複数のセグメントを含む図を書いていますが、tikz ではそれが気に入らないようです。そこで以下を追加しました:

\usepgfplotslibrary{external}
\usetikzlibrary{matrix,chains,positioning,decorations.pathreplacing,arrows}
\tikzexternalize

うまく動作しましたが、突然、アークが 1 つだけ増えたため、コンパイルがブロックされました。

\write18 enabled.
entering extended mode

myFigure.logを見ても、何も問題は見当たりません。

Package: ifpdf 2011/01/30 v2.3 Provides the ifpdf switch (HO)
Package ifpdf Info: pdfTeX in PDF mode is detected.
)
Package pdftexcmds Info: LuaTeX not detected.
Package pdftexcmds Info: \pdf@primitive is availabl

エラーメッセージがないので、どこを探せばいいのか全く分かりません。

以下は、私のシステムではコンパイルされない 2 つの図の例です。

\documentclass[11pt,a4]{article}
\usepackage{graphics}
\usepackage{url}
\usepackage{amsmath}
\usepackage{amssymb}
\usepackage[dcucite,abbr]{harvard}
\usepackage{tikz}
\usepackage{pgfplots}
\pgfplotsset{compat=1.8}
\usepgfplotslibrary{external}
\usetikzlibrary{matrix,chains,positioning,decorations.pathreplacing,arrows}
\tikzexternalize

\textwidth 150mm \textheight 230mm \topmargin -20mm
\renewcommand{\baselinestretch}{1.25}
\marginparwidth 17mm
\oddsidemargin 7mm
\newcommand{\cvd}{\hfill\raisebox{3pt}{\fbox{\rule{0mm}{1mm}\hspace*{1mm}\rule{0mm}{1mm}}\,} \vspace{5mm}}
\newcommand{\proof}{\vspace{1mm}\noindent{\it Proof}\quad}
\renewcommand{\thefootnote}{\arabic{footnote}}
\newcounter{bean}

\date{}

\begin{document}
\pagestyle{empty}

\begin{figure}[h]\begin{center}

\begin{tikzpicture}[
init/.style={
  draw,
  circle,
  inner sep=2pt,
  font=\Huge,
}]
\matrix[row sep= 5mm, column sep=8mm] (m) {
\node [init] (x0) {}; & \node [init] (x1) {}; & \node[init] (x2) {}; & \node[init] (x3) {}; & \node[init] (x4) {}; & \node[init] (x5) {}; & \node[init] (x6) {}; & \node[init] (x7) {};\\
\node [init] (y0) {}; & \node [init] (y1) {}; & \node[init] (y2) {}; & \node[init] (y3) {}; & \node[init] (y4) {}; & \node[init] (y5) {}; & \node[init] (y6) {}; & \node[init] (y7) {};\\
\node [init] (z0) {}; & \node [init] (z1) {}; & \node[init] (z2) {}; & \node[init] (z3) {}; & \node[init] (z4) {}; & \node[init] (z5) {}; & \node[init] (z6) {}; & \node[init] (z7) {};\\
};

\node [init, left=of m] (s) {$s$};

\node [init, right=of m] (e) {$e$};

\path (s) edge[->, dotted] (x0);
\path (s) edge[->, dotted] (y0);
\path (s) edge[->, dotted] (z0);
\path (s) edge[->, dotted] (x1);
%\path (s) edge[->, dotted] (y1);
\path (s) edge[->, thick] (z1);
\path (s) edge[->, dotted] (x2);
%\path (s) edge[->, dotted] (y2);
\path (s) edge[->, dotted] (z2);
\path (s) edge[->, dotted] (x3);
%\path (s) edge[->, dotted] (y3);
\path (s) edge[->, dotted] (z3);
\path (s) edge[->, dotted] (x4);
%\path (s) edge[->, dotted] (y4);
\path (s) edge[->, dotted] (z4);
\path (s) edge[->, dotted] (x5);
%\path (s) edge[->, dotted] (y5);
\path (s) edge[->, dotted] (z5);
\path (s) edge[->, dotted] (x6);
%\path (s) edge[->, dotted] (y6);
\path (s) edge[->, dotted] (z6);
\path (s) edge[->, dotted] (x7);
%\path (s) edge[->, dotted] (y7);
\path (s) edge[->, dotted] (z7);

