HarfBuzz レンダラーの使用時に、Devanagari UTF-8 テキスト抽出コードが lua エラーを生成する

HarfBuzz レンダラーの使用時に、Devanagari UTF-8 テキスト抽出コードが lua エラーを生成する

Devanagari UTF-8 テキスト抽出コードは、fontspec の Node レンダラーを使用しているときに lua エラーを生成しませんが、Node レンダラーのバグの可能性があるため、正しい結果が生成されません。これを別の質問として提出しました:LuaTeX: デーヴァナーガリー文字のグリフ順序が TEX の内部ノードリストで逆になっています。グリフノードをトラバースしながら正しい順序を回復するにはどうすればよいですか?

TeX ボックスから UTF-8 テキストを抽出するためのさまざまな手法を試しているときに、fontspec の Node レンダラーを使用してデーヴァナーガリー文字テキストを抽出する際に lua エラーを生成しない 2 つの手法が、fontspec の HarfBuzz レンダラー (Renderer = Harfbuzz、Renderer = OpenType) を使用すると lua エラーを生成することに気付きました。

ここでは 2 つの手法について詳しく説明します。テクニック-1(使用ミカール-H21get_unicode機能)とここでは:テクニック2(unicode.utf8.char複雑なグリフの構成要素にのみ適用)。複数のデーヴァナーガリー フォントを試しましたが、すべて同じ動作になりました。

両方の手法の完全なテスト コードと、それぞれのエラー シグネチャが、以下のブロックに順番にリストされています。私の例では、ここから無料で入手できる Noto Sans Devanagari (通常の太さ) を使用しました。Noto Sans Devanagari の Google Fonts GitHub へのリンク

テクニック-1Devanagari と HarfBuzz を使用 (Node レンダラーでコンパイルした場合は lua エラーは発生しません):

\documentclass{article}
\usepackage[lmargin=0.5in,tmargin=0.5in,rmargin=0.5in,bmargin=0.5in]{geometry}
\usepackage{fontspec}
\usepackage{microtype}

%\newfontscript{Devanagari}{deva,dev2}
\newfontfamily{\devanagarifam}{Noto Sans Devanagari}[Script=Devanagari, Scale=1, Renderer=HarfBuzz]

\begin{document}

% Devanagari text is at the right end of following line
% of code, you might have to scroll right to read it
\setbox0=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devanagarifam एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}

\directlua{
    % local fontstyles = require "l4fontstyles"
  local char = unicode.utf8.char
  local glyph_id = node.id("glyph")
  local glue_id  = node.id("glue")
  local hlist_id = node.id("hlist")
  local vlist_id = node.id("vlist")
  local disc_id  = node.id("disc")
  local minglue  = tex.sp("0.2em")
  local usedcharacters = {}
  local identifiers = fonts.hashes.identifiers
  local function get_unicode(xchar,font_id)
    local current = {}
    local uchar = identifiers[font_id].characters[xchar].tounicode
    for i= 1, string.len(uchar), 4 do
      local cchar = string.sub(uchar, i, i + 3)
      print(xchar,uchar,cchar, font_id, i)
      table.insert(current,char(tonumber(cchar,16)))
    end
    return current
  end
  local function nodeText(n)
    local t =  {}
    for x in node.traverse(n) do
      % glyph node
      if x.id == glyph_id then
        % local currentchar = fonts.hashes.identifiers[x.font].characters[x.char].tounicode
        local chars = get_unicode(x.char,x.font)
        for _, current_char in ipairs(chars) do
          table.insert(t,current_char)
        end
      % glue node
      elseif x.id == glue_id and  node.getglue(x) > minglue then
        table.insert(t," ")
      % discretionaries
      elseif x.id == disc_id then
        table.insert(t, nodeText(x.replace))
      % recursivelly process hlist and vlist nodes
      elseif x.id == hlist_id or x.id == vlist_id then
        table.insert(t,nodeText(x.head))
      end
    end
    return table.concat(t)
  end
  local n = tex.getbox(0)
  print(nodeText(n.head))
  local f = io.open("hello.txt","w")
  f:write(nodeText(n.head))
  f:close()
}

\box0
\end{document}

Technique-1 (HarfBuzz レンダラー) のエラー署名:

[\directlua]:1: bad argument #1 to 'len' (string expected, got nil)
stack traceback:
    [C]: in function 'string.len'
    [\directlua]:1: in upvalue 'get_unicode'
    [\directlua]:1: in local 'nodeText'
    [\directlua]:1: in main chunk.
l.62 }

