pandocLaTeX PDF テンプレートを使用して、Markdown ファイルを PDF に変換するプロジェクトがあります。
表に関して奇妙な問題が発生しています。ごくまれに (200 文書中 2 件程度)、表がページ区切りの後に挿入されます。LaTeX の経験がほとんどないため、ページ区切りかどうかはわかりませんが、そのようです。
これは私が変換している Markdown ファイルの 1 つです。
... More stuff above
Lorem
- Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s.
# LOREM IPSUM
## Lorem Ipsum is simply dummy
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting.
| Column 1 | Column 2 |
| ---------------------------------------------- | --------------------------------------------------------------------------- |
| Lorem Ipsum is simply dummy text | Lorem Ipsum |
| Lorem Ipsum is simply dummy text of the | Lorem Ipsum is simply dummy text of the printing and typesetting industry. |
## Lorem Ipsum is simply dummy text of the
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book.
... More stuff below
私のpandocコマンドは次のようになります (Powershell で実行されます。ドル記号の付いた変数はそのためのものなのです):
pandoc --metadata=title:"asasas" `
--resource-path="$markdownPath" `
--template="$pdfTemplatePath" `
--fail-if-warnings `
--variable numbersections="true" `
--variable mainfont="Arial" `
--variable sansfont="Helvetica" `
--variable monofont="Courier" `
--variable fontsize=12pt `
--variable version=2.0 `
--variable geometry="left=20mm, top=10mm, right=20mm, bottom=20mm" `
--variable toc-own-page="true" `
--toc `
--toc-depth=5 `
--lua-filter="version_table.lua" `
--variable titlepage="true" `
--variable logo="PDF/logo.eps" `
--columns=50 `
-f markdown-implicit_figures+escaped_line_breaks+raw_tex `
-t latex `
-s `
-o "$outputFileName" `
"$tempFileName"
私が使用しているPDFテンプレートは、pandoc-latex-テンプレートおそらくその上に建てられたのでしょう。
コマンドを実行するとpandoc、テーブルの出力は次のようになります。
何が問題なのか、何か心当たりはありますか? 何か試すべきことはありますか?
これは、上のスクリーンショット用に生成されたTexファイルの一部です。
\PassOptionsToPackage{unicode}{hyperref}
\PassOptionsToPackage{hyphens}{url}
\PassOptionsToPackage{dvipsnames,svgnames*,x11names*,table}{xcolor}
%
\documentclass[
12pt,
a4paper,
,tablecaptionabove
]{scrartcl}
\usepackage{lmodern}
\usepackage{setspace}
\setstretch{1.2}
\usepackage{amssymb,amsmath}
\usepackage{ifxetex,ifluatex}
\usepackage[utf8x]{inputenc}
\ifnum 0\ifxetex 1\fi\ifluatex 1\fi=0 % if pdftex
\usepackage[T1]{fontenc}
% \usepackage[utf8x]{inputenc}
\usepackage{textcomp} % provide euro and other symbols
\else % if luatex or xetex
\usepackage{unicode-math}
\defaultfontfeatures{Scale=MatchLowercase}
\defaultfontfeatures[\rmfamily]{Ligatures=TeX,Scale=1}
\setmainfont[]{Arial}
\setsansfont[]{Helvetica}
\setmonofont[]{Courier}
\fi
% Use upquote if available, for straight quotes in verbatim environments
\IfFileExists{upquote.sty}{\usepackage{upquote}}{}
\IfFileExists{microtype.sty}{% use microtype if available
\usepackage[]{microtype}
\UseMicrotypeSet[protrusion]{basicmath} % disable protrusion for tt fonts
}{}
\makeatletter
\@ifundefined{KOMAClassName}{% if non-KOMA class
\IfFileExists{parskip.sty}{%
\usepackage{parskip}
}{% else
\setlength{\parindent}{0pt}
\setlength{\parskip}{6pt plus 2pt minus 1pt}}
}{% if KOMA class
\KOMAoptions{parskip=half}}
\makeatother
\usepackage{xcolor}
\definecolor{default-linkcolor}{HTML}{A50000}
\definecolor{default-filecolor}{HTML}{A50000}
\definecolor{default-citecolor}{HTML}{4077C0}
\definecolor{default-urlcolor}{HTML}{4077C0}
\IfFileExists{xurl.sty}{\usepackage{xurl}}{} % add URL line breaks if available
\IfFileExists{bookmark.sty}{\usepackage{bookmark}}{\usepackage{hyperref}}
\hypersetup{
pdftitle={asasas},
hidelinks,
breaklinks=true,
