DirectAccess サーバーをセットアップするのは今回が初めてです。サーバー上でウィザードを完了し、すべてが完了し、エラーなしで実行されています。ラップトップは正常に接続できません。ネットワーク名は表示されますが、"接続中" 状態のままです。
トラブルシューティングの一環として、ウィザードのいくつかの手順を変更し、ネットワーク名を指定しました。私のラップトップでは、元の DA ネットワーク名のみが必要で、新しい名前は必要ありません。これまで一度も正常に接続できなかったことに注意してください。
これは、DA サーバーから接続できる別の NLS サーバーで構成されています。DA サーバーは、単一のネットワーク アダプターを使用します。
Netsh インターフェース httpstunnel インターフェースの表示エラーコード0x0が表示され、インターフェースはアクティブです。名前解決失敗のためにDA 接続ステータス Netsh dnsclient 状態を表示DirectAccessと設定および有効化企業ネットワーク外のクライアントと
以下は、DA クライアント トラブルシューターの出力です。トラブルシューティングに関しては、文字通りアイデアが尽きています。おそらく私が見逃している明らかな何かかもしれませんが、どんな助けでもいただければ幸いです。
[23/02/2015 10:48:45]: Running Inside/Outside location tests.<br>
[23/02/2015 10:48:45]: NLS is hxxps://nls.xxxxxxxxxxxxx.local/.<br>
[23/02/2015 10:48:46]: NLS is not reachable via HTTPS, the client computer is not connected to the corporate network (external) or the NLS is offline.<br>
[23/02/2015 10:48:46]: NRPT contains 2 rules.<br>
[23/02/2015 10:48:46]: Found (unique) DNS server: fdcd:c700:98ec:3333::1<br>
[23/02/2015 10:48:46]: Send an ICMP message to check if the server is reachable.<br>
[23/02/2015 10:48:58]: DNS Server fdcd:c700:98ec:3333::1 does not reply on ICMP Echo requests.<br>
[23/02/2015 10:48:58]: Running IP connectivity tests.<br>
[23/02/2015 10:49:04]: The 6to4 interface is disabled.<br>
[23/02/2015 10:49:04]: Teredo inferface status is offline.<br>
[23/02/2015 10:49:04]: The configured DirectAccess Teredo server is win8.ipv6.microsoft.com..<br>
[23/02/2015 10:49:04]: The IPHTTPS interface is operational.<br>
[23/02/2015 10:49:04]: The IPHTTPS interface status is IPHTTPS interface active.<br>
[23/02/2015 10:49:04]: IPHTTPS is used as IPv6 transition technology.<br>
[23/02/2015 10:49:04]: The configured IPHTTPS URL is hxxps://directa.xxxxxxxxxx.com:443.<br>
[23/02/2015 10:49:04]: IPHTTPS has a single site configuration.<br>
[23/02/2015 10:49:04]: IPHTTPS URL endpoint is: hxxps://directa.xxxxxxxxxx.com:443.<br>
[23/02/2015 10:49:05]: Successfully connected to endpoint hxxps://directa.xxxxxxxxxx.com:443.<br>
[23/02/2015 10:49:05]: No response received from xxxxxxxxxx.local.<br>
[23/02/2015 10:49:05]: Running Windows Firewall tests.<br>
[23/02/2015 10:49:05]: The current profile of the Windows Firewall is Public.<br>
[23/02/2015 10:49:05]: The Windows Firewall is enabled in the current profile Public.<br>
[23/02/2015 10:49:06]: The outbound Windows Firewall rule Core Networking - Teredo (UDP-Out) is enabled.<br>
[23/02/2015 10:49:06]: The outbound Windows Firewall rule Core Networking - IPHTTPS (TCP-Out) is enabled.<br>
[23/02/2015 10:49:06]: Running certificate tests.<br>
[23/02/2015 10:49:06]: Found 1 machine certificates on this client computer.<br>
[23/02/2015 10:49:06]: Checking certificate CN=xxxxx-xxxxx.xxxxxxxxxxxx.local with the serial number [5BC7E01767145B8E403BF44D3234AFD6].<br>
[23/02/2015 10:49:06]: The certificate [5BC7E01767145B8E403BF44D3234AFD6] contains the EKU Client Authentication.<br>
[23/02/2015 10:49:06]: The trust chain for the certificate [5BC7E01767145B8E403BF44D3234AFD6] was sucessfully verified.<br>
