フローフレームが次のページに移動しない

このフローフレームを次のページに拡張しようとしましたが、うまくいきません。ページ番号 [1-2] を定義しても、コンパイラはテキストを揃えません。フローを次のページに継続する必要があります。単一ページに制限されます。

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Document properties and packages
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\documentclass[a4paper,12pt,final]{memoir}

% misc
\renewcommand{\familydefault}{bch}  % font
\pagestyle{empty}                   % no pagenumbering
\setlength{\parindent}{0pt}         % no paragraph indentation


% required packages (add your own)
\usepackage{flowfram}                                       % column layout
\usepackage[top=1cm,left=1cm,right=1cm,bottom=1cm]{geometry}% margins
\usepackage{graphicx}                                       % figures
\usepackage{url}                                            % URLs
\usepackage[usenames,dvipsnames]{xcolor}                    % color
\usepackage{multicol}                                       % columns env.
    \setlength{\multicolsep}{0pt}
\usepackage{paralist}                                       % compact lists
\usepackage{tikz}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Create column layout
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define length commands
\setlength{\vcolumnsep}{\baselineskip}
\setlength{\columnsep}{\vcolumnsep}

% frame setup (flowfram package)
% left frame
\newflowframe{0.2\textwidth}{\textheight}{0pt}{0pt}[left]
    \newlength{\LeftMainSep}
    \setlength{\LeftMainSep}{0.2\textwidth}
    \addtolength{\LeftMainSep}{2\columnsep}
% right frame
\newflowframe{0.7\textwidth}{\textheight}{\LeftMainSep}{0pt}[main01]

% horizontal rule between frames (using TikZ)
\renewcommand{\ffvrule}[3]{%
\hfill
\tikz{%
    \draw[loosely dotted,color=RoyalBlue,line width=1.5pt,yshift=-#1]
    (0,0) -- (0pt,#3);}%
\hfill\mbox{}}
\insertvrule{flow}{1}{flow}{2}


%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define macros (for convience)
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\newcommand{\Sep}{\vspace{1.5em}}
\newcommand{\SmallSep}{\vspace{0.5em}}

\newenvironment{AboutMe}
    {\ignorespaces\textbf{\color{RoyalBlue} About me}}
    {\Sep\ignorespacesafterend}

\newcommand{\CVSection}[1]
    {\Large\textbf{#1}\par
    \SmallSep\normalsize\normalfont}

\newcommand{\CVItem}[1]
    {\textbf{\color{RoyalBlue} #1}}


%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Begin document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{document}

% Left frame
%%%%%%%%%%%%%%%%%%%%
%
% Upload your own photo using the files menu
\begin{figure}
    \hfill
    \includegraphics[width=0.6\columnwidth]{cv-photo.png}
    \vspace{-7cm}
\end{figure}

\begin{flushright}\small
    Johnathan S. Doe \\
    \url{[email protected]}  \\
    \url{www.website.com} \\
    (555) 555-3333
\end{flushright}\normalsize
\framebreak


% Right frame
%%%%%%%%%%%%%%%%%%%%
\Huge\bfseries {\color{RoyalBlue} John Doe} \\
\Large\bfseries  Graphics designer \\

\normalsize\normalfont

% About me
\begin{AboutMe}
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla. Pellentesque condimentum justo ut ligula feugiat nec facilisis tellus ultricies. Nullam sit amet dictum ipsum. Sed lacus neque, hendrerit eu rhoncus nec, pellentesque vitae sem.
\end{AboutMe}

% Experience
\CVSection{Experience}
\CVItem{May 2010 - present, Lorem ipsum}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\SmallSep

\CVItem{Aug 2007 - Feb 2010, Vivamus vel}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus.
\Sep

% Education
\CVSection{Education}
\CVItem{2010 - present, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep

\CVItem{2007 - 2010, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep

\CVItem{2005 - 2007, Vivamus vel bibendum}\\
Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\Sep

% Skills
\CVSection{Skills}
\CVItem{Platforms}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
    \item Lorem
    \item Ipsum
\end{compactitem}
\end{multicols}
\SmallSep

\CVItem{Computer software}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
    \item Lorem
    \item Ipsum
    \item Dolor
    \item Sit
    \item Amet
    \item Consectetur
    \item Adipiscing
    \item Elit
    \item \ldots
\end{compactitem}
\end{multicols}
\Sep

% References
\CVSection{References}
References upon request.

