図内の画像とテキスト - LATEX

Question

現在、いくつかのゲートとその操作をまとめた表がありますが、場違いな感じがして、フォーマットも正しくありません。画像とテキストを揃える方法をご存知の方はいらっしゃいますか? また、「効果」列では、テキストを上下に並べたいです。以下の LaTex コードと添付の画像をご覧ください。

\begin{figure}
  \centering
  \begin{threeparttable}
    \begin{tabular}{cccc}
    %{m{15mm} m{70mm} m{18mm}}
    Gates  & Circuit Symbol & Matrix Representation & Effect\\
     \midrule\midrule



Pauli-X  &

\includegraphics[scale = 1 , trim= {50 50 32 25}, clip
]{Chapter2/Figs/Raster/x.png} &

$U(\pi, 0 , \pi) =
\begin{pmatrix}
0 & 1 \\
1& 0
\end{pmatrix}$ &

\begin{itemize}
\item $\emph{X}\ket{0}\longrightarrow\ket{1}$
\item $\emph{X}\ket{1}\longrightarrow\ket{0}$
\end{itemize}

\\%new row

Pauli-Y  &

\includegraphics[scale = 1 , trim= {50 50 32 25}, clip
]{Chapter2/Figs/Raster/y.png} &

$U(\pi , \frac{\pi}{2},\frac{\pi}{2}) =
\begin{pmatrix}
0 & -i \\
i & 0
\end{pmatrix}$ &

\begin{itemize}
\item $\emph{Y}\ket{0}\longrightarrow i\ket{1}$
\item $\emph{Y}\ket{1}\longrightarrow-i\ket{0}$,
\end{itemize}

\\%new row

Pauli-Z  &

\includegraphics[scale = 1 , trim= {50 50 32 25}, clip
]{Chapter2/Figs/Raster/z.png} &

$U(0 , 0 , \pi) =
\begin{pmatrix}
1 & 0 \\
0 & -1
\end{pmatrix}$ &

\begin{itemize}
\item $\emph{Z}\ket{0}\longrightarrow\ket{0}$
\item $\emph{Z}\ket{1}\longrightarrow-\ket{1}$
\end{itemize}

\\%new row

Hadamard  &
\includegraphics[scale = 1 , trim= {50 50 32 25}, clip
]{Chapter2/Figs/Raster/h.png} &

$U(\frac{\pi}{2},0 , \pi) = \frac{1}{\sqrt{2}}
\begin{pmatrix}
1 & 1 \\
1 & -1
\end{pmatrix}$ &

\begin{itemize}
\item $\emph{H}\ket{0}\longrightarrow \frac{1}{\sqrt{2}}(\ket{0}+\ket{1})$
\item $\emph{H}\ket{1}\longrightarrow \frac{1}{\sqrt{2}}(\ket{0}-\ket{1})$  \end{itemize}

\\% end of rows
    \midrule\midrule
    \end{tabular}
    \begin{tablenotes}
  \caption{Names, circuit symbols and unitary matrix representation for common single qubit gates.}

\end{tablenotes}
\end{threeparttable}
  \end{figure}

Answer 1

\raisebox{-0.5\height}表のセル内で画像を垂直に中央揃えにするには、の前にを使用します\includegraphics。シンプルな表と標準的なサンプル画像を使用した場合、 ありと なしの場合の結果は次のようになります。\raisebox{-0.5\height}

完全なコードは

\documentclass[leqno]{article}
\usepackage{graphicx}
\usepackage{booktabs}
\begin{document}
%
%
\begin{table}
    \centering
    \caption{Vertical centering of figures in cells.}
    \begin{tabular}{lll}
        \toprule
        Column1 & Column2 & Column3 \\
        \midrule
        Cols1 & \raisebox{-0.5\height}{\includegraphics[width=2cm]{example-image}} & Cols3 \\
        Cols1 & \raisebox{-0.5\height}{\includegraphics[width=4cm]{example-image}} & Cols3 \\
        Cols1 & Cols2 & Cols3 \\
        \bottomrule
    \end{tabular}
\end{table}
%
\begin{table}
    \centering
    \caption{NO vertical centering of figures in cells.}
    \begin{tabular}{lll}
        \toprule
        Column1 & Column2 & Column3 \\
        \midrule
        Cols1 & \includegraphics[width=2cm]{example-image} & Cols3 \\
        Cols1 & \includegraphics[width=4cm]{example-image} & Cols3 \\
        Cols1 & Cols2 & Cols3 \\
        \bottomrule
    \end{tabular}
\end{table}
%

\end{document}

幸運を！

Answer 2

valign=cパッケージに付属している の使用に関する私の提案を以下に示します。また、このテーブル内での使用のためにadjustboxのカスタマイズ バージョンも追加しました。itemize

\documentclass{article}
\usepackage{graphicx}
\usepackage[export]{adjustbox}
\usepackage{amsmath}

\usepackage{booktabs}
%\usepackage{threeparttable}
\usepackage{array}
\usepackage{physics}

\usepackage{enumitem}
\newlist{tabitem}{itemize}{1}
\setlist[tabitem]{wide=0pt, leftmargin= * ,label=\textbullet}

\begin{document}
\begin{figure}

  \centering
%  \begin{threeparttable}
    \begin{tabular}{cccm{37mm}}
    %{m{15mm} m{70mm} m{18mm}}
    Gates  & Circuit Symbol & Matrix Representation & Effect\\
     \midrule\midrule



Pauli-X  &

\includegraphics[width=1cm, valign=c]{example-image} &

$U(\pi, 0 , \pi) =
\begin{pmatrix}
0 & 1 \\
1& 0
\end{pmatrix}$ &

\begin{tabitem}
\item $\emph{X}\ket{0}\longrightarrow\ket{1}$
\item $\emph{X}\ket{1}\longrightarrow\ket{0}$
\end{tabitem}

\\%new row

Pauli-Y  &

\includegraphics[width=1cm, valign=c]{example-image} &

$U(\pi , \frac{\pi}{2},\frac{\pi}{2}) =
\begin{pmatrix}
0 & -i \\
i & 0
\end{pmatrix}$ &

\begin{tabitem}
\item $\emph{Y}\ket{0}\longrightarrow i\ket{1}$
\item $\emph{Y}\ket{1}\longrightarrow-i\ket{0}$,
\end{tabitem}

\\%new row

Pauli-Z  &

\includegraphics[width=1cm, valign=c]{example-image} &

$U(0 , 0 , \pi) =
\begin{pmatrix}
1 & 0 \\
0 & -1
\end{pmatrix}$ &

\begin{tabitem}
\item $\emph{Z}\ket{0}\longrightarrow\ket{0}$
\item $\emph{Z}\ket{1}\longrightarrow-\ket{1}$
\end{tabitem}

\\%new row

Hadamard  &
\includegraphics[width=1cm, valign=c]{example-image} &

$U(\frac{\pi}{2},0 , \pi) = \frac{1}{\sqrt{2}}
\begin{pmatrix}
1 & 1 \\
1 & -1
\end{pmatrix}$ &

\begin{tabitem}
\item $\emph{H}\ket{0}\longrightarrow \frac{1}{\sqrt{2}}(\ket{0}+\ket{1})$
\item $\emph{H}\ket{1}\longrightarrow \frac{1}{\sqrt{2}}(\ket{0}-\ket{1})$
\end{tabitem}

\\% end of rows
    \midrule\midrule
    \end{tabular}
%    \begin{tablenotes}
%
%\end{tablenotes}
%\end{threeparttable}
    \caption{Names, circuit symbols and unitary matrix representation for common single qubit gates.}

  \end{figure}
  \end{document}
