私が欲しいのはこれです:
現在私が持っているものは次のとおりです:
\documentclass{report}
\usepackage{wrapfig}
\usepackage{multicol}
\usepackage{import}
\pdfminorversion=7
\usepackage{pdfpages}
\usepackage{transparent}
\newcommand{\incfig}[2][]{%
\def\svgwidth{#1\columnwidth}
\import{./figures/}{#2.pdf_tex}
}
\begin{document}
Copy each of the following expressions onto your paper and either state the
value or state that the value is undefined or doesn't exist. Make sure that
when discussing the values you use proper terminology. All expressions are in
reference to the function $g$ shown in Figure~\ref{fig:limit_graph}.
\begin{wrapfigure}{r}{0.4\linewidth}
\centering
\caption{$y = g(x)$}
\incfig[0.4]{limit-graph}
\label{fig:limit_graph}
\end{wrapfigure}
$ $
\begin{multicols}{2}
\begin{enumerate}
\item[\textbf{2.)}] $g(5)$.
\vspace{2cm}
\item[\textbf{10.)}] $g(-2)$.
\vspace{2cm}
\item[\textbf{12.)}] $\lim_{x \to 2^{+}} g(t)$.
\vspace{2cm}
\end{enumerate}\columnbreak\begin{enumerate}
\item[\textbf{3.)}] $\lim_{t \to 5} g(t)$.
\vspace{2cm}
\item[\textbf{11.)}] $\lim_{t \to 2^{-}} g(t)$.
\vspace{2cm}
\item[\textbf{13.)}] $\lim_{x \to -2} g(t)$.
\vspace{2cm}
\end{enumerate}
\end{multicols}
Create tables similar to Tables 2.1.3 and 2.1.4 from which you can deduce
each of the following limit values. Make sure that you include table numbers,
table captions, and meaningful column headings. Make sure that your input
values follow patterns similar to those used in Tables 2.1.3 and 2.1.3. Make
sure that you round your output values in such a way that a clear and
compelling pattern in the output is clearly demonstrated by your stated
values. Make sure that you state the limit value!
[\textbf{\textit{2pts}}] \\\\
\textbf{19.)} $\displaystyle\lim_{x \to 1^{+}} \frac{\sin(x + 1)}{3x + 3}$.
\end{document}
しかし、出力は次のようになります。
何が間違っているのでしょうか?
答え1
タスクパッケージを使用してグラフをミニページに配置することを提案します
%https://tex.stackexchange.com/questions/661529/place-figure-next-to-two-enumerate-enivronments-side-by-side
\documentclass{report}
\usepackage{tasks}
\usepackage{graphicx}
\parindent=0pt
\settasks{label=\bfseries\arabic*.),label-width=2em}
\begin{document}
Copy each of the following expressions onto your paper and either state the
value or state that the value is undefined or doesn't exist. Make sure that
when discussing the values you use proper terminology. All expressions are in
reference to the function $g$ shown in Figure.
\begin{minipage}[t]{0.6\linewidth}
\vspace{0pt}
\begin{tasks}[start=2](2)
\task $g(5)$.
\vspace{2cm}
\task $g(-2)$.
\vspace{2cm}
\end{tasks}
\begin{tasks}[start=10](2)
\task $\lim_{x \to 2^{+}} g(t)$.
\vspace{2cm}
\task $\lim_{t \to 5} g(t)$.
\vspace{2cm}
\task $\lim_{t \to 2^{-}} g(t)$.
\vspace{2cm}
\task $\lim_{x \to -2} g(t)$.
\vspace{2cm}
\end{tasks}
\end{minipage}%
\begin{minipage}[t]{0.4\linewidth}
\vspace{0pt}
\centering
\includegraphics[width=\linewidth]{example-image-duck}
$y = g(x)$
\end{minipage}
Create tables similar to Tables 2.1.3 and 2.1.4 from which you can deduce
each of the following limit values. Make sure that you include table numbers,
table captions, and meaningful column headings. Make sure that your input
values follow patterns similar to those used in Tables 2.1.3 and 2.1.3. Make
sure that you round your output values in such a way that a clear and
compelling pattern in the output is clearly demonstrated by your stated
values. Make sure that you state the limit value!
[\textbf{\textit{2pts}}]
\begin{tasks}[start=19](2)
\task $\displaystyle\lim_{x \to 1^{+}} \frac{\sin(x + 1)}{3x + 3}$.
