Betriebssystem: Linux Mint 18.2 Cinnamon + Windows 10 Pro; Dual-Boot.
Ich habe diese Website gerade verwendethttp://test-ipv6.com/um meine IPv6-Bereitschaft zu überprüfen.
Ergebnisse auf Windows 10 Pro:
Ergebnisse auf Linux Mint 18.2 Cinnamon:
Wie Sie sehen, habe ichmancheProblem mit den DNS-Einstellungen auf meinem Linux Mint. Aber alles scheint eingeschaltet zu sein, wie zum Beispiel in den Netzwerkeinstellungen - Abschnitt IPv6:
Ich bin mir nicht sicher, wo ich nach der fehlgeschlagenen DNS-Einstellung suchen soll. Oder ist Linux Mint 18 noch nicht bereit für IPv6?
BEARBEITEN1:
$ cat /etc/resolv.conf
nameserver 209.222.18.222
nameserver 209.222.18.218
Aber im Netzwerkmanager wird mir der Google DNS als primär und der meines IPS als sekundär angezeigt, was ich im DHCP meines Routers im Abschnitt IPv4 konfiguriert habe:
Ich nehme an, dass dies die sind, die mein Laptop verwendet.
$ nmcli dev show | grep DNS
IP4.DNS[1]: 8.8.8.8
IP4.DNS[2]: 10.255.255.10
IP6.DNS[1]: 2a02:768:0:1010::3
IP6.DNS[2]: 2a02:768:0:1010::2
Ich gebe zu, dass ich IPv6 überhaupt nicht verstehe, aber ich verstehe nicht, warum der Test, d. h. IPv6, unter Windows voll funktionsfähig ist und unter Linux nicht.
$ cat /etc/gai.conf
# Configuration for getaddrinfo(3).
#
# So far only configuration for the destination address sorting is needed.
# RFC 3484 governs the sorting. But the RFC also says that system
# administrators should be able to overwrite the defaults. This can be
# achieved here.
#
# All lines have an initial identifier specifying the option followed by
# up to two values. Information specified in this file replaces the
# default information. Complete absence of data of one kind causes the
# appropriate default information to be used. The supported commands include:
#
# reload <yes|no>
# If set to yes, each getaddrinfo(3) call will check whether this file
# changed and if necessary reload. This option should not really be
# used. There are possible runtime problems. The default is no.
#
# label <mask> <value>
# Add another rule to the RFC 3484 label table. See section 2.1 in
# RFC 3484. The default is:
#
#label ::1/128 0
#label ::/0 1
#label 2002::/16 2
#label ::/96 3
#label ::ffff:0:0/96 4
#label fec0::/10 5
#label fc00::/7 6
#label 2001:0::/32 7
#
# This default differs from the tables given in RFC 3484 by handling
# (now obsolete) site-local IPv6 addresses and Unique Local Addresses.
# The reason for this difference is that these addresses are never
# NATed while IPv4 site-local addresses most probably are. Given
# the precedence of IPv6 over IPv4 (see below) on machines having only
# site-local IPv4 and IPv6 addresses a lookup for a global address would
# see the IPv6 be preferred. The result is a long delay because the
# site-local IPv6 addresses cannot be used while the IPv4 address is
# (at least for the foreseeable future) NATed. We also treat Teredo
# tunnels special.
#
# precedence <mask> <value>
# Add another rule to the RFC 3484 precedence table. See section 2.1
# and 10.3 in RFC 3484. The default is:
#
#precedence ::1/128 50
#precedence ::/0 40
#precedence 2002::/16 30
#precedence ::/96 20
#precedence ::ffff:0:0/96 10
#
# For sites which prefer IPv4 connections change the last line to
#
precedence ::ffff:0:0/96 100
#
# scopev4 <mask> <value>
# Add another rule to the RFC 6724 scope table for IPv4 addresses.
# By default the scope IDs described in section 3.2 in RFC 6724 are
# used. Changing these defaults should hardly ever be necessary.
# The defaults are equivalent to:
#
#scopev4 ::ffff:169.254.0.0/112 2
#scopev4 ::ffff:127.0.0.0/104 2
#scopev4 ::ffff:0.0.0.0/96 14
Es ist also fast alles auskommentiert.
Außerdem haben Sie gefragt, welchen DHCP-Client ich verwende:
$ dhclient --help
Internet Systems Consortium DHCP Client 4.3.3
...
