まず最初に、私は MATLAB と Linux についてはほとんど初心者なので、何か明らかなことを見逃しているかもしれませんが、その場合はどうかご容赦ください。
数学科のモデリング プロジェクトを手伝うよう頼まれたので、すべてのコードをダウンロードし、コンピューターに matlab をインストールし、いくつかの手順 (「glu」というライブラリをインストールする必要があった) を踏んだ後、スクリプト自体は実際に実行されました。プロットをレンダリングしようとしていると思われるところまで来て、システムがクラッシュし、ctrl-alt-F(何でも) で他の tty にアクセスできなくなり、しばらくすると右上に点滅するカーソルが表示されますが、ctrl-alt-delete でも何もできません。そこで、電源ボタンを押したままコンピューターをシャットダウンしました。
クラッシュ ダンプを見つけましたが、そのうちのかなりの数は空で、いくつかには何らかの情報が含まれています。以下は「matlab_crash_dump.4121-1」です。
------------------------------------------------------------------------
Assertion detected at Sun Sep 18 17:13:44 2016
------------------------------------------------------------------------
Configuration:
Crash Decoding : Disabled
Crash Mode : continue (default)
Current Graphics Driver: Intel Open Source Technology Center Mesa DRI Intel(R) Sandybridge Mobile Version 3.0 Mesa 11.0.6
Current Visual : 0x47 (class 4, depth 24)
Default Encoding : UTF-8
GNU C Library : 2.22 stable
Host Name : q
Java Crash Report : /home/d/hs_error_pid4121.log
Java Log : /home/d/java.log.4121
MATLAB Architecture : glnxa64
MATLAB Root : /usr/local/MATLAB/R2016a
MATLAB Version : 9.0.0.341360 (R2016a)
OpenGL : hardware
Operating System : Linux 4.4.6-gentoo #6 SMP Sun Sep 18 16:32:36 MDT 2016 x86_64
Processor ID : x86 Family 6 Model 42 Stepping 7, GenuineIntel
Virtual Machine : Java 1.7.0_60-b19 with Oracle Corporation Java HotSpot(TM) 64-Bit Server VM mixed mode
Window System : The X.Org Foundation (11704000), display :0
Fault Count: 1
Assertion in void {anonymous}::mwJavaAbort() at javainit.cpp line 1389:
Fatal Java Exception. See Java Crash Report for details.
Register State (captured):
RAX = 00007f22a75e21e0 RBX = 00007f2329790878
RCX = 0000000000000000 RDX = 00007f2329770c20
RSP = 00007f22a75e2100 RBP = 00007f22a75e24c0
RSI = 00007f23295273b8 RDI = 00007f22a75e2110
R8 = 0000000000000000 R9 = 00007f230ec258e0
R10 = 0000000000000000 R11 = 000000000000000f
R12 = 00007f230ec251bb R13 = 00007f230ec258e0
R14 = 00007f23297807e8 R15 = 00007f22a75e2d30
RIP = 00007f232949459e EFL = 00007f232fa03500
CS = f0b8 FS = 2939 GS = 7f23
Stack Trace (captured):
[ 0] 0x00007f232949459e /usr/local/MATLAB/R2016a/bin/glnxa64/libmwfl.so+01082782 _ZN2fl4diag5linux6x86_6412context_base12capture_dataEv+00000030
[ 1] 0x00007f2329490541 /usr/local/MATLAB/R2016a/bin/glnxa64/libmwfl.so+01066305
[ 2] 0x00007f2329491bd0 /usr/local/MATLAB/R2016a/bin/glnxa64/libmwfl.so+01072080
[ 3] 0x00007f2329491c42 /usr/local/MATLAB/R2016a/bin/glnxa64/libmwfl.so+01072194
[ 4] 0x00007f230ebe675a /usr/local/MATLAB/R2016a/bin/glnxa64/libmwjmi.so+01099610
[ 5] 0x00007f230d8298bb /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+08513723
[ 6] 0x00007f230d6599f2 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06613490
[ 7] 0x00007f21f308ac02 /usr/local/MATLAB/R2016a/bin/glnxa64/libnativewindow_x11.so+00011266 NativewindowCommon_FatalError+00000268
[ 8] 0x00007f21f308b95a /usr/local/MATLAB/R2016a/bin/glnxa64/libnativewindow_x11.so+00014682
[ 9] 0x00007f232275edde /usr/lib64/libX11.so.6+00282078 _XIOError+00000078
[ 10] 0x00007f232275cebb /usr/lib64/libX11.so.6+00274107 _XReply+00001019
[ 11] 0x00007f2322743cb7 /usr/lib64/libX11.so.6+00171191 _XGetWindowAttributes+00000183
[ 12] 0x00007f2322743e31 /usr/lib64/libX11.so.6+00171569 XGetWindowAttributes+00000049
[ 13] 0x00007f22e16a3c44 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/xawt/libmawt.so+00109636
[ 14] 0x00007f22e19112f6 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/libawt.so+00209654 Java_sun_java2d_loops_Blit_Blit+00000534
[ 15] 0x00007f22fd012d98 <unknown-module>+00000000
[ 16] 0x00007f22fd006058 <unknown-module>+00000000
[ 17] 0x00007f22fd006058 <unknown-module>+00000000
[ 18] 0x00007f22fd006350 <unknown-module>+00000000
[ 19] 0x00007f22fd006350 <unknown-module>+00000000
[ 20] 0x00007f22fd0069fe <unknown-module>+00000000
[ 21] 0x00007f22fd0069fe <unknown-module>+00000000
