私は、Dias & Vermunt 2007 の図 2 で説明されているように、マルコフ マップを作成しようとしています。http://members.home.nl/jeroenvermunt/dias2006c.pdf
図は次のとおりです。
これまで私はTiのグリッドを使ってみましたけZ はグラデーションカラーには機能していますが、州名を追加できないようです。テーブルでも試してみましたが、この結果は見栄えがよくありません (非常に乱雑で、セルのサイズが異なります)。
（初めてなので、正しく行われていることを願っています！）
ヘッダー名を追加して素敵なマップを作成する方法を知っている人はいますか?
どうもありがとう！
コメントに返信する方法がわかりません。だからこうします。Tiのマトリックスライブラリけz は非常にうまく機能します (コメントに投稿された結果を確認できます)。ただし、22 * 22 行列に拡張すると、エラーが表示されます。
ほぼすべての段落で \hbox がいっぱいです...
サイズ、最小幅、テキスト幅を変更してみましたが、効果はありませんでした。これらの測定値の意味と修正方法を説明していただけますか? 改めて感謝いたします!
隣り合うマルコフ マップをいくつか必要としていますが、下の 2 つのマップの位置が異なるため、配置がうまくいきません。この問題を解決する方法を誰か知っていますか?
\begin{figure}[tb]
\subcaptionbox{Cluster 1, $\pi_1 = 0.18$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=30mm, text width=28mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{ \& AC \& CH \& DP \& HP \& IA \& LB \& LP \& NL \& SC \& show\_discount\_reminder \& show\_funnel\_campaign \& show\_recc \& show\_recp \& show\_upsell \& show\_wijnatlas \& WV \& XT \\
AC \& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 45 ]|\& |[fill=black! 6 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 37 ]|\& |[fill=black! 0 ]|\& |[fill=black! 3 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 5 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
XT \& |[fill=black! 8 ]|\& |[fill=black! 0 ]|\& |[fill=black! 17 ]|\& |[fill=black! 17 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 25 ]|\& |[fill=black! 0 ]|\& |[fill=black! 13 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 17 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 2, $\pi_2 = 0.16$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
%column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{ AC \& CH \& DP \& HP \& IA \& LB \& LP \& NL \& SC \& show\_discount\_reminder \& show\_funnel\_campaign \& show\_recc \& show\_recp \& show\_upsell \& show\_wijnatlas \& WV \& XT \\
|[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 17 ]|\& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 79 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
|[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 14 ]|\& |[fill=black! 3 ]|\& |[fill=black! 0 ]|\& |[fill=black! 49 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 33 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 3, $\pi_3 = 0.23$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
%row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=30mm, text width=28mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{AC \& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 40 ]|\& |[fill=black! 10 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 40 ]|\& |[fill=black! 0 ]|\& |[fill=black! 7 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
XT \& |[fill=black! 4 ]|\& |[fill=black! 0 ]|\& |[fill=black! 18 ]|\& |[fill=black! 19 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 25 ]|\& |[fill=black! 1 ]|\& |[fill=black! 20 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 9 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 4, $\pi_4 = 0.13$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
%row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
%column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{ |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 71 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 6 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 21 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
|[fill=black! 3 ]|\& |[fill=black! 0 ]|\& |[fill=black! 16 ]|\& |[fill=black! 11 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 19 ]|\& |[fill=black! 0 ]|\& |[fill=black! 6 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 40 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 5, $\pi_5 = 0.17$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
%row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{AC \& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 17 ]|\& |[fill=black! 4 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 76 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
XT \& |[fill=black! 4 ]|\& |[fill=black! 0 ]|\& |[fill=black! 9 ]|\& |[fill=black! 28 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 29 ]|\& |[fill=black! 0 ]|\& |[fill=black! 13 ]|\& |[fill=black! 0 ]|\& |[fill=black! 3 ]|\& |[fill=black! 2 ]|\& |[fill=black! 0 ]|\& |[fill=black! 5 ]|\& |[fill=black! 8 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\subcaptionbox{Cluster 6, $\pi_6 = 0.12$}{
\begin{tikzpicture}[font=\ttfamily, ampersand replacement=\&]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
%row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