pdfcreator={LaTeX via pandoc with the Eisvogel template}}
\urlstyle{same} % disable monospaced font for URLs
\usepackage[margin=2.5cm,includehead=true,includefoot=true,centering,left=20mm, top=10mm, right=20mm, bottom=20mm]{geometry}
\usepackage[export]{adjustbox}
\usepackage{graphicx}
\usepackage{longtable,booktabs}
% Correct order of tables after \paragraph or \subparagraph
\usepackage{etoolbox}
\makeatletter
\patchcmd\longtable{\par}{\if@noskipsec\mbox{}\fi\par}{}{}
\makeatother
% Allow footnotes in longtable head/foot
\IfFileExists{footnotehyper.sty}{\usepackage{footnotehyper}}{\usepackage{footnote}}
\makesavenoteenv{longtable}
\usepackage{graphicx,grffile}
\makeatletter
\def\ScaleWidthIfNeeded{%
\ifdim\Gin@nat@width>\linewidth
\linewidth
\else
\Gin@nat@width
\fi
}
\def\ScaleHeightIfNeeded{%
\ifdim\Gin@nat@height>0.9\textheight
0.9\textheight
\else
\Gin@nat@width
\fi
}
\makeatother
\setkeys{Gin}{width=\ScaleWidthIfNeeded,height=\ScaleHeightIfNeeded,keepaspectratio}%
\setlength{\emergencystretch}{3em} % prevent overfull lines
\providecommand{\tightlist}{%
\setlength{\itemsep}{0pt}\setlength{\parskip}{0pt}}
\setcounter{secnumdepth}{5}
\usepackage{float}
\floatplacement{figure}{H}
\title{asasas}
\date{}
\ifnum 0\ifxetex 1\fi\ifluatex 1\fi=0 % if pdftex
\usepackage[shorthands=off,main=english]{babel}
\else
\usepackage{polyglossia}
\setmainlanguage[]{english}
\fi
\usepackage{pagecolor}
\usepackage{afterpage}
\usepackage{multicol}
\PassOptionsToPackage{hyphens}{url}
\usepackage{csquotes}
\definecolor{caption-color}{HTML}{777777}
\usepackage[font={stretch=1.2}, textfont={color=caption-color}, position=top, skip=4mm, labelfont=bf, singlelinecheck=false, justification=raggedright]{caption}
\setcapindent{0em}
\definecolor{blockquote-border}{RGB}{221,221,221}
\definecolor{blockquote-text}{RGB}{119,119,119}
\usepackage{mdframed}
\newmdenv[rightline=false,bottomline=false,topline=false,linewidth=3pt,linecolor=blockquote-border,skipabove=\parskip]{customblockquote}
\renewenvironment{quote}{\begin{customblockquote}\list{}{\rightmargin=0em\leftmargin=0em}%
\item\relax\color{blockquote-text}\ignorespaces}{\unskip\unskip\endlist\end{customblockquote}}
\definecolor{heading-color}{RGB}{40,40,40}
\addtokomafont{section}{\color{heading-color}}
\usepackage{titling}
\title{asasas}
\author{}
% tables
\definecolor{table-row-color}{HTML}{F5F5F5}
\definecolor{table-rule-color}{HTML}{999999}
\arrayrulecolor{table-rule-color} % color of \toprule, \midrule, \bottomrule
\setlength\heavyrulewidth{0.3ex} % thickness of \toprule, \bottomrule
\renewcommand{\arraystretch}{1.3} % spacing (padding)
\let\oldlongtable\longtable
\let\endoldlongtable\endlongtable
\renewenvironment{longtable}{
\rowcolors{3}{}{table-row-color!100} % row color
\oldlongtable} {
\endoldlongtable
\global\rownum=0\relax}
\setlength{\parindent}{0pt}
\setlength{\parskip}{6pt plus 2pt minus 1pt}
\setlength{\emergencystretch}{3em} % prevent overfull lines
\usepackage{fancyhdr,lastpage}
\fancypagestyle{eisvogel-header-footer}{
\fancyhead{}
\fancyfoot{}
\lhead[]{asasas}
\chead[]{}
\rhead[asasas]{}
\lfoot{{Version: 2}{, effective date: 01-Sep-2020}}
\cfoot[]{}
\rfoot{{\thepage} of \pageref{LastPage}}
\renewcommand{\headrulewidth}{0.4pt}
\renewcommand{\footrulewidth}{0.4pt}
}
\pagestyle{eisvogel-header-footer}
\ifx\paragraph\undefined\else
\let\oldparagraph\paragraph
\renewcommand{\paragraph}[1]{\oldparagraph{#1}\mbox{}}
\fi
