tabularx私は Kile を使用しており、ページの幅内に収まるテーブルを作成する方法を学ぼうとしています。

しかし、大きな問題が 2 つあります。

  • 列のサイズには X を使用する必要があるため、列のサイズを設定できません (たとえば、列が 4 つある場合、列 A のサイズを 10% にし、列 B、C、D に残りを均等に分散します)。
  • テーブルがようやくページの幅内に収まるようになりましたが、ページの高さは考慮されません...

これを修正するために、ドキュメントを読んで次の MWE を使用しました。

\documentclass[a4paper,10pt]{article}
\usepackage[utf8]{inputenc}
\usepackage{tabularx}

\begin{document}
\begin{table}
{%
\newcommand{\mc}[3]{\multicolumn{#1}{#2}{#3}}
\begin{center}
\begin{tabularx}{\textwidth}{>{\hsize=.25\hsize}X>{\hsize=1.25\hsize}X>{\hsize=1.25\hsize}X>{\hsize=1.25\hsize}X}\cline{2-4}
\textbf{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
\mc{1}{|l|}{\textbf{Goal}} & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
\mc{1}{|l|}{\textbf{NoSQL and Datastores supported}} & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
\mc{1}{|l|}{\textbf{Operations supported}} & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
\mc{1}{|l|}{\textbf{No support for}} & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
\mc{1}{|l|}{\textbf{Future}} & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
\mc{1}{|l|}{\textbf{Commercial support}} & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
\mc{1}{|l|}{\textbf{Documentation}} & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
\end{tabularx}
\end{center}
}%
\end{table}


\end{document}

ただし、前置きは正しいように見えますが (4 つの列がある場合、列 B、C、D は列 A の 6 倍である必要があります)、何も起こりません。

私は一体何を望んでいるのでしょうか? テーブルの合計幅が 100% だとします。列 A の幅をその 10% にし、列 B、C、D の幅をそれぞれ 30% にしたいと思います。

また、この表を 1 ページに収め、余分なページに拡張しないようにしたいと思います。そのため、longtable は使用できません...

MWE は現在次のようなものを生成します:

ここに画像の説明を入力してください

私が読んだドキュメントはここにあります:

どうすれば問題を解決できますか?

答え1

その方法の 1 つを以下に示します。

  • p{<width>}通常の 内のすべての列に使用しますtabular。
  • これを行うには、新しい長さを作成し\tabularlength、それを表の合計幅に設定します。.975\linewidthここでは使用しました。
  • 次に、各列を\tabularlength次のように定義しますp{.1\tabularlength}。
  • 最初の列を正常に動作させるには、multicolumn行を分割できるように省略します。
  • これはハイフネーションが必要なことを意味するので、 をロードしますbabel。
  • これでは列の最初の単語のハイフネーションが許可されないため、十分ではありません。そのため、 を使用してこれらの単語を手動でハイフネーションします\-。
  • geometryページレイアウトを正しくするために使用します。
  • >{\bfseries}すべての行に太字を指定する必要がないように、最初の列に使用します。
  • \multicolumn不必要な垂直線が出ないように、最初の行にも 1 つ必要です。
  • \centering環境ではなくを使用してくださいcenter。後者は、ここでは不要なスペースを追加します。

これは実際には（少し）余裕を持って収まります。テーブルがもっと大きい場合は、環境\small内でを使用してtableフォント サイズを少し小さく設定することを検討できます。または、 を使用して余白などを調整することもできますgeometry。これは、ドキュメント全体に対して行うことも、必要に応じて 1 ページに対して行うこともできます。

コード

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{tabularx}

\begin{document}

\begin{table}
  \newlength{\tabularlength}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries}p{.1\tabularlength}|*{3}{p{.3\tabularlength}}}
  \cline{2-4}
  \multicolumn{1}{l}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
  Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
  NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
  Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
  No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
  Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
  Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
  Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
  \end{tabular}
\end{table}

\end{document}

出力

ページにフィットした表

代替レイアウト

表を横向きで表示することも検討すると、人々が理解しやすくなると思います。たとえば、次のようになります。

横向きの表形式

この場合、最初の列に\raggedright適切な外観にするために、追加の書式設定ディレクティブ を使用しました。

横長表のコード

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{array}
\usepackage{pdflscape}

\begin{document}

\begin{landscape}

\begin{table}
  \newlength{\tabularlength}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries\raggedright}p{.1\tabularlength}|*{3}{p{.3\tabularlength}}}
    \cline{2-4}
    \multicolumn{1}{l}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
    Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
    NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
    Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
    No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
    Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
    Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
    Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
  \end{tabular}
\end{table}

\end{landscape}

\end{document}

中央揃えの列と垂直線

Flame_Phoenix のコメントで指摘されているように、m{<width>}指定された幅の列を垂直方向に中央揃えで提供します。この指定子にはパッケージが必要ですarray。

「Hibernate OGM」の前に垂直線を追加するには、表の最初のエントリの を調整するだけです\multicolumn。すべてのセルを水平方向と垂直方向に中央揃えするには、>{\centering}表の構成に を追加します。ただし、これは少し面倒で、一貫して調整するのが難しくなります。より優れた解決策は、 の機能を使用してarray新しい列タイプを定義することです。

