クラスター内でポッドとして実行するようにボールトを設定しました。以下のデプロイメント YAML ファイルには、ポッドが最初に起動したときにボールトの初期化と封印解除が行われるように設定されています。ただし、ポッドが再起動されると、ボールトが再初期化されるため、ポッドは crashLoopBackOff 状態になります。これは、デプロイメント ファイルの postStart ライフサイクル コマンドに初期化コマンドと封印解除コマンドの両方を含めたためです。ポッドを 1 回だけ初期化し、後でポッドが再起動したときに、既存のキーを使用してボールトを封印解除する方法はありますか?
デプロイメントファイル:
apiVersion: extensions/v1beta1
kind: Deployment
metadata:
labels:
app: vault
name: vault
spec:
replicas: 1
template:
metadata:
labels:
app: vault
spec:
containers:
- image: vault
name: vault
imagePullPolicy: Always
ports:
- containerPort: 8200
name: vaultport
protocol: TCP
securityContext:
capabilities:
add:
- IPC_LOCK
env:
- name: VAULT_ADDR
value: "http://0.0.0.0:8200"
command: ["vault", "server"]
args:
- "-config=/vault/config/config.hcl"
volumeMounts:
- name: vault-unseal
mountPath: /vault/file/unseal.sh
subPath: unseal.sh
- name: vault-config
mountPath: /vault/config/config.hcl
subPath: config.hcl
lifecycle:
postStart:
exec:
command: ["/bin/sh", "-c", "vault operator init > /vault/file/keys.txt; sh /vault/file/unseal.sh" ]
volumes:
- name: vault-unseal
configMap:
name: vault-unseal
- name: vault-config
configMap:
name: vault-config
imagePullSecrets:
- name: regcred
kubectl describe pod の出力:
Name: vault-677bfd9c9c-dwsgv
Namespace: xxx
Priority: 0
Node: xxxxxxx-5b587f98-ljf4/10.0.0.11
Start Time: Thu, 30 Jan 2020 06:26:21 +0000
Labels: app=vault
pod-template-hash=677bfd9c9c
Annotations: <none>
Status: Running
IP: 10.4.2.10
IPs: <none>
Controlled By: ReplicaSet/vault-677bfd9c9c
Containers:
vault:
Container ID: xxxxxxxxxxx
Image: xxxxxxxxxxxxxxxx
Image ID: xxxxxxxxxxxxxxxxxxxxxxxxx
Port: 8200/TCP
Host Port: 0/TCP
Command:
vault
server
Args:
-config=/vault/config/config.hcl
State: Waiting
Reason: CrashLoopBackOff
Last State: Terminated
Reason: Completed
Exit Code: 0
Started: Thu, 30 Jan 2020 06:26:26 +0000
Finished: Thu, 30 Jan 2020 06:26:27 +0000
Ready: False
Restart Count: 1
Environment:
VAULT_ADDR: http://0.0.0.0:8200
Mounts:
/var/run/secrets/kubernetes.io/serviceaccount from default-token-kxfdb (ro)
/vault/config/config.hcl from vault-config (rw,path="config.hcl")
/vault/file from vault-data (rw)
/vault/file/unseal.sh from vault-unseal (rw,path="unseal.sh")
Conditions:
Type Status
Initialized True
Ready False
ContainersReady False
PodScheduled True
Volumes:
vault-unseal:
Type: ConfigMap (a volume populated by a ConfigMap)
Name: vault-unseal
Optional: false
vault-config:
Type: ConfigMap (a volume populated by a ConfigMap)
Name: vault-config
Optional: false
vault-data:
Type: PersistentVolumeClaim (a reference to a PersistentVolumeClaim in the same namespace)
ClaimName: vault-data
ReadOnly: false
default-token-kxfdb:
Type: Secret (a volume populated by a Secret)
SecretName: default-token-kxfdb
Optional: false
QoS Class: BestEffort
Node-Selectors: <none>
Tolerations: node.kubernetes.io/not-ready:NoExecute for 300s
node.kubernetes.io/unreachable:NoExecute for 300s
Events:
Type Reason Age From Message
---- ------ ---- ---- -------
Normal Scheduled 18s default-scheduler Successfully assigned xxx/xxxxxxxxxx
Normal Pulling 13s (x2 over 15s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 pulling image "xxxxxxxxx"
Normal Pulled 13s (x2 over 15s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Successfully pulled image "xxxxxxx"
Normal Created 13s (x2 over 15s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Created container
Normal Started 13s (x2 over 14s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Started container
Warning FailedPostStartHook 12s (x2 over 14s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Exec lifecycle hook ([/bin/sh -c vault operator init > /vault/file/keys.txt; sh /vault/file/unseal.sh]) for Container "vault" in Pod "vault-677bfd9c9c-dwsgv_xxx(6ebdc17a-4329-11ea-9fc1-4201c0a80004)" failed - error: command '/bin/sh -c vault operator init > /vault/file/keys.txt; sh /vault/file/unseal.sh' exited with 2: Error initializing: Error making API request.