\end{tasks}
\end{document}
編集2問題領域 paracol によるより良い解決策。
パッケージのデバッグオプションは非常に興味深い
%https://tex.stackexchange.com/questions/661529/place-figure-next-to-two-enumerate-enivronments-side-by-side
\documentclass{report}
\usepackage{graphicx}
\usepackage{tasks}
\usepackage{paracol}
\parindent=0pt
\settasks{label=\bfseries\arabic*.),label-width=2em,before-skip = 0pt,after-skip=2cm,after-item-skip = 2cm,debug}
%\settasks{label=\bfseries\arabic*.),label-width=2em,before-skip = 0pt,after-skip=2cm,after-item-skip = 2cm}
\begin{document}
Copy each of the following expressions onto your paper and either state the
value or state that the value is undefined or doesn't exist. Make sure that
when discussing the values you use proper terminology. All expressions are in
reference to the function $g$ shown in Figure~\ref{fig:limit_graph}.
\smallskip
\begin{paracol}{2}
\begin{tasks}[start=2](2)
\task $g(5)$.
\task $g(-2)$.
\end{tasks}
\begin{tasks}[start=10](2)
\task $\lim_{x \to 2^{+}} g(t)$.
\task $\lim_{t \to 5} g(t)$.
\task $\lim_{t \to 2^{-}} g(t)$.
\task $\lim_{x \to -2} g(t)$.
\end{tasks}
\switchcolumn
\begin{figure}
\includegraphics[width=\linewidth,height=7cm]{example-image-duck}
\caption{$y = g(x)$}
\label{fig:limit_graph}
\end{figure}
\end{paracol}
Create tables similar to Tables 2.1.3 and 2.1.4 from which you can deduce
each of the following limit values. Make sure that you include table numbers,
table captions, and meaningful column headings. Make sure that your input
values follow patterns similar to those used in Tables 2.1.3 and 2.1.3. Make
sure that you round your output values in such a way that a clear and
compelling pattern in the output is clearly demonstrated by your stated
values. Make sure that you state the limit value!
[\textbf{\textit{2pts}}]
\begin{tasks}[start=19]
\task $\displaystyle\lim_{x \to 1^{+}} \frac{\sin(x + 1)}{3x + 3}$.
\end{tasks}
\end{document}
答え2
これが私の解決策です:
\documentclass{report}
\usepackage{wrapfig}
\usepackage{multicol}
\usepackage{import}
\pdfminorversion=7
\usepackage{pdfpages}
\usepackage{transparent}
\newcommand{\incfig}[2][]{%
\def\svgwidth{#1\columnwidth}
\import{./figures/}{#2.pdf_tex}
}
\begin{document}
Copy each of the following expressions onto your paper and either state the
value or state that the value is undefined or doesn't exist. Make sure that
when discussing the values you use proper terminology. All expressions are in
reference to the function $g$ shown in Figure~\ref{fig:limit_graph}.
\begin{wrapfigure}[7]{r}{0.4\linewidth}
\centering
\incfig[0.4]{limit-graph}
\caption{$y = g(x)$}
\label{fig:limit_graph}
\end{wrapfigure}
$ $
\begin{multicols}{2}
\begin{enumerate}
\item[\textbf{2.)}] $g(5)$.
\vspace{2cm}
\item[\textbf{10.)}] $g(-2)$.
\vspace{2cm}
\item[\textbf{12.)}] $\lim_{x \to 2^{+}} g(t)$.
\vspace{2cm}
\end{enumerate}\columnbreak\begin{enumerate}
\item[\textbf{3.)}] $\lim_{t \to 5} g(t)$.
\vspace{2cm}
\item[\textbf{11.)}] $\lim_{t \to 2^{-}} g(t)$.
\vspace{2cm}
\item[\textbf{13.)}] $\lim_{x \to -2} g(t)$.
\vspace{2cm}
\end{enumerate}
\end{multicols}
\vspace{1.1cm}
Create tables similar to Tables 2.1.3 and 2.1.4 from which you can deduce
each of the following limit values. Make sure that you include table numbers,
table captions, and meaningful column headings. Make sure that your input
values follow patterns similar to those used in Tables 2.1.3 and 2.1.3. Make
sure that you round your output values in such a way that a clear and
compelling pattern in the output is clearly demonstrated by your stated
values. Make sure that you state the limit value!
[\textbf{\textit{2pts}}] \\\\
\textbf{19.)} $\displaystyle\lim_{x \to 1^{+}} \frac{\sin(x + 1)}{3x + 3}$.
\end{document}
出力は次のとおりです。
wrapfigureあまり変更していません。キャプションの位置を変更し、次の段落に折り返されないように、折り返す行数を明示的に指定しただけです。