テクニック2Devanagari と HarfBuzz を使用 (Node レンダラーでコンパイルした場合は lua エラーは発生しません):

\documentclass{article}
\usepackage[lmargin=0.5in,tmargin=0.5in,rmargin=0.5in,bmargin=0.5in]{geometry}
\usepackage{fontspec}
\usepackage{microtype}

%\newfontscript{Devanagari}{deva,dev2}
\newfontfamily{\devanagarifam}{Noto Sans Devanagari}[Script=Devanagari, Scale=1, Renderer=HarfBuzz]

\begin{document}

% Devanagari text is at the right end of following line
% of code, you might have to scroll right to read it
\setbox0=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devanagarifam एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}

\directlua{
  local glyph_id = node.id("glyph")
  local disc_id = node.id("disc")
  local glue_id  = node.id("glue")
  local hlist_id = node.id("hlist")
  local vlist_id = node.id("vlist")
  local minglue = tex.sp("0.2em")
  local function nodeText(n)
    local t =  {}
    for x in node.traverse(n) do
      % glyph node
      if x.id == glyph_id then
        if bit32.band(x.subtype,2) \csstring~=0 and unicode.utf8.char(x.char) \csstring~="“" and unicode.utf8.char(x.char) \csstring~="”" then %
          for g in node.traverse_id(glyph_id,x.components) do
            if bit32.band(g.subtype, 2) \csstring~=0 then
              for gc in node.traverse_id(glyph_id,g.components) do
                table.insert(t,unicode.utf8.char(gc.char))
              end
            else
              table.insert(t,unicode.utf8.char(g.char))
            end
          end
        else
          table.insert(t,unicode.utf8.char(x.char))
        end
      % disc node
      elseif x.id == disc_id then
        for g in node.traverse_id(glyph_id,x.replace) do
          if bit32.band(g.subtype, 2) \csstring~=0 then
            for gc in node.traverse_id(glyph_id,g.components) do
              table.insert(t,unicode.utf8.char(gc.char))
            end
          else
            table.insert(t,unicode.utf8.char(g.char))
          end
        end
        % glue node
      elseif x.id == glue_id and  node.getglue(x) > minglue then
        table.insert(t," ")
      elseif x.id == hlist_id or x.id == vlist_id then
        table.insert(t,nodeText(x.head))
      end
    end
    return table.concat(t)
  end
  local n = tex.getbox(0)
  print(nodeText(n.head))
  local f = io.open("hello.txt","w")
  f:write(nodeText(n.head))
  f:close()

}

\box0
\end{document}


Technique-2 (HarfBuzz レンダラー) のエラー署名:

[\directlua]:1: bad argument #1 to 'char' (invalid value)
stack traceback:
    [C]: in field 'char'
    [\directlua]:1: in local 'nodeText'
    [\directlua]:1: in main chunk.
l.64 }

答え1

ノード モードでは、出力がシェイプされ、シェイプされたグリフを入力テキストに一意にマッピングできないため、テキスト全体を復元することは通常不可能です。tounicode 値を使用して近似することしかできません。これらは実際の PDF ファイルの ToUnicode CMap エントリにマッピングされるため、グリフから Unicode へのマッピングの制限されたモデルに従います。すべてのグリフは、Unicode コードポイントの固定シーケンスに相当します。これらのマッピングは、レンダリング順に連結されます。ご覧のとおり、このモデルはデーヴァナーガリー グリフを入力テキストにマッピングするには不十分です。

harfこの問題を回避するには、代わりにモードを使用できます。harfモードは、グリフの形状リストを提供するだけでなく、ToUnicode では正しくモデル化できないシーケンスで ToUnicode マッピングをオーバーライドする PDF マーク付きコンテンツ ActualText エントリも作成するため、この制限付きモデルの影響を受けません。このマッピングに必要なデータは、プロパティを使用して Lua コードから照会できますglyph_data。(これは文書化されていない実装の詳細であり、将来変更される可能性があります)

テキストから可能な限り多くの情報を抽出したい場合は、このプロパティ ベースと ToUnicode ベースのアプローチを Lua コードで組み合わせることができます。

ファイルを作成extracttext.luaする

local type = type
local char = utf8.char
local unpack = table.unpack
local getproperty = node.getproperty
local getfont = font.getfont
local is_glyph = node.is_glyph

