94GB の RAM と 24 個の CPU コアを持つサーバーが 40 の同時接続を処理できないという問題に対処しています。abツールを使用して、一度に 40 のリクエストを送信しています。
ab -n 40 -c 40 http://ip-address/
最初のリクエストはすぐに完了します。
Concurrency Level: 40
Time taken for tests: 1.951 seconds
Complete requests: 40
Failed requests: 0
Non-2xx responses: 40
Total transferred: 20280 bytes
HTML transferred: 0 bytes
Requests per second: 20.50 [#/sec] (mean)
Time per request: 1951.311 [ms] (mean)
Time per request: 48.783 [ms] (mean, across all concurrent requests)
Transfer rate: 10.15 [Kbytes/sec] received
Connection Times (ms)
min mean[+/-sd] median max
Connect: 27 73 28.7 75 120
Processing: 540 1008 129.6 998 1256
Waiting: 536 1007 129.9 998 1255
Total: 575 1081 153.1 1071 1376
Percentage of the requests served within a certain time (ms)
50% 1071
66% 1177
75% 1208
80% 1237
90% 1261
95% 1322
98% 1376
99% 1376
100% 1376 (longest request)
しかし、同じコマンドをもう一度実行すると、接続がタイムアウトになります。次の数分間はサーバーに SSH 接続できなくなります。
リクエストを送信しているページは、748 SELECTクエリを含む 760 クエリを実行します。MariaDBmax_connectionsを設定しており500、PHP-FPM プールの構成は次のとおりです。
listen = 127.0.0.1:9000
listen.allowed_clients = 127.0.0.1
listen.owner = nginx
listen.group = nginx
listen.mode = 0660
user = xxxx ; modified
group = xxxx ; modified
pm = ondemand
pm.max_children = 1000
pm.start_servers = 200
pm.min_spare_servers = 50
pm.max_spare_servers = 100
pm.max_requests = 500
request_terminate_timeout = 100s
pm.process_idle_timeout = 3s
php_admin_value[error_log] = /var/log/php-fpm/pool-error.log
php_admin_flag[log_errors] = on
php_value[session.save_handler] = files
php_value[session.save_path] = /var/lib/php/session
設定したpmので、もう適用されないondemandと思います。max_children
私も SELinux の操作に苦労しました。これが原因でしょうか?
アップデート
出力mysqltuner.pl:
Currently running supported MySQL version 10.4.6-MariaDB
[OK] Operating on 64-bit architecture
-------- Log file Recommendations ------------------------------------------------------------------
[--] Log file: /var/lib/mysql/localhost.localdomain.err(0B)
[!!] Log file /var/lib/mysql/localhost.localdomain.err doesn't exist
[!!] Log file /var/lib/mysql/localhost.localdomain.err isn't readable.
-------- Storage Engine Statistics -----------------------------------------------------------------
[--] Status: +Aria +CSV +InnoDB +MEMORY +MRG_MyISAM +MyISAM +PERFORMANCE_SCHEMA +SEQUENCE
[--] Data in MyISAM tables: 72.0K (Tables: 12)
[--] Data in InnoDB tables: 1.9G (Tables: 449)
[--] Data in MEMORY tables: 0B (Tables: 17)
[OK] Total fragmented tables: 0
-------- Analysis Performance Metrics --------------------------------------------------------------
[--] innodb_stats_on_metadata: OFF
[OK] No stat updates during querying INFORMATION_SCHEMA.
-------- Security Recommendations ------------------------------------------------------------------
[OK] There are no anonymous accounts for any database users
[OK] All database users have passwords assigned
[!!] There is no basic password file list!
-------- CVE Security Recommendations --------------------------------------------------------------
[--] Skipped due to --cvefile option undefined
-------- Performance Metrics -----------------------------------------------------------------------
[--] Up for: 3m 0s (15K q [85.489 qps], 401 conn, TX: 44M, RX: 4M)
[--] Reads / Writes: 99% / 1%
[--] Binary logging is disabled
[--] Physical Memory : 94.2G
[--] Max MySQL memory : 154.1G
[--] Other process memory: 0B
[--] Total buffers: 50.4G global + 52.7M per thread (2000 max threads)
[--] P_S Max memory usage: 867M
[--] Galera GCache Max memory usage: 0B
[OK] Maximum reached memory usage: 69.0G (73.22% of installed RAM)
[!!] Maximum possible memory usage: 154.1G (163.47% of installed RAM)
[!!] Overall possible memory usage with other process exceeded memory
[OK] Slow queries: 0% (0/15K)
[OK] Highest usage of available connections: 17% (346/2000)
[OK] Aborted connections: 0.50% (2/401)
[OK] Query cache is disabled by default due to mutex contention on multiprocessor machines.
