2 台の仮想マシン (kvm) に基本クラスターを展開し、そのうち 1 台をマスターとして指定し、その上にコントロール プレーンを使用しましたkubeadm init。すべてが正しく起動しているように見えますが、最も基本的なチェックを実行しようとすると、kubectl接続拒否エラーが発生します。
更新2:
動作はしましたが、理由がわかりません。もともと、sudo を使用してすべてを専用ユーザーとして実行していました。root に切り替えて (su root)、手順を繰り返すと、すべてが機能し始めました。変更の原因は何ですか。ユーザーではなく root 環境になったことと何らかの関係がありますか。ホーム ディレクトリが違うのですか。作業ディレクトリですか。わかりません。
更新 1: 最小限の失敗例:
今回はUbuntu 20.04を実行する別の仮想マシンを作成し、それをレプリカにしようとしました。このチュートリアル元の例にできるだけ近づけていますが、最後のステップは最初の問題と同じように失敗します。このチュートリアルは実際に完了していますか?
ステップごとに実行します:
curl https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key --keyring /usr/share/keyrings/cloud.google.gpg add -
echo "deb [signed-by=/usr/share/keyrings/cloud.google.gpg] https://apt.kubernetes.io/ kubernetes-xenial main" | sudo tee /etc/apt/sources.list.d/kubernetes.list
apt update
apt install -y kubelet=1.20.0-00 kubeadm=1.20.0-00 kubectl=1.20.0-00
apt-mark hold kubelet kubeadm kubectl
export VERSION=19.03 && curl -sSL get.docker.com | sh
cat <<EOF | sudo tee /etc/docker/daemon.json
{
"exec-opts": ["native.cgroupdriver=systemd"],
"log-driver": "json-file",
"log-opts": {
"max-size": "100m"
},
"storage-driver": "overlay2"
}
EOF
systemctl enable docker
systemctl daemon-reload
systemctl restart docker
kubeadm init --ignore-preflight-errors=all
>>> At this point everything fails - some service is missing?
環境についての詳細:
- ホストはUbuntu 20.04 LTSで、kvmを実行しています。
- ゲスト（k8sをインストールする場所）はUbuntuサーバー22.04です
- ホストネットワークは192.168.xyにあります
- VMのブリッジは10.0.1.x/24にあります
- UFWは非活性
通信網：
ip route show
- default via 10.0.1.254 dev ens3 proto static # これは、仮想マシンを外部の世界に接続するブリッジの一部です。
- 10.0.1.0/24 dev ens3 proto kernel scope link src 10.0.1.10 # これはマシンの IP です。ノードをホストしているマシンの IP は 11、12、13 などで終わります。
- 172.17.0.0/16 dev docker0 proto kernel scope link src 172.17.0.1 linkdown # docker によって自動生成 - 最新のネットマスク形式は苦手なので、docker /16 は問題ないと信じています。何もしていません。
cat /etc/hosts
primaryをホストに追加しました。残りは自動生成されます。
127.0.0.1 localhost
127.0.0.1 primary
127.0.1.1 k8-vm
# The following lines are desirable for IPv6 capable hosts
::1 ip6-localhost ip6-loopback
fe00::0 ip6-localnet
ff00::0 ip6-mcastprefix
ff02::1 ip6-allnodes
ff02::2 ip6-allrouters
dockerデーモンの設定
cat /etc/docker/daemon.json
{
"exec-opts": ["native.cgroupdriver=systemd"],
"log-driver": "json-file",
"log-opts": {
"max-size": "100m"
},
"storage-driver": "overlay2"
}
me@k8-vm:~$ kubectl ポッドを取得します
E0117 09:10:43.476675 13492 memcache.go:265] couldn't get current server API group list: Get "https://10.0.1.10:6443/api?timeout=32s": dial tcp 10.0.1.10:6443: connect: connection refused
E0117 09:10:43.477525 13492 memcache.go:265] couldn't get current server API group list: Get "https://10.0.1.10:6443/api?timeout=32s": dial tcp 10.0.1.10:6443: connect: connection refused
E0117 09:10:43.479198 13492 memcache.go:265] couldn't get current server API group list: Get "https://10.0.1.10:6443/api?timeout=32s": dial tcp 10.0.1.10:6443: connect: connection refused
E0117 09:10:43.479754 13492 memcache.go:265] couldn't get current server API group list: Get "https://10.0.1.10:6443/api?timeout=32s": dial tcp 10.0.1.10:6443: connect: connection refused
E0117 09:10:43.481822 13492 memcache.go:265] couldn't get current server API group list: Get "https://10.0.1.10:6443/api?timeout=32s": dial tcp 10.0.1.10:6443: connect: connection refused
The connection to the server 10.0.1.10:6443 was refused - did you specify the right host or port?
