tikZ のアルゴリズム フローチャート

以下のフローチャートは、時計回りに実行されるデータと関数を表すブロックで構成されており、この一連のブロックの外側には説明的な手順があります。ブロック内のテキストと周囲の手順の両方を編集可能にしながら、これを LaTeX でコード化するにはどうすればよいでしょうか。Tikz が適しているでしょうか。研究論文の図として使用します。

ここに画像の説明を入力してください

答え1

レイアウトは簡単ですが、テキストを入力するのは面倒です。そのため、私はいろいろと追加しました。必要なのは、マトリックスとハッチングなどのスタイルだけです。周囲のテキストを追加するには、図を に配置しlocal bounding box、ノードの垂直位置または水平位置を使用してテキストを配置します。

\documentclass[tikz,border=3mm]{standalone}
\usetikzlibrary{arrows.meta,matrix,patterns.meta,positioning}
\begin{document}
\begin{tikzpicture}[node font=\sffamily,>=Triangle,
    Dotted/.style={% https://tex.stackexchange.com/a/52856/194703
    line width=1.2pt,
    dash pattern=on 0.01\pgflinewidth off #1\pgflinewidth,line cap=round,
    shorten >=0.5em,shorten <=0.5em},
    Dotted/.default=6,
    mmat/.style={matrix of nodes,nodes in empty cells,
        row sep=-\pgflinewidth,nodes={minimum width=3em,
            draw,anchor=center,
            text depth=0.25ex,text height=0.8em}},
    dotcell/.style={minimum height=4em,path picture={
        \draw[Dotted] (path picture bounding box.north)--
        (path picture bounding box.south);}},
    hatchcell/.style={pattern={Lines[angle=45,distance={3pt}]}},
    vcell/.style={xshift=-1ex,hatchcell},
    block/.style={draw,align=center}
    ]
 \begin{scope}[local bounding box=diagram]
  \node[mmat] (vmat1) {|[vcell]|1 \\
     2 \\ |[dotcell]|\\  10\\ };
  %
  \node[mmat,below=2em of vmat1] (vmat2) {1 \\
     |[vcell]| 2 \\ |[dotcell]|\\  10\\ };
  %
  \node[mmat,below=3em of vmat2] (vmat3) {1 \\
     2 \\ |[dotcell]|\\  |[vcell]|  10\\ };
  %
  \foreach \X in {1,2,3}
  {\node[right=3em of vmat\X,block](b\X){regression\textsubscript{a}\\
     regression\textsubscript{b}\\ regression\textsubscript{c}};
  \draw[->] (vmat\X-3-1.east|-b\X) -- (b\X);}
  %
  \node[right=3em of b1.south east,anchor=south west,mmat,
     column 1/.style={nodes={hatchcell}}] (hmat1) {
   1 & $Z_{1\mathsf{a}}$ & $Z_{1\mathsf{b}}$ & $Z_{1\mathsf{c}}$ \\
   2 & $Z_{2\mathsf{a}}$ & $Z_{2\mathsf{b}}$ & $Z_{2\mathsf{c}}$ \\
  };
  \draw[->] (b1.east|-hmat1-1-1.west) -- (hmat1-1-1.west);
  %
  \node[right=3em of b2.north east,anchor=north west,mmat,
     column 1/.style={nodes={hatchcell}}] (hmat2) {
   10 & $Z_{10\mathsf{a}}$ & $Z_{10\mathsf{b}}$ & $Z_{10\mathsf{c}}$ \\
  };
  \foreach \X [count=\Y] in {a,b,c}
  {\node[below=\Y*2em of hmat2-1-\the\numexpr\Y+1\relax,block]
     (CV\Y) {CV Risk\textsubscript{\X}};
  \draw[->] (hmat2-1-\the\numexpr\Y+1\relax) -- (CV\Y); }
  \draw (CV1.west) -- ++ (-1ex,0) |- (CV3);
  \draw[->] (b2.east) -- ++(1em,0) |- (hmat1-2-1.west);
  \draw[->] (b3.east) -- ++(2em,0) |- (hmat2-1-1.west);
  %
  \node[block,below=12em of hmat2](F){Family of weighted\\
     combinations};
  \draw[->] (CV2.south-|F) -- (F);
  %
  \node[block,below=4em of F.south west,xshift=-3em] (P)
  {Some long formula with P};
  \draw[<-] (P.east) -- ++ (1em,0) coordinate (aux) -- (F.south-|aux);
  \node[block,left=3em of P,text width=8em] (PP)  {\vphantom{P}};
  \draw[->] (P) -- (PP);
  %
  \node[left=3em of vmat2.north west,block] (A){Collection of\\ algorithms};
  \node[left=3em of vmat2.south west,block] (MD){Mortality\\ data};
  \draw[->] (A.east) -- ++ (1.2em,0) |- (vmat1-3-1);
  \draw[->] (A.east) -- ++ (1.2em,0) |- (vmat3-3-1);
  \draw[->] (MD.east) -- ++ (1.2em,0) |- (vmat2-3-1);
  \path (current bounding box.south west) + (-1ex,-1ex)
  (current bounding box.north east) + (1ex,1ex);
 \end{scope}
 \node[text width=7em,above] at (MD|-diagram.north){1.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=7em,above] at (vmat1|-diagram.north){2.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=7em,above] at (b1|-diagram.north){3.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=12em,above] at (hmat1|-diagram.north){4.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
  bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=8em,right] at (hmat2-|diagram.east){5.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
  bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=8em,right] at (F-|diagram.east){6.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=9em,below] at (P|-diagram.south){7.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=9em,below] at (PP|-diagram.south){8.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
\end{tikzpicture}
\end{document}