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% End document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\end{document}

答え1

MWEには実際には2ページ分のテキストがないので、lipsumパッケージ。問題は、1 ページ目の右フレームのテキストが 2 ページ目のはるかに狭い左フレームに流れ込むことです。これにより、段落の途中で行幅を調整できないという問題が TeX で発生します。ただし、実際には 1 ページ目の右フレームのテキストを 2 ページ目の右フレームに流し込む必要があるのではないかと思います。その場合、左フレームは動的フレームとして適しており、コンテンツはdynamiccontents(またはdynamiccontents*) 環境または などのコマンドのいずれかを使用して設定できます\setdynamiccontents。以下は、MWE の修正です。

\documentclass[a4paper,12pt,final,oneside]{memoir}

% misc
\renewcommand{\familydefault}{bch}  % font
\pagestyle{empty}                   % no pagenumbering
\setlength{\parindent}{0pt}         % no paragraph indentation


% required packages (add your own)
\usepackage{flowfram}                                       % column layout
\usepackage[top=1cm,left=1cm,right=1cm,bottom=1cm]{geometry}% margins
\usepackage{graphicx}                                       % figures
\usepackage{url}                                            % URLs
\usepackage[usenames,dvipsnames]{xcolor}                    % color
\usepackage{multicol}                                       % columns env.
    \setlength{\multicolsep}{0pt}
\usepackage{paralist}                                       % compact lists
\usepackage{tikz}
\usepackage{lipsum}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Create column layout
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define length commands
\setlength{\vcolumnsep}{\baselineskip}
\setlength{\columnsep}{\vcolumnsep}

% frame setup (flowfram package)
% left frame
\newdynamicframe{0.2\textwidth}{\textheight}{0pt}{0pt}[left]
    \newlength{\LeftMainSep}
    \setlength{\LeftMainSep}{0.2\textwidth}
    \addtolength{\LeftMainSep}{2\columnsep}

\setdynamicframe*{left}{clear}

% right frame
\newflowframe{0.7\textwidth}{\textheight}{\LeftMainSep}{0pt}[main01]

% horizontal rule between frames (using TikZ)
\renewcommand{\ffvrule}[3]{%
\hfill
\tikz{%
    \draw[loosely dotted,color=RoyalBlue,line width=1.5pt,yshift=-#1]
    (0,0) -- (0pt,#3);}%
\hfill\mbox{}}
\insertvrule*{dynamic}{left}{flow}{main01}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define macros (for convience)
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\newcommand{\Sep}{\vspace{1.5em}}
\newcommand{\SmallSep}{\vspace{0.5em}}

\newenvironment{AboutMe}
    {\ignorespaces\textbf{\color{RoyalBlue} About me}}
    {\Sep\ignorespacesafterend}

\newcommand{\CVSection}[1]
    {\Large\textbf{#1}\par
    \SmallSep\normalsize\normalfont}

\newcommand{\CVItem}[1]
    {\textbf{\color{RoyalBlue} #1}}


%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Begin document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{document}

% Left frame
%%%%%%%%%%%%%%%%%%%%
%
% Upload your own photo using the files menu
\begin{dynamiccontents*}{left}
{\centering
    \includegraphics[width=0.6\linewidth]{example-image}
\par
}

\begin{flushright}\small
    Johnathan S. Doe \\
    \url{[email protected]}  \\
    \url{www.website.com} \\
    (555) 555-3333
\end{flushright}\normalsize
\end{dynamiccontents*}


% Right frame
%%%%%%%%%%%%%%%%%%%%
\Huge\bfseries {\color{RoyalBlue} John Doe} \\
\Large\bfseries  Graphics designer \\

\normalsize\normalfont

% About me
\begin{AboutMe}
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla. Pellentesque condimentum justo ut ligula feugiat nec facilisis tellus ultricies. Nullam sit amet dictum ipsum. Sed lacus neque, hendrerit eu rhoncus nec, pellentesque vitae sem.
\end{AboutMe}

% Experience
\CVSection{Experience}
\CVItem{May 2010 - present, Lorem ipsum}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\SmallSep

\CVItem{Aug 2007 - Feb 2010, Vivamus vel}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus.
\Sep

% Education
\CVSection{Education}
\CVItem{2010 - present, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep

\CVItem{2007 - 2010, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep

\CVItem{2005 - 2007, Vivamus vel bibendum}\\
Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\Sep

% Skills
\CVSection{Skills}
\CVItem{Platforms}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
    \item Lorem
    \item Ipsum
\end{compactitem}
\end{multicols}
\SmallSep

\CVItem{Computer software}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
    \item Lorem
    \item Ipsum
    \item Dolor
    \item Sit
    \item Amet
    \item Consectetur
    \item Adipiscing
    \item Elit
    \item \ldots
\end{compactitem}
\end{multicols}
\Sep

% References
\CVSection{References}
References upon request.

\lipsum

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% End document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\end{document}

主な違いは、onesideクラスオプション、左フレームを動的フレームに変更すること、dynamiccontents*環境を使用してコンテンツを設定することです。

\setdynamicframe*{left}{clear}

各ページ区切りの後に左のフレームをクリアします。これを行わない場合は、この行を削除します。