-- tounicode id UTF-16 in hex, so we need to handle surrogate pairs...
local utf16hex_to_utf8 do -- Untested, but should more or less work
  local l = lpeg
  local tonumber = tonumber
  local hex = l.R('09', 'af', 'AF')
  local byte = hex * hex
  local simple = byte * byte / function(s) return char(tonumber(s, 16)) end
  local surrogate = l.S'Dd' * l.C(l.R('89', 'AB', 'ab') * byte)
                  * l.S'Dd' * l.C(l.R('CF', 'cf') * byte) / function(high, low)
                      return char(0x10000 + ((tonumber(high, 16) & 0x3FF) << 10 | (tonumber(low, 16) & 0x3FF)))
                    end
  utf16hex_to_utf8 = l.Cs((surrogate + simple)^0)
end

-- First the non-harf case

-- Standard caching setup
local identity_table = setmetatable({}, {__index = function(_, id) return char(id) end})
local cached_text = setmetatable({}, {__index = function(t, fid)
  local fontdir = getfont(fid)
  local characters = fontdir and fontdir.tounicode == 1 and fontdir.characters
  local font_cache = characters and setmetatable({}, {__index = function(tt, slot)
    local character = characters[slot]
    local text = character and character.tounicode or slot
    -- At this point we have the tounicode value in text. This can have different forms.
    -- The order in the if ... elseif chain is based on how likely it is to encounter them.
    -- This is a small performance optimization.
    local t = type(text)
    if t == 'string' then
      text = utf16hex_to_utf8:match(text)
    elseif t == 'number' then
      text = char(text)
    elseif t == 'table' then
      text = char(unpack(text)) -- I haven't tested this case, but it should work
    end
    tt[slot] = text
    return text
  end}) or identity_table
  t[fid] = font_cache
  return font_cache
end})

-- Now the tounicode case just has to look up the value
local function from_tounicode(n)
  local slot, fid = is_glyph(n)
  return cached_text[fid][slot]
end

-- Now the traversing stuff. Nothing interesting to see here except for the
-- glyph case
local traverse = node.traverse
local glyph, glue, disc, hlist, vlist = node.id'glyph', node.id'glue', node.id'disc', node.id'hlist', node.id'vlist'
local extract_text_vlist
-- We could replace i by #t+1 but this should be slightly faster
local function real_extract_text(head, t, i)
  for n, id in traverse(head) do
    if id == glyph then
      -- First handle harf mode: Look for a glyph_info property. If that does not exists
      -- use from_tounicode. glyph_info will sometimes/often be an empty string. That's
      -- intentional and it should *not* trigger a fallback. The actual mapping will be
      -- contained in surrounding chars.
      local props = getproperty(n)
      t[i] = props and props.glyph_info or from_tounicode(n)
      i = i + 1
    elseif id == glue then
      if n.width > 1001 then -- 1001 is arbitrary but sufficiently high to be bigger than most weird glue uses
        t[i] = ' '
        i = i + 1
      end
    elseif id == disc then
      i = real_extract_text(n.replace, t, i)
    elseif id == hlist then
      i = real_extract_text(n.head, t, i)
    elseif id == vlist then
      i = extract_text_vlist(n.head, t, i)
    end
  end
  return i
end
function extract_text_vlist(head, t, i) -- glue should not become a space here
  for n, id in traverse(head) do
    if id == hlist then
      i = real_extract_text(n.head, t, i)
    elseif id == vlist then
      i = extract_text_vlist(n.head, t, i)
    end
  end
  return i
end
return function(list)
  local t = {}
  real_extract_text(list.head, t, 1)
  return table.concat(t)
end

これは通常の Lua モジュールとして使用できます。

\documentclass{article}
\usepackage{fontspec}

\newfontfamily{\devharf}{Noto Sans Devanagari}[Script=Devanagari, Renderer=HarfBuzz]
\newfontfamily{\devnode}{Noto Sans Devanagari}[Script=Devanagari, Renderer=Node]

\begin{document}

% Devanagari text is at the right end of following line
% of code, you might have to scroll right to read it
\setbox0=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devharf एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}
\setbox1=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devnode एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}

\directlua{
  local extracttext = require'extracttext'
  local f = io.open("hello.harf.txt","w") % Can reproduce the full input text
  f:write(extracttext(tex.getbox(0)))
  f:close()

  f = io.open("hello.node.txt","w") % In node mode, we only get an approximation
  f:write(extracttext(tex.getbox(1)))
  f:close()
}

\box0
\box1
\end{document}

より一般的な注意: ご覧のとおり、シェイプされたリストからテキストを取得する場合、特にサロゲートペアなどをマッピングする必要があるToUnicodeの場合、いくつかの作業が必要です。これは主にシェイプされたテキストがないこのような用途を想定しています。グリフノードが保護されると(別名、subtype(n) >= 256 またはnot is_char(n)true.charエントリには Unicode 値ではなく内部識別子が含まれるようになり、.fontエントリは期待どおりの値ではなくなり、一部のグリフはグリフとしてまったく表現されなくなる可能性があります。ほとんどの場合、テキストの視覚的な表示だけでなく、ボックスの背後にあるテキストに実際にアクセスしたいので、リストをインターセプトする必要があります。前にまず最初に形が決まります。