EDIT2:
$ cat /etc/dhcp/dhclient.conf
# Configuration file for /sbin/dhclient.
#
# This is a sample configuration file for dhclient. See dhclient.conf's
# man page for more information about the syntax of this file
# and a more comprehensive list of the parameters understood by
# dhclient.
#
# Normally, if the DHCP server provides reasonable information and does
# not leave anything out (like the domain name, for example), then
# few changes must be made to this file, if any.
#
option rfc3442-classless-static-routes code 121 = array of unsigned integer 8;
send host-name = gethostname();
request subnet-mask, broadcast-address, time-offset, routers,
domain-name, domain-name-servers, domain-search, host-name,
dhcp6.name-servers, dhcp6.domain-search, dhcp6.fqdn, dhcp6.sntp-servers,
netbios-name-servers, netbios-scope, interface-mtu,
rfc3442-classless-static-routes, ntp-servers;
#send dhcp-client-identifier 1:0:a0:24:ab:fb:9c;
#send dhcp-lease-time 3600;
#supersede domain-name "fugue.com home.vix.com";
#prepend domain-name-servers 127.0.0.1;
#require subnet-mask, domain-name-servers;
timeout 300;
#retry 60;
#reboot 10;
#select-timeout 5;
#initial-interval 2;
#script "/sbin/dhclient-script";
#media "-link0 -link1 -link2", "link0 link1";
#reject 192.33.137.209;
#alias {
# interface "eth0";
# fixed-address 192.5.5.213;
# option subnet-mask 255.255.255.255;
#}
#lease {
# interface "eth0";
# fixed-address 192.33.137.200;
# medium "link0 link1";
# option host-name "andare.swiftmedia.com";
# option subnet-mask 255.255.255.0;
# option broadcast-address 192.33.137.255;
# option routers 192.33.137.250;
# option domain-name-servers 127.0.0.1;
# renew 2 2000/1/12 00:00:01;
# rebind 2 2000/1/12 00:00:01;
# expire 2 2000/1/12 00:00:01;
#}
EDIT3:
Nach dem Kopieren und Einfügen der IPv6-Zeile eine Zeile weiter oben:
cat /etc/dhcp/dhclient.conf
# Configuration file for /sbin/dhclient.
#
# This is a sample configuration file for dhclient. See dhclient.conf's
# man page for more information about the syntax of this file
# and a more comprehensive list of the parameters understood by
# dhclient.
#
# Normally, if the DHCP server provides reasonable information and does
# not leave anything out (like the domain name, for example), then
# few changes must be made to this file, if any.
#
option rfc3442-classless-static-routes code 121 = array of unsigned integer 8;
send host-name = gethostname();
request subnet-mask, broadcast-address, time-offset, routers,
dhcp6.name-servers, dhcp6.domain-search, dhcp6.fqdn, dhcp6.sntp-servers,
domain-name, domain-name-servers, domain-search, host-name,
netbios-name-servers, netbios-scope, interface-mtu,
rfc3442-classless-static-routes, ntp-servers;
#send dhcp-client-identifier 1:0:a0:24:ab:fb:9c;
#send dhcp-lease-time 3600;
#supersede domain-name "fugue.com home.vix.com";
#prepend domain-name-servers 127.0.0.1;
#require subnet-mask, domain-name-servers;
timeout 300;
#retry 60;
#reboot 10;
#select-timeout 5;
#initial-interval 2;
#script "/sbin/dhclient-script";
#media "-link0 -link1 -link2", "link0 link1";
#reject 192.33.137.209;
#alias {
# interface "eth0";
# fixed-address 192.5.5.213;
# option subnet-mask 255.255.255.255;
#}
#lease {
# interface "eth0";
# fixed-address 192.33.137.200;
# medium "link0 link1";
# option host-name "andare.swiftmedia.com";
# option subnet-mask 255.255.255.0;
# option broadcast-address 192.33.137.255;
# option routers 192.33.137.250;
# option domain-name-servers 127.0.0.1;
# renew 2 2000/1/12 00:00:01;
# rebind 2 2000/1/12 00:00:01;
# expire 2 2000/1/12 00:00:01;
#}
EDIT4:
Vielleicht lag es an der Anwendung meines VPN-Anbieters, ich habe keine Änderungen vorgenommen. Ich verwende das VPN derzeit nicht und wollte deshalb testen, ob mein Linux IPv6 unterstützt. Die Nameserver in resolv.conf gehören zum VPN-Anbieter: Private Internet Access.
