Ich habe überall gesucht und binso nahzum Abschluss dieser Treiberinstallation. Es handelt sich um einen Archer T2UH, AC600 USB-Dongle. Auf der Maschine, auf der ich ihn installiere, läuft Kubuntu 17.04. Ich habe den Treiber erfolgreich kompiliert und installiert vondieses Github-Repowie empfohlen von chili555Hiersowie an anderen Orten. Ich hatte das Glück, nicht so viele Probleme wie andere zu haben, da ich weiß, dass dies ein schwieriger Treiber ist.
Das Kernproblem meines Problems ist im Moment, dass ichsehenNetzwerke, aber ich kann keine Verbindung zu einem davon herstellen. Andere Leute hatten Probleme beim Verbinden mehrerer Adapter, aber ich bin immer nur mit einem verbunden. Ich habe versucht, eine Verbindung über die GUI von NetworkManager herzustellen und manuellmit WPA Supplicant(unter Verwendung von beidem wpa_cliund einer Konfigurationsdatei). Das Gerät blinkt grün und zeigt damit an, dass die Treiber geladen werden müssen.
Ich werde unten verschiedene Protokolle einfügen, die bei der Diagnose des Problems helfen. Bitte lassen Sie mich wissen, wenn ich noch etwas bereitstellen kann.
Mein USB-WLAN-Dongle; über lsusb:
Bus 001 Device 008: ID 148f:761a Ralink Technology, Corp.
Hardware-Blockierung; überrfkill list all
2: phy2: Wireless LAN
Soft blocked: no
Hard blocked: no
Relevante Informationen zur Netzwerkhardware; über lshw -class network:
*-network
description: Wireless interface
physical id: 1
logical name: wlan0
serial: 84:16:f9:1c:be:d9
capabilities: ethernet physical wireless
configuration: broadcast=yes driver=RALINK WLAN multicast=yes wireless=Ralink STA
Schnittstellenstatus; über ip link:
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN mode DEFAULT group default qlen 1000
link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
2: enp10s0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc pfifo_fast state DOWN mode DEFAULT group default qlen 1000
link/ether 6c:f0:49:56:8a:f3 brd ff:ff:ff:ff:ff:ff
5: wlan0: <NO-CARRIER,BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast state DORMANT mode DORMANT group default qlen 1000
link/ether 84:16:f9:1c:be:d9 brd ff:ff:ff:ff:ff:ff
Mein Versuch, manuell eine Verbindung zum Netzwerk herzustellen; über sudo wpa_supplicant -i wlan0 -c /etc/wpa_supplicant/archerCoolbox5.conf:
Successfully initialized wpa_supplicant
wlan0: Trying to associate with a4:2b:b0:fa:40:85 (SSID='CoolBox_5G' freq=5180 MHz)
wlan0: Authentication with a4:2b:b0:fa:40:85 timed out.
wlan0: CTRL-EVENT-DISCONNECTED bssid=a4:2b:b0:fa:40:85 reason=3 locally_generated=1
wlan0: Trying to associate with a4:2b:b0:fa:40:85 (SSID='CoolBox_5G' freq=5180 MHz)
wlan0: Authentication with a4:2b:b0:fa:40:85 timed out.
wlan0: CTRL-EVENT-DISCONNECTED bssid=a4:2b:b0:fa:40:85 reason=3 locally_generated=1
wlan0: CTRL-EVENT-SSID-TEMP-DISABLED id=0 ssid="CoolBox_5G" auth_failures=1 duration=10 reason=CONN_FAILED
wlan0: CTRL-EVENT-SSID-REENABLED id=0 ssid="CoolBox_5G"
wlan0: Trying to associate with a4:2b:b0:fa:40:85 (SSID='CoolBox_5G' freq=5180 MHz)
wlan0: Authentication with a4:2b:b0:fa:40:85 timed out.
wlan0: CTRL-EVENT-DISCONNECTED bssid=a4:2b:b0:fa:40:85 reason=3 locally_generated=1
wlan0: CTRL-EVENT-SSID-TEMP-DISABLED id=0 ssid="CoolBox_5G" auth_failures=2 duration=23 reason=CONN_FAILED
...
Relevante Protokolle von dmesg; über dmesg:
...
