映画のフィルムストリップの画像

Question

埋め込まれた PDF 画像から映画のフィルムストリップを作成することは可能ですか?

Answer 1

\documentclass{article}

\usepackage{color,graphicx}

\newcommand{\whitebox}{\hfill\textcolor{white}{\rule[1mm]{1.8mm}{2.8mm}}\hfill}
\newcommand{\filmbox}[1]{%
    \setlength{\fboxsep}{0pt}%
    \colorbox{black}{%
        \begin{minipage}{3.2cm}
            \rule{0mm}{4.8mm}\whitebox\whitebox\whitebox\whitebox\whitebox%
            \whitebox\whitebox\whitebox\whitebox\null\\%
            \null\hfill\includegraphics[width=3cm]{#1}\hfill\null\\[1mm]%
            \null\whitebox\whitebox\whitebox\whitebox\whitebox%
            \whitebox\whitebox\whitebox\whitebox\null
        \end{minipage}}}

\begin{document}

\noindent
\filmbox{1}\filmbox{2}\filmbox{3}\\
\filmbox{4}\filmbox{5}\filmbox{6}

\end{document}

---

SDrolet が指摘したように、含まれる画像のアスペクト比が異なるとフレームが不均一になります。これは 2 つの方法で解決できます。

• SDrolet のソリューションを使用して、特定のサイズにトリミングします。これにより、画像の一部が失われます。
• の定義にheightのオプションを追加して、特定のサイズに拡大縮小します。これは画像を歪めることを意味します。\importgraphics\filmbox

Answer 2

Jonas Granholm は巧妙な解決策を提供しました。ただし、画像が同じ寸法でない場合、ムービー ストリップは不均等になります (例: 下の最初のムービー フィルム ストリップ)。"adjustbox" パッケージ (Martin Sharrer) と Amaru / Paul Gaborit が提供したコードは、この問題を解決するのに役立ちます (例: 下 2 番目のムービー フィルム ストリップ)。最終的なコードは次のとおりです。

\documentclass{book}

\usepackage{color}
\usepackage{graphicx}
\usepackage{adjustbox} %  Martin Sharrer package
\usepackage{calc}
\usepackage{ifthen}

% % % Method to adjust images to the same dimensions
% % % By Amaru / Paul Gaborit / based on Martin Sharrer package "adjustbox" http://tex.stackexchange.com/questions/60918/how-to-scale-and-then-trim-an-image/61073#61073

\newlength{\oH}
\newlength{\oW}
\newlength{\rH}
\newlength{\rW}
\newlength{\cH}
\newlength{\cW}

\newcommand\ClipImage[3]{% width, height, image
\settototalheight{\oH}{\includegraphics{#3}}%
\settowidth{\oW}{\includegraphics{#3}}%
\setlength{\rH}{\oH * \ratio{#1}{\oW}}%
\setlength{\rW}{\oW * \ratio{#2}{\oH}}%
\ifthenelse{\lengthtest{\rH < #2}}{%
    \setlength{\cW}{(\rW-#1)*\ratio{\oH}{#2}}%
    \adjincludegraphics[height=#2,clip,trim=0 0 \cW{} 0]{#3}%
}{%
    \setlength{\cH}{(\rH-#2)*\ratio{\oW}{#1}}%
    \adjincludegraphics[width=#1,clip,trim=0 \cH{} 0 0]{#3}%
}%
}


% %
% % Explanation for movie film strip cells:
% %
% %  The basic cell is made of a black colorbox (colorbox).
% %              \colorbox{color}{text} : same color as \textcolor{color}{text}
% %  Multiple lines of text can be placed inside a colorbox providing that they are included in a minipage of a specified width.
% %              \begin{minipage}{width} text \end{minipage}
% %  The first and last lines of text are composed of nine small colored (white) rules (boxes) equally spaced with \hfill. The color of each rule is the same as the textcolor.
% %              \textcolor{color}{text}
% %              \rule[depth]{width}{height}
% %              \null is the same as \hbox{} and it can be used for a material which reserves no space but shows TeX that there is a box which is taken into account for typesetting (Herbert: http://tex.stackexchange.com/questions/24919/what-is-null-and-when-do-we-need-to-use-it)
% %
% %
% %

\newcommand{\whitebox}{\hfill\textcolor{white}{\rule[1mm]{1.8mm}{2.8mm}}\hfill}

\newcommand{\SetColorForColoredSmallBoxes}[1]{ %
\def\ColoredSmallBox{\hfill\textcolor{#1}{\rule[1mm]{1.8mm}{2.8mm}}\hfill}}

\SetColorForColoredSmallBoxes{red}

\newcommand{\filmbox}[1]{%  ( Jonas Granholm )
    \setlength{\fboxsep}{0pt}%
    \colorbox{black}{%
        \begin{minipage}{3.2cm}
            \rule{0mm}{4.8mm}\whitebox\whitebox\whitebox\whitebox\whitebox%
            \whitebox\whitebox\whitebox\whitebox\null\\%
            \null\hfill\includegraphics[width=3cm]{#1}\hfill\null\\[1mm]%
            \null\whitebox\whitebox\whitebox\whitebox\whitebox%
            \whitebox\whitebox\whitebox\whitebox\null
        \end{minipage}}}

