中括弧で囲まれた表

表を中括弧で囲みたいと思います。ここに例を Photoshop で作成しました: 表の中括弧

表のMWEはこちらです、パッケージ等はご自由に追加して下さい。

`

\documentclass[11pt]{article}

\begin{document}

\begin{table}[]
\centering
\scriptsize
\renewcommand{\arraystretch}{1.5}
\begin{tabular}{p{3cm} p{0.7cm} p{8cm}}

$D_{1}~Value Proposition$ & D1 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
$D_{2}~Value Proposition$ & D1 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
\end{tabular}
\end{table}

\end{document}

`

答え1

このようなもの？

\documentclass{article}
\usepackage{amsmath,array}
\usepackage[a4paper,left=2cm,right=2cm]{geometry}

\newcommand{\verysloppy}{\tolerance=2000 \hbadness=2000 \emergencystretch=\linewidth}

\begin{document}

\begin{equation*}
\mathrm{Taxonomy}_1=
\begin{Bmatrix}
\mbox{%
  \renewcommand{\arraystretch}{1.3}%
  \footnotesize
  \begin{tabular}{@{} >{$}l<{$} l >{$}r<{{}$} @{} >{\verysloppy}p{8cm}@{}}
  D_{1} & Value Proposition & D_1 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
  D_{2} & Value Proposition & D_2 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
  D_{3} & Value Proposition & D_3 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
  D_{4} & Value Proposition & D_4 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
  D_{5} & Value Proposition & D_5 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
  D_{6} & Value Proposition & D_6 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
  \end{tabular}%
}
\end{Bmatrix}
\end{equation*}

\end{document}

ここに画像の説明を入力してください

答え2

次のように表形式を数式環境内に配置し、と を\[\]使用します。\left\{\right\}

\documentclass[11pt]{article}

\begin{document}

\begin{table}[!htb]
\centering
\scriptsize
\renewcommand{\arraystretch}{1.5}

\[\left\{\begin{tabular}{p{3cm} p{0.7cm} p{8cm}}

$D_{1}~Value Proposition$ & D1 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
$D_{2}~Value Proposition$ & D1 = & \{C1,7 Blockchain, C1,8 Digital Platform, C1,9 Decision Support System,,C1,10 Marketplace, C1,11 Database, C1,12 Transaction Processing, System\} \\
\end{tabular}\right\}\]
\end{table}

\end{document}

編集：を追加し\text{Taxonomy=}、長い行を手動で分割しました。

\documentclass[11pt]{article}
\usepackage{lipsum}
\usepackage{amsmath}
\begin{document}

\lipsum[1]

\begingroup
\centering
\scriptsize
\renewcommand{\arraystretch}{1.5}

\[\text{Taxonomy=}\left\{\begin{tabular}{p{3cm} p{0.7cm} l}

$D_{1}$~\emph{Value Proposition} & D1 = & \{C1,7 Blockchain, C1,8 Digital Platform,\\ &&C1,9 Decision Support System,,\\&&C1,10 Marketplace, C1,11 Database,\\&& C1,12 Transaction Processing, System\} \\
$D_{2}$~\emph{Value Proposition} & D1 = & \{C1,7 Blockchain, C1,8 Digital Platform,\\ &&C1,9 Decision Support System,,\\&&C1,10 Marketplace, C1,11 Database,\\&& C1,12 Transaction Processing, System\} \\
\end{tabular}\right\}\]
\endgroup

\end{document}
