奇数を表示する

Question

奇数を表示するにはどうすればいいですかxticklabels?

コード:

\documentclass[margin=3mm]{standalone}
\usepackage[english,spanish]{babel}         % multilenguaje
\usepackage{pgfplots}
\usetikzlibrary{babel,
    positioning}
\pgfplotsset{compat=1.16,width=0.98\linewidth}



\usepackage{filecontents}
\begin{filecontents}{performance.data}
    x    A       B         C        D        E         F
    0.01 0.9126  0.9126   0.9313   0.9494   0.9524   0.9462
    0.02 0.8872  0.8872   0.8980   0.9044   0.9014   0.8966
    0.03 0.8713  0.8713   0.8747   0.8767   0.8737   0.8722
    0.05 0.8549  0.8549   0.8552   0.8541   0.8538   0.8532
    0.09 0.8710  0.8710   0.8700   0.8687   0.8676   0.8667
    0.10 0.8782  0.8782   0.8771   0.8751   0.8740   0.8738
    0.20 0.9301  0.9301   0.9281   0.9275   0.9269   0.9271
\end{filecontents}
\decimalpoint


\begin{document}
    \begin{tikzpicture}
    \begin{axis}[
    grid = none,
    legend style={at={(0.97,0.03)}, anchor=south east, draw=black},
%   legend cell align=left,
%   legend pos=north east,
    xmin=0.000499999999999999, xmax=0.2095,
    ylabel={RMSE},
    xlabel={$\lambda$},
    %
    xticklabel style={font=\small,
        /pgf/number format/fixed},
    yticklabel style={font=\small},
    %
    every axis plot post/.append style={line width=1.2pt},
    %
    mark size=1.3pt,
    cycle list={
        {blue,mark=*},
        {black,mark=*},
        {red,mark=*},
        {green,mark=*},
        {orange,mark=*},
        {cyan,mark=*},% <-- don't add a comma here
    },
    ]
    \addplot    table [y=A] {performance.data};
    \addlegendentry{20 f}
    \addplot    table [y=B] {performance.data};
    \addlegendentry{40 f}
    \addplot    table [y=C] {performance.data};
    \addlegendentry{60 f}
    \addplot    table [y=D] {performance.data};
    \addlegendentry{100 f}
    \addplot    table [y=E] {performance.data};
    \addlegendentry{150 f}
    \addplot    table [y=F] {performance.data};
    \addlegendentry{200 f}
    \end{axis}
    \end{tikzpicture}
\end{document}

Answer 1

コメントを回答に変換しています。

次のように手動で指定できますxticks。

xtick={0.01,0.03,...,0.20},

奇数目盛りのみが表示されるようになります。

結果：

\documentclass[margin=3mm]{standalone}
\usepackage[english,spanish]{babel}         % multilenguaje
\usepackage{pgfplots}
\usetikzlibrary{babel,positioning}
\pgfplotsset{compat=1.16,width=0.98\linewidth}
\usepackage{filecontents}
\begin{filecontents}{performance.data}
    x    A       B         C        D        E         F
    0.01 0.9126  0.9126   0.9313   0.9494   0.9524   0.9462
    0.02 0.8872  0.8872   0.8980   0.9044   0.9014   0.8966
    0.03 0.8713  0.8713   0.8747   0.8767   0.8737   0.8722
    0.05 0.8549  0.8549   0.8552   0.8541   0.8538   0.8532
    0.09 0.8710  0.8710   0.8700   0.8687   0.8676   0.8667
    0.10 0.8782  0.8782   0.8771   0.8751   0.8740   0.8738
    0.20 0.9301  0.9301   0.9281   0.9275   0.9269   0.9271
\end{filecontents}
\decimalpoint


\begin{document}
    \begin{tikzpicture}
    \begin{axis}[
    grid = none,
    legend style={at={(0.97,0.03)}, anchor=south east, draw=black},
%   legend cell align=left,
%   legend pos=north east,
    xmin=0.000499999999999999, xmax=0.2095,
    ylabel={RMSE},
    xlabel={$\lambda$},
    %
    xtick={0.01,0.03,...,0.20},
    xticklabel style={font=\small,
        /pgf/number format/fixed},
    yticklabel style={font=\small},
    %
    every axis plot post/.append style={line width=1.2pt},
    %
    mark size=1.3pt,
    cycle list={
        {blue,mark=*},
        {black,mark=*},
        {red,mark=*},
        {green,mark=*},
        {orange,mark=*},
        {cyan,mark=*},% <-- don't add a comma here
    },
    ]
    \addplot    table [y=A] {performance.data};
    \addlegendentry{20 f}
    \addplot    table [y=B] {performance.data};
    \addlegendentry{40 f}
    \addplot    table [y=C] {performance.data};
    \addlegendentry{60 f}
    \addplot    table [y=D] {performance.data};
    \addlegendentry{100 f}
    \addplot    table [y=E] {performance.data};
    \addlegendentry{150 f}
    \addplot    table [y=F] {performance.data};
    \addlegendentry{200 f}
    \end{axis}
    \end{tikzpicture}
\end{document}