Ich versuche herauszufinden, warum resolv.confnicht aktualisiert wird:
$ lsattr /etc/resolv.conf
-------------e-- /etc/resolv.conf
EDIT5:
$ sudo tcpdump -i eth0 udp port 53
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode
listening on eth0, link-type EN10MB (Ethernet), capture size 262144 bytes
13:28:35.416720 IP 192.168.0.11.46858 > resolver1.privateinternetaccess.com.domain: 22927+ A? imap.gmail.com. (32)
13:28:35.416730 IP 192.168.0.11.46858 > resolver1.privateinternetaccess.com.domain: 8909+ AAAA? imap.gmail.com. (32)
13:28:35.416974 IP 192.168.0.11.39732 > resolver1.privateinternetaccess.com.domain: 35471+ PTR? 222.18.222.209.in-addr.arpa. (45)
13:28:35.436305 IP 192.168.0.11.52326 > resolver1.privateinternetaccess.com.domain: 65414+ A? live.mozillamessaging.com. (43)
13:28:35.436310 IP 192.168.0.11.52326 > resolver1.privateinternetaccess.com.domain: 30886+ AAAA? live.mozillamessaging.com. (43)
13:28:35.478049 IP 192.168.0.11.46175 > resolver1.privateinternetaccess.com.domain: 5292+ A? mx.endora.cz. (30)
13:28:35.478053 IP 192.168.0.11.46175 > resolver1.privateinternetaccess.com.domain: 16624+ AAAA? mx.endora.cz. (30)
13:28:35.815497 IP 192.168.0.11.50734 > resolver1.privateinternetaccess.com.domain: 17117+ A? clients1.google.com. (37)
13:28:35.815508 IP 192.168.0.11.50734 > resolver1.privateinternetaccess.com.domain: 34551+ AAAA? clients1.google.com. (37)
13:28:35.816481 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.46175: 5292 1/0/0 A 88.86.120.212 (46)
13:28:35.818739 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.46175: 16624 0/1/0 (86)
13:28:35.959874 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.50734: 17117 2/0/0 CNAME clients.l.google.com., A 172.217.12.142 (77)
13:28:35.959899 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.50734: 34551 2/0/0 CNAME clients.l.google.com., AAAA 2607:f8b0:4006:819::200e (89)
13:28:35.972396 IP 192.168.0.11.50409 > resolver1.privateinternetaccess.com.domain: 53313+ A? ocsp2.globalsign.com. (38)
13:28:35.972406 IP 192.168.0.11.50409 > resolver1.privateinternetaccess.com.domain: 62184+ AAAA? ocsp2.globalsign.com. (38)
13:28:36.145921 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.50409: 62184 3/0/0 CNAME cdn.globalsigncdn.com., AAAA 2400:cb00:2048:1::681f:4a7c, AAAA 2400:cb00:2048:1::681f:4b7c (126)
13:28:36.153394 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.50409: 53313 3/0/0 CNAME cdn.globalsigncdn.com., A 104.31.75.124, A 104.31.74.124 (102)
13:28:36.345446 IP 192.168.0.11.39036 > resolver1.privateinternetaccess.com.domain: 49155+ A? www.googleapis.com. (36)
13:28:36.345462 IP 192.168.0.11.39036 > resolver1.privateinternetaccess.com.domain: 10791+ AAAA? www.googleapis.com. (36)
13:28:36.483314 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.39036: 49155 13/0/0 CNAME googleapis.l.google.com., A 172.217.6.234, A 172.217.10.234, A 172.217.12.170, A 172.217.12.202, A 172.217.9.234, A 172.217.10.10, A 172.217.10.42, A 172.217.10.74, A 172.217.10.138, A 172.217.3.106, A 172.217.12.138, A 172.217.6.202 (262)
13:28:36.483344 IP resolver1.privateinternetaccess.com.domain > 192.168.0.11.39036: 10791 2/0/0 CNAME googleapis.l.google.com., AAAA 2607:f8b0:4006:812::200a (98)
^C
EDIT6:
sudo dhclient -r
sudo dhclient -v eth0
Internet Systems Consortium DHCP Client 4.3.3
Copyright 2004-2015 Internet Systems Consortium.
All rights reserved.
For info, please visit https://www.isc.org/software/dhcp/
Listening on LPF/eth0/d8:50:e6:05:e1:db
Sending on LPF/eth0/d8:50:e6:05:e1:db
Sending on Socket/fallback
DHCPDISCOVER on eth0 to 255.255.255.255 port 67 interval 3 (xid=0x3ede007c)
DHCPREQUEST of 192.168.0.11 on eth0 to 255.255.255.255 port 67 (xid=0x7c00de3e)
DHCPOFFER of 192.168.0.11 from 192.168.0.1
DHCPACK of 192.168.0.11 from 192.168.0.1
/etc/resolvconf/update.d/libc: Warning: /etc/resolv.conf is not a symbolic link to /run/resolvconf/resolv.conf
bound to 192.168.0.11 -- renewal in 2147483648 seconds.
