: [ 470.843026] usb 1-1.2: USB disconnect, device number 4
Dec 22 14:33:12 thecabbage kernel: [ 470.843063] usb 1-1.2.1: USB disconnect, device number 5
Dec 22 14:33:12 thecabbage kernel: [ 470.853453] Buffer I/O error on device sda1, logical block 38034432
Dec 22 14:33:12 thecabbage kernel: [ 470.853499] Buffer I/O error on device sda1, logical block 38034433
Dec 22 14:33:12 thecabbage kernel: [ 470.853519] Buffer I/O error on device sda1, logical block 38034434
Dec 22 14:33:12 thecabbage kernel: [ 470.853535] Buffer I/O error on device sda1, logical block 38034435
Dec 22 14:33:12 thecabbage kernel: [ 470.853551] Buffer I/O error on device sda1, logical block 38034436
Dec 22 14:33:12 thecabbage kernel: [ 470.853567] Buffer I/O error on device sda1, logical block 38034437
Dec 22 14:33:12 thecabbage kernel: [ 470.853583] Buffer I/O error on device sda1, logical block 38034438
Dec 22 14:33:12 thecabbage kernel: [ 470.853599] Buffer I/O error on device sda1, logical block 38034439
Dec 22 14:33:12 thecabbage kernel: [ 470.853614] Buffer I/O error on device sda1, logical block 38034440
Dec 22 14:33:12 thecabbage kernel: [ 470.853632] Buffer I/O error on device sda1, logical block 38034441
Dec 22 14:33:12 thecabbage kernel: [ 470.853648] Buffer I/O error on device sda1, logical block 38034442
Dec 22 14:33:12 thecabbage kernel: [ 470.853665] Buffer I/O error on device sda1, logical block 38034443
Dec 22 14:33:12 thecabbage kernel: [ 470.853681] Buffer I/O error on device sda1, logical block 38034444
Dec 22 14:33:12 thecabbage kernel: [ 470.853698] Buffer I/O error on device sda1, logical block 38034445
Dec 22 14:33:12 thecabbage kernel: [ 470.853713] Buffer I/O error on device sda1, logical block 38034446
Dec 22 14:33:12 thecabbage kernel: [ 470.853729] Buffer I/O error on device sda1, logical block 38034447
Dec 22 14:33:12 thecabbage kernel: [ 470.853746] Buffer I/O error on device sda1, logical block 38034448q
このエラーの原因が何か分かる人はいますか？USBハブと電源管理が原因だと思いますが、確認方法が分かりません。ハードドライブに欠陥があるのでしょうか？/etc/fstabに従ってマウントされています。
UUID=915a8f36-5c7d-40e3-a451-a3babb0fa610 /media/usb1 ext4 defaults 0 0
ご協力ありがとうございます！
