MotoG3 スマートフォンの Android スマートフォンでビデオを録画したところ、結果として得られたビデオが (おそらくスマートフォンを振ったため) 回転して、つまり垂直に再生されてしまいました。これは望んでいたものではありません。ビデオは MP4 コンテナーに保存されました。

録画されたファイルを調べたところ、(ffprobeとの両方を使用してmediainfo)ビデオ ストリームが 90 度回転していることを示すフラグが含まれていることがわかりました。これは、ビデオの再生中に回転する理由を説明しています。 からの出力は次のとおりですffprobe

$ ffprobe -hide_banner ~/Pictures/2016/06/19/vid_20160619_170845475.mp4
Input #0, mov,mp4,m4a,3gp,3g2,mj2, from '/home/rbrito/Pictures/2016/06/19/vid_20160619_170845475.mp4':
  Metadata:
    major_brand     : mp42
    minor_version   : 0
    compatible_brands: isommp42
    creation_time   : 2016-06-19 20:25:49
    com.android.version: 6.0
  Duration: 00:17:01.96, start: 0.000000, bitrate: 17134 kb/s
    Stream #0:0(eng): Video: h264 (High) (avc1 / 0x31637661), yuv420p, 1920x1080, 17000 kb/s, SAR 1:1 DAR 16:9, 29 fps, 29.42 tbr, 90k tbn, 180k tbc (default)
    Metadata:
      rotate          : 90
      creation_time   : 2016-06-19 20:25:49
      handler_name    : VideoHandle
      encoder         : MOTO
    Side data:
      displaymatrix: rotation of -90.00 degrees
    Stream #0:1(eng): Audio: aac (LC) (mp4a / 0x6134706D), 48000 Hz, stereo, fltp, 128 kb/s (default)
    Metadata:
      creation_time   : 2016-06-19 20:25:49
      handler_name    : SoundHandle

このビデオは息子との珍しい出来事を撮影したものなので、ビデオ ファイルの変更は最小限に抑え、できれば回転メタデータのみを削除し、それ以外は何も変更しないようにしたいと思います。

残念ながら、その他の回答役に立たなかった。以下を試してみた:

ffmpeg -i ~/Pictures/2016/06/19/vid_20160619_170845475.mp4 -c copy -metadata:s:v:0 rotate=0 -an vid_20160619_170845475_unrotated.mp4

しかし、日付などの他のメタデータは結果のファイルには存在しません。これにより、特に、ファイルを日付順に表示するときにオーガナイザー プログラムが混乱する原因になります。

入力データを最小限に変更して(おそらく再多重化して)、元のデータにできるだけ近づける方法はありますか? 特に、ファイルを再エンコードしたくありません。

Linux で利用可能なツールが推奨されます。


追加情報

ffmpeg の完全な出力が求められたので、ここに示します。これは純粋な Debian テスト ユーザーランドです。

補足ですが、ffmpeg は Debian で 2 回コンパイルされており、1 回は問題となる可能性のあるコーデックなしで、もう 1 回は追加のコーデックありでコンパイルされているため、ライブラリが一致しないというエラーが出ています。私は追加のコーデックがあるバージョンを使用していますが、ここでは多重化のみが使用されているため、これは問題ではないと思います。

再多重化前のメタデータ

$ ffprobe  -hide_banner ~/Pictures/2016/06/19/vid_20160619_170845475.mp4
Input #0, mov,mp4,m4a,3gp,3g2,mj2, from '/home/rbrito/Pictures/2016/06/19/vid_20160619_170845475.mp4':
  Metadata:
    major_brand     : mp42
    minor_version   : 0
    compatible_brands: isommp42
    creation_time   : 2016-06-19 20:25:49
    com.android.version: 6.0
  Duration: 00:17:01.96, start: 0.000000, bitrate: 17134 kb/s
    Stream #0:0(eng): Video: h264 (High) (avc1 / 0x31637661), yuv420p, 1920x1080, 17000 kb/s, SAR 1:1 DAR 16:9, 29 fps, 29.42 tbr, 90k tbn, 180k tbc (default)
    Metadata:
      rotate          : 90
      creation_time   : 2016-06-19 20:25:49
      handler_name    : VideoHandle
      encoder         : MOTO
    Side data:
      displaymatrix: rotation of -90.00 degrees
    Stream #0:1(eng): Audio: aac (LC) (mp4a / 0x6134706D), 48000 Hz, stereo, fltp, 128 kb/s (default)
    Metadata:
      creation_time   : 2016-06-19 20:25:49
      handler_name    : SoundHandle

