定数 pool_size が 350000 に設定されているときに、TeX initex エラー「TeX の容量を超えました。申し訳ありません [プール サイズ = 8563]」が発生しました。どうすればいいですか?

Question

注意: このTeXはウェブ2js Jim Fowler の WEB/TeX Pascal から WebAssembly へのコンパイラ。

これは次の質問に対するフォローアップですTeX (または WEB) コマンドで WEB 定数を出力することは可能ですか?。

lplain.loglplain 形式をダンプしようとすると、このエラーが発生します。

This is TeX, Version 3.14159265 (INITEX)  4 JUL 1776 12:00
**lplain.tex \dump
(lplain.tex Preloading the plain format: codes, registers,!
...
TeX capacity exceeded, sorry [pool size=8563].
l.4015 \let\
            @accii=\`
If you really absolutely need more capacity,
you can ask a wizard to enlarge me.

ただし、pool_size 定数は 350000 (デフォルト値: 32000) に設定されています。

私が使用した tex.sys は次のとおりです (tex.ch は使用していません)。

eTeX compatible constants for web2js

@x
@<Constants...@>=
@!mem_max=30000; {greatest index in \TeX's internal |mem| array;
  must be strictly less than |max_halfword|;
  must be equal to |mem_top| in \.{INITEX}, otherwise |>=mem_top|}
@!mem_min=0; {smallest index in \TeX's internal |mem| array;
  must be |min_halfword| or more;
  must be equal to |mem_bot| in \.{INITEX}, otherwise |<=mem_bot|}
@!buf_size=500; {maximum number of characters simultaneously present in
  current lines of open files and in control sequences between
  \.{\\csname} and \.{\\endcsname}; must not exceed |max_halfword|}
@!error_line=72; {width of context lines on terminal error messages}
@!half_error_line=42; {width of first lines of contexts in terminal
  error messages; should be between 30 and |error_line-15|}
@!max_print_line=79; {width of longest text lines output; should be at least 60}
@!stack_size=200; {maximum number of simultaneous input sources}
@!max_in_open=6; {maximum number of input files and error insertions that
  can be going on simultaneously}
@!font_max=75; {maximum internal font number; must not exceed |max_quarterword|
  and must be at most |font_base+256|}
@!font_mem_size=20000; {number of words of |font_info| for all fonts}
@!param_size=60; {maximum number of simultaneous macro parameters}
@!nest_size=40; {maximum number of semantic levels simultaneously active}
@!max_strings=3000; {maximum number of strings; must not exceed |max_halfword|}
@!string_vacancies=8000; {the minimum number of characters that should be
  available for the user's control sequences and font names,
  after \TeX's own error messages are stored}
@!pool_size=32000; {maximum number of characters in strings, including all
  error messages and help texts, and the names of all fonts and
  control sequences; must exceed |string_vacancies| by the total
  length of \TeX's own strings, which is currently about 23000}
@!save_size=600; {space for saving values outside of current group; must be
  at most |max_halfword|}
@!trie_size=8000; {space for hyphenation patterns; should be larger for
  \.{INITEX} than it is in production versions of \TeX}
@!trie_op_size=500; {space for ``opcodes'' in the hyphenation patterns}
@!dvi_buf_size=800; {size of the output buffer; must be a multiple of 8}
@!file_name_size=40; {file names shouldn't be longer than this}
@!pool_name='TeXformats:TEX.POOL                     ';
  {string of length |file_name_size|; tells where the string pool appears}
@.TeXformats@>

@ Like the preceding parameters, the following quantities can be changed
at compile time to extend or reduce \TeX's capacity. But if they are changed,
it is necessary to rerun the initialization program \.{INITEX}
@.INITEX@>
to generate new tables for the production \TeX\ program.
One can't simply make helter-skelter changes to the following constants,
since certain rather complex initialization
numbers are computed from them. They are defined here using
\.{WEB} macros, instead of being put into \PASCAL's |const| list, in order to
emphasize this distinction.