\path (x0) edge[->, dotted] (x1);
\path (x0) edge[->, dotted] (y1);
\path (x0) edge[->, dotted] (z1);
\path (y0) edge[->, dotted] (x1);
\path (y0) edge[->, dotted] (y1);
\path (y0) edge[->, dotted] (z1);
\path (z0) edge[->, dotted] (x1);
\path (z0) edge[->, dotted] (y1);
\path (z0) edge[->, dotted] (z1);

\path (x1) edge[->, dotted] (x2);
\path (x1) edge[->, dotted] (y2);
\path (x1) edge[->, dotted] (z2);
\path (y1) edge[->, dotted] (x2);
\path (y1) edge[->, dotted] (y2);
\path (y1) edge[->, dotted] (z2);
\path (z1) edge[->, dotted] (x2);
\path (z1) edge[->, thick] (y2);
\path (z1) edge[->, dotted] (z2);

\path (x2) edge[->, dotted] (x3);
\path (x2) edge[->, dotted] (y3);
\path (x2) edge[->, dotted] (z3);
\path (y2) edge[->, dotted] (x3);
\path (y2) edge[->, thick] (y3);
\path (y2) edge[->, dotted] (z3);
\path (z2) edge[->, dotted] (x3);
\path (z2) edge[->, dotted] (y3);
\path (z2) edge[->, dotted] (z3);

\path (x3) edge[->, dotted] (x4);
\path (x3) edge[->, dotted] (y4);
\path (x3) edge[->, dotted] (z4);
\path (y3) edge[->, dotted] (x4);
\path (y3) edge[->, thick] (y4);
\path (y3) edge[->, dotted] (z4);
\path (z3) edge[->, dotted] (x4);
\path (z3) edge[->, dotted] (y4);
\path (z3) edge[->, dotted] (z4);

\path (x4) edge[->, dotted] (x5);
\path (x4) edge[->, dotted] (y5);
\path (x4) edge[->, dotted] (z5);
\path (y4) edge[->, thick] (x5);
\path (y4) edge[->, thick] (y5);
\path (y4) edge[->, dotted] (z5);
\path (z4) edge[->, dotted] (x5);
\path (z4) edge[->, dotted] (y5);
\path (z4) edge[->, dotted] (z5);

\path (x5) edge[->, thick] (x6);
\path (x5) edge[->, dotted] (y6);
\path (x5) edge[->, dotted] (z6);
\path (y5) edge[->, thick] (x6);
\path (y5) edge[->, dotted] (y6);
\path (y5) edge[->, dotted] (z6);
\path (z5) edge[->, dotted] (x6);
\path (z5) edge[->, dotted] (y6);
\path (z5) edge[->, dotted] (z6);

\path (x6) edge[->, thick] (x7);
\path (x6) edge[->, dotted] (y7);
\path (x6) edge[->, dotted] (z7);
\path (y6) edge[->, dotted] (x7);
\path (y6) edge[->, dotted] (y7);
\path (y6) edge[->, dotted] (z7);
\path (z6) edge[->, dotted] (x7);
\path (z6) edge[->, dotted] (y7);
\path (z6) edge[->, dotted] (z7);

\path (x0) edge[->, dotted] (e);
%\path (y0) edge[->, dotted] (e);
\path (z0) edge[->, dotted] (e);
\path (x1) edge[->, dotted] (e);
%\path (y1) edge[->, dotted] (e);
\path (z1) edge[->, dotted] (e);
\path (x2) edge[->, dotted] (e);
%\path (y2) edge[->, dotted] (e);
\path (z2) edge[->, dotted] (e);
\path (x3) edge[->, dotted] (e);
%\path (y3) edge[->, dotted] (e);
\path (z3) edge[->, dotted] (e);
\path (x4) edge[->, dotted] (e);
%\path (y4) edge[->, dotted] (e);
\path (z4) edge[->, dotted] (e);
\path (x5) edge[->, dotted] (e);
%\path (y5) edge[->, dotted] (e);
\path (z5) edge[->, dotted] (e);
\path (x6) edge[->, dotted] (e);
%\path (y6) edge[->, dotted] (e);
\path (z6) edge[->, dotted] (e);
\path (x7) edge[->, dotted] (e);
\path (x7) edge[->, thick] (e);
\path (z7) edge[->, dotted] (e);