\newcolumntype{M}{>{\centering}m{.3\tabularlength}}

私の例では縦向きと横向きの両方のレイアウトを示しているため、すでに定義されている長さを定義しないように、環境\tabularlengthから追加を引き出す必要もあります。tabular

\newlength{\tabularlength}

列mタイプは、\\行の末尾ではなく、列内の新しい行として扱われます。したがって、\\\hlineを に置き換える必要があります\tabularnewline\hline。

最後に、整頓のために右端に縦罫線を追加しました。

コード

\documentclass[a4paper,10pt,british]{article}
\usepackage{babel,geometry}
\usepackage[utf8]{inputenc}
\usepackage{array}
\usepackage{pdflscape}
\newlength{\tabularlength}
\newcolumntype{M}{>{\centering}m{.3\tabularlength}}

\begin{document}

\begin{table}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\centering\bfseries}m{.1\tabularlength}|*{3}{M}|}
  \cline{2-4}
  \multicolumn{1}{l|}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\tabularnewline\hline
  Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\tabularnewline\hline
  NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\tabularnewline\hline
  Oper\-ations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\tabularnewline\hline
  No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\tabularnewline\hline
  Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\tabularnewline\hline
  Com\-mer\-cial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\tabularnewline\hline
  Docu\-ment\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\tabularnewline\hline
  \end{tabular}
\end{table}

\begin{landscape}

\begin{table}
  \setlength{\tabularlength}{.975\linewidth}
  \centering
  \begin{tabular}{|>{\bfseries\centering}m{.1\tabularlength}|*{3}{M}|}
    \cline{2-4}
    \multicolumn{1}{l|}{} & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\tabularnewline\hline
    Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\tabularnewline\hline
    NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\tabularnewline\hline
    Operations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\tabularnewline\hline
    No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\tabularnewline\hline
    Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\tabularnewline\hline
    Commercial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\tabularnewline\hline
    Document\-ation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\tabularnewline\hline
  \end{tabular}
\end{table}

\end{landscape}

\end{document}

出力

すべて中央揃えの表形式

答え2

ここに画像の説明を入力してください

主なエラーは、指定された幅の列を自然な幅の列に置き換えていたマルチ列でしたl。

\documentclass[a4paper,10pt]{article}
\usepackage[utf8]{inputenc}
\usepackage{array}

\begin{document}
\begin{table}
\centering\small
\newcommand{\mc}[3]{\multicolumn{#1}{#2}{#3}}
\setlength{\dimen0}{\dimexpr\textwidth-6\tabcolsep\relax}
\begin{tabular}{@{}>{\hspace*{0pt}\bfseries}p{.1\dimen0}*3{p{.3\dimen0}}}
 & \textbf{Hibernate OGM} & \textbf{EclipseLink NoSQL} & \textbf{DataNucleus}\\\hline
Goal & Complement JPA with NoSQL, key-value stores & Integrates in the father project main goal of providing a complete persistence solution & Being a standards compliant and efficient JPA and JDO platform\\\hline
NoSQL and Datastores supported & Infinispan, EHCache, MongoDB & MongoDB, Oracle NoSQL, Oracle AQ, JMS, XML files & Google Big Table, MongoDB, Cassandra, Excel, OOXML, ODF, XML, HBase, AppEngine/DataStore, Neo4j, JSON, Amazon S3, GoogleStorage, LDAP, NeoDatis, db4o\\\hline
Operations supported & Object Oriented queries (JP-QL), CRUD of entities, Polymorphic entities, Embeddable objects, Basic types (partial), Unidirectional and Bidirectional relationships (partial), Collections, Hibernate Search queries, JPA and Hibernate ORM API & Object Oriented Queries, Polymorphic entities, Basic types, Unidirectional relationships, Collections, JPA (partial), Complex hierarchical, Indexed hierarchical data, Mapped hierarchical data, CRUD operations, Embedded objects and collections, Inheritance, Subset of JP-QL and Criteria API, Denormalization & CRUD operations, Embedded objects and collections, Inheritance, Relationships (Unidirectional and Bidirectional), Queries for JP-QL, JDOQL and SQL (partial),  Basic types, Joins.\\\hline
No support for & Denormalization, Complex joins and aggregations & Joins & Aggregations? (not specified in documentation)\\\hline
Future & High performance sequence generator, parallel key fetching, support for Map/Reduce, more NoSQL classes, better mixing of NoSQL and RDBMS & ? & JPA2.1 full feature list, Official support for Cassandra, Considering a plugin for REDIS\\\hline
Commercial support & Red Hat & Oracle (via TopLink) & Supported by DataNucleus team\\\hline
Documentation & Scattered, inactive forums, official documentation lacking & Bureaucratic forums, information is complete and gathered mainly in the official website & Active forums, acceptable official documentation, but the big advantage comes from user support in form of blogs and posts scattered around the Internet\\\hline
\end{tabular}

\end{table}


\end{document}
