grub の起動の問題; Arch Linux、Xen、DomU

2024-5-13 • tag-icon

私のDom0の内部

私のエラーログ:

sudo xl create /etc/xen/arkOS-Dev_PV.cfg

/var/log/xen/bootloader.1.log
   pyGRUB  version 0.6
 ┌────────────────────────────────────────────────────────────────────────┐
 │ Arch GNU/Linux, with Linux core repo kernel                            │
 │                                                                        │
 │                                                                        │
 │                                                                        │
 │                                                                        │
 │                                                                        │
 │                                                                        │
 │                                                                        │
 └────────────────────────────────────────────────────────────────────────┘
Use the ^ and ┴ keys to select which entry is highlighted.
Press enter to boot the selected OS, 'e' to edit the
commands before booting, 'a' to modify the kernel arguments
before booting, or 'c' for a command line.







[Errno 2] No such file or directory
Error opening /boot/vmlinuz-linux in guest

私の古い設定:

/etc/xen/ArkOS-Dev.cfg.old

name = 'ArkOS-Dev'
kernel = "/mnt/arch/boot/x86_64/vmlinuz"
ramdisk = "/mnt/arch/boot/x86_64/archiso.img"
extra = "archisobasedir=arch archisolabel=ARCH_201511"
memory = 512
disk = [ "phy:/dev/sda3,xvda,w", "file:/home/xen/ISO/archlinux-2015.11.01-dual.iso,xvdb:cdrom,r" ]
vif = [ 'mac=00:16:3e:49:2b:a1,bridge=xenbr0' ]

現在の設定:

/etc/xen/Arkos-Dev.cfg

name = 'ArkOS-Dev'
bootloader = "pygrub"
memory = 512
disk = [ "phy:/dev/sda3,xvda,w" ]
vif = [ 'mac=00:16:3e:49:2b:a1,bridge=xenbr0' ]

lsblk -f

NAME   FSTYPE LABEL UUID                                 MOUNTPOINT
sda
|-sda1 vfat         FF2C-B8A3                            /boot
|-sda2 btrfs        b3f4f40f-a8a1-4438-a187-dc02f2104340 /
|-sda3
`-sda4 swap         f90e6e95-5f00-4138-aa76-13feb4bce985 [SWAP]

マウント -o loop /home/xen/ISO/archlinux-201511.01-dual.iso /mnt ls /mnt -lah

total 26K
drwxr-xr-x 1 root root 2.0K Nov  1 09:34 .
drwxr-xr-x 1 root root  136 Oct 29 20:39 ..
drwxr-xr-x 1 root root 2.0K Nov  1 09:34 EFI
drwxr-xr-x 1 root root 2.0K Nov  1 09:35 arch
drwxr-xr-x 1 root root 2.0K Nov  1 09:34 isolinux
drwxr-xr-x 1 root root 2.0K Nov  1 09:34 loader

/dev/sda3 /mnt をマウントします

mount: wrong fs type, bad option, bad superblock on /dev/sda3,
       missing codepage or helper program, or other error

       In some cases useful info is found in syslog - try
       dmesg | tail or so.

私のDomU内部（古いセットアップ経由）

lsblk -f

http://pastebin.archlinux.fr/1717775

arch-chroot /mnt /bin/bash lsblk -f

http://pastebin.archlinux.fr/1717771

ls -lah /ブート

http://pastebin.archlinux.fr/1717772

私の grub ファイル:

ブートファイル

http://pastebin.archlinux.fr/1717774