[ 5178.630667] 80211> CFG80211_Scaning ==>
[ 5178.630674] 80211> cfg80211_inform_bss_frame
[ 5179.137074] 80211> CFG80211_Scaning ==>
[ 5179.137084] 80211> cfg80211_inform_bss_frame
[ 5179.359807] 80211> cfg80211_scan_done
[ 5179.360051] 80211> CFG80211_OpsSurveyGet ==>
[ 5179.360055] 80211> busy time = -109729513193472 0
[ 5179.360445] 80211 [CONNECT TEST]> CFG80211_OpsConnect ==>
[ 5179.360448] Groupwise: fac04
[ 5179.360449] Pairwise fac04
[ 5179.360450] Wpa_versions 2
[ 5179.360451] Keymgmt fac02
[ 5179.360452] Auth_type 0
[ 5179.360453] WLAN_CIPHER_SUITE_CCMP...
[ 5179.360454] ConnInfo.KeyLen ===> 0
[ 5179.360455] ConnInfo.KeyIdx ===> 0
[ 5179.360458] 80211> Connect bssid a4:2b:b0:fa:40:85
[ 5179.360462] 80211> EncrypType = 6
[ 5189.365254] 80211> CFG80211_OpsDisconnect ==>
[ 5189.365258] 80211> ReasonCode = 3
[ 5189.471796] 80211> CFG80211_OpsScan ==>
[ 5189.497392] 80211> CFG80211_Scaning ==>
[ 5189.497399] 80211> cfg80211_inform_bss_frame
[ 5189.555788] 80211> CFG80211_Scaning ==>
...
Der Zugangspunkt, mit dem ich mich verbinden möchte; über iw wlan0 scan:
BSS a4:2b:b0:fa:40:85(on wlan0)
TSF: 6658656914006 usec (77d, 01:37:36)
freq: 5180
beacon interval: 100 TUs
capability: ESS Privacy SpectrumMgmt ShortSlotTime (0x0511)
signal: 0.-47 dBm
last seen: 3912 ms ago
Information elements from Probe Response frame:
SSID: CoolBox_5G
Supported rates: 6.0* 9.0 12.0* 18.0 24.0* 36.0 48.0 54.0
DS Parameter set: channel 36
Country: US Environment: Indoor/Outdoor
Channels [36 - 36] @ 17 dBm
Channels [40 - 40] @ 17 dBm
Channels [44 - 44] @ 17 dBm
Channels [48 - 48] @ 17 dBm
Channels [52 - 52] @ 23 dBm
Channels [56 - 56] @ 23 dBm
Channels [60 - 60] @ 23 dBm
Channels [64 - 64] @ 23 dBm
Channels [100 - 100] @ 23 dBm
Channels [104 - 104] @ 23 dBm
Channels [108 - 108] @ 23 dBm
Channels [112 - 112] @ 23 dBm
Channels [116 - 116] @ 23 dBm
Channels [132 - 132] @ 23 dBm
Channels [136 - 136] @ 23 dBm
Channels [140 - 140] @ 23 dBm
Channels [149 - 149] @ 30 dBm
Channels [153 - 153] @ 30 dBm
Channels [157 - 157] @ 30 dBm
Channels [161 - 161] @ 30 dBm
Channels [165 - 165] @ 30 dBm
Power constraint: 3 dB
HT capabilities:
Capabilities: 0x9ef
RX LDPC
HT20/HT40
SM Power Save disabled
RX HT20 SGI
RX HT40 SGI
TX STBC
RX STBC 1-stream
Max AMSDU length: 7935 bytes
No DSSS/CCK HT40
Maximum RX AMPDU length 65535 bytes (exponent: 0x003)
Minimum RX AMPDU time spacing: 8 usec (0x06)
HT TX/RX MCS rate indexes supported: 0-23
HT operation:
* primary channel: 36
* secondary channel offset: above
* STA channel width: any
* RIFS: 1
* HT protection: no
* non-GF present: 1
* OBSS non-GF present: 0
* dual beacon: 0
* dual CTS protection: 0
* STBC beacon: 0
* L-SIG TXOP Prot: 0
* PCO active: 0
* PCO phase: 0
Extended capabilities: 6
VHT capabilities:
VHT Capabilities (0x338001b2):
Max MPDU length: 11454
Supported Channel Width: neither 160 nor 80+80
RX LDPC
short GI (80 MHz)
TX STBC
RX antenna pattern consistency
TX antenna pattern consistency
VHT RX MCS set:
1 streams: MCS 0-9
2 streams: MCS 0-9
3 streams: MCS 0-9
4 streams: not supported
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
VHT RX highest supported: 0 Mbps
VHT TX MCS set:
1 streams: MCS 0-9
2 streams: MCS 0-9