%column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=right}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{ |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 40 ]|\& |[fill=black! 6 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 18 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 33 ]|\& |[fill=black! 0 ]|\& |[fill=black! 1 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
|[fill=black! 7 ]|\& |[fill=black! 1 ]|\& |[fill=black! 8 ]|\& |[fill=black! 29 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\& |[fill=black! 19 ]|\& |[fill=black! 0 ]|\& |[fill=black! 10 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 15 ]|\& |[fill=black! 0 ]|\& |[fill=black! 2 ]|\& |[fill=black! 7 ]|\& |[fill=black! 0 ]|\& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
}
\label{TP_userS6}
\caption{Transition probabilities of user data (ADJ) using MMM}
\end{figure}
答え1
次を使用できますmatrix:
\documentclass[tikz,border=2mm]{standalone}
\usetikzlibrary{matrix}
\begin{document}
\begin{tikzpicture}[font=\sffamily\tiny]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=12mm, text width=10mm, align=left}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{
& frontpage & news & tech \\
frontpage & |[fill=red]| & |[fill=orange]| & \\
news & & |[fill=red!70!black]| & \\
tech & & |[fill=yellow]| & |[fill=red!70!black]| \\
};
\end{tikzpicture}
\end{document}
アップデート：
22x22行列の問題は、そのサイズではなく、最初の列のノードのサイズにあります。前の例では、次のように定義されていました。
column 1/.style={nodes={draw=none, minimum width=12mm, text width=10mm, align=left}},
このサイズでは、 に適合しますfrontpageが、 には適合しませんshow\_discount\_reminer。列 1 のノードをこれらの長い単語に対応できるほど長く宣言すると、 に関するすべてのメッセージoverfull horizontal boxが消えます。
\documentclass{article}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage{lmodern}
\usepackage{tikz}
\usetikzlibrary{matrix}
\usepackage{lipsum}
\begin{document}
\lipsum[1]
\begin{figure}[tb]
\begin{tikzpicture}[font=\itshape]
\matrix (A) [nodes in empty cells,
matrix of nodes,
nodes={draw, minimum size=3mm, inner sep=0pt, outer sep=0pt, anchor=center},
row 1/.style={nodes={draw=none, rotate=90, anchor=west, inner xsep=1mm}},
column 1/.style={nodes={draw=none, minimum width=43mm, text width=40mm, align=left}},
column sep=-\pgflinewidth,
row sep=-\pgflinewidth
]
{
& AC & ACRC & CH & DP & HP & IA & infl\_discount\_reminder & infl\_funnel\_campaign & infl\_upsell & infl\_wijnatlas & LB & LP & NL & SC & show\_discount\_reminder & show\_funnel\_campaign & show\_recc & show\_recp & show\_upsell & show\_wijnatlas & WV & XT \\
AC & |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 39 ]|& |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 43 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 8 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
ACRC & |[fill=black! 40 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 20 ]|& |[fill=black! 20 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 20 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
CH & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 18 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 30 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 22 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 22 ]|\\
DP & |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 17 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 8 ]|& |[fill=black! 0 ]|& |[fill=black! 9 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 52 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|\\
HP & |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 7 ]|& |[fill=black! 49 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 18 ]|& |[fill=black! 0 ]|& |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 13 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 3 ]|\\
IA & |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 14 ]|& |[fill=black! 14 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 18 ]|& |[fill=black! 1 ]|& |[fill=black! 25 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|\\
infl\_discount\_reminder & |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 6 ]|& |[fill=black! 2 ]|& |[fill=black! 2 ]|& |[fill=black! 30 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 33 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|\\
infl\_funnel\_campaign & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 27 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 48 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 22 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|\\
infl\_upsell & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 64 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 36 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