@d mem_bot=0 {smallest index in the |mem| array dumped by \.{INITEX};
  must not be less than |mem_min|}
@d mem_top==30000 {largest index in the |mem| array dumped by \.{INITEX};
  must be substantially larger than |mem_bot|
  and not greater than |mem_max|}
@y
@<Constants...@>=
@!mem_max=200000; {greatest index in \TeX's internal |mem| array;
  must be strictly less than |max_halfword|;
  must be equal to |mem_top| in \.{INITEX}, otherwise |>=mem_top|}
@!mem_min=0; {smallest index in \TeX's internal |mem| array;
  must be |min_halfword| or more;
  must be equal to |mem_bot| in \.{INITEX}, otherwise |<=mem_bot|}
@!buf_size=5000; {maximum number of characters simultaneously present in
  current lines of open files and in control sequences between
  \.{\\csname} and \.{\\endcsname}; must not exceed |max_halfword|}
@!error_line=72; {width of context lines on terminal error messages}
@!half_error_line=42; {width of first lines of contexts in terminal
  error messages; should be between 30 and |error_line-15|}
@!max_print_line=79; {width of longest text lines output; should be at least 60}
@!stack_size=1000; {maximum number of simultaneous input sources}
@!max_in_open=6; {maximum number of input files and error insertions that
  can be going on simultaneously}
@!font_max=75; {maximum internal font number; must not exceed |max_quarterword|
  and must be at most |font_base+256|}
@!font_mem_size=20000; {number of words of |font_info| for all fonts}
@!param_size=60; {maximum number of simultaneous macro parameters}
@!nest_size=40; {maximum number of semantic levels simultaneously active}
@!max_strings=60000; {maximum number of strings; must not exceed |max_halfword|}
@!string_vacancies=300000; {the minimum number of characters that should be
  available for the user's control sequences and font names,
  after \TeX's own error messages are stored}
@!pool_size=350000; {maximum number of characters in strings, including all
  error messages and help texts, and the names of all fonts and
  control sequences; must exceed |string_vacancies| by the total
  length of \TeX's own strings, which is currently about 23000}
@!save_size=600; {space for saving values outside of current group; must be
  at most |max_halfword|}
@!trie_size=8000; {space for hyphenation patterns; should be larger for
  \.{INITEX} than it is in production versions of \TeX}
@!trie_op_size=500; {space for ``opcodes'' in the hyphenation patterns}
@!dvi_buf_size=800; {size of the output buffer; must be a multiple of 8}
@!file_name_size=40; {file names shouldn't be longer than this}
@!pool_name='TeXformats:TEX.POOL                     ';
  {string of length |file_name_size|; tells where the string pool appears}
@.TeXformats@>

@ Like the preceding parameters, the following quantities can be changed
at compile time to extend or reduce \TeX's capacity. But if they are changed,
it is necessary to rerun the initialization program \.{INITEX}
@.INITEX@>
to generate new tables for the production \TeX\ program.
One can't simply make helter-skelter changes to the following constants,
since certain rather complex initialization
numbers are computed from them. They are defined here using
\.{WEB} macros, instead of being put into \PASCAL's |const| list, in order to
emphasize this distinction.

@d mem_bot=0 {smallest index in the |mem| array dumped by \.{INITEX};
  must not be less than |mem_min|}
@d mem_top==200000 {largest index in the |mem| array dumped by \.{INITEX};
  must be substantially larger than |mem_bot|
  and not greater than |mem_max|}
@z

@x
@d min_quarterword=0 {smallest allowable value in a |quarterword|}
@d max_quarterword=255 {largest allowable value in a |quarterword|}
@d min_halfword==0 {smallest allowable value in a |halfword|}
@d max_halfword==65535 {largest allowable value in a |halfword|}
@y
@d min_quarterword=0 {smallest allowable value in a |quarterword|}
@d max_quarterword=255 {largest allowable value in a |quarterword|}
@d min_halfword==0 {smallest allowable value in a |halfword|}
@d max_halfword==16777215 {largest allowable value in a |halfword|}
@z

Answer 1

私は次のことに成功しましたTeX_big.sys:

LaTeX 2.09 などの形式ではlplaint.tex、TeX_big システムは約 350 ページのメモリ、つまり約 1.4 MB のメモリを使用します。

% this is tex_big.sys
% eTeX compatible constants for web2js

% https://www.cv.nrao.edu/~abridle/toolmemo/miktex_manual.pdf
% explanated options from page 30
% global.pages in dt_global.js = 1000

% changes Fr, 02.08.2019 according to mainbody.h


% https://docs.miktex.org/2.9/manual/runtimeparams.html
% ✓ main_memory   =2000000        % /1024/1024 => approx. 2 MB
% ✓ extra_mem_bot =2000000
% ✓ font_mem_size =2000000
% main_memory:        Total words of memory available, for TeX, METAFONT, and MetaPost.
% in DEK terms:       "main memory size" = mem_max+1-mem_min; mem_min must be 0 or more
% extra_mem_bot:      Extra space for large TeX data structures: boxes, glue, breakpoints, et al.
% font_mem_size:      Words of font info available for TeX
% it concerns array sizes!