~/.kube/config に設定をセットアップしました:
cat ~/.kube/config
apiVersion: v1
clusters:
- cluster:
certificate-authority-data: secret_stuff
server: https://10.0.1.10:6443
name: kubernetes
contexts:
- context:
cluster: kubernetes
user: kubernetes-admin
name: kubernetes-admin@kubernetes
current-context: kubernetes-admin@kubernetes
kind: Config
preferences: {}
users:
- name: kubernetes-admin
user:
client-certificate-data: secret_stuff
client-key-data: secret_stuff
iptablesをフラッシュしてみましたが、何か復元中です。iptables 内の疑わしいエントリ:
Chain KUBE-FIREWALL (2 references)
target prot opt source destination
DROP all -- !localhost/8 localhost/8 /* block incoming localnet connections */ ! ctstate RELATED,ESTABLISHED,DNAT
Chain KUBE-FORWARD (1 references)
target prot opt source destination
DROP all -- anywhere anywhere ctstate INVALID
Chain KUBE-SERVICES (2 references)
target prot opt source destination
REJECT tcp -- anywhere 10.96.0.1 /* default/kubernetes:https has no endpoints */ reject-with icmp-port-unreachable
REJECT udp -- anywhere 10.96.0.10 /* kube-system/kube-dns:dns has no endpoints */ reject-with icmp-port-unreachable
REJECT tcp -- anywhere 10.96.0.10 /* kube-system/kube-dns:dns-tcp has no endpoints */ reject-with icmp-port-unreachable
REJECT tcp -- anywhere 10.96.0.10 /* kube-system/kube-dns:metrics has no endpoints */ reject-with icmp-port-unreachable
kubectl が iptables によってブロックされている可能性がありますか?
ログ、出力:
me@primary:~$ sudo kubeadm init --apiserver-advertise-address=172.105.148.95 --apiserver-cert-extra-sans=172.105.148.95 --pod-network-cidr=10.13.13.0/16 --node-name primary
[init] Using Kubernetes version: v1.29.1
[preflight] Running pre-flight checks
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action in beforehand using 'kubeadm config images pull'
W0119 09:35:48.771333 2949 checks.go:835] detected that the sandbox image "registry.k8s.io/pause:3.8" of the container runtime is inconsistent with that used by kubeadm. It is recommended that using "registry.k8s.io/pause:3.9" as the CRI sandbox image.