\node [left=of x0, xshift=-1cm] (A1) {A};
\node [left=of y0, xshift=-1cm] (A2) {B};
\node [left=of z0, xshift=-1cm] (A3) {C};

\node [above=of A1] (types) {Title 1};
\node [above=of m] (types) {Title 2};

\node [below=of z0, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{a}};
\node [below=of z1, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{b}};
\node [below=of z2, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{c}};
\node [below=of z3, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{d}};
\node [below=of z4, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{e}};
\node [below=of z5, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{f}};
\node [below=of z6, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{g}};
\node [below=of z7, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{h}};

\end{tikzpicture}

\end{center}\end{figure}

\begin{figure}[h!]\begin{center}

\begin{tikzpicture}[
init/.style={
  draw,
  circle,
  inner sep=2pt,
  font=\Huge,
  %join = by -latex
}]
\matrix[row sep= 5mm, column sep=8mm] (m) {
\node [init] (x0) {}; & \node [init] (x1) {}; & \node[init] (x2) {}; & \node[init] (x3) {}; & \node[init] (x4) {}; & \node[init] (x5) {}; & \node[init] (x6) {}; & \node[init] (x7) {};\\
\node [init] (y0) {}; & \node [init] (y1) {}; & \node[init] (y2) {}; & \node[init] (y3) {}; & \node[init] (y4) {}; & \node[init] (y5) {}; & \node[init] (y6) {}; & \node[init] (y7) {};\\
\node [init] (z0) {}; & \node [init] (z1) {}; & \node[init] (z2) {}; & \node[init] (z3) {}; & \node[init] (z4) {}; & \node[init] (z5) {}; & \node[init] (z6) {}; & \node[init] (z7) {};\\
};

\node [init, left=of m] (s) {$s$};

\node [init, right=of m] (e) {$e$};

\path (s) edge[->, dotted, very thick] node {\textbf{7}} (x0);
\path (s) edge[->, dotted, very thick] node {\textbf{1}} (y0);
\path (s) edge[->, dotted, very thick] node {\textbf{2}} (z0);
\path (s) edge[->, dotted] (x1);
\path (s) edge[->, dotted] (e);
\path (s) edge[->, dotted] (z1);
\path (s) edge[->, dotted] (x2);
\path (s) edge[->, dotted] (z2);
\path (s) edge[->, dotted] (x3);
\path (s) edge[->, dotted] (z3);
\path (s) edge[->, dotted] (x4);
\path (s) edge[->, dotted] (z4);
\path (s) edge[->, dotted] (x5);
\path (s) edge[->, dotted] (z5);
\path (s) edge[->, dotted] (x6);
\path (s) edge[->, dotted] (z6);
\path (s) edge[->, dotted] (x7);
\path (s) edge[->, dotted] (z7);

\path (x0) edge[->, dotted, very thick] node {\textbf{7}} (x1);
\path (x0) edge[->, dotted] (y1);
\path (x0) edge[->, dotted] (z1);
\path (y0) edge[->, dotted, very thick] node {\textbf{7}} (x1);
\path (y0) edge[->, dotted] (z1);
\path (z0) edge[->, dotted, very thick] node {\textbf{7}} (x1);
\path (z0) edge[->, dotted] (y1);
\path (z0) edge[->, dotted] (z7);

\path (x1) edge[->, dotted] (x7);
\path (x1) edge[->, dotted, very thick] node {\textbf{1}} (y2);
\path (x1) edge[->, dotted] (z2);
\path (y1) edge[->, dotted] (x2);
\path (y1) edge[->, dotted, very thick] node {\textbf{1}} (y2);
\path (y1) edge[->, dotted] (z2);
\path (z1) edge[->, dotted] (x2);
\path (z1) edge[->, dotted, very thick] node {\textbf{1}} (y2);

\path (x2) edge[->, dotted] (y3);
\path (x2) edge[->, dotted, very thick] node {\textbf{2}} (z3);
\path (y2) edge[->, dotted] (x3);
\path (y2) edge[->, dotted, very thick] node {\textbf{2}} (z3);
\path (z2) edge[->, dotted] (x3);
\path (z2) edge[->, dotted] (y3);
\path (z2) edge[->, dotted, very thick] node {\textbf{2}} (z3);