再多重化プロセス

ここで、オーディオ メタデータはコピーされないことに注意してください (オプションのため、これは予想どおりです-metadata:s:v:0)。ffmpeg は、ビデオ メタデータ (回転設定なし) をコピーしていると通知します。

$ ffmpeg -hide_banner -i ~/Pictures/2016/06/19/vid_20160619_170845475.mp4 -c copy -metadata:s:v:0 rotate=0 -an vid_20160619_170845475_unrotated.mp4
Input #0, mov,mp4,m4a,3gp,3g2,mj2, from '/home/rbrito/Pictures/2016/06/19/vid_20160619_170845475.mp4':
  Metadata:
    major_brand     : mp42
    minor_version   : 0
    compatible_brands: isommp42
    creation_time   : 2016-06-19 20:25:49
    com.android.version: 6.0
  Duration: 00:17:01.96, start: 0.000000, bitrate: 17134 kb/s
    Stream #0:0(eng): Video: h264 (High) (avc1 / 0x31637661), yuv420p, 1920x1080, 17000 kb/s, SAR 1:1 DAR 16:9, 29 fps, 29.42 tbr, 90k tbn, 180k tbc (default)
    Metadata:
      rotate          : 90
      creation_time   : 2016-06-19 20:25:49
      handler_name    : VideoHandle
      encoder         : MOTO
    Side data:
      displaymatrix: rotation of -90.00 degrees
    Stream #0:1(eng): Audio: aac (LC) (mp4a / 0x6134706D), 48000 Hz, stereo, fltp, 128 kb/s (default)
    Metadata:
      creation_time   : 2016-06-19 20:25:49
      handler_name    : SoundHandle
Output #0, mp4, to 'vid_20160619_170845475_unrotated.mp4':
  Metadata:
    major_brand     : mp42
    minor_version   : 0
    compatible_brands: isommp42
    com.android.version: 6.0
    encoder         : Lavf57.25.100
    Stream #0:0(eng): Video: h264 ([33][0][0][0] / 0x0021), yuv420p, 1920x1080 [SAR 1:1 DAR 16:9], q=2-31, 17000 kb/s, 29 fps, 29.42 tbr, 90k tbn, 90k tbc (default)
    Metadata:
      encoder         : MOTO
      creation_time   : 2016-06-19 20:25:49
      handler_name    : VideoHandle
      rotate          : 0
Stream mapping:
  Stream #0:0 -> #0:0 (copy)
Press [q] to stop, [?] for help
frame=29640 fps=403 q=-1.0 Lsize= 2121038kB time=00:17:01.91 bitrate=17003.0kbits/s speed=13.9x
video:2120800kB audio:0kB subtitle:0kB other streams:0kB global headers:0kB muxing overhead: 0.011211%

再多重化後のメタデータ

ここで、出力にはビデオ メタデータはなく、コンテナー レベルのメタデータのみがあることに注意してください。

$ ffprobe -hide_banner vid_20160619_170845475_unrotated.mp4
Input #0, mov,mp4,m4a,3gp,3g2,mj2, from 'vid_20160619_170845475_unrotated.mp4':
  Metadata:
    major_brand     : isom
    minor_version   : 512
    compatible_brands: isomiso2avc1mp41
    encoder         : Lavf57.25.100
  Duration: 00:17:01.95, start: 0.000000, bitrate: 17002 kb/s
    Stream #0:0(eng): Video: h264 (High) (avc1 / 0x31637661), yuv420p, 1920x1080, 17000 kb/s, 29 fps, 29.42 tbr, 90k tbn, 180k tbc (default)
    Metadata:
      handler_name    : VideoHandler