3 streams: MCS 0-9
4 streams: not supported
5 streams: not supported
6 streams: not supported
7 streams: not supported
8 streams: not supported
VHT TX highest supported: 0 Mbps
VHT operation:
* channel width: 1 (80 MHz)
* center freq segment 1: 42
* center freq segment 2: 0
* VHT basic MCS set: 0xfffc
WMM: * Parameter version 1
* u-APSD
* BE: CW 15-1023, AIFSN 3
* BK: CW 15-1023, AIFSN 7
* VI: CW 7-15, AIFSN 2, TXOP 3008 usec
* VO: CW 3-7, AIFSN 2, TXOP 1504 usec
WPS: * Version: 1.0
* Wi-Fi Protected Setup State: 2 (Configured)
* Response Type: 3 (AP)
* UUID: 12345678-9abc-def0-1234-a42bb0fa4086
* Manufacturer: TP-LINK
* Model: Archer C7
* Model Number: 2.0
* Serial Number: 1.0
* Primary Device Type: 6-0050f204-1
* Device name: Wireless Router Archer C7
* Config methods: Display
* RF Bands: 0x3
* Unknown TLV (0x1049, 6 bytes): 00 37 2a 00 01 20
RSN: * Version: 1
* Group cipher: CCMP
* Pairwise ciphers: CCMP
* Authentication suites: PSK
* Capabilities: 1-PTKSA-RC 1-GTKSA-RC (0x0000)
WPA: * Version: 1
* Group cipher: CCMP
* Pairwise ciphers: CCMP
* Authentication suites: PSK
Der teilweise verschleierte Inhalt von /etc/wpa_supplicant/archerCoolbox5.conf:
ctrl_interface=/var/run/wpa_supplicant
network={
ssid="CoolBox_5G"
#psk="xxxxxxxxxx"
psk=xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
}
Beweise dafür, dass ich die zufällige MAC-Adressierung deaktiviert habe; über cat /etc/NetworkManager/NetworkManager.conf:
[main]
plugins=ifupdown,keyfile
[ifupdown]
managed=false
[device]
wifi.scan-rand-mac-address=no
Energiespareinstellungen; über cat /etc/NetworkManager/conf.d/default-wifi-powersave-on.conf:
[connection]
wifi.powersave = 3
Verbindungsversuch; über iwconfig wlan0 essid CoolBox_5G && iwconfig wlan0:
wlan0 Ralink STA ESSID:"" Nickname:""
Mode:Auto Frequency=2.412 GHz Access Point: Not-Associated
Bit Rate:1 Mb/s
RTS thr:off Fragment thr:off
Link Quality=10/100 Signal level:0 dBm Noise level:0 dBm
Rx invalid nwid:0 Rx invalid crypt:0 Rx invalid frag:0
Tx excessive retries:0 Invalid misc:0 Missed beacon:0
Die jeweilige Dmesg-Ausgabe des Versuchs; über dmesg:
[ 994.390379] 80211> CFG80211_OpsDisconnect ==>
[ 994.390380] 80211> ReasonCode = 3
[ 994.426236] ==>mt7610u_chip_onoff(): OnOff:0, Reset= 0, pAd->WlanFunCtrl:0xff000003, Reg-WlanFunCtrl=0xff000003
[ 994.429843] receive cmd msg fail(-2)
[ 994.429910] tx_kickout_fail_count = 0
[ 994.429912] tx_timeout_fail_count = 0
[ 994.429912] rx_receive_fail_count = 0
[ 997.486662] ==>mt7610u_chip_onoff(): OnOff:1, Reset= 0, pAd->WlanFunCtrl:0xff000000, Reg-WlanFunCtrl=0xff000000
[ 997.486872] MACVersion = 0x76502000
[ 997.487246] MAC[Ver=0x76502000]
[ 997.487250] usb 1-5: loading firmware mt7610u.bin
[ 997.492319] usb 1-5: firmware mt7610u.bin loaded
[ 997.497995] fw version:0.1.00
[ 997.497997] build:7640
[ 997.497997] build time:
[ 997.497998] ilm length = 68780(bytes)
[ 997.497999] dlm length = 11476(bytes)
[ 997.580031] #
[ 997.586409] loading fw
[ 997.587481] .
[ 997.594002] .
[ 997.600500] .
[ 997.607007] .
[ 997.613378] .
[ 997.619609] .
[ 997.708167] #
[ 997.924565] RTMP_TimerListAdd: add timer obj ffffac9f03346728!
[ 997.924566] RTMP_TimerListAdd: add timer obj ffffac9f03346798!
