\begin{tikzpicture}
\coordinate (1) at (0,0);
\coordinate (2) at (2,0);
\coordinate (3) at (2,2);
\coordinate (4) at (0,2);
\coordinate (5) at (0,0);
\coordinate (6) at ($(1)!.5!(2)$);
\coordinate (7) at ($(2)!.5!(3)$);
\coordinate (8) at ($(3)!.5!(4)$);
\coordinate (9) at ($(4)!.5!(1)$);
\foreach \i in {1,2}
\fill (\i) circle (1pt) node [below] {\tiny \i};
\foreach \i in {3,4}
\fill (\i) circle (1pt) node [above] {\tiny \i};
\foreach \i in {6}
\fill (\i) circle (1pt) node [below] {\tiny 5};
\foreach \i in {7}
\fill (\i) circle (1pt) node [right] {\tiny 6};
\foreach \i in {8}
\fill (\i) circle (1pt) node [above] {\tiny 7};
\foreach \i in {9}
\fill (\i) circle (1pt) node [left] {\tiny 8};
\draw (1)--(2)--(3)--(4)--(5);
\end{tikzpicture}
上記の右側の正方形のコードでは、左側の正方形のポイント(9)で示される中間点を作成したいのですが?
答え1
点 の中間点は を(9)
介して計算できます。これはパス形式からへの(1)!0.5!(3)
点を表します。これを 1 つの に縮小することもできます。0.5
(1)
(3)
\foreach
コード:
documentclass{article}
\usepackage{tikz}
\usetikzlibrary{calc}
\begin{document}
\begin{tikzpicture}
\coordinate (1) at (0,0);
\coordinate (2) at (2,0);
\coordinate (3) at (2,2);
\coordinate (4) at (0,2);
\coordinate (5) at ($(1)!.5!(2)$);
\coordinate (6) at ($(2)!.5!(3)$);
\coordinate (7) at ($(3)!.5!(4)$);
\coordinate (8) at ($(1)!.5!(4)$);
\coordinate (9) at ($(1)!.5!(3)$);
\foreach \i/\Position in {1/below, 2/below, 3/above, 4/above, 5/below, 6/right, 7/above, 8/left, 9/above right} {
\fill (\i) circle (1pt) node [\Position] {\tiny \i};
}
\draw (1)--(2)--(3)--(4)-- cycle;
\end{tikzpicture}
\end{document}
答え2
直交座標を使用することもできます。
\coordinate (9) at (8-|5); %%% <--- new
(8-|5)
y
は、ノードと同じ - 座標(8)
とノードと同じ x 座標を取ることを意味します(5)。
また、\foreach
ループを改良することもできます。
\documentclass[tikz,varwidth]{standalone}%
\usetikzlibrary{calc,positioning}
\begin{document}
\begin{tikzpicture}
\coordinate (1) at (0,0);
\coordinate (2) at (2,0);
\coordinate (3) at (2,2);
\coordinate (4) at (0,2);
\coordinate (5) at ($(1)!.5!(2)$);
\coordinate (6) at ($(2)!.5!(3)$);
\coordinate (7) at ($(3)!.5!(4)$);
\coordinate (8) at ($(4)!.5!(1)$);
\coordinate (9) at (8-|5); %%% <--- new
\foreach \i/\position in {1/below,2/below,3/above,4/above,5/below,6/right,7/above,8/left,9/above right}
\fill (\i) circle (1pt) node [\position] {\tiny \i};
\draw (1)--(2)--(3)--(4)--cycle;
\end{tikzpicture}
\end{document}
もう 1 つの簡単な方法は、長方形ノードを使用することです。
\documentclass[tikz,varwidth]{standalone}%
\usetikzlibrary{calc,positioning}
\begin{document}
\begin{tikzpicture}
\node[draw,minimum height=2cm,minimum width=2cm] (a) at (1,1) {};
\foreach \i/\a/\position in
{south west/1/below,south east/2/below,north east/3/above,north west/4/above,
south/5/below,east/6/right,north/7/above,west/8/left,center/9/above right} {%
\fill (a.\i) circle (1pt) node [\position] {\tiny \a};
}
\end{tikzpicture}
\end{document}