ここに画像の説明を入力してください

これは、（一部の）古い TeX インストールで動作するバージョンです。

\documentclass[tikz,border=3mm]{standalone}
\usetikzlibrary{arrows.meta,matrix,patterns,positioning}
\begin{document}
\begin{tikzpicture}[node font=\sffamily,>=Triangle,
    Dotted/.style={% https://tex.stackexchange.com/a/52856/194703
    line width=1.2pt,
    dash pattern=on 0.01\pgflinewidth off #1\pgflinewidth,line cap=round,
    shorten >=0.5em,shorten <=0.5em},
    Dotted/.default=6,
    mmat/.style={matrix of nodes,nodes in empty cells,
        row sep=-\pgflinewidth,nodes={minimum width=3em,
            draw,anchor=center,
            text depth=0.25ex,text height=0.8em}},
    dotcell/.style={minimum height=4em,path picture={
        \draw[Dotted] (path picture bounding box.north)--
        (path picture bounding box.south);}},
    hatchcell/.style={pattern=north east lines},
    vcell/.style={xshift=-1ex,hatchcell},
    block/.style={draw,align=center}
    ]
 \begin{scope}[local bounding box=diagram]
  \node[mmat] (vmat1) {|[vcell]|1 \\
     2 \\ |[dotcell]|\\  10\\ };
  %
  \node[mmat,below=2em of vmat1] (vmat2) {1 \\
     |[vcell]| 2 \\ |[dotcell]|\\  10\\ };
  %
  \node[mmat,below=3em of vmat2] (vmat3) {1 \\
     2 \\ |[dotcell]|\\  |[vcell]|  10\\ };
  %
  \foreach \X in {1,2,3}
  {\node[right=3em of vmat\X,block](b\X){regression\textsubscript{a}\\
     regression\textsubscript{b}\\ regression\textsubscript{c}};
  \draw[->] (vmat\X-3-1.east|-b\X) -- (b\X);}
  %
  \node[right=3em of b1.south east,anchor=south west,mmat,
     column 1/.style={nodes={hatchcell}}] (hmat1) {
   1 & $Z_{1\mathsf{a}}$ & $Z_{1\mathsf{b}}$ & $Z_{1\mathsf{c}}$ \\
   2 & $Z_{2\mathsf{a}}$ & $Z_{2\mathsf{b}}$ & $Z_{2\mathsf{c}}$ \\
  };
  \draw[->] (b1.east|-hmat1-1-1.west) -- (hmat1-1-1.west);
  %
  \node[right=3em of b2.north east,anchor=north west,mmat,
     column 1/.style={nodes={hatchcell}}] (hmat2) {
   10 & $Z_{10\mathsf{a}}$ & $Z_{10\mathsf{b}}$ & $Z_{10\mathsf{c}}$ \\
  };
  \foreach \X [count=\Y] in {a,b,c}
  {\node[below=\Y*2em of hmat2-1-\the\numexpr\Y+1\relax,block]
     (CV\Y) {CV Risk\textsubscript{\X}};
  \draw[->] (hmat2-1-\the\numexpr\Y+1\relax) -- (CV\Y); }
  \draw (CV1.west) -- ++ (-1ex,0) |- (CV3);
  \draw[->] (b2.east) -- ++(1em,0) |- (hmat1-2-1.west);
  \draw[->] (b3.east) -- ++(2em,0) |- (hmat2-1-1.west);
  %
  \node[block,below=12em of hmat2](F){Family of weighted\\
     combinations};
  \draw[->] (CV2.south-|F) -- (F);
  %
  \node[block,below=4em of F.south west,xshift=-3em] (P)
  {Some long formula with P};
  \draw[<-] (P.east) -- ++ (1em,0) coordinate (aux) -- (F.south-|aux);
  \node[block,left=3em of P,text width=8em] (PP)  {\vphantom{P}};
  \draw[->] (P) -- (PP);
  %
  \node[left=3em of vmat2.north west,block] (A){Collection of\\ algorithms};
  \node[left=3em of vmat2.south west,block] (MD){Mortality\\ data};
  \draw[->] (A.east) -- ++ (1.2em,0) |- (vmat1-3-1);
  \draw[->] (A.east) -- ++ (1.2em,0) |- (vmat3-3-1);
  \draw[->] (MD.east) -- ++ (1.2em,0) |- (vmat2-3-1);
  \path (current bounding box.south west) + (-1ex,-1ex)
  (current bounding box.north east) + (1ex,1ex);
 \end{scope}
 \node[text width=7em,above] at (MD|-diagram.north){1.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=7em,above] at (vmat1|-diagram.north){2.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=7em,above] at (b1|-diagram.north){3.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=12em,above] at (hmat1|-diagram.north){4.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
  bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=8em,right] at (hmat2-|diagram.east){5.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
  bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=8em,right] at (F-|diagram.east){6.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=9em,below] at (P|-diagram.south){7.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
 \node[text width=9em,below] at (PP|-diagram.south){8.\ bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla bla
 bla bla};
\end{tikzpicture}
\end{document}
