表: 2つの列の値を一列に揃える

長い文書を書いていて、ようやく作業計画を表にまとめられるところまで来ました。今度は、各アクティビティのタイムラインを設定して、対応するタスクに合わせたいと思います。

以下のMSE:

\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage{booktabs}
\usepackage{floatrow}
\usepackage{tabularx}

\begin{document}

\begin{table}[h]
        \caption{Table of activities}
        \label{tblactivity}
        \centering
        \begin{tabular}{lccc}
            \toprule
             \textbf{No.} & \textbf{Activity}   & \textbf{Task(s) to be completed}  &
              \textbf{Timeline}\\
            \midrule
              \textbf{1} &\multicolumn{1}{m{3cm}}{\textbf{\textit{Activity number 1}}} & \multicolumn{1}{m{7cm}}{ \begin{enumerate}
                  \item Some long sentence here, describing task 1 of activity 1
                  \item Another long sentence here, describing task 2 of activity 1
                  \item Yet another long sentence here, describing task 3 of activity 1
                  \item Activity 1 task 4 ...
              \end{enumerate} } &
                  \\
              \midrule
              \textbf{2} &  \multicolumn{1}{m{3cm}}{\textbf{\textit{Activity number 2}}} & \multicolumn{1}{m{7cm}}{ \begin{enumerate}
                  \item Activity 2 task 1
                  \item Activity 2 task 2
                  \item Activity 2 task 3
              \end{enumerate} } \\

        \bottomrule
        \end{tabular}
         \hfill
\end{table}

\end{document}

ここに画像の説明を入力してください

アクティビティ 1 の各タスク 1、2、3、4 (たとえば、2 か月、2 か月、1 か月、1 か月) について、時間がタスクと一致するように期限を設定します。アクティビティ 2 なども同様です。

答え1

期限をタスクに合わせる最も簡単な方法は、環境を使用せずenumerate、各タスクをテーブル内の別のセルに配置することです。この方法により、各期限を対応するタスクに適切に合わせた独自のセルに簡単に配置できます。

\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage{booktabs}
\usepackage{floatrow}
\usepackage{tabularx}
\usepackage{multirow}

\begin{document}

\begin{table}[h]
        \caption{Table of activities}
        \label{tblactivity}
        \centering
        \begin{tabular}{llp{1mm}p{6cm}p{2cm}}
            \toprule
             \textbf{No.} & \multicolumn{1}{c}{\textbf{Activity}} && \textbf{Task(s) to be completed}  &
              \textbf{Timeline}\\
            \midrule
              \multirow{7}{*}{\textbf{1}} & \multirow{7}{*}{\textbf{\textit{Activity number 1}}}
                & 1. & Some long sentence here, describing task 1 of activity 1 & Deadline 1 \\
                && 2. & Another long sentence here, describing task 2 of activity 1 & Deadline 2 \\
                && 3. & Yet another long sentence here, describing task 3 of activity 1 & Deadline 3 \\
                && 4. & Activity 1 task 4 & Deadline 4 \\
              \midrule
              \multirow{3}{*}{\textbf{2}} & \multirow{3}{*}{\textbf{\textit{Activity number 2}}}
                & 1. & Activity 2 task 1 & Deadline 1 \\
                && 2. & Activity 2 task 2 & Deadline 2 \\
                && 3. & Activity 2 task 3  & Deadline 3 \\
        \bottomrule
        \end{tabular}
         \hfill
\end{table}

\end{document}

答え2

E統合された特別な列スタイルを定義するとenumerate、次のようになりますminipage。

\documentclass{article}
\usepackage{ragged2e}
\usepackage{booktabs, makecell, multirow, tabularx}
\newcolumntype{E}{ >{\csname @minipagetrue\endcsname% list is in minipage env.
                     \RaggedRight\enumerate}X<{\endenumerate}}  % <---
\newcommand*\mcc[1]{\multicolumn{1}{>{\bfseries}l}{#1}}         % <---
\usepackage{enumitem}

