FFMPEG で DVD からの VOB ファイルの連結 (マージ) を自動化する際の問題

Question

多くの実験と調査を行った結果、変数に 2 番目の BAT ファイルスクリプトを作成し、それを一時 BAT ファイルとして保存する BAT ファイルスクリプトを作成することが最善の方法であることがわかりました。作成された BAT ファイルは、必要な DVD タイトルセットとタイトルセット内の検出されたファイル数に基づいて、カスタム作成された "concat: " パラメーターを使用して作成できます。唯一の難点は、パイプ (|) 文字を含む変数に文字列を作成することがほぼ不可能であることです。ビルド中に '@' 文字を置き換えてこの問題を解決し、後でオープンソースのファイル検索および置換ユーティリティを使用して '@' インスタンスを "|" に変更しました。問題なく動作します。注: Windows 10 と、2020 年 6 月にダウンロードおよびインストールされた FFMPEG バージョン git-2020-06-26-7447045 を使用しています。以下は私が作成したコメント付きのバッチファイルです。同様のことをしたい場合は、ここから始めることができます。改善の余地があることはわかっていますが、うまく機能しています (常に良いスタートです)。

::
:: Batch file to automate conversion of a series of VOB files in a DVD
::  titleset into a single MPG file, via FFMPEG.
:: Pass a name you'd like for the final output movie file in param 1

:: This script needs a a file search and replace utility, and I'm useing
:: SKF (Swiss Army Knife), which is open source and free ...
:: https://sourceforge.net/projects/swissfileknife/

:: Whatever search/replace util you use, you'll have to put it in a
:: 'utilities' folder somewhere in your C: drive, and make sure
:: your system (or USER) PATH variable includes it.

:: Also, unless you have unencrytpted DVD copies to work with, OR a
:: Decryptor that automatically works in the background (like DVD43),
:: you'll have to start with a program like "1-Click DVD Copy (Pro)".
:: In that case you can put the Resulting VIDEO_TS folder in a temp
:: area on your HD. This will make this batch process run faster,
:: and eliminate the needs to waste a blank DVD.

echo off
SETLOCAL ENABLEDELAYEDEXPANSION

:: Set a path where converted ouptput videos will go
:: Temporary files created by this script will also go here.
set outPath="C:\Users\Public\Videos\Temp"
:: set a path to your DVD. Playable DVDs always have aVIDEO_TS folder
set inPathDVD="Q:\VIDEO_TS"
:: In the event you are making unencrypted copies (maybe with 1-Click),
:: set that software to put its output files here. In that case,
:: the parameter you pass this script should match the folder name
:: created by that software!
set inPathHD="C:\Users\Public\Videos\Temp\%1\Video_TS"

:: some variables to construct expecteed files to seach for and gather
set inpTitleSet=VTS_
set inpExt=.VOB
set output=%outPath%\%1.mpg
set outTemp=%outPath%\%1%inpExt%

:: choose whether files come directly from DVD (must be unencrypted!)
:: or defined location on HD
choice /M "Choose Source 1 = DVD  2 = HD Temp Area" /C 12

if ERRORLEVEL 1 set inPath=%inPathDVD%
if ERRORLEVEL 2 set inPath=%inPathHD%

echo input path is: %inPath%
cd /D %inPath%
echo .
echo VOB files from %inpath%...
echo .

:: create filespec for search "VTS_01_*.vob"
set inputFileSpec=%inpTitleSet%*%inpExt%
dir %inputFileSpec%
echo .
:: select desired titleset. Usually the group with the
:: biggest file sizes is  the main movie titleset.
:: You'll be entering the digit after "VTS_0"
choice /M "Select Desired Titleset (digit after VTS_): " /C 12345678
echo you picked %ERRORLEVEL%
set inpTitleSet=%inpTitleSet%0%ERRORLEVEL%_
set inputFileSpec=%inpTitleSet%*%inpExt%