[certs] Using certificateDir folder "/etc/kubernetes/pki"
[certs] Generating "ca" certificate and key
[certs] Generating "apiserver" certificate and key
[certs] apiserver serving cert is signed for DNS names [kubernetes kubernetes.default kubernetes.default.svc kubernetes.default.svc.cluster.local primary] and IPs [10.96.0.1 172.105.148.95]
[certs] Generating "apiserver-kubelet-client" certificate and key
[certs] Generating "front-proxy-ca" certificate and key
[certs] Generating "front-proxy-client" certificate and key
[certs] Generating "etcd/ca" certificate and key
[certs] Generating "etcd/server" certificate and key
[certs] etcd/server serving cert is signed for DNS names [localhost primary] and IPs [172.105.148.95 127.0.0.1 ::1]
[certs] Generating "etcd/peer" certificate and key
[certs] etcd/peer serving cert is signed for DNS names [localhost primary] and IPs [172.105.148.95 127.0.0.1 ::1]
[certs] Generating "etcd/healthcheck-client" certificate and key
[certs] Generating "apiserver-etcd-client" certificate and key
[certs] Generating "sa" key and public key
[kubeconfig] Using kubeconfig folder "/etc/kubernetes"
[kubeconfig] Writing "admin.conf" kubeconfig file
[kubeconfig] Writing "super-admin.conf" kubeconfig file
[kubeconfig] Writing "kubelet.conf" kubeconfig file
[kubeconfig] Writing "controller-manager.conf" kubeconfig file
[kubeconfig] Writing "scheduler.conf" kubeconfig file
[etcd] Creating static Pod manifest for local etcd in "/etc/kubernetes/manifests"
[control-plane] Using manifest folder "/etc/kubernetes/manifests"
[control-plane] Creating static Pod manifest for "kube-apiserver"
[control-plane] Creating static Pod manifest for "kube-controller-manager"
[control-plane] Creating static Pod manifest for "kube-scheduler"
[kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
[kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
[kubelet-start] Starting the kubelet
[wait-control-plane] Waiting for the kubelet to boot up the control plane as static Pods from directory "/etc/kubernetes/manifests". This can take up to 4m0s
[kubelet-check] Initial timeout of 40s passed.
Unfortunately, an error has occurred:
timed out waiting for the condition
This error is likely caused by:
- The kubelet is not running
- The kubelet is unhealthy due to a misconfiguration of the node in some way (required cgroups disabled)
If you are on a systemd-powered system, you can try to troubleshoot the error with the following commands:
- 'systemctl status kubelet'
- 'journalctl -xeu kubelet'
Additionally, a control plane component may have crashed or exited when started by the container runtime.
To troubleshoot, list all containers using your preferred container runtimes CLI.
Here is one example how you may list all running Kubernetes containers by using crictl:
- 'crictl --runtime-endpoint unix:///var/run/containerd/containerd.sock ps -a | grep kube | grep -v pause'
Once you have found the failing container, you can inspect its logs with:
- 'crictl --runtime-endpoint unix:///var/run/containerd/containerd.sock logs CONTAINERID'
error execution phase wait-control-plane: couldn't initialize a Kubernetes cluster
To see the stack trace of this error execute with --v=5 or higher
@user23204747 - あなたの質問に答えます:
journalctl -fu kubelet
Jan 19 09:42:58 primary kubelet[3063]: E0119 09:42:58.312695 3063 kubelet_node_status.go:96] "Unable to register node with API server" err="Post \"https://172.105.148.95:6443/api/v1/nodes\": dial tcp 172.105.148.95:6443: connect: connection refused" node="primary"