答え1

FFmpeg はデフォルトではほとんどのユーザー メタデータを転送しませんが、回転タグなどのフィールドは転送します。

以下のコマンドは、FFmpeg にすべてのメタデータを転送するように指示しますが、回転タグの値を上書きします。

ffmpeg -i in.mp4 -c copy -map_metadata 0 -metadata:s:v:0 rotate=0 -an out.mp4

答え2

次のコマンドを実行します:

ffmpeg -i oldfile.mp4 -codec copy -metadata title="" -metadata album="" -metadata year="" -metadata container="" -metadata artist="" -metadata comment="" newfile.mp4

各メタデータ タイプで "" を使用すると、古いメタデータが空になり、ffmpeg はメタデータがクリアされた新しいファイルにファイル全体をコピーします。

重複を避けるため、新しいファイルを作成した後は古いファイルを削除する必要があります。

答え3

  • mutagen python ライブラリをインストールします。

    python3.6 -m pip install --user mutagen


    または:

    python2.7 -m pip install --user mutagen


    Mutagen は、オーディオ メタデータを処理する Python モジュールです。

  • 以下の内容を として保存しますmetadata_cleaner.pyが、任意の名前を付けることができます。

  • 変数を変更しますVIDEO_FOLDER = 'your_full_path_for_your_videos_folder'

  • 「Your changes」と書かれた行の間で上書きしたい属性を変更します。

  • どこでも走れますpython metadata_cleaner.py

スクリプトは次のとおりです。

import os
from mutagen.mp4 import MP4
## Can import MP3 as well if you want to modify MP3 files

## Folder full path to the files you want to modify:

FILES_FOLDER = "/media/removable/64GB-Micro/FilesToClean"

def get_all_files(path):
    """Returns all the files in the path as a list
    """
    return os.listdir(path)

def clean_metadata(videos_dir, files):
    """
    Receives two variables videos_dir (full file folder path) and files (list)
    Iterates over all the files in the directory and creates full paths for
    every file using the videos_dir path and os.path.join function.
    """
    for file_name in files:
        file_path = os.path.join(videos_dir, file_name)

        ## create MP4 video_file instance

        video_file = MP4(file_path)

        ## This line will print out all key-value for the video_file-s:
        ## Useful if you don't know which attributes you want to modify yet

        print(video_file)

        ## In this example I wanted to clean the ART, aArt = Artist metadata
        ## and nam = Song Name metadata
        ## These prints will show artists and titles for each file before clean
        ## -------------------------- Your changes ---------------------------
        print("file_name: {}".format(file_name))
        print("Old ART: {}".format(video_file.get('\xa9ART', "Key not found")))
        print("Old aArt: {}".format(video_file.get('aART', "Key not found")))
        print("Old nam: {}".format(video_file.get('\xa9nam', "Key not found")))

        ## clean artist and name
        ## This part will overwrite the artist and song name attributes

        video_file['\xa9ART'] = ''
        video_file['aART'] = ''
        video_file['\xa9nam'] = ''
        ## -------------------------- Your changes ---------------------------
        ## save new metadata

        video_file.save()

        ## show video_file artist and title after clean
        ## Just to see if our actions were successful print out song metadata
        ## again after the changes

        print("New ART: {}".format(video_file.get('\xa9ART', "Key not found")))
        print("New aArt: {}".format(video_file.get('aART', "Key not found")))
        print("New nam: {}".format(video_file.get('\xa9nam', "Key not found")))


if __name__ == '__main__':
    ## load all the files into files variable as a list

    files = get_all_files(FILES_FOLDER)

    ## run clean_metadata function to clean all the files in the VIDEO_FOLDER
    ## path
    clean_metadata(videos_dir=FILES_FOLDER, files=files)