:: use a brute force loop to calculate number of
:: files matching %inputFileSpec% and display them.
:: Note that the '0' file is usually title/menu information,
:: and is skipped by making the %start% var '1'

echo files selected...
echo .
set start=1
:loop0
set tmp=%inpTitleSet%%start%%inpExt%
IF EXIST %tmp% (
echo %tmp%
set /A start=start+1
GOTO loop0
)
set /A count=%start%-1
echo .
:: confirm total files
echo Total Files = %count%

:: safety exit, in odd event where no movie files found
if %count% NEQ 0 GOTO continue1
echo .
echo Must Exit... no Files Found.
goto exit
:continue1

:: Build string containing of file names for FFMPEG "concat:" parameter.
:: Another Brute force loop. Again file *0.VOB will be skipped,
:: by making loop start=1::

:: set an 'empty' variable
set cc=
set start=1
:: create a temp substitute for the pipe "|" character,
:: because | can't be cant be used in a script (^| or similar
::  constructs just won't work here). So I'll use '@' and change it
:: later with a file search/replace utility.
set mypipe=@

:loop1
set tmp=%inpTitleSet%%start%%inpExt%
if %start% EQU %count% set mypipe=
IF EXIST %tmp% (
set cc=%cc%%inp%%tmp%%mypipe%
set /A start=start+1
GOTO loop1
)

:: create whole FFMPEG command as a string
set ffm=ffmpeg -i "concat:%cc%" -f DVD -c copy %output%

:: put it in a tmp batch file
set cmdfile=tmp.bat
echo %ffm%  > %outPath%\%cmdfile%

:: now use SKF to replace the @ chars with |
:: if you have another search/replace utility, feel free to use it.
sfk replace %outPath%\%cmdfile% "/@/|/" -yes -quiet

:: prove string in batch file looks right. You can delete
:: these two lines if you want.
echo Final command...
type %outPath%\%cmdfile%

:: run the new batch file... Give user chance to start process
@pause
call %outPath%\%cmdfile%

:: delete batch file?
del %outPath%\%cmdfile%
echo .
echo .
echo %output% converted file should be ready

ENDLOCAL
:exit

Answer 1

多くの実験と調査を行った結果、変数に 2 番目の BAT ファイルスクリプトを作成し、それを一時 BAT ファイルとして保存する BAT ファイルスクリプトを作成することが最善の方法であることがわかりました。作成された BAT ファイルは、必要な DVD タイトルセットとタイトルセット内の検出されたファイル数に基づいて、カスタム作成された "concat: " パラメーターを使用して作成できます。唯一の難点は、パイプ (|) 文字を含む変数に文字列を作成することがほぼ不可能であることです。ビルド中に '@' 文字を置き換えてこの問題を解決し、後でオープンソースのファイル検索および置換ユーティリティを使用して '@' インスタンスを "|" に変更しました。問題なく動作します。注: Windows 10 と、2020 年 6 月にダウンロードおよびインストールされた FFMPEG バージョン git-2020-06-26-7447045 を使用しています。以下は私が作成したコメント付きのバッチファイルです。同様のことをしたい場合は、ここから始めることができます。改善の余地があることはわかっていますが、うまく機能しています (常に良いスタートです)。

::
:: Batch file to automate conversion of a series of VOB files in a DVD
::  titleset into a single MPG file, via FFMPEG.
:: Pass a name you'd like for the final output movie file in param 1

:: This script needs a a file search and replace utility, and I'm useing
:: SKF (Swiss Army Knife), which is open source and free ...
:: https://sourceforge.net/projects/swissfileknife/

:: Whatever search/replace util you use, you'll have to put it in a
:: 'utilities' folder somewhere in your C: drive, and make sure
:: your system (or USER) PATH variable includes it.