Jan 19 09:42:59 primary kubelet[3063]: E0119 09:42:59.476195 3063 event.go:355] "Unable to write event (may retry after sleeping)" err="Post \"https://172.105.148.95:6443/api/v1/namespaces/default/events\": dial tcp 172.105.148.95:6443: connect: connection refused" event="&Event{ObjectMeta:{primary.17abb5f60468180b default 0 0001-01-01 00:00:00 +0000 UTC <nil> <nil> map[] map[] [] [] []},InvolvedObject:ObjectReference{Kind:Node,Namespace:,Name:primary,UID:primary,APIVersion:,ResourceVersion:,FieldPath:,},Reason:NodeHasSufficientPID,Message:Node primary status is now: NodeHasSufficientPID,Source:EventSource{Component:kubelet,Host:primary,},FirstTimestamp:2024-01-19 09:35:52.130377739 +0000 UTC m=+0.287533886,LastTimestamp:2024-01-19 09:35:52.130377739 +0000 UTC m=+0.287533886,Count:1,Type:Normal,EventTime:0001-01-01 00:00:00 +0000 UTC,Series:nil,Action:,Related:nil,ReportingController:kubelet,ReportingInstance:primary,}"
Jan 19 09:43:02 primary kubelet[3063]: E0119 09:43:02.208913 3063 eviction_manager.go:282] "Eviction manager: failed to get summary stats" err="failed to get node info: node \"primary\" not found"
Jan 19 09:43:05 primary kubelet[3063]: E0119 09:43:05.289531 3063 controller.go:145] "Failed to ensure lease exists, will retry" err="Get \"https://172.105.148.95:6443/apis/coordination.k8s.io/v1/namespaces/kube-node-lease/leases/primary?timeout=10s\": dial tcp 172.105.148.95:6443: connect: connection refused" interval="7s"
Jan 19 09:43:05 primary kubelet[3063]: I0119 09:43:05.315765 3063 kubelet_node_status.go:73] "Attempting to register node" node="primary"
Jan 19 09:43:05 primary kubelet[3063]: E0119 09:43:05.424960 3063 kubelet_node_status.go:96] "Unable to register node with API server" err="Post \"https://172.105.148.95:6443/api/v1/nodes\": dial tcp 172.105.148.95:6443: connect: connection refused" node="primary"
Jan 19 09:43:05 primary kubelet[3063]: W0119 09:43:05.450439 3063 reflector.go:539] vendor/k8s.io/client-go/informers/factory.go:159: failed to list *v1.Service: Get "https://172.105.148.95:6443/api/v1/services?limit=500&resourceVersion=0": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:05 primary kubelet[3063]: E0119 09:43:05.450569 3063 reflector.go:147] vendor/k8s.io/client-go/informers/factory.go:159: Failed to watch *v1.Service: failed to list *v1.Service: Get "https://172.105.148.95:6443/api/v1/services?limit=500&resourceVersion=0": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:09 primary kubelet[3063]: I0119 09:43:09.129122 3063 scope.go:117] "RemoveContainer" containerID="af6057fbd0e43b4628685f316cffef08e6ea4a6236223120ce825681b53a45ad"
Jan 19 09:43:09 primary kubelet[3063]: E0119 09:43:09.129843 3063 pod_workers.go:1298] "Error syncing pod, skipping" err="failed to \"StartContainer\" for \"etcd\" with CrashLoopBackOff: \"back-off 5m0s restarting failed container=etcd pod=etcd-primary_kube-system(b8faf6a4553601b5610c06ed8c93f9e3)\"" pod="kube-system/etcd-primary" podUID="b8faf6a4553601b5610c06ed8c93f9e3"
Jan 19 09:43:09 primary kubelet[3063]: E0119 09:43:09.585849 3063 event.go:355] "Unable to write event (may retry after sleeping)" err="Post \"https://172.105.148.95:6443/api/v1/namespaces/default/events\": dial tcp 172.105.148.95:6443: connect: connection refused" event="&Event{ObjectMeta:{primary.17abb5f60468180b default 0 0001-01-01 00:00:00 +0000 UTC <nil> <nil> map[] map[] [] [] []},InvolvedObject:ObjectReference{Kind:Node,Namespace:,Name:primary,UID:primary,APIVersion:,ResourceVersion:,FieldPath:,},Reason:NodeHasSufficientPID,Message:Node primary status is now: NodeHasSufficientPID,Source:EventSource{Component:kubelet,Host:primary,},FirstTimestamp:2024-01-19 09:35:52.130377739 +0000 UTC m=+0.287533886,LastTimestamp:2024-01-19 09:35:52.130377739 +0000 UTC m=+0.287533886,Count:1,Type:Normal,EventTime:0001-01-01 00:00:00 +0000 UTC,Series:nil,Action:,Related:nil,ReportingController:kubelet,ReportingInstance:primary,}"
