セグメントの長さのラベル付けに関する質問を読んだのですが、これまでの質問では長さ/距離のラベル付けに角度を使用していたため、私にとってはかなり難しく、その概念を理解していませんでした。セグメントの長さのラベル付けの概念について教えていただけませんか?

私の実験と、それを TikZ で記述する必要がある問題を説明します。

私が試したコードは次のとおりです:

\begin{tikzpicture}
\tikzset{
mydot/.style={
fill,
circle,
inner sep=1.5pt
}
}
\path (0:4.5) coordinate (A) (0:1.5) coordinate (B) (0:0) coordinate (C);
\draw (A)
-- (B) node [midway, above]{$x$} -- (C) node [midway, above]{$y$}  -- (A) -- cycle;
\node[mydot,label={below left:$A$}] at (A) {};
\node[mydot,label={below left:$B$}] at (B) {};
\node[mydot,label={below left:$C$}] at (C) {};
\draw[|<->|] ($(A)!5mm!90:(C)$)--node[fill=white] {$z$} ($(C)!5mm!0:(A)$);
\end{tikzpicture}

実際、このコードは過去に投稿された質問からコピーしたものですが、ここでは自分のケースに合わせてアレンジしました。

これは私がTikZで説明したい問題の切り抜き画像です

問題

ちなみに、セグメントを水平にしたいのですが。 よろしくお願いします。

答え1

このようなもの

ここに画像の説明を入力してください

\begin{tikzpicture}
\tikzset{
    mydot/.style={
        fill,
        circle,
        inner sep=1.5pt
    }
}
\coordinate  (A) at(0,0) ;
\coordinate  (B)  at (3,0);
\coordinate  (C) at (6,0);
\coordinate  (D) at (9,0);
% (3,0) coordinate (B) (6,0) coordinate (C) (9,0) coordinate (D);
\draw (A) -- node [midway, above]{\scriptsize $x=21-14$}
(B)  -- node [midway, above]{\scriptsize $y=13-x$}
(C)   --
(D);
\node[mydot,label={below left:$A$}] at (A) {};
\node[mydot,label={below left:$B$}] at (B) {};
\node[mydot,label={below left:$C$}] at (C) {};
\node[mydot,label={below left:$D$}] at (D) {};
\draw[|<->|,red,line width=1pt] ($(A)!10mm!-90:(C)$)--node[fill=white] {$13$} ($(C)!10mm!90:(A)$);
\draw[|<->|,blue,line width=1pt] ($(B)!15mm!-90:(D)$)--node[fill=white] {$14$} ($(D)!15mm!90:(B)$);
\draw[|<->|,green,line width=1pt] ($(A)!20mm!-90:(D)$)--node[fill=white] {$21$} ($(D)!20mm!90:(A)$);
\end{tikzpicture}

編集 -- セグメント上のラベル

ここに画像の説明を入力してください

\begin{tikzpicture}
\tikzset{
    mydot/.style={
        fill,
        circle,
        inner sep=1.5pt
    }
}
\coordinate  (A) at(0,0) ;
\coordinate  (B)  at (3,0);
\coordinate  (C) at (6,0);
\coordinate  (D) at (9,0);
% (3,0) coordinate (B) (6,0) coordinate (C) (9,0) coordinate (D);
\draw (A) -- node [midway, above]{\scriptsize $x=21-14$}
(B)  -- node [midway, above]{\scriptsize $y=13-x$}
(C)   --
(D);
\node[mydot,label={below left:$A$}] at (A) {};
\node[mydot,label={below left:$B$}] at (B) {};
\node[mydot,label={below left:$C$}] at (C) {};
\node[mydot,label={below left:$D$}] at (D) {};
\draw[|<->|,red,line width=1pt] ($(A)!10mm!90:(C)$)--node[fill=white] {$13$} ($(C)!10mm!-90:(A)$);
\draw[|<->|,blue,line width=1pt] ($(B)!15mm!90:(D)$)--node[fill=white] {$14$} ($(D)!15mm!-90:(B)$);
\draw[|<->|,green,line width=1pt] ($(A)!20mm!90:(D)$)--node[fill=white] {$21$} ($(D)!20mm!-90:(A)$);
\end{tikzpicture}

答え2

編集: @jsbibra のコメントを検討します。

このような:

ここに画像の説明を入力してください

\documentclass[tikz, margin=3mm]{standalone}
\usetikzlibrary{arrows.meta,
                positioning,
                quotes}
\usepackage{amsmath}


\begin{document}
    \begin{tikzpicture}[x=7mm,
dot/.style = {circle, fill, inner sep=1.5pt,
              label=#1,
              node contents={}},
arr/.style = {{Bar[width=3mm].Straight Barb[]}-{Straight Barb[].Bar[width=3mm]},
              shorten >=-0.5\pgflinewidth, shorten <=-0.5\pgflinewidth,
              very thin},
every edge quotes/.style = {font=\small, auto=center}
                        ]
\node (a) [dot=${A=0}$];
\node (b) [dot=$B$, right= 7 of a];
\node (c) [dot=${C=13}$, right=13 of a];
\node (d) [dot=${D=21}$, right=21 of a];
%
\draw (a) to["${\begin{aligned}
                \overline{AB} & = \overline{AD}-\overline{BD}\\
                              & = 21-14=\color{red}7
                \end{aligned}}$"]   (b)
          to["${\begin{aligned}
                \overline{BC} & = \overline{AC}-\overline{AB}\\
                              & = 13-7=\color{red}6
                \end{aligned}}$"]   (c)   -- (d);
% aux coordinate and dimension BD
\coordinate[below=6mm of b] (b1);
\draw[arr]  (b1) to ["${\overline{BD} = 14}$" fill=white]  (b1-|d);
\end{tikzpicture}
\end{document}