[ 997.924567] RTMP_TimerListAdd: add timer obj ffffac9f03346808!
[ 997.924568] RTMP_TimerListAdd: add timer obj ffffac9f033466b8!
[ 997.924569] RTMP_TimerListAdd: add timer obj ffffac9f03346568!
[ 997.924570] RTMP_TimerListAdd: add timer obj ffffac9f033465d8!
[ 997.924571] RTMP_TimerListAdd: add timer obj ffffac9f032d8a60!
[ 997.924572] RTMP_TimerListAdd: add timer obj ffffac9f032c78e0!
[ 997.924573] RTMP_TimerListAdd: add timer obj ffffac9f032c7958!
[ 997.924573] RTMP_TimerListAdd: add timer obj ffffac9f032d8bd0!
[ 997.924575] RTMP_TimerListAdd: add timer obj ffffac9f032d8980!
[ 997.924576] RTMP_TimerListAdd: add timer obj ffffac9f032d8b60!
[ 997.924587] CfgSetCountryRegion():CountryRegion in eeprom was programmed
[ 997.924593] CfgSetCountryRegion():CountryRegion in eeprom was programmed
[ 997.924622] cfg_mode=13
[ 997.924624] wmode_band_equal(): Band Not Equal!
[ 997.925183] 1. Phy Mode = 61
[ 997.925184] 2. Phy Mode = 61
[ 997.929272] /home/alan/src/mt7610u/chips/mt76x0.c:1708 assert (pAd->TxPower[choffset].Channel == 36)failed
[ 997.937018] ERROR!!!
[ 997.937020] E2PROM: WRONG VERSION 0x2, should be 1
[ 997.938520] BT Coexistence word [66] = 0000ffff
[ 997.939022] 0x24 = 0xffef, 0x0104 = 0x0033ffef
[ 997.939023] EEPROM_NIC_CFG1_OFFSET = 0xfd11
[ 997.939395] mt76x0_read_tx_alc_info_from_eeprom: EEPROM_MT76x0_TEMPERATURE_OFFSET (0xD1) = 0xf8
[ 997.939396] mt76x0_read_tx_alc_info_from_eeprom: TemperatureOffset = 0xfffffff8
[ 997.939396] Temperature Tx ALC not enabled
[ 997.942801] 3. Phy Mode = 61
[ 997.950380] TxPath = 1, RxPath = 1, RFIC=17
[ 997.950389] RTMPSetPhyMode: channel is out of range, use first channel=1
[ 997.951770] MCS Set = ff 00 00 00 01
[ 997.961729] <==== rt28xx_init, Status=0
[ 997.961731] 80211> re-init bands...
[ 997.961883] 80211> re-init bands...
[ 997.961884] 80211> RFICType = 3
[ 997.961885] 80211> Number of channel = 44
[ 997.961886] 80211> Number of rate = 12
[ 997.961886] 80211> CurTxPower = 0 dBm
[ 997.961888] 80211> TxStream = 1
[ 997.961889] crda> CFG80211_RegRuleApply ==>
[ 997.961890] crda> reset chan/power for 2.4GHz
[ 997.961891] Chan 001: power 0 dBm, DFS 0, DFS Type 0
[ 997.961892] Chan 002: power 0 dBm, DFS 0, DFS Type 0
[ 997.961893] Chan 003: power 0 dBm, DFS 0, DFS Type 0
[ 997.961894] Chan 004: power 0 dBm, DFS 0, DFS Type 0
[ 997.961895] Chan 005: power 0 dBm, DFS 0, DFS Type 0
[ 997.961896] Chan 006: power 0 dBm, DFS 0, DFS Type 0
[ 997.961897] Chan 007: power 0 dBm, DFS 0, DFS Type 0
[ 997.961898] Chan 008: power 0 dBm, DFS 0, DFS Type 0
[ 997.961899] Chan 009: power 0 dBm, DFS 0, DFS Type 0
[ 997.961900] Chan 010: power 0 dBm, DFS 0, DFS Type 0
[ 997.961901] Chan 011: power 0 dBm, DFS 0, DFS Type 0
[ 997.961902] Chan 012: power 0 dBm, DFS 0, DFS Type 0
[ 997.961903] Chan 013: power 0 dBm, DFS 0, DFS Type 0
[ 997.961904] Chan 014: power 0 dBm, DFS 0, DFS Type 0
[ 997.961905] crda> reset chan/power for 5GHz