Jan 19 09:43:12 primary kubelet[3063]: I0119 09:43:12.128675 3063 scope.go:117] "RemoveContainer" containerID="a9185c62d88f3192935626d7213b4378816563580b4afa1ac14b74f4029b548c"
Jan 19 09:43:12 primary kubelet[3063]: E0119 09:43:12.209179 3063 eviction_manager.go:282] "Eviction manager: failed to get summary stats" err="failed to get node info: node \"primary\" not found"
Jan 19 09:43:12 primary kubelet[3063]: E0119 09:43:12.398807 3063 controller.go:145] "Failed to ensure lease exists, will retry" err="Get \"https://172.105.148.95:6443/apis/coordination.k8s.io/v1/namespaces/kube-node-lease/leases/primary?timeout=10s\": dial tcp 172.105.148.95:6443: connect: connection refused" interval="7s"
Jan 19 09:43:12 primary kubelet[3063]: I0119 09:43:12.427248 3063 kubelet_node_status.go:73] "Attempting to register node" node="primary"
Jan 19 09:43:12 primary kubelet[3063]: E0119 09:43:12.551820 3063 kubelet_node_status.go:96] "Unable to register node with API server" err="Post \"https://172.105.148.95:6443/api/v1/nodes\": dial tcp 172.105.148.95:6443: connect: connection refused" node="primary"
Jan 19 09:43:14 primary kubelet[3063]: W0119 09:43:14.542312 3063 reflector.go:539] vendor/k8s.io/client-go/informers/factory.go:159: failed to list *v1.CSIDriver: Get "https://172.105.148.95:6443/apis/storage.k8s.io/v1/csidrivers?limit=500&resourceVersion=0": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:14 primary kubelet[3063]: E0119 09:43:14.542441 3063 reflector.go:147] vendor/k8s.io/client-go/informers/factory.go:159: Failed to watch *v1.CSIDriver: failed to list *v1.CSIDriver: Get "https://172.105.148.95:6443/apis/storage.k8s.io/v1/csidrivers?limit=500&resourceVersion=0": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:17 primary kubelet[3063]: W0119 09:43:17.648986 3063 reflector.go:539] vendor/k8s.io/client-go/informers/factory.go:159: failed to list *v1.RuntimeClass: Get "https://172.105.148.95:6443/apis/node.k8s.io/v1/runtimeclasses?limit=500&resourceVersion=0": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:17 primary kubelet[3063]: E0119 09:43:17.649087 3063 reflector.go:147] vendor/k8s.io/client-go/informers/factory.go:159: Failed to watch *v1.RuntimeClass: failed to list *v1.RuntimeClass: Get "https://172.105.148.95:6443/apis/node.k8s.io/v1/runtimeclasses?limit=500&resourceVersion=0": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:19 primary kubelet[3063]: E0119 09:43:19.507898 3063 controller.go:145] "Failed to ensure lease exists, will retry" err="Get \"https://172.105.148.95:6443/apis/coordination.k8s.io/v1/namespaces/kube-node-lease/leases/primary?timeout=10s\": dial tcp 172.105.148.95:6443: connect: connection refused" interval="7s"
Jan 19 09:43:19 primary kubelet[3063]: I0119 09:43:19.554658 3063 kubelet_node_status.go:73] "Attempting to register node" node="primary"
Jan 19 09:43:19 primary kubelet[3063]: E0119 09:43:19.679757 3063 kubelet_node_status.go:96] "Unable to register node with API server" err="Post \"https://172.105.148.95:6443/api/v1/nodes\": dial tcp 172.105.148.95:6443: connect: connection refused" node="primary"
