Linux PPPD-Verbindung beendet -> LCP vom Peer beendet (Benutzeranforderung)

Ich versuche, mit dem Telit HE910-Modem eine GPRS-PPP-Verbindung (zum Rogers Wireless-Datennetzwerk in Kanada) herzustellen, aber bei der DNS-Aushandlung scheint etwas schief zu laufen:

Serial connection established.
using channel 16
Using interface ppp0
Connect: ppp0 <--> /dev/ttyACM3
rcvd [LCP ConfReq id=0x1 <asyncmap 0x0> <auth pap> <magic 0x218a9f69> <pcomp> <accomp>]
sent [LCP ConfReq id=0x1 <asyncmap 0x0> <magic 0x10535642>]
sent [LCP ConfRej id=0x1 <pcomp> <accomp>]
rcvd [LCP ConfAck id=0x1 <asyncmap 0x0> <magic 0x10535642>]
rcvd [LCP ConfReq id=0x2 <asyncmap 0x0> <auth pap> <magic 0x218a9f69>]
sent [LCP ConfAck id=0x2 <asyncmap 0x0> <auth pap> <magic 0x218a9f69>]
sent [LCP EchoReq id=0x0 magic=0x10535642]
sent [PAP AuthReq id=0x1 user="cm-debian" password=""]
rcvd [LCP EchoRep id=0x0 magic=0x218a9f69]
rcvd [PAP AuthAck id=0x1 ""]
PAP authentication succeeded
kernel does not support PPP filtering
sent [IPCP ConfReq id=0x1 <addr 0.0.0.0> <ms-dns1 0.0.0.0> <ms-dns2 0.0.0.0>]
rcvd [IPCP ConfNak id=0x1 <ms-dns1 10.11.12.13> <ms-dns2 10.11.12.14>]
sent [IPCP ConfReq id=0x2 <addr 0.0.0.0> <ms-dns1 10.11.12.13> <ms-dns2 10.11.12.14>]
rcvd [IPCP ConfNak id=0x2 <ms-dns1 10.11.12.13> <ms-dns2 10.11.12.14>]
sent [IPCP ConfReq id=0x3 <addr 0.0.0.0> <ms-dns1 10.11.12.13> <ms-dns2 10.11.12.14>]
rcvd [LCP TermReq id=0x3 "User request"]
LCP terminated by peer (User request)
sent [LCP TermAck id=0x3]
rcvd [IPCP ConfNak id=0x3 <ms-dns1 10.11.12.13> <ms-dns2 10.11.12.14>]
Discarded non-LCP packet when LCP not open
Connection terminated.
Modem hangup

Dies sind die geltenden PPP-Optionen:

pppd options in effect:
debug                   # (from /etc/ppp/pppd_script)
nodetach                # (from /etc/ppp/pppd_script)
dump                    # (from /etc/ppp/pppd_script)
noauth                  # (from /etc/ppp/pppd_script)
/dev/ttyACM3            # (from /etc/ppp/pppd_script)
115200                  # (from /etc/ppp/pppd_script)
lock                    # (from /etc/ppp/pppd_script)
connect /usr/sbin/chat -v -f /etc/chatscripts/hsdpa_connect    # (from /etc/ppp/pppd_script)
crtscts                 # (from /etc/ppp/pppd_script)
modem                   # (from /etc/ppp/options)
noaccomp                # (from /etc/ppp/pppd_script)
asyncmap 0              # (from /etc/ppp/options)
nopcomp                 # (from /etc/ppp/pppd_script)
lcp-echo-failure 5      # (from /etc/ppp/pppd_script)
lcp-echo-interval 5     # (from /etc/ppp/pppd_script)
lcp-max-terminate 10    # (from /etc/ppp/options)
lcp-max-configure 10    # (from /etc/ppp/options)
lcp-max-failure 10      # (from /etc/ppp/options)
show-password           # (from /etc/ppp/pppd_script)
novj                    # (from /etc/ppp/pppd_script)
novjccomp               # (from /etc/ppp/pppd_script)
ipcp-accept-local       # (from /etc/ppp/pppd_script)
ipcp-accept-remote      # (from /etc/ppp/pppd_script)
defaultroute            # (from /etc/ppp/pppd_script)
usepeerdns              # (from /etc/ppp/pppd_script)
nobsdcomp               # (from /etc/ppp/pppd_script)
noipx                   # (from /etc/ppp/options)

Und hier ist meine Chatdatei:

#!/bin/sh
# Connection to the network
'' AT+CGDCONT=1,"IP","internet.com"
# Dial the number.
OK ATD*99***1#
# The modem is waiting for the following answer
CONNECT ''

Kann mir jemand helfen zu verstehen, warum der Peer mir ein LCP-TermReq senden würde?

Antwort1

Für alle anderen, bei denen dieses Problem auftritt: Das Problem bestand letztendlich darin, dass mein mobiler Datenanbieter (der auf dem Rogers-Netzwerk mitnutzt, aber nicht wirklich Rogers ist) seinen eigenen privaten APN hatte und ich mein Chat-Skript aktualisieren musste, um den APN-Namen des privaten Anbieters anstelle des öffentlichen Namens von Rogers zu verwenden.