[ 22] 0x00007f22fd006350 <unknown-module>+00000000
[ 23] 0x00007f22fd006350 <unknown-module>+00000000
[ 24] 0x00007f22fd006350 <unknown-module>+00000000
[ 25] 0x00007f22fd006706 <unknown-module>+00000000
[ 26] 0x00007f22fd006058 <unknown-module>+00000000
[ 27] 0x00007f22fd006058 <unknown-module>+00000000
[ 28] 0x00007f22fd006058 <unknown-module>+00000000
[ 29] 0x00007f22fd006058 <unknown-module>+00000000
[ 30] 0x00007f22fd006058 <unknown-module>+00000000
[ 31] 0x00007f22fd006058 <unknown-module>+00000000
[ 32] 0x00007f22fd006058 <unknown-module>+00000000
[ 33] 0x00007f22fd006058 <unknown-module>+00000000
[ 34] 0x00007f22fd006058 <unknown-module>+00000000
[ 35] 0x00007f22fd006058 <unknown-module>+00000000
[ 36] 0x00007f22fd006058 <unknown-module>+00000000
[ 37] 0x00007f22fd006058 <unknown-module>+00000000
[ 38] 0x00007f22fd006058 <unknown-module>+00000000
[ 39] 0x00007f22fd006058 <unknown-module>+00000000
[ 40] 0x00007f22fd006058 <unknown-module>+00000000
[ 41] 0x00007f22fd006706 <unknown-module>+00000000
[ 42] 0x00007f22fd006058 <unknown-module>+00000000
[ 43] 0x00007f22fd006058 <unknown-module>+00000000
[ 44] 0x00007f22fd006058 <unknown-module>+00000000
[ 45] 0x00007f22fd006058 <unknown-module>+00000000
[ 46] 0x00007f22fd006058 <unknown-module>+00000000
[ 47] 0x00007f22fd006058 <unknown-module>+00000000
[ 48] 0x00007f22fd006233 <unknown-module>+00000000
[ 49] 0x00007f22fd0004e7 <unknown-module>+00000000
[ 50] 0x00007f230d60a8f5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06289653
[ 51] 0x00007f230d609358 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06284120
[ 52] 0x00007f230d68fc74 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06835316 JVM_DoPrivileged+00000676
[ 53] 0x00007f22fd012d98 <unknown-module>+00000000
[ 54] 0x00007f22fd006233 <unknown-module>+00000000
[ 55] 0x00007f22fd006233 <unknown-module>+00000000
[ 56] 0x00007f22fd0068e1 <unknown-module>+00000000
[ 57] 0x00007f22fd006233 <unknown-module>+00000000
[ 58] 0x00007f22fd0004e7 <unknown-module>+00000000
[ 59] 0x00007f230d60a8f5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06289653
[ 60] 0x00007f230d609358 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06284120
[ 61] 0x00007f230d68fc74 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06835316 JVM_DoPrivileged+00000676
[ 62] 0x00007f22fd012d98 <unknown-module>+00000000
[ 63] 0x00007f22fd006233 <unknown-module>+00000000
[ 64] 0x00007f22fd0068e1 <unknown-module>+00000000
[ 65] 0x00007f22fd006058 <unknown-module>+00000000
[ 66] 0x00007f22fd006058 <unknown-module>+00000000
[ 67] 0x00007f22fd006058 <unknown-module>+00000000
[ 68] 0x00007f22fd006058 <unknown-module>+00000000
[ 69] 0x00007f22fd006058 <unknown-module>+00000000
[ 70] 0x00007f22fd006058 <unknown-module>+00000000
[ 71] 0x00007f22fd0004e7 <unknown-module>+00000000
[ 72] 0x00007f230d60a8f5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06289653
[ 73] 0x00007f230d609358 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06284120
[ 74] 0x00007f230d609627 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06284839
[ 75] 0x00007f230d609747 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06285127
[ 76] 0x00007f230d6861d5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+06795733
[ 77] 0x00007f230d963bdf /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+09800671
[ 78] 0x00007f230d963ce5 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+09800933
[ 79] 0x00007f230d82a7f8 /usr/local/MATLAB/R2016a/sys/java/jre/glnxa64/jre/lib/amd64/server/libjvm.so+08517624
[ 80] 0x00007f232d73d494 /lib64/libpthread.so.0+00029844
[ 81] 0x00007f232d4825dd /lib64/libc.so.6+00955869 clone+00000109
[ 82] 0x0000000000000000 <unknown-module>+00000000
If this problem is reproducible, please submit a Service Request via:
http://www.mathworks.com/support/contact_us/
A technical support engineer might contact you with further information.