[ 997.961906] Chan 036: power 0 dBm, DFS 0, DFS Type 0
[ 997.961907] Chan 038: power 0 dBm, DFS 0, DFS Type 0
[ 997.961908] Chan 040: power 0 dBm, DFS 0, DFS Type 0
[ 997.961909] Chan 044: power 0 dBm, DFS 0, DFS Type 0
[ 997.961910] Chan 046: power 0 dBm, DFS 0, DFS Type 0
[ 997.961911] Chan 048: power 0 dBm, DFS 0, DFS Type 0
[ 997.961912] Chan 052: power 0 dBm, DFS 1, DFS Type 0
[ 997.961913] Chan 054: power 0 dBm, DFS 1, DFS Type 0
[ 997.961914] Chan 056: power 0 dBm, DFS 1, DFS Type 0
[ 997.961915] Chan 060: power 0 dBm, DFS 1, DFS Type 0
[ 997.961916] Chan 062: power 0 dBm, DFS 1, DFS Type 0
[ 997.961917] Chan 064: power 0 dBm, DFS 1, DFS Type 0
[ 997.961918] Chan 100: power 0 dBm, DFS 1, DFS Type 0
[ 997.961919] Chan 104: power 0 dBm, DFS 1, DFS Type 0
[ 997.961920] Chan 108: power 0 dBm, DFS 1, DFS Type 0
[ 997.961921] Chan 112: power 0 dBm, DFS 1, DFS Type 0
[ 997.961922] Chan 116: power 0 dBm, DFS 1, DFS Type 0
[ 997.961923] Chan 118: power 0 dBm, DFS 1, DFS Type 0
[ 997.961924] Chan 120: power 0 dBm, DFS 1, DFS Type 0
[ 997.961925] Chan 124: power 0 dBm, DFS 1, DFS Type 0
[ 997.961926] Chan 126: power 0 dBm, DFS 1, DFS Type 0
[ 997.961927] Chan 128: power 0 dBm, DFS 1, DFS Type 0
[ 997.961928] Chan 132: power 0 dBm, DFS 1, DFS Type 0
[ 997.961929] Chan 134: power 0 dBm, DFS 1, DFS Type 0
[ 997.961930] Chan 136: power 0 dBm, DFS 1, DFS Type 0
[ 997.961931] Chan 140: power 0 dBm, DFS 1, DFS Type 0
[ 997.961932] Chan 149: power 0 dBm, DFS 0, DFS Type 0
[ 997.961933] Chan 151: power 0 dBm, DFS 0, DFS Type 0
[ 997.961934] Chan 153: power 0 dBm, DFS 0, DFS Type 0
[ 997.961935] Chan 157: power 0 dBm, DFS 0, DFS Type 0
[ 997.961936] Chan 159: power 0 dBm, DFS 0, DFS Type 0
[ 997.961937] Chan 161: power 0 dBm, DFS 0, DFS Type 0
[ 997.961939] Chan 165: power 0 dBm, DFS 0, DFS Type 0
[ 997.961939] Chan 167 (frq 5835): not allowed!
[ 997.961940] Chan 169 (frq 5845): not allowed!
[ 997.961941] Chan 171 (frq 5855): not allowed!
[ 997.961942] Chan 173 (frq 5865): not allowed!
[ 997.961943] Chan 184 (frq 4920): not allowed!
[ 997.961944] Chan 188 (frq 4940): not allowed!
[ 997.961944] Chan 192 (frq 4960): not allowed!
[ 997.961945] Chan 196 (frq 4980): not allowed!
[ 997.961946] Chan 208 (frq 6040): not allowed!
[ 997.961947] Chan 212 (frq 6060): not allowed!
[ 997.961947] Chan 216 (frq 6080): not allowed!
[ 997.961948] crda> Number of channels = 47
[ 997.963024] 0x1300 = 00064300
[ 997.963025] RTMPDrvSTAOpen(1):Check if PDMA is idle!
[ 997.963144] RTMPDrvSTAOpen(2):Check if PDMA is idle!
Antwort1
[connection]
wifi.powersave = 3
Schalten Sie es aus mitwifi.powersave = 2
Denn aus dem Quelltext: wifi.powersavekann folgenden Wert haben:
NM_SETTING_WIRELESS_POWERSAVE_DEFAULT (0): use the default value
NM_SETTING_WIRELESS_POWERSAVE_IGNORE (1): don't touch existing setting
NM_SETTING_WIRELESS_POWERSAVE_DISABLE (2): disable powersave
NM_SETTING_WIRELESS_POWERSAVE_ENABLE (3): enable powersave