URL: PUT http://0.0.0.0:8200/v1/sys/init
Code: 400. Errors:
* Vault is already initialized
An error occurred attempting to ask for an unseal key. The raw error message
is shown below, but usually this is because you attempted to pipe a value
into the unseal command or you are executing outside of a terminal (tty). You
should run the unseal command from a terminal for maximum security. If this
is not an option, the unseal key can be provided as the first argument to the
unseal command. The raw error was: file descriptor 0 is not a terminal
An error occurred attempting to ask for an unseal key. The raw error message
is shown below, but usually this is because you attempted to pipe a value
into the unseal command or you are executing outside of a terminal (tty). You
should run the unseal command from a terminal for maximum security. If this
is not an option, the unseal key can be provided as the first argument to the
unseal command. The raw error was: file descriptor 0 is not a terminal
An error occurred attempting to ask for an unseal key. The raw error message
is shown below, but usually this is because you attempted to pipe a value
into the unseal command or you are executing outside of a terminal (tty). You
should run the unseal command from a terminal for maximum security. If this
is not an option, the unseal key can be provided as the first argument to the
unseal command. The raw error was: file descriptor 0 is not a terminal
Token (will be hidden):
Error authenticating: An error occurred attempting to ask for a token. The raw error message is shown below, but usually this is because you attempted to pipe a value into the command or you are executing outside of a terminal (tty). If you want to pipe the value, pass "-" as the argument to read from stdin. The raw error was: file descriptor 0 is not a terminal
, message: "Unseal Key (will be hidden): \nUnseal Key (will be hidden): \nUnseal Key (will be hidden): \nKey Value\n--- -----\nSeal Type shamir\nInitialized true\nSealed true\nTotal Shares 5\nThreshold 3\nUnseal Progress 0/3\nUnseal Nonce n/a\nVersion 1.3.2\nHA Enabled false\n++++++++++++ Vault Status +++++++++\nKey Value\n--- -----\nSeal Type shamir\nInitialized true\nSealed true\nTotal Shares 5\nThreshold 3\nUnseal Progress 0/3\nUnseal Nonce n/a\nVersion 1.3.2\nHA Enabled false\nError initializing: Error making API request.\n\nURL: PUT http://0.0.0.0:8200/v1/sys/init\nCode: 400. Errors:\n\n* Vault is already initialized\nAn error occurred attempting to ask for an unseal key. The raw error message\nis shown below, but usually this is because you attempted to pipe a value\ninto the unseal command or you are executing outside of a terminal (tty). You\nshould run the unseal command from a terminal for maximum security. If this\nis not an option, the unseal key can be provided as the first argument to the\nunseal command. The raw error was: file descriptor 0 is not a terminal\nAn error occurred attempting to ask for an unseal key. The raw error message\nis shown below, but usually this is because you attempted to pipe a value\ninto the unseal command or you are executing outside of a terminal (tty). You\nshould run the unseal command from a terminal for maximum security. If this\nis not an option, the unseal key can be provided as the first argument to the\nunseal command. The raw error was: file descriptor 0 is not a terminal\nAn error occurred attempting to ask for an unseal key. The raw error message\nis shown below, but usually this is because you attempted to pipe a value\ninto the unseal command or you are executing outside of a terminal (tty). You\nshould run the unseal command from a terminal for maximum security. If this\nis not an option, the unseal key can be provided as the first argument to the\nunseal command. The raw error was: file descriptor 0 is not a terminal\nToken (will be hidden): \nError authenticating: An error occurred attempting to ask for a token. The raw error message is shown below, but usually this is because you attempted to pipe a value into the command or you are executing outside of a terminal (tty). If you want to pipe the value, pass \"-\" as the argument to read from stdin. The raw error was: file descriptor 0 is not a terminal\n"
Normal Killing 12s (x2 over 14s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Killing container with id docker://vault:FailedPostStartHook
Warning BackOff 10s (x2 over 11s) kubelet, gke-cluster-testing--np-testing-featu-5b587f98-ljf4 Back-off restarting failed container
答え1
はい、この場合、ボールトがすでに初期化されているかどうかを最初に確認するようにスクリプトをよりスマートにする必要があります。これはbashスクリプトを使った非常に簡単な例です。
また、これを実現するための一般的なパターンは、サイドカー (最終的には無期限に「スリープ」状態になる) を使用することですが、postStart
場合によってはボールト コンテナーが起動する前にスクリプトが実行され、最終的に両方が同期するまでボールト コンテナーが強制終了されて再起動されることを考慮して、スクリプトを十分に回復力のあるものにする限り、フックも機能するはずです。
強くお勧めしますセス・ヴァーゴによるこの講演自動初期化は、より複雑な Golang プログラムを使用して実行されます。