Jan 19 09:43:19 primary kubelet[3063]: E0119 09:43:19.694847 3063 event.go:355] "Unable to write event (may retry after sleeping)" err="Post \"https://172.105.148.95:6443/api/v1/namespaces/default/events\": dial tcp 172.105.148.95:6443: connect: connection refused" event="&Event{ObjectMeta:{primary.17abb5f60468180b default 0 0001-01-01 00:00:00 +0000 UTC <nil> <nil> map[] map[] [] [] []},InvolvedObject:ObjectReference{Kind:Node,Namespace:,Name:primary,UID:primary,APIVersion:,ResourceVersion:,FieldPath:,},Reason:NodeHasSufficientPID,Message:Node primary status is now: NodeHasSufficientPID,Source:EventSource{Component:kubelet,Host:primary,},FirstTimestamp:2024-01-19 09:35:52.130377739 +0000 UTC m=+0.287533886,LastTimestamp:2024-01-19 09:35:52.130377739 +0000 UTC m=+0.287533886,Count:1,Type:Normal,EventTime:0001-01-01 00:00:00 +0000 UTC,Series:nil,Action:,Related:nil,ReportingController:kubelet,ReportingInstance:primary,}"
Jan 19 09:43:20 primary kubelet[3063]: W0119 09:43:20.761463 3063 reflector.go:539] vendor/k8s.io/client-go/informers/factory.go:159: failed to list *v1.Node: Get "https://172.105.148.95:6443/api/v1/nodes?fieldSelector=metadata.name%3Dprimary&limit=500&resourceVersion=0": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:20 primary kubelet[3063]: E0119 09:43:20.761607 3063 reflector.go:147] vendor/k8s.io/client-go/informers/factory.go:159: Failed to watch *v1.Node: failed to list *v1.Node: Get "https://172.105.148.95:6443/api/v1/nodes?fieldSelector=metadata.name%3Dprimary&limit=500&resourceVersion=0": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:21 primary kubelet[3063]: E0119 09:43:21.126858 3063 certificate_manager.go:562] kubernetes.io/kube-apiserver-client-kubelet: Failed while requesting a signed certificate from the control plane: cannot create certificate signing request: Post "https://172.105.148.95:6443/apis/certificates.k8s.io/v1/certificatesigningrequests": dial tcp 172.105.148.95:6443: connect: connection refused
Jan 19 09:43:22 primary kubelet[3063]: E0119 09:43:22.209975 3063 eviction_manager.go:282] "Eviction manager: failed to get summary stats" err="failed to get node info: node \"primary\" not found"
Jan 19 09:43:24 primary kubelet[3063]: I0119 09:43:24.129352 3063 scope.go:117] "RemoveContainer" containerID="af6057fbd0e43b4628685f316cffef08e6ea4a6236223120ce825681b53a45ad"
Jan 19 09:43:24 primary kubelet[3063]: E0119 09:43:24.130066 3063 pod_workers.go:1298] "Error syncing pod, skipping" err="failed to \"StartContainer\" for \"etcd\" with CrashLoopBackOff: \"back-off 5m0s restarting failed container=etcd pod=etcd-primary_kube-system(b8faf6a4553601b5610c06ed8c93f9e3)\"" pod="kube-system/etcd-primary"
ポッドUID="b8faf6a4553601b5610c06ed8c93f9e3"
CRI出力:
sudo crictl ps --all
WARN[0000] runtime connect using default endpoints: [unix:///var/run/dockershim.sock unix:///run/containerd/containerd.sock unix:///run/crio/crio.sock unix:///var/run/cri-dockerd.sock]. As the default settings are now deprecated, you should set the endpoint instead.
ERRO[0000] validate service connection: validate CRI v1 runtime API for endpoint "unix:///var/run/dockershim.sock": rpc error: code = Unavailable desc = connection error: desc = "transport: Error while dialing: dial unix /var/run/dockershim.sock: connect: no such file or directory"
WARN[0000] image connect using default endpoints: [unix:///var/run/dockershim.sock unix:///run/containerd/containerd.sock unix:///run/crio/crio.sock unix:///var/run/cri-dockerd.sock]. As the default settings are now deprecated, you should set the endpoint instead.