:: Also, unless you have unencrytpted DVD copies to work with, OR a
:: Decryptor that automatically works in the background (like DVD43),
:: you'll have to start with a program like "1-Click DVD Copy (Pro)".
:: In that case you can put the Resulting VIDEO_TS folder in a temp
:: area on your HD. This will make this batch process run faster,
:: and eliminate the needs to waste a blank DVD.

echo off
SETLOCAL ENABLEDELAYEDEXPANSION

:: Set a path where converted ouptput videos will go
:: Temporary files created by this script will also go here.
set outPath="C:\Users\Public\Videos\Temp"
:: set a path to your DVD. Playable DVDs always have aVIDEO_TS folder
set inPathDVD="Q:\VIDEO_TS"
:: In the event you are making unencrypted copies (maybe with 1-Click),
:: set that software to put its output files here. In that case,
:: the parameter you pass this script should match the folder name
:: created by that software!
set inPathHD="C:\Users\Public\Videos\Temp\%1\Video_TS"

:: some variables to construct expecteed files to seach for and gather
set inpTitleSet=VTS_
set inpExt=.VOB
set output=%outPath%\%1.mpg
set outTemp=%outPath%\%1%inpExt%

:: choose whether files come directly from DVD (must be unencrypted!)
:: or defined location on HD
choice /M "Choose Source 1 = DVD  2 = HD Temp Area" /C 12

if ERRORLEVEL 1 set inPath=%inPathDVD%
if ERRORLEVEL 2 set inPath=%inPathHD%

echo input path is: %inPath%
cd /D %inPath%
echo .
echo VOB files from %inpath%...
echo .

:: create filespec for search "VTS_01_*.vob"
set inputFileSpec=%inpTitleSet%*%inpExt%
dir %inputFileSpec%
echo .
:: select desired titleset. Usually the group with the
:: biggest file sizes is  the main movie titleset.
:: You'll be entering the digit after "VTS_0"
choice /M "Select Desired Titleset (digit after VTS_): " /C 12345678
echo you picked %ERRORLEVEL%
set inpTitleSet=%inpTitleSet%0%ERRORLEVEL%_
set inputFileSpec=%inpTitleSet%*%inpExt%

:: use a brute force loop to calculate number of
:: files matching %inputFileSpec% and display them.
:: Note that the '0' file is usually title/menu information,
:: and is skipped by making the %start% var '1'

echo files selected...
echo .
set start=1
:loop0
set tmp=%inpTitleSet%%start%%inpExt%
IF EXIST %tmp% (
echo %tmp%
set /A start=start+1
GOTO loop0
)
set /A count=%start%-1
echo .
:: confirm total files
echo Total Files = %count%

:: safety exit, in odd event where no movie files found
if %count% NEQ 0 GOTO continue1
echo .
echo Must Exit... no Files Found.
goto exit
:continue1

:: Build string containing of file names for FFMPEG "concat:" parameter.
:: Another Brute force loop. Again file *0.VOB will be skipped,
:: by making loop start=1::

:: set an 'empty' variable
set cc=
set start=1
:: create a temp substitute for the pipe "|" character,
:: because | can't be cant be used in a script (^| or similar
::  constructs just won't work here). So I'll use '@' and change it
:: later with a file search/replace utility.
set mypipe=@

:loop1
set tmp=%inpTitleSet%%start%%inpExt%
if %start% EQU %count% set mypipe=
IF EXIST %tmp% (
set cc=%cc%%inp%%tmp%%mypipe%
set /A start=start+1
GOTO loop1
)

:: create whole FFMPEG command as a string
set ffm=ffmpeg -i "concat:%cc%" -f DVD -c copy %output%

:: put it in a tmp batch file
set cmdfile=tmp.bat
echo %ffm%  > %outPath%\%cmdfile%

:: now use SKF to replace the @ chars with |
:: if you have another search/replace utility, feel free to use it.
sfk replace %outPath%\%cmdfile% "/@/|/" -yes -quiet

:: prove string in batch file looks right. You can delete
:: these two lines if you want.
echo Final command...
type %outPath%\%cmdfile%

:: run the new batch file... Give user chance to start process
@pause
call %outPath%\%cmdfile%

:: delete batch file?
del %outPath%\%cmdfile%
echo .
echo .
echo %output% converted file should be ready

ENDLOCAL
:exit