答え2

tounicodeHarfBuzz フォントが Luaotfload によってどのように処理されるかについてはよく知りませんが、のおかげでフィールドを取得する方法を見つけることができましたtable.serialize。そのため、Harfbuzz 用に適合させた元のコードは次のようになります。

\documentclass{article}
\usepackage[lmargin=0.5in,tmargin=0.5in,rmargin=0.5in,bmargin=0.5in]{geometry}
\usepackage{fontspec}
\usepackage{microtype}
\usepackage{luacode}

%\newfontscript{Devanagari}{deva,dev2}
\newfontfamily{\devanagarifam}{Noto Sans Devanagari}[Script=Devanagari, Scale=1, Renderer=HarfBuzz]
\newfontfamily{\arabicfam}{Amiri}[Script=Arabic, Scale=1, Renderer=HarfBuzz]

\begin{document}

\setbox0=\hbox{Příliš žluťoučký \textit{kůň} úpěl \hbox{ďábelské} ódy difference diffierence. \devanagarifam एक गांव -- में मोहन नाम का लड़का रहता था। उसके पिताजी एक मामूली मजदूर थे।}
\setbox1=\hbox{\arabicfam \textdir TRT  هذه المقالة عن براغ. لتصفح عناوين مشابهة، انظر براغ (توضيح).}

\begin{luacode*}
  -- local fontstyles = require "l4fontstyles"
  local char = unicode.utf8.char
  local glyph_id = node.id("glyph")
  local glue_id  = node.id("glue")
  local hlist_id = node.id("hlist")
  local vlist_id = node.id("vlist")
  local disc_id  = node.id("disc")
  local minglue  = tex.sp("0.2em")
  local usedcharacters = {}
  local identifiers = fonts.hashes.identifiers
  local fontcache = {}

  local function to_unicode_chars(uchar)
    local uchar = uchar or ""
    -- put characters into a table
    local current = {}
    -- each codepoint is 4 bytes long, we loop over tounicode entry and cut it into 4 bytes chunks
    for i= 1, string.len(uchar), 4 do
      local cchar = string.sub(uchar, i, i + 3)
      -- codepoint is hex string, we need to convert it to number ad then to UTF8 char
      table.insert(current,char(tonumber(cchar,16)))
    end
    return current
  end
  -- cache character lookup, to speed up things
  local function get_character_from_cache(xchar, font_id)
    local current_font = fontcache[font_id] or {characters = {}}
    fontcache[font_id] = current_font -- initialize font cache for the current font if it doesn't exist
    return current_font.characters[xchar]
  end

  -- save characters to cache for faster lookup
  local function save_character_to_cache(xchar, font_id, replace)
    fontcache[font_id][xchar] = replace
    -- return value
    return replace
  end

  local function initialize_harfbuzz_cache(font_id, hb)
    -- save some harfbuzz tables for faster lookup
    local current_font = fontcache[font_id]
    -- the unicode data can be in two places
    -- 1. hb.shared.glyphs[glyphid].backmap
    current_font.glyphs = current_font.glyphs or hb.shared.glyphs
    -- 2. hb.shared.unicodes
    -- it contains mapping between Unicode and glyph id
    -- we must create new table that contains reverse mapping
    if not current_font.backmap then
      current_font.backmap = {}
      for k,v in pairs(hb.shared.unicodes) do
        current_font.backmap[v] = k
      end
    end
    -- save it back to the font cache
    fontcache[font_id] = current_font
    return current_font.glyphs, current_font.backmap
  end