\path (x3) edge[->, dotted] (y4);
\path (x3) edge[->, dotted] (z4);
\path (y3) edge[->, dotted] (x4);
%\path (y3) edge[->, dotted] (y4);
\path (y3) edge[->, dotted] (z4);
\path (z3) edge[->, dotted] (x4);
\path (z3) edge[->, dotted] (y4);
%\path (z3) edge[->, dotted] (z4);
%
%\path (x4) edge[->, dotted] (x5);
\path (x4) edge[->, dotted] (y5);
\path (x4) edge[->, dotted[ (z5);
\path (y4) edge[->, dotted] (x5);
%\path (y4) edge[->, dotted] (y5);
\path (y4) edge[->, dotted] (z5);
%\path (z4) edge[->, dotted] (x5);
%\path (z4) edge[->, dotted] (y5);
%\path (z4) edge[->, dotted] (z5);
%
%\path (x5) edge[->, dotted] (x6);
%\path (x5) edge[->, dotted] (y6);
%\path (x5) edge[->, dotted] (z6);
%\path (y5) edge[->, dotted] (x6);
%\path (y5) edge[->, dotted] (y6);
%\path (y5) edge[->, dotted] (z6);
%\path (z5) edge[->, dotted] (x6);
%\path (z5) edge[->, dotted] (y6);
%\path (z5) edge[->, dotted] (z6);
%
%\path (x6) edge[->, dotted] (x7);
%\path (x6) edge[->, dotted] (y7);
%\path (x6) edge[->, dotted] (z7);
%\path (y6) edge[->, dotted] (x7);
%\path (y6) edge[->, dotted] (y7);
%\path (y6) edge[->, dotted] (z7);
%\path (z6) edge[->, dotted] (x7);
%\path (z6) edge[->, dotted] (y7);
%\path (z6) edge[->, dotted] (z7);
%
%\path (x0) edge[->, dotted] (e);
%\path (y0) edge[->, dotted] (e);
%\path (z0) edge[->, dotted] (e);
%\path (x1) edge[->, dotted] (e);
%\path (y1) edge[->, dotted] (e);
%\path (z1) edge[->, dotted] (e);
%\path (x2) edge[->, dotted] (e);
%\path (y2) edge[->, dotted] (e);
%\path (z2) edge[->, dotted] (e);
%\path (x3) edge[->, dotted] (e);
%\path (y3) edge[->, dotted] (e);
%\path (z3) edge[->, dotted] (e);
%\path (x4) edge[->, dotted] (e);
%\path (y4) edge[->, dotted] (e);
%\path (z4) edge[->, dotted] (e);
%\path (x5) edge[->, dotted] (e);
%\path (y5) edge[->, dotted] (e);
%\path (z5) edge[->, dotted, very thick] node {\textbf{0}} (e);
%\path (x6) edge[->, dotted] (e);
%\path (y6) edge[->, dotted] (e);
%\path (z6) edge[->, dotted] (e);
%\path (x7) edge[->, dotted, very thick] node {\textbf{0}} (e);
%\path (y7) edge[->, dotted, very thick] node {\textbf{0}} (e);
%\path (z7) edge[->, dotted, very thick] node {\textbf{0}} (e);

\node [left=of x0, xshift=-1cm] (A1) {A};
\node [left=of y0, xshift=-1cm] (A2) {B};
\node [left=of z0, xshift=-1cm] (A3) {C};

\node [below=of z0, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{a}};
\node [below=of z1, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{b}};
\node [below=of z2, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{c}};
\node [below=of z3, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{d}};
\node [below=of z4, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{e}};
\node [below=of z5, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{f}};
\node [below=of z6, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{g}};
\node [below=of z7, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{h}};

\end{tikzpicture}

\end{center}\end{figure}

\end{document}

これにより、test-figure0.dep、.dpth、.log、.md5、.pdf というファイルが作成されますが、figure1 の場合は PDF 以外のファイルが作成されます。私は TeXShop を使用して、デフォルトのコマンドとして 'pdflatex -shell-escape' でコンパイルします。