[OK] Sorts requiring temporary tables: 0% (0 temp sorts / 1K sorts)
[!!] Joins performed without indexes: 47
[!!] Temporary tables created on disk: 55% (519 on disk / 927 total)
[!!] Thread cache hit rate: 13% (346 created / 401 connections)
[OK] Table cache hit rate: 98% (589 open / 595 opened)
[OK] Open file limit used: 1% (81/8K)
[OK] Table locks acquired immediately: 100% (552 immediate / 552 locks)
-------- Performance schema ------------------------------------------------------------------------
[--] Memory used by P_S: 867.5M
[--] Sys schema isn't installed.
-------- ThreadPool Metrics ------------------------------------------------------------------------
[--] ThreadPool stat is enabled.
[--] Thread Pool Size: 24 thread(s).
[--] Using default value is good enough for your version (10.4.6-MariaDB)
-------- MyISAM Metrics ----------------------------------------------------------------------------
[!!] Key buffer used: 18.2% (24M used / 134M cache)
[OK] Key buffer size / total MyISAM indexes: 128.0M/23.0K
-------- InnoDB Metrics ----------------------------------------------------------------------------
[--] InnoDB is enabled.
[--] InnoDB Thread Concurrency: 0
[OK] InnoDB File per table is activated
[OK] InnoDB buffer pool / data size: 50.0G/1.9G
[OK] Ratio InnoDB log file size / InnoDB Buffer pool size: 6.0G * 2/50.0G should be equal to 25%
[OK] InnoDB buffer pool instances: 50
[--] Number of InnoDB Buffer Pool Chunk : 400 for 50 Buffer Pool Instance(s)
[OK] Innodb_buffer_pool_size aligned with Innodb_buffer_pool_chunk_size & Innodb_buffer_pool_instances
[OK] InnoDB Read buffer efficiency: 99.92% (31587444 hits/ 31612740 total)
[!!] InnoDB Write Log efficiency: 168.97% (49 hits/ 29 total)
[OK] InnoDB log waits: 0.00% (0 waits / 78 writes)
-------- AriaDB Metrics ----------------------------------------------------------------------------
[--] AriaDB is enabled.
[OK] Aria pagecache size / total Aria indexes: 128.0M/2.5M
[OK] Aria pagecache hit rate: 99.1% (59K cached / 542 reads)
-------- TokuDB Metrics ----------------------------------------------------------------------------
[--] TokuDB is disabled.
-------- XtraDB Metrics ----------------------------------------------------------------------------
[--] XtraDB is disabled.
-------- Galera Metrics ----------------------------------------------------------------------------
[--] Galera is disabled.
-------- Replication Metrics -----------------------------------------------------------------------
[--] Galera Synchronous replication: NO
[--] No replication slave(s) for this server.
[--] Binlog format: MIXED
[--] XA support enabled: ON
[--] Semi synchronous replication Master: OFF
[--] Semi synchronous replication Slave: OFF
[--] This is a standalone server
-------- Recommendations ---------------------------------------------------------------------------
General recommendations:
MySQL was started within the last 24 hours - recommendations may be inaccurate
Reduce your overall MySQL memory footprint for system stability
Dedicate this server to your database for highest performance.
Adjust your join queries to always utilize indexes
When making adjustments, make tmp_table_size/max_heap_table_size equal
Reduce your SELECT DISTINCT queries which have no LIMIT clause
Consider installing Sys schema from https://github.com/mysql/mysql-sys for MySQL
Consider installing Sys schema from https://github.com/good-dba/mariadb-sys for MariaDB
Variables to adjust:
*** MySQL's maximum memory usage is dangerously high ***
*** Add RAM before increasing MySQL buffer variables ***
join_buffer_size (> 50.0M, or always use indexes with JOINs)
tmp_table_size (> 100M)
max_heap_table_size (> 100M)
thread_cache_size (> 2000)
答え1
ベンチマークは難しい作業です。 2 つの異なるハードウェア/ソフトウェア構成を比較するのに優れたベンチマークもありますが、システムの絶対的な能力の現実的な推定値を返すのに優れたベンチマークはほとんどありません。
この例では、数ミリ秒以内に 40 個の同一の CPU バウンド クエリがサーバーに殺到したようです。コアが 24 個しかないため、プロセスはすぐに互いにつまずき始めました。ミリ秒のタイミングに注目してください: 575 1081 1376。これはつまずきを裏付けています。
最初のクエリが25番目のクエリが開始される前に575ms実行されるようにすると、処理は「永遠に」うまく進む可能性があります。これは約40毎秒一度に 40 個ではなく、
したがって、abリクエストを分散させることができれば (25 ミリ秒ごとに新しいリクエスト)、「問題はない」ことがわかるでしょう。
一方、Web ページの場合、575 ミリ秒は応答時間としては非常に長いです。高速化を目的として、関連するクエリを確認してみましょう。
現実には、HTTP リクエストは「同時」と「均等間隔」の間のどこかで Web サーバーに届きます。テストでは上限のみが示されました。