  local function get_unicode(xchar,font_id)
    -- try to load character from cache first
    local current_char = get_character_from_cache(xchar, font_id)
    if current_char then return current_char end
    -- get tounicode for non HarfBuzz fonts
    local characters = identifiers[font_id].characters
    local uchar = characters[xchar].tounicode
    -- stop processing if tounicode exists
    if uchar then return save_character_to_cache(xchar, font_id, to_unicode_chars(uchar)) end
    -- detect if font is processed by Harfbuzz
    local hb = identifiers[font_id].hb
    -- try HarfBuzz data
    if not uchar and hb then
      -- get glyph index of the character
      local index = characters[xchar].index
      -- load HarfBuzz tables from cache
      local glyphs, backmap = initialize_harfbuzz_cache(font_id, hb)
      -- get tounicode field from HarfBuzz glyph info
      local tounicode = glyphs[index].tounicode
      if tounicode then
        return save_character_to_cache(xchar, font_id, to_unicode_chars(tounicode))
      end
      -- if this fails, try backmap, which contains mapping between glyph index and Unicode
      local backuni = backmap[index]
      if backuni then
        return save_character_to_cache(xchar, font_id, {char(backuni)})
      end
      -- if this fails too, discard this character
      return save_character_to_cache(xchar, font_id, {})
    end
    -- return just the original char if everything else fails
    return save_character_to_cache(xchar, font_id, {char(xchar)})
  end

  local function nodeText(n)
    -- output buffer
    local t =  {}
    for x in node.traverse(n) do
      -- glyph node
      if x.id == glyph_id then
        -- get table with characters for current node.char
        local chars = get_unicode(x.char,x.font)
        for _, current_char in ipairs(chars) do
          -- save characters to the output buffer
          table.insert(t,current_char)
        end
      -- glue node
      elseif x.id == glue_id and  node.getglue(x) > minglue then
        table.insert(t," ")
      -- discretionaries
      elseif x.id == disc_id then
        table.insert(t, nodeText(x.replace))
      -- recursivelly process hlist and vlist nodes
      elseif x.id == hlist_id or x.id == vlist_id then
        table.insert(t,nodeText(x.head))
      end
    end
    return table.concat(t)
  end
  local n = tex.getbox(0)
  local n1 = tex.getbox(1)
  print(nodeText(n.head))
  local f = io.open("hello.txt","w")
  f:write(nodeText(n.head))
  f:write(nodeText(n1.head))
  f:close()
\end{luacode*}

\box0

\box1
\end{document}

アラビア語のサンプルも追加しましたウィキペディア. の内容は次のとおりですhello.txt:

Příliš žluťoučký kůň úpěl ďábelské ódy difference diffierence. एक गांव -- में मोहन नाम का लड़का रहता था। उसके पताजी एक मामूली मजदूर थे।هذه المقالة عن براغ. لتصفح عناوين مشابهة، انظر براغ (توضيح).

2つの重要な機能は次の通りです

  local function to_unicode_chars(uchar)
    local uchar = uchar or ""
    local current = {}
    for i= 1, string.len(uchar), 4 do
      local cchar = string.sub(uchar, i, i + 3)
      table.insert(current,char(tonumber(cchar,16)))
    end
    return current
  end

to_unicode_charsこの関数は to_unicode エントリを 4 バイトのチャンクに分割し、それを UTF 8 文字に変換します。エントリのないグリフも処理できますがtounicode、この場合は空の文字列を返します。

  local function get_unicode(xchar,font_id)
    -- try to load character from cache first
    local current_char = get_character_from_cache(xchar, font_id)
    if current_char then return current_char end
    -- get tounicode for non HarfBuzz fonts
    local characters = identifiers[font_id].characters
    local uchar = characters[xchar].tounicode
    -- stop processing if tounicode exists
    if uchar then return save_character_to_cache(xchar, font_id, to_unicode_chars(uchar)) end
    -- detect if font is processed by Harfbuzz
    local hb = identifiers[font_id].hb
    -- try HarfBuzz data
    if not uchar and hb then
      -- get glyph index of the character
      local index = characters[xchar].index
      -- load HarfBuzz tables from cache
      local glyphs, backmap = initialize_harfbuzz_cache(font_id, hb)
      -- get tounicode field from HarfBuzz glyph info
      local tounicode = glyphs[index].tounicode
      if tounicode then
        return save_character_to_cache(xchar, font_id, to_unicode_chars(tounicode))
      end
      -- if this fails, try backmap, which contains mapping between glyph index and Unicode
      local backuni = backmap[index]
      if backuni then
        return save_character_to_cache(xchar, font_id, {char(backuni)})
      end
      -- if this fails too, discard this character
      return save_character_to_cache(xchar, font_id, {})
    end
    -- return just the original char if everything else fails
    return save_character_to_cache(xchar, font_id, {char(xchar)})
  end

この関数は、まず現在のフォント情報から Uniocode データをロードしようとします。失敗した場合は、Harfbuzz テーブルで検索を試みます。ほとんどの文字はテーブルtounicode内にマッピングされていますglyphs。それが利用できない場合は、unicodesグリフ インデックスと Unicode 間のマッピングを含むテーブルを試します。それでも失敗した場合は、この文字を破棄します。

関連情報