答え1

問題は、edge2 番目の図の の数が多すぎることです。これにより、何らかの理由で (正確な理由はわかりませんが)、「メモリ不足」エラーは発生せずにコンパイラがフリーズします。

図を外部化しても役に立ちません。結局のところ、pdflatex は外部の図に対して呼び出す必要があり、コンパイラが再びフリーズしてしまうからです。

コードとコンパイルを改善するには、次の 2 つの戦略があります。

  1. の代わりに\path (a) edge[options] (b);\draw[options] (a) -- (b);edgeの代わりにdrawを使用するとメモリ消費量が減ります(理由は分かりません)

  2. ループを使用してください。これによってメモリ消費量が削減される理由が思い浮かばない場合でも、少なくともコードが短くなり、読みやすく、保守しやすくなります。

これは2番目の図についての私の見解です。

\begin{tikzpicture}[
init/.style={
  draw,
  circle,
  inner sep=2pt,
  font=\Huge,
  %join = by -latex
}]
\matrix[row sep= 5mm, column sep=8mm] (m) {
\node [init] (x0) {}; & \node [init] (x1) {}; & \node[init] (x2) {}; & \node[init] (x3) {}; &             → \node[init] (x4) {}; & \node[init] (x5) {}; & \node[init] (x6) {}; & \node[init] (x7) {};\\
\node [init] (y0) {}; & \node [init] (y1) {}; & \node[init] (y2) {}; & \node[init] (y3) {}; &             → \node[init] (y4) {}; & \node[init] (y5) {}; & \node[init] (y6) {}; & \node[init] (y7) {};\\
\node [init] (z0) {}; & \node [init] (z1) {}; & \node[init] (z2) {}; & \node[init] (z3) {}; &             → \node[init] (z4) {}; & \node[init] (z5) {}; & \node[init] (z6) {}; & \node[init] (z7) {};\\
};

\node [init, left=of m] (s) {$s$};
\node [init, right=of m] (e) {$e$};

\foreach \start/\end/\label in {
    s/x0/7,  s/y0/1,  s/z0/2,
    x0/x1/7, y0/x1/7, z0/x1/7,
    x1/y2/1, y1/y2/1, z1/y2/1,
    x2/z3/2, y2/z3/2, z2/z3/2 } {
        \draw[->,dotted,very thick] (\start) -- (\end) node[midway] {\textbf{\label}};
};
\foreach \n [count=\previous from 0] in {1,...,7} {
    \draw[->,dotted] (s) -- (x\n);   \draw[->,dotted] (x\n) -- (e);
    \draw[->,dotted] (s) -- (z\n);   \draw[->,dotted] (z\n) -- (e);
    \draw[->,dotted] (x\previous) -- (y\n);
    \draw[->,dotted] (x\previous) -- (z\n);
    \draw[->,dotted] (y\previous) -- (x\n);
    \draw[->,dotted] (y\previous) -- (z\n);
    \draw[->,dotted] (z\previous) -- (x\n);
    \draw[->,dotted] (z\previous) -- (y\n);
}
\path (s) edge[->, dotted] (e);

\node [left=of x0, xshift=-1cm] (A1) {A};
\node [left=of y0, xshift=-1cm] (A2) {B};
\node [left=of z0, xshift=-1cm] (A3) {C};

\foreach \letter [count=\n from 0]in {a,b,c,d,e,f,g,h} {
    \node [below=of z\n, xshift=-0.3cm, yshift=0.5cm]  {\rotatebox{60}{\letter}};
}
\end{tikzpicture}

このコードは問題なくコンパイルされ、短時間で次の結果が生成されます。

結果

アップデート

いくつかのエッジが欠落していることに気づきました (意図した図が何であるかはわかりません)。また、ノード間の無数の小さなエッジを描画する部分で、内部ループを使用してコードをさらに圧縮する機会が 1 つあります。

\foreach \n [count=\previous from 0] in {1,...,7} {
    \draw[->,dotted] (s) -- (x\n);   \draw[->,dotted] (x\n) -- (e);
    \draw[->,dotted] (s) -- (z\n);   \draw[->,dotted] (z\n) -- (e);
    \foreach \s in {x,y,z} {
       \foreach \e in {x,y,z} {
          \draw[->,dotted] (\s\previous) -- (\e\n);
        }
    }
}

結果は次のとおりです。

新しい結果
