測定計算にもかかわらず、「測定単位が正しくありません (pt が挿入されました)」?

測定計算にもかかわらず、「測定単位が正しくありません (pt が挿入されました)」?

ヒントに従ってこの答え@JasperHabricht さん、次のマクロを改善しようとしていますが、Illegal unit of measure (pt inserted)測定計算が行われ、他のマクロで使用する前はすべて正常に動作していたにもかかわらず、しか表示されません。また、はい、と を に\pgfmathsetmacro置き換えてみました。\newlength\setlength\pgfmathsetmacro

\newcounter{coordinateCounter}
\setcounter{coordinateCounter}{1}
\newlength{\coordinateShift}
\newlength{\leftRightShift}
\newlength{\topBottomShift}
% Parameters
%
% 1: dimension (in cm)
% 2: board size (square)
% 3: step
%
% Example: A 19x19 board with size 10cm x 10cm: `\coordinates{10}{19}{\step}'
\newcommand{\coordinates}[3]{
  % For some reason, TeX doesn't like dividin by non-integers?
  \setlength{\leftRightShift}{\dimexpr #3 * 10 / 14 \relax}
  \setlength{\topBottomShift}{\dimexpr #3 * 10 / 15 \relax}

  \foreach [count=\i] \l in {A, B, ..., Z} {
    \ifthenelse{\equal{\l}{I} \OR \i > \numexpr #2 + 1 \relax}{}{
      \setlength{\coordinateShift}{\dimexpr #3 * (\thecoordinateCounter - 1) \relax}

      % Top
      \draw[
        xshift = \coordinateShift,
        yshift = #1cm + \topBottomShift,
      ] node {\l};
      % Right
      \draw[
        xshift = #1cm + \leftRightShift,
        yshift = \coordinateShift,
      ] node {\thecoordinateCounter};
      % Bottom
      \draw[
        xshift = \coordinateShift,
        yshift = -(\leftRightShift),
      ] node {\l};
      % Left
      \draw[
        xshift = -(\leftRightShift),
        yshift = \coordinateShift,
      ] node {\thecoordinateCounter};

      \stepcounter{coordinateCounter}
    }
  }
  \setcounter{coordinateCounter}{1}
}

完全な最小限の例:

\documentclass{article}

\usepackage{tikz}
\usepackage{ifthen}

% Parameters
%
% 1: dimension (in cm)
% 2: board size (square)
%
% Example: A 19x19 board with size 10cm x 10cm: `\gogrid{10}{19}'
\newcommand{\goGrid}[2]{
  \pgfmathsetmacro{\step}{#1 / (#2 - 1)} % chktex 1

  \draw[step=\step] (0, 0) grid (#1, #1);

  \boardOutline{#1}

  \coordinates{#1}{#2}{\step} % chktex 1

  \drawHoshis{#1}{#2}{\step}
}

% Parameters
%
% 1: dimension (in cm)
% 2: board size (square)
% 3: step
%
% Example: A 19x19 board with size 10cm x 10cm: `\drawHoshis{10}{19}{\step}'
\newcommand{\drawHoshis}[3]{
  \ifnum#2=9\relax
    \foreach \sloc in {{3, 3}, {3, 7}, {7, 3}, {7, 7}, {5, 5}}{
      \pgfmathsetmacro{\hoshiCoordX}{#3 * ({\sloc}[0] - 1)}
      \pgfmathsetmacro{\hoshiCoordY}{#3 * ({\sloc}[1] - 1)}

      \filldraw (\hoshiCoordX, \hoshiCoordY)
        circle [radius=#3 / 10];
    }
  \fi
}

% Parameters
%
% 1: dimension (in cm)
%
% Example: \boardOutline{10}
\newcommand{\boardOutline}[1]{
  \pgfmathsetmacro{\boardOutlineLineWidth}{#1 * 5 / 1000}
  % Just so the board outline isn't jagged
  \pgfmathsetmacro{\boardOutlinePadding}{\boardOutlineLineWidth / 2}

  % Top
  \draw[black, line width = \boardOutlineLineWidth]
    (-\boardOutlinePadding, #1) -- (#1 + \boardOutlinePadding, #1); % chktex 1 chktex 8
  % Right
  \draw[black, line width = \boardOutlineLineWidth]
    (#1, 0) -- (#1, #1); % chktex 8
  % Bottom
  \draw[black, line width = \boardOutlineLineWidth]
    (-\boardOutlinePadding, 0) -- (#1 + \boardOutlinePadding, 0); % chktex 1 chktex 8
  % Left
  \draw[black, line width = \boardOutlineLineWidth]
    (0, 0) -- (0, #1); % chktex 8
}

\newcounter{coordinateCounter}
\setcounter{coordinateCounter}{1}
\newlength{\coordinateShift}
\newlength{\leftRightShift}
\newlength{\topBottomShift}
% Parameters
%
% 1: dimension (in cm)
% 2: board size (square)
% 3: step
%
% Example: A 19x19 board with size 10cm x 10cm: `\coordinates{10}{19}{\step}'
\newcommand{\coordinates}[3]{
  % For some reason, TeX doesn't like dividin by non-integers?
  \setlength{\leftRightShift}{\dimexpr #3 * 10 / 14 \relax}
  \setlength{\topBottomShift}{\dimexpr #3 * 10 / 15 \relax}

  \foreach [count=\i] \l in {A, B, ..., Z} {
    \ifthenelse{\equal{\l}{I} \OR \i > \numexpr #2 + 1 \relax}{}{
      \setlength{\coordinateShift}{\dimexpr #3 * (\thecoordinateCounter - 1) \relax}

      % Top
      \draw[
        xshift = \coordinateShift,
        yshift = #1cm + \topBottomShift,
      ] node {\l};
      % Right
      \draw[
        xshift = #1cm + \leftRightShift,
        yshift = \coordinateShift,
      ] node {\thecoordinateCounter};
      % Bottom
      \draw[
        xshift = \coordinateShift,
        yshift = -(\leftRightShift),
      ] node {\l};
      % Left
      \draw[
        xshift = -(\leftRightShift),
        yshift = \coordinateShift,
      ] node {\thecoordinateCounter};

      \stepcounter{coordinateCounter}
    }
  }
  \setcounter{coordinateCounter}{1}
}

\begin{document}
  \begin{figure}[ht]
    \begin{center}
      \begin{tikzpicture}
        \goGrid{5}{9}
      \end{tikzpicture}
      \caption{Goban 1}\label{my_goban_1}
    \end{center}
  \end{figure}
\end{document}

答え1

例から100行ほど削除することもできます。エラーメッセージはエラーの場所を強調表示します。

! Illegal unit of measure (pt inserted).
<to be read again>
                   *

あなたが持っている

\setlength{\leftRightShift}{\dimexpr #3 * 10 / 14 \relax}

この時点で、#3それ\stepは本質的に次のように定義されます

\def\step{0.625}

エラー メッセージにあるように、この式には単位がありません。

たとえば、次のいずれかを使用できます。

\pgfmathsetmacro{\leftRightShift}{#3 * 10 / 14}

あるいはこれ:

\setlength{\leftRightShift}{\dimexpr #3cm * 10 / 15 \relax}