ERRO[0000] validate service connection: validate CRI v1 image API for endpoint "unix:///var/run/dockershim.sock": rpc error: code = Unavailable desc = connection error: desc = "transport: Error while dialing: dial unix /var/run/dockershim.sock: connect: no such file or directory"
CONTAINER IMAGE CREATED STATE NAME ATTEMPT POD ID POD
58dcdbbbbdb57 53b148a9d1963 About a minute ago Exited kube-apiserver 17 aa7a744e3afca kube-apiserver-primary
af6057fbd0e43 a0eed15eed449 3 minutes ago Exited etcd 19 12ffe5fa72b5c etcd-primary
a20b25ee9f45e 406945b511542 3 minutes ago Running kube-scheduler 5 507b8c9d8b7ab kube-scheduler-primary
049545de2ba82 79d451ca186a6 3 minutes ago Running kube-controller-manager 4 75616efa726fd kube-controller-manager-primary
8fbf3e41714a7 79d451ca186a6 8 minutes ago Exited kube-controller-manager 3 ae5e4208a01ef kube-controller-manager-primary
4b13c766ae730 406945b511542 8 minutes ago Exited kube-scheduler 4 7e4f0405277e4 kube-scheduler-primary
コンテナログ: 少し乱雑ですが、結局再試行して失敗するような同じエラーメッセージが出力され続けます。
W0119 09:43:29.388741 1 logging.go:59] [core] [Channel #1 SubChannel #2] grpc: addrConn.createTransport failed to connect to {Addr: "127.0.0.1:2379", ServerName: "127.0.0.1:2379", }. Err: connection error: desc = "transport: Error while dialing: dial tcp 127.0.0.1:2379: connect: connection refused"
W0119 09:43:30.103643 1 logging.go:59] [core] [Channel #3 SubChannel #4] grpc: addrConn.createTransport failed to connect to {Addr: "127.0.0.1:2379", ServerName: "127.0.0.1:2379", }. Err: connection error: desc = "transport: Error while dialing: dial tcp 127.0.0.1:2379: connect: connection refused"
F0119 09:43:33.102160 1 instance.go:290] Error creating leases: error creating storage factory: context deadline exceeded
kubelet ステータス:
sudo systemctl status kubelet
● kubelet.service - kubelet: The Kubernetes Node Agent
Loaded: loaded (/lib/systemd/system/kubelet.service; enabled; vendor preset: enabled)
Drop-In: /etc/systemd/system/kubelet.service.d
└─10-kubeadm.conf
Active: active (running) since Fri 2024-01-19 13:36:51 UTC; 12min ago
Docs: https://kubernetes.io/docs/home/
Main PID: 8539 (kubelet)
Tasks: 12 (limit: 37581)
Memory: 33.6M
CPU: 19.659s
CGroup: /system.slice/kubelet.service
└─8539 /usr/bin/kubelet --bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.conf --kubeconfig=/etc/kubernetes/kubelet.conf --config=/var/lib/kubelet/config.yaml --container-runtime-endpoint=unix:///var/run/containerd/containerd.sock --pod-infra-container-image=registry.k8s.io/p>
Jan 19 13:49:18 primary kubelet[8539]: W0119 13:49:18.366543 8539 reflector.go:535] vendor/k8s.io/client-go/informers/factory.go:150: failed to list *v1.Service: Get "https://master-node:6443/api/v1/services?limit=500&resourceVersion=0": dial tcp: lookup master-node on 127.0.0.53:53: server m>
Jan 19 13:49:18 primary kubelet[8539]: E0119 13:49:18.366695 8539 reflector.go:147] vendor/k8s.io/client-go/informers/factory.go:150: Failed to watch *v1.Service: failed to list *v1.Service: Get "https://master-node:6443/api/v1/services?limit=500&resourceVersion=0": dial tcp: lookup master-no>
Jan 19 13:49:19 primary kubelet[8539]: E0119 13:49:19.481598 8539 controller.go:146] "Failed to ensure lease exists, will retry" err="Get \"https://master-node:6443/apis/coordination.k8s.io/v1/namespaces/kube-node-lease/leases/primary?timeout=10s\": dial tcp: lookup master-node on 127.0.0.53:>
Jan 19 13:49:19 primary kubelet[8539]: I0119 13:49:19.902400 8539 kubelet_node_status.go:70] "Attempting to register node" node="primary"
Jan 19 13:49:19 primary kubelet[8539]: E0119 13:49:19.904293 8539 kubelet_node_status.go:92] "Unable to register node with API server" err="Post \"https://master-node:6443/api/v1/nodes\": dial tcp: lookup master-node on 127.0.0.53:53: server misbehaving" node="primary"
Jan 19 13:49:21 primary kubelet[8539]: E0119 13:49:21.741936 8539 eviction_manager.go:258] "Eviction manager: failed to get summary stats" err="failed to get node info: node \"primary\" not found"
Jan 19 13:49:26 primary kubelet[8539]: E0119 13:49:26.261529 8539 event.go:289] Unable to write event: '&v1.Event{TypeMeta:v1.TypeMeta{Kind:"", APIVersion:""}, ObjectMeta:v1.ObjectMeta{Name:"primary.17abc31ca21e74b4", GenerateName:"", Namespace:"default", SelfLink:"", UID:"", ResourceVersion:>
Jan 19 13:49:26 primary kubelet[8539]: E0119 13:49:26.483811 8539 controller.go:146] "Failed to ensure lease exists, will retry" err="Get \"https://master-node:6443/apis/coordination.k8s.io/v1/namespaces/kube-node-lease/leases/primary?timeout=10s\": dial tcp: lookup master-node on 127.0.0.53:>
Jan 19 13:49:26 primary kubelet[8539]: I0119 13:49:26.907141 8539 kubelet_node_status.go:70] "Attempting to register node" node="primary"
Jan 19 13:49:26 primary kubelet[8539]: E0119 13:49:26.909431 8539 kubelet_node_status.go:92] "Unable to register node with API server" err="Post \"https://master-node:6443/api/v1/nodes\": dial tcp: lookup master-node on 127.0.0.53:53: server misbehaving" node="primary"
答え1
まず、apiserver ポッドが稼働しているかどうかを確認し、その側で問題が発生していないことを確認します。コントロール プレーン ノードで以下の操作を試してください。
まず、kubelet ログに何か疑わしい点はありますか?