EDIT7:
$ sudo tcpdump -i eth0 -vvv -n port 68
tcpdump: listening on eth0, link-type EN10MB (Ethernet), capture size 262144 bytes
14:30:18.135530 IP (tos 0x10, ttl 128, id 0, offset 0, flags [none], proto UDP (17), length 328)
0.0.0.0.68 > 255.255.255.255.67: [udp sum ok] BOOTP/DHCP, Request from d8:50:e6:05:e1:db, length 300, xid 0x7a30842b, Flags [none] (0x0000)
Client-Ethernet-Address d8:50:e6:05:e1:db
Vendor-rfc1048 Extensions
Magic Cookie 0x63825363
DHCP-Message Option 53, length 1: Request
Requested-IP Option 50, length 4: 192.168.0.11
Hostname Option 12, length 10: "vb-nb-mint"
Parameter-Request Option 55, length 18:
Subnet-Mask, BR, Time-Zone, Default-Gateway
Domain-Name, Domain-Name-Server, Option 119, Hostname
Netbios-Name-Server, Netbios-Scope, MTU, Classless-Static-Route
NTP, Classless-Static-Route, Classless-Static-Route-Microsoft, Static-Route
Option 252, NTP
END Option 255, length 0
PAD Option 0, length 0, occurs 18
14:30:18.136280 IP (tos 0x0, ttl 64, id 15220, offset 0, flags [none], proto UDP (17), length 576)
192.168.0.1.67 > 192.168.0.11.68: [udp sum ok] BOOTP/DHCP, Reply, length 548, xid 0x7a30842b, Flags [none] (0x0000)
Your-IP 192.168.0.11
Client-Ethernet-Address d8:50:e6:05:e1:db
Vendor-rfc1048 Extensions
Magic Cookie 0x63825363
DHCP-Message Option 53, length 1: ACK
Server-ID Option 54, length 4: 192.168.0.1
Lease-Time Option 51, length 4: 4294967295
Subnet-Mask Option 1, length 4: 255.255.255.0
Default-Gateway Option 3, length 4: 192.168.0.1
Domain-Name-Server Option 6, length 8: 8.8.8.8,10.255.255.10
END Option 255, length 0
PAD Option 0, length 0, occurs 270
^C
+
$ cat /run/resolvconf/resolv.conf
# Dynamic resolv.conf(5) file for glibc resolver(3) generated by resolvconf(8)
# DO NOT EDIT THIS FILE BY HAND -- YOUR CHANGES WILL BE OVERWRITTEN
nameserver 8.8.8.8
nameserver 10.255.255.10
nameserver 127.0.1.1
Antwort1
In /etc/gai.conf müssen Sie die Zeile, die IPv6 Vorrang vor IPv4 gibt, wie folgt auskommentieren:
# precedence ::ffff:0:0/96 100
Sie müssen auch /etc/dhclient/dhclient6.conf bearbeiten und möglicherweise den Parameter -6 an dhclient übergeben, wenn das nicht ausreicht.
Ich würde auch vorschlagen, den resolv.conf-Link zu korrigieren.
Ich könnte auch schwören, dass dhclient nur die ersten beiden über DHCP übergebenen DNS-Server verwendet, aber ich könnte mich irren.
BEARBEITEN:
Der obige Schritt ist korrekt, d. h. unser erster Schritt besteht darin, die folgende Zeile auszukommentieren:
precedence ::ffff:0:0/96 100in der folgenden Datei:
/etc/gai.confDie genannten Schritte ausführenin Microsoft-Dokumentengilt für Linux Mint 18.x, das auf Ubuntu 16.04 basiert:
Erstellen Sie die folgende Datei:
/etc/dhcp/dhclient6.confmit Inhalt:
timeout 10;Erstellen Sie die folgende Datei:
/etc/network/interfaces.d/50-cloud-init.cfgmit Inhalt:
iface eth0 inet6 auto up sleep 5 up dhclient -1 -6 -cf /etc/dhcp/dhclient6.conf -lf /var/lib/dhcp/dhclient6.eth0.leases -v eth0 || trueUnd schließlich wird der symbolische Link erstellt und dabei das Original überschrieben
resolv.conf:ln -sf /run/resolvconf/resolv.conf /etc/resolv.confNeustart und voilà, IPv6 von DHCP funktioniert.
Antwort2
Sie können IPv6 gegenüber IPv4 den Vorrang geben, indem Sie die Zeile hinzufügen precedence 2001:470::/32 100und precedence ::ffff:0:0/96 100in der Datei /etc/gai.conf einen Kommentar hinzufügen.