infl\_wijnatlas & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 64 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 27 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 9 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
LB & |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 13 ]|& |[fill=black! 22 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 32 ]|& |[fill=black! 0 ]|& |[fill=black! 8 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 14 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
LP & |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 8 ]|& |[fill=black! 4 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 36 ]|& |[fill=black! 0 ]|& |[fill=black! 8 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 18 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 15 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|\\
NL & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|& |[fill=black! 5 ]|& |[fill=black! 81 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|\\
SC & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 9 ]|& |[fill=black! 2 ]|& |[fill=black! 1 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 4 ]|& |[fill=black! 0 ]|& |[fill=black! 47 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 23 ]|& |[fill=black! 0 ]|& |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|\\
show\_discount\_reminder & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 82 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 7 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|\\
show\_funnel\_campaign & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 81 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|\\
show\_recc & |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 11 ]|& |[fill=black! 4 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 13 ]|& |[fill=black! 0 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 34 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|& |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|\\
show\_recp & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 50 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 50 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
show\_upsell & |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 6 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 4 ]|& |[fill=black! 0 ]|& |[fill=black! 45 ]|& |[fill=black! 1 ]|& |[fill=black! 3 ]|& |[fill=black! 32 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 2 ]|\\
show\_wijnatlas & |[fill=black! 10 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 12 ]|& |[fill=black! 3 ]|& |[fill=black! 1 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 43 ]|& |[fill=black! 0 ]|& |[fill=black! 7 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 21 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|\\
WV & |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 9 ]|& |[fill=black! 33 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 24 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 10 ]|& |[fill=black! 3 ]|\\
XT & |[fill=black! 5 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 15 ]|& |[fill=black! 19 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|& |[fill=black! 25 ]|& |[fill=black! 0 ]|& |[fill=black! 15 ]|& |[fill=black! 0 ]|& |[fill=black! 1 ]|& |[fill=black! 14 ]|& |[fill=black! 0 ]|& |[fill=black! 3 ]|& |[fill=black! 2 ]|& |[fill=black! 0 ]|& |[fill=black! 0 ]|\\
};
\end{tikzpicture}
\caption{Markov map aggregated data (S=1).}
\end{figure}
\end{document}
答え2
質問で提案されたアプローチに似たアプローチは次のとおりです。2 つのループを使用して列と行にラベルを付け、次に\fill選択したセルにラベルを付け、最後にグリッドを使用します。グリッドは最後のステップとして描画されるため、グリッドの線は塗りつぶされたセルの端を覆います。
\documentclass [border=2mm]{standalone}
\usepackage{graphicx}
\usepackage{tikz}
\begin{document}
\begin{tikzpicture}[scale=0.4]
% Put column headers
\foreach \header [count=\c] in {Lorem, ipsum, dolor, sit, amet, consectetur, adipiscing, elit, Proin, vulputate, dignissim, odio, eu, euismod, sapien, sodales, eu, Curabitur, ipsum, nibh, dictum, eu} {
\node[above] at (\c-0.5,22) {\rotatebox{90}{\small\sffamily\header}};
}
% Put row headers
\foreach \header [count=\c] in {Lorem, ipsum, dolor, sit, amet, consectetur, adipiscing, elit, Proin, vulputate, dignissim, odio, eu, euismod, sapien, sodales, eu, Curabitur, ipsum, nibh, dictum, eu} {
\node[left] at (0,22-\c+0.5) {\small\sffamily\header};
}
% Fill some squares
\fill[black!10] (0,21) rectangle +(1,1); % Use relative coordinates for the rectangle size
\fill[black!30] (1,20) rectangle +(1,1); % Use relative coordinates for the rectangle size
% Finally, the grid
\draw[black, very thin] (0,0) grid (22,22);
\end{tikzpicture}
\end{document}
結果：