Thank you for your help.
そして、対応する「java.log.4121」は次のようになります。
Operating System: Linux 4.4.6-gentoo #6 SMP Sun Sep 18 16:32:36 MDT 2016 x86_64
Processor ID: x86 Family 6 Model 42 Stepping 7, GenuineIntel
Host Name: q
FATAL ERROR in native method: Nativewindow X11 IOError: Display 0x7f230b054450 (:0): Resource temporarily unavailable
at sun.java2d.loops.Blit.Blit(Native Method)
at sun.java2d.pipe.DrawImage.blitSurfaceData(Unknown Source)
at sun.java2d.pipe.DrawImage.renderImageCopy(Unknown Source)
at sun.java2d.pipe.DrawImage.copyImage(Unknown Source)
at sun.java2d.pipe.DrawImage.copyImage(Unknown Source)
at sun.java2d.pipe.ValidatePipe.copyImage(Unknown Source)
at sun.java2d.SunGraphics2D.copyImage(Unknown Source)
at sun.java2d.SunGraphics2D.drawImage(Unknown Source)
at sun.java2d.SunGraphics2D.drawImage(Unknown Source)
at com.jogamp.opengl.awt.GLJPanel$OffscreenBackend.doPaintComponent(GLJPanel.java:2101)
at com.jogamp.opengl.awt.GLJPanel.paintComponent(GLJPanel.java:568)
at com.mathworks.hg.peer.JavaSceneServerGLJPanel.paintComponent(JavaSceneServerGLJPanel.java:147)
at javax.swing.JComponent.paint(Unknown Source)
at javax.swing.JComponent.paintChildren(Unknown Source)
- locked <0x00000000e81d1210> (a java.awt.Component$AWTTreeLock)
at javax.swing.JComponent.paint(Unknown Source)
at javax.swing.JComponent.paintChildren(Unknown Source)
- locked <0x00000000e81d1210> (a java.awt.Component$AWTTreeLock)
at javax.swing.JComponent.paint(Unknown Source)
at java.awt.GraphicsCallback$PaintCallback.run(Unknown Source)
at sun.awt.SunGraphicsCallback.runOneComponent(Unknown Source)
at sun.awt.SunGraphicsCallback.runComponents(Unknown Source)
at java.awt.Container.paint(Unknown Source)
at java.awt.Window.paint(Unknown Source)
at sun.awt.RepaintArea.paintComponent(Unknown Source)
at sun.awt.X11.XRepaintArea.paintComponent(Unknown Source)
at sun.awt.RepaintArea.paint(Unknown Source)
at sun.awt.X11.XComponentPeer.handleEvent(Unknown Source)
at java.awt.Component.dispatchEventImpl(Unknown Source)
at java.awt.Container.dispatchEventImpl(Unknown Source)
at java.awt.Window.dispatchEventImpl(Unknown Source)
at java.awt.Component.dispatchEvent(Unknown Source)
at java.awt.EventQueue.dispatchEventImpl(Unknown Source)
at java.awt.EventQueue.access$200(Unknown Source)
at java.awt.EventQueue$3.run(Unknown Source)
at java.awt.EventQueue$3.run(Unknown Source)
at java.security.AccessController.doPrivileged(Native Method)
at java.security.ProtectionDomain$1.doIntersectionPrivilege(Unknown Source)
at java.security.ProtectionDomain$1.doIntersectionPrivilege(Unknown Source)
at java.awt.EventQueue$4.run(Unknown Source)
at java.awt.EventQueue$4.run(Unknown Source)
at java.security.AccessController.doPrivileged(Native Method)
at java.security.ProtectionDomain$1.doIntersectionPrivilege(Unknown Source)
at java.awt.EventQueue.dispatchEvent(Unknown Source)
at java.awt.EventDispatchThread.pumpOneEventForFilters(Unknown Source)
at java.awt.EventDispatchThread.pumpEventsForFilter(Unknown Source)
at java.awt.EventDispatchThread.pumpEventsForHierarchy(Unknown Source)
at java.awt.EventDispatchThread.pumpEvents(Unknown Source)
at java.awt.EventDispatchThread.pumpEvents(Unknown Source)
at java.awt.EventDispatchThread.run(Unknown Source)
この時点では、これはグラフィックの問題だと確信しています。OpenGL ソフトウェア レンダリングも試しました。プロジェクトのディレクターは、システム全体に影響が出ているため、カーネルに問題がある可能性があると示唆しました。この時点で、彼は別の環境に切り替えるように求めており、先に進むことができますが、それでも Gentoo で何が起こっているのか知りたいです。
私が考えていたことの1つは、DEを持っておらず、タイリングWM（素晴らしい3.5）だけを持っていることです。これが問題を引き起こすかどうかはわかりませんが、単なる考えです。
私が取り組んでいるのは以下のものです:
Matlab2016a
素晴らしい 3.5
ジェントゥー4.4.6
インテル 2760M
Quadro 2000M (これを使っていないと思います)
20GBのRAM
これらの部品の標準ドライバーと一緒に
他に何か必要なことがあればお知らせください。
