\subsection{Checksum: Factor, Specific, and Total Variance}
Perhaps the most basic test of a regression model is if the factor and specific variances sum to equal the total variance. Here, we
present this diagnostic as an xy-plot, with the sum of factor and specific variance on the x-axis and the total variance on the y-axis. We
expect the plotted points to line up tightly along the identity line.
\clearpage
\begin{figure}[!h]
\centering
\includegraphics{\Sexpr{image_dir}xyplotFacSpecTotVarTest.pdf}
\caption{Total Variance vs. Sum of Factor and Specific Variance, All Instruments Passing Exposure Model.}
\end{figure}
質問:
「xyplotFacSpecTotVarTest.pdf」が存在しない状況をどのように処理すればよいでしょうか。ファイルはテーブルの内容から生成されますが、データが含まれている場合と含まれていない場合があります。「xyplotFacSpecTotVarTest.pdf」がない場合、最終的な PDF 生成プロセスでエラーが発生します。このシナリオをどのように処理すればよいでしょうか。/IfFileExist を試しましたが、機能していないようです。次の実装を参照してください。
\IfFileExists{{image_dir}{xyplotFacSpecTotVarTest.pdf}} {
\clearpage
\begin{figure}[!h]
\centering
\includegraphics{\Sexpr{image_dir}{xyplotFacSpecTotVarTest.pdf}}
\typeout{File Exist: xyplotFacSpecTotVarTest.pdf}
\caption{Total Variance vs. Sum of Factor and Specific Variance, All Instruments Passing Exposure Model.}
\end{figure} }
{\typeout{File DOESNT Exist: xyplotFacSpecTotVarTest.pdf}}
答え1
タグを見ると、 を使用していると思いますknitr
。ファイルが存在するかどうかを R 自体に (黙って) 判断させないのはなぜでしょうか?
<<chunkname,results='asis',echo=FALSE>>=
if (file.exists(file.path(image_dir, "xyplotFacSpecTotVarTest.pdf"))) {
cat("\\clearpage\n")
cat("\\begin{figure}[!h]\n")
# and so on
}
else {
cat("\\textbf{File does not exist.}\n\n")
}
@
chunk オプションに注意してくださいresults='asis'
。'd された各文字列は、そのままファイルcat
に出力されます(オプションの名前の由来)。言い換えると、 'd された各文字列は、コンパイルされる LaTeX コマンドになります。.tex
cat
たとえば、 という高度な R 関数を作成して上記のコードを一般化しinclude_if_exists(filename)
、それを多くのチャンクで再利用することもできます。