\begin{document}
    \begin{table}
    \setcellgapes{1pt}
    \makegapedcells
\setlist[enumerate]{%
         resume=column, % ensure sequential numbering
         nosep,
         leftmargin=*,
         label=\arabic*.,
         after=\vspace*{-\baselineskip}
                 }
\begin{tabularx}{\linewidth}{@{} c >{\RaggedRight}p{17mm} E l @{}}
    \toprule
\mcc{No.}
    & \mcc{Activity}
        & \mcc{Task(s) to be completed}         & \mcc{Timeline}    \\
    \midrule
1   &   \multirow[t]{4}{=}{Activity number 1}
        & \setcounter{enumi}{0}   %%%% <------- start numbering with 1
          \item Some long sentence here,
                describing task 1 of activity 1 & monday            \\
    &   & \item Another long sentence here,
                describing task 2 of activity 1 & in 2 weeks        \\
    &   & \item Yet another long sentence here,
                describing task 3 of activity 1 & timeline          \\
    &   & \item Activity 1 task 4 \dots         & timeline          \\
    \midrule
2   &   \multirow[t]{2}{=}{Activity number 2}
        & \setcounter{enumi}{0}   %%%% <------- restart numbering with 1
          \item Some long sentence here,
                describing task 1 of activity 1 & monday            \\
    &   & \item Another long sentence here,
                describing task 2 of activity 1 & in 2 weeks        \\
    &   & \item Yet another long sentence here,
                describing task 3 of activity 1 & timeline          \\
    &   & \item Activity 1 task 4 \dots         & timeline          \\
    \bottomrule
\end{tabularx}
    \end{table}
\end{document}

ここに画像の説明を入力してください

答え3

enumitemここでは、入力を節約するために、カスタム定義コマンドを使用するという私の提案を示します。tabularxまた、テーブルをテキスト幅に合わせるためにも使用しました。また、左の列の空白が少ない代替レイアウトも追加しました。

ここに画像の説明を入力してください ここに画像の説明を入力してください

\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage{booktabs}
\usepackage{tabularx}

\usepackage{enumitem}

\newcommand{\mytabenum}[2][resume=mylist]{\begin{enumerate}[#1, label*=\arabic*.,leftmargin=*,nosep,leftmargin=*,before=\vspace{-0.5\baselineskip},after=\vspace{-1\baselineskip}]\item #2 \end{enumerate}}



\begin{document}


\begin{table}[h]
        \caption{Table of activities}
        \label{tblactivity}
        \centering
\begin{tabularx}{\textwidth}{l>{\raggedright\arraybackslash}p{1.5cm}Xl}
\toprule
\textbf{No.} & \textbf{Activity}   & \textbf{Task(s) to be completed}  &  \textbf{Timeline}\\
\midrule
1 & Activity number 1 & \mytabenum[series=mylist]{Some long sentence here, describing task 1 of activity 1} & monday \\
 &  & \mytabenum{Another long sentence here, describing task 2 of activity 1} & in 2 weeks\\
 &  & \mytabenum{Yet another long sentence here, describing task 3 of activity 1} & timeline\\
 &  & \mytabenum{Activity 1 task 4 ...} & timeline\\
 \midrule
2 & Activity number 2 & \mytabenum[series=mylist]{Some long sentence here, describing task 1 of activity 1} & monday \\
 &  & \mytabenum{Another long sentence here, describing task 2 of activity 1} & in 2 weeks\\
 &  & \mytabenum{Yet another long sentence here, describing task 3 of activity 1} & timeline\\
 &  & \mytabenum{Activity 1 task 4 ...} & timeline\\
\bottomrule
\end{tabularx}
\end{table}


\begin{table}[h]
        \caption{Table of activities}
        \label{tblactivity}
        \centering
\begin{tabularx}{\textwidth}{p{\tabcolsep}Xl}
\toprule
   & \textbf{Task(s) to be completed}  &  \textbf{Timeline}\\
\midrule
\multicolumn{3}{l}{1 Activity number 1} \\
  & \mytabenum[series=mylist]{Some long sentence here, describing task 1 of activity 1} & monday \\
  & \mytabenum{Another long sentence here, describing task 2 of activity 1} & in 2 weeks\\
  & \mytabenum{Yet another long sentence here, describing task 3 of activity 1} & timeline\\
  & \mytabenum{Activity 1 task 4 ...} & timeline\\
 \midrule
\multicolumn{3}{l}{2 Activity number 2} \\
  & \mytabenum[series=mylist]{Some long sentence here, describing task 1 of activity 1} & monday \\
  & \mytabenum{Another long sentence here, describing task 2 of activity 1} & in 2 weeks\\
  & \mytabenum{Yet another long sentence here, describing task 3 of activity 1} & timeline\\
  & \mytabenum{Activity 1 task 4 ...} & timeline\\
\bottomrule
\end{tabularx}
\end{table}
\end{document}