\ifx\subparagraph\undefined\else
\let\oldsubparagraph\subparagraph
\renewcommand{\subparagraph}[1]{\oldsubparagraph{#1}\mbox{}}
\fi
\usepackage[table]{xcolor}
\usepackage{tabularx}
\usepackage{colortbl}
\begin{document}
\arrayrulecolor{table-rule-color}
\restoregeometry
{
\setcounter{tocdepth}{5}
\tableofcontents
\newpage
}
\hypertarget{process-description}{%
\section{LOREM IPSUM}\label{process-description}}
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy text ever since the
1500s, when an unknown printer took a galley of
type and scrambled it to make a type specimen
book. It has survived not only five centuries, but
also the leap into electronic typesetting.
\hypertarget{objective-and-benefits}{%
\section{OBJECTIVE AND
BENEFITS}\label{objective-and-benefits}}
\hypertarget{objective}{%
\subsection{Objective}\label{objective}}
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard
\hypertarget{benefits}{%
\subsection{Benefits}\label{benefits}}
\begin{itemize}
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.
\end{itemize}
\hypertarget{definition}{%
\section{DEFINITION}\label{definition}}
Lorem Ipsum
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.
\end{itemize}
Lorem Ipsum
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy text ever since the
1500s, when an unknown printer took
\end{itemize}
Lorem Ipsum
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy
\end{itemize}
Lorem Ipsum
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy text
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum is
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum is
\end{itemize}
\hypertarget{roles-responsibilities}{%
\section{LOREM IPSUM}\label{roles-responsibilities}}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been
the industry's standard dummy text ever since
the 1500s Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been
the industry's standard dummy text ever since
the 1500s.
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lore
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been
the industry's standard dummy text ever since
the 1500s.
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been
the industry's standard dummy text ever since
the 1500s.
\end{itemize}
\hypertarget{lorem-ipsum}{%
\section{LOREM IPSUM}\label{lorem-ipsum}}
\hypertarget{lorem-ipsum-is-simply-dummy}{%
\subsection{Lorem Ipsum is simply
dummy}\label{lorem-ipsum-is-simply-dummy}}
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy text ever since the
1500s, when an unknown printer took a galley of
type and scrambled it to make a type specimen
book. It has survived not only five centuries, but
also the leap into electronic typesetting.
\begin{longtable}[]{@{}ll@{}}
\toprule
\begin{minipage}[b]{0.36\columnwidth}\raggedright
Column 1\strut
\end{minipage} &
\begin{minipage}[b]{0.58\columnwidth}\raggedright
Column 2\strut
\end{minipage}\tabularnewline
\midrule
\endhead
\begin{minipage}[t]{0.36\columnwidth}\raggedright
Lorem Ipsum is simply dummy text\strut
\end{minipage} &
\begin{minipage}[t]{0.58\columnwidth}\raggedright
Lorem Ipsum\strut
\end{minipage}\tabularnewline
\begin{minipage}[t]{0.36\columnwidth}\raggedright
Lorem Ipsum is simply dummy text of the\strut
\end{minipage} &
\begin{minipage}[t]{0.58\columnwidth}\raggedright
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.\strut
\end{minipage}\tabularnewline
\bottomrule
\end{longtable}
\end{document}