\newcommand{\filmboxClipImage}[1]{%
    \setlength{\fboxsep}{0pt}%
    \colorbox{black}{%
        \begin{minipage}{3.2cm}
            \rule{0mm}{4.8mm}
            \ColoredSmallBox\whitebox\ColoredSmallBox\whitebox\ColoredSmallBox
            \whitebox\ColoredSmallBox\whitebox\ColoredSmallBox\null\\%
            \null\hfill\ClipImage{3cm}{3cm}{#1}\hfill\null\\[1mm]%
            \null\whitebox\whitebox\whitebox\whitebox\whitebox%
            \whitebox\whitebox\whitebox\whitebox\null
        \end{minipage}}}

\begin{document}

\noindent
\filmbox{First-rectangle}\filmbox{Second-rectangle}\filmbox{Third-rectangle}\\

\noindent
\filmboxClipImage{First-rectangle}\filmboxClipImage{Second-rectangle}\filmboxClipImage{Third-rectangle}\\

\end{document}

Answer 3

以下は、Jonas Granholm が提案した修正を加えた最終コードです。

\documentclass{book}

\usepackage{color}
\usepackage{graphicx}
\usepackage{adjustbox} %  Martin Sharrer package
\usepackage{calc}
\usepackage{ifthen}

% % % Method to adjust images to the same dimensions
% % % By Amaru / Paul Gaborit / based on Martin Sharrer package "adjustbox" http://tex.stackexchange.com/questions/60918/how-to-scale-and-then-trim-an-image/61073#61073

\newlength{\oH}
\newlength{\oW}
\newlength{\rH}
\newlength{\rW}
\newlength{\cH}
\newlength{\cW}

\newcommand\ClipImage[3]{% width, height, image
\settototalheight{\oH}{\includegraphics{#3}}%
\settowidth{\oW}{\includegraphics{#3}}%
\setlength{\rH}{\oH * \ratio{#1}{\oW}}%
\setlength{\rW}{\oW * \ratio{#2}{\oH}}%
\ifthenelse{\lengthtest{\rH < #2}}{%
    \setlength{\cW}{(\rW-#1)*\ratio{\oH}{#2}}%
    \adjincludegraphics[height=#2,clip,trim=0 0 \cW{} 0]{#3}%
}{%
    \setlength{\cH}{(\rH-#2)*\ratio{\oW}{#1}}%
    \adjincludegraphics[width=#1,clip,trim=0 \cH{} 0 0]{#3}%
}%
}


% %
% % Explanation for movie film strip cells:
% %
% %  The basic cell is made of a black colorbox (colorbox).
% %              \colorbox{color}{text} : same color as \textcolor{color}{text}
% %  Multiple lines of text can be placed inside a colorbox providing that they are included in a minipage of a specified width.
% %              \begin{minipage}{width} text \end{minipage}
% %  The first and last lines of text are composed of nine small colored (white) rules (boxes) equally spaced with \hfill. The color of each rule is the same as the textcolor.
% %              \textcolor{color}{text}
% %              \rule[depth]{width}{height}
% %              \null is the same as \hbox{} and it can be used for a material which reserves no space but shows TeX that there is a box which is taken into account for typesetting (Herbert: http://tex.stackexchange.com/questions/24919/what-is-null-and-when-do-we-need-to-use-it)
% %
% %
% %

\newcommand{\whitebox}{\hfill\textcolor{white}{\rule[1mm]{1.8mm}{2.8mm}}\hfill}

\newcommand{\SetColorForColoredSmallBoxes}[1]{%
\def\ColoredSmallBox{\hfill\textcolor{#1}{\rule[1mm]{1.8mm}{2.8mm}}\hfill}}

\SetColorForColoredSmallBoxes{red}

\newcommand{\filmbox}[1]{%  ( Jonas Granholm )
    \setlength{\fboxsep}{0pt}%
    \colorbox{black}{%
        \begin{minipage}{3.2cm}
            \rule{0mm}{4.8mm}\whitebox\whitebox\whitebox\whitebox\whitebox%
            \whitebox\whitebox\whitebox\whitebox\null\\%
            \null\hfill\includegraphics[width=3cm]{#1}\hfill\null\\[1mm]%
            \null\whitebox\whitebox\whitebox\whitebox\whitebox%
            \whitebox\whitebox\whitebox\whitebox\null
        \end{minipage}}}

\newcommand{\filmboxClipImage}[1]{%
    \setlength{\fboxsep}{0pt}%
    \colorbox{black}{%
        \begin{minipage}{3.2cm}
            \rule{0mm}{4.8mm}%
            \ColoredSmallBox\whitebox\ColoredSmallBox\whitebox\ColoredSmallBox
            \whitebox\ColoredSmallBox\whitebox\ColoredSmallBox\null\\%
            \null\hfill\ClipImage{3cm}{3cm}{#1}\hfill\null\\[1mm]%
            \null\whitebox\whitebox\whitebox\whitebox\whitebox%
            \whitebox\whitebox\whitebox\whitebox\null
        \end{minipage}}}

\begin{document}

\noindent
\filmbox{First-rectangle}\filmbox{Second-rectangle}\filmbox{Third-rectangle}\\

\noindent
\filmboxClipImage{First-rectangle}\filmboxClipImage{Second-rectangle}\filmboxClipImage{Third-rectangle}\\

\end{document}