journalctl -fu kubelet
次に、ポッドのコンテナ ランタイム ログ。
sudo crictl ps --all # get container_id
sudo crictl logs container_id
実行したコマンド全体が含まれていないのでkubeadm init、--apiserver-advertise-address正しく設定されていることを確認してください。
答え2
このconnection refusedエラーは通常、リクエストがサーバーに到達したが、指定されたポートでサービスが実行されていないことを意味します。マスター ノードで api-server が起動されていることを確認してください。kube-api サーバーのステータスを確認するには、次のコマンドを使用します。
Systemctl status kube-apiserver
kubeconfig ファイルは にあるため
\~/.kube/config、KUBECONFIG 環境変数が正しいファイルを指すように設定してください。クライアント マシンとマスター ノードの間にネットワーク接続があることを確認します。マシンからマスター ノードの IP アドレスにアクセスできることを確認します。
ファイアウォールとセキュリティ グループを確認します。Kubernetes API 通信に必要なポートが開いていることを確認します。デフォルトでは、Kubernetes API サーバーはポート 6443 をリッスンします。
iptablesに疑わしいエントリがあると思われる場合は、次のコマンドを使用してiptableルールを調べます。
iptables -L -n - Kubernetes API通信を妨害する可能性のあるルールを探すことができます。コマンドを使用してルールを一時的にフラッシュすることができます。iptables -F
- マスターノードでkube-proxyのステータスを確認するには、
kubectl -n kube-system get pods -l k8s-app=kube-proxy。
編集
This error is likely caused by: - The kubelet is not running - The kubelet is unhealthy due to a misconfiguration of the node in some way (required cgroups disabled)
上記のエラー メッセージから、接続拒否エラーは、必要な cgroup が無効になっているなどのノード上の誤った構成によって発生している可能性があり、kubelet で問題が発生する可能性が高くなります。
- 次のコマンドを実行して、ノード上の kubelet サービスのステータスを確認します。
systemctl status kubelet- このコマンドは、障害が発生したか不健康なkubeletを表示します。kubeletが動作していない場合は、次のコマンドで起動してみてください。systemctl start kubelet
- ノード構成を検証して正しく設定されていることを確認し、必要な設定がないか確認します。cグループ無効になっているか、誤って構成されています。
A. コンテナをcriとして使用している場合は、次のコマンドを実行して、これを次SystemdCgroup = falseのように変更します。SystemdCgroup = true
sudo systemctl restart containerd
sudo systemctl restart kubelet
マシンを再起動します（オプションの場合があります）
B. docker を cri として使用している場合は、次のコマンドを実行します。vi /etc/docker/daemon.json を開き、["native.cgroupdriver=systemd"] を "exec-opts": ["native.cgroupdriver=cgroupfs"] に変更します。
sudo systemctl daemon-reload
sudo systemctl restart kubelet
マシンを再起動します（オプションの場合があります）