% https://docs.miktex.org/2.9/manual/texmfdefaults.html
% https://docs.miktex.org/2.9/manual/texdefaults.html
% other default values !!


% ✅ @d max_quarterword =  65535 {largest allowable value in a |quarterword|}
% ✅ @d min_halfword    ==-1073741823 {smallest allowable value in a |halfword|}
% ✅ @d max_halfword    ==1073741823 {largest allowable value in a |halfword|}
% halfword 3FFFFFFF can address 1024 MByte i.e. 1 GB of memory

% - bigger codepage for UTF-8 input (chi-problem)
% Marcel Krüger 26.07.2019 StackExchange TeX
% https://tex.stackexchange.com/a/501647/192681
% UTF-8 bigger codepage

% Marcel Krüger 17.07.2019 StackExchange TeX
% https://tex.stackexchange.com/a/500402/192681



@x
@<Constants...@>=
@!mem_max=30000; {greatest index in \TeX's internal |mem| array;
  must be strictly less than |max_halfword|;
  must be equal to |mem_top| in \.{INITEX}, otherwise |>=mem_top|}
@!mem_min=0; {smallest index in \TeX's internal |mem| array;
  must be |min_halfword| or more;
  must be equal to |mem_bot| in \.{INITEX}, otherwise |<=mem_bot|}
@!buf_size=500; {maximum number of characters simultaneously present in
  current lines of open files and in control sequences between
  \.{\\csname} and \.{\\endcsname}; must not exceed |max_halfword|}
@!error_line=72; {width of context lines on terminal error messages}
@!half_error_line=42; {width of first lines of contexts in terminal
  error messages; should be between 30 and |error_line-15|}
@!max_print_line=79; {width of longest text lines output; should be at least 60}
@!stack_size=200; {maximum number of simultaneous input sources}
@!max_in_open=6; {maximum number of input files and error insertions that
  can be going on simultaneously}
@!font_max=75; {maximum internal font number; must not exceed |max_quarterword|
  and must be at most |font_base+256|}
@!font_mem_size=20000; {number of words of |font_info| for all fonts}
@!param_size=60; {maximum number of simultaneous macro parameters}
@!nest_size=40; {maximum number of semantic levels simultaneously active}
@!max_strings=3000; {maximum number of strings; must not exceed |max_halfword|}
@!string_vacancies=8000; {the minimum number of characters that should be
  available for the user's control sequences and font names,
  after \TeX's own error messages are stored}
@!pool_size=32000; {maximum number of characters in strings, including all
  error messages and help texts, and the names of all fonts and
  control sequences; must exceed |string_vacancies| by the total
  length of \TeX's own strings, which is currently about 23000}
@!save_size=600; {space for saving values outside of current group; must be
  at most |max_halfword|}
@!trie_size=8000; {space for hyphenation patterns; should be larger for
  \.{INITEX} than it is in production versions of \TeX}
@!trie_op_size=500; {space for ``opcodes'' in the hyphenation patterns}
@!dvi_buf_size=800; {size of the output buffer; must be a multiple of 8}
@!file_name_size=40; {file names shouldn't be longer than this}
@!pool_name='TeXformats:TEX.POOL                     ';
  {string of length |file_name_size|; tells where the string pool appears}
@.TeXformats@>

@ Like the preceding parameters, the following quantities can be changed
at compile time to extend or reduce \TeX's capacity. But if they are changed,
it is necessary to rerun the initialization program \.{INITEX}
@.INITEX@>
to generate new tables for the production \TeX\ program.
One can't simply make helter-skelter changes to the following constants,
since certain rather complex initialization
numbers are computed from them. They are defined here using
\.{WEB} macros, instead of being put into \PASCAL's |const| list, in order to
emphasize this distinction.

@d mem_bot=0 {smallest index in the |mem| array dumped by \.{INITEX};
  must not be less than |mem_min|}
@d mem_top==30000 {largest index in the |mem| array dumped by \.{INITEX};
  must be substantially larger than |mem_bot|
  and not greater than |mem_max|}
@y
@<Constants...@>=
@!mem_max=2000000; {greatest index in \TeX's internal |mem| array;
  must be strictly less than |max_halfword|;
  must be equal to |mem_top| in \.{INITEX}, otherwise |>=mem_top|}
@!mem_min=0; {smallest index in \TeX's internal |mem| array;
  must be |min_halfword| or more;
  must be equal to |mem_bot| in \.{INITEX}, otherwise |<=mem_bot|}
@!buf_size=5000; {maximum number of characters simultaneously present in
  current lines of open files and in control sequences between
  \.{\\csname} and \.{\\endcsname}; must not exceed |max_halfword|}
@!error_line=72; {width of context lines on terminal error messages}
@!half_error_line=42; {width of first lines of contexts in terminal
  error messages; should be between 30 and |error_line-15|}
@!max_print_line=79; {width of longest text lines output; should be at least 60}
@!stack_size=1000; {maximum number of simultaneous input sources}
@!max_in_open=6; {maximum number of input files and error insertions that
  can be going on simultaneously}
@!font_max=75; {maximum internal font number; must not exceed |max_quarterword|
  and must be at most |font_base+256|}
@!font_mem_size=2000000; {number of words of |font_info| for all fonts}
@!param_size=60; {maximum number of simultaneous macro parameters}
@!nest_size=40; {maximum number of semantic levels simultaneously active}
@!max_strings=60000; {maximum number of strings; must not exceed |max_halfword|}
@!string_vacancies=300000; {the minimum number of characters that should be
  available for the user's control sequences and font names,
  after \TeX's own error messages are stored}
@!pool_size=350000; {maximum number of characters in strings, including all
  error messages and help texts, and the names of all fonts and
  control sequences; must exceed |string_vacancies| by the total
  length of \TeX's own strings, which is currently about 23000}
@!save_size=600; {space for saving values outside of current group; must be
  at most |max_halfword|}
@!trie_size=8000; {space for hyphenation patterns; should be larger for
  \.{INITEX} than it is in production versions of \TeX}
@!trie_op_size=500; {space for ``opcodes'' in the hyphenation patterns}
@!dvi_buf_size=800; {size of the output buffer; must be a multiple of 8}
@!file_name_size=40; {file names shouldn't be longer than this}
@!pool_name='TeXformats:TEX.POOL                     ';
  {string of length |file_name_size|; tells where the string pool appears}
@.TeXformats@>

@ Like the preceding parameters, the following quantities can be changed
at compile time to extend or reduce \TeX's capacity. But if they are changed,
it is necessary to rerun the initialization program \.{INITEX}
@.INITEX@>
to generate new tables for the production \TeX\ program.
One can't simply make helter-skelter changes to the following constants,
since certain rather complex initialization
numbers are computed from them. They are defined here using
\.{WEB} macros, instead of being put into \PASCAL's |const| list, in order to
emphasize this distinction.

@d mem_bot=0 {smallest index in the |mem| array dumped by \.{INITEX};
  must not be less than |mem_min|}
@d mem_top==2000000 {largest index in the |mem| array dumped by \.{INITEX};
  must be substantially larger than |mem_bot|
  and not greater than |mem_max|}
@z


@x
for i:=0 to @'37 do xchr[i]:=' ';
for i:=@'177 to @'377 do xchr[i]:=' ';
@y
for i:=0 to @'37 do xchr[i]:=chr(i);
for i:=@'177 to @'377 do xchr[i]:=chr(i);
@z



@x
@d min_quarterword=0 {smallest allowable value in a |quarterword|}
@d max_quarterword=255 {largest allowable value in a |quarterword|}
@d min_halfword==0 {smallest allowable value in a |halfword|}
@d max_halfword==65535 {largest allowable value in a |halfword|}
@y
@d min_quarterword=0 {smallest allowable value in a |quarterword|}
@d max_quarterword=65535 {largest allowable value in a |quarterword|}
@d min_halfword==-1073741823 {smallest allowable value in a |halfword|}
@d max_halfword==1073741823 {largest allowable value in a |halfword|}
@z
