Wie konfiguriert man CIFS, damit lokale und Domänenbenutzer schnelle Übertragungsgeschwindigkeiten haben?
Ich habe massive Leistungsprobleme bei der Verwendung von CIFS / SMB / Samba in Kombination mit Benutzern. Dies ist unabhängig davon, ob Active Directory (AD) aktiviert oder deaktiviert ist. Sowohl lokale als auch Domänenbenutzer übertragen Daten sehr langsam. Als Gastbenutzer ist alles in Ordnung.
Ich kann jedoch nicht herausfinden, was den Engpass für authentifizierte Benutzer verursacht. Und wie konfiguriere ich Samba, um das Problem zu vermeiden?
CIFS-/SMB-Übertragungsgeschwindigkeiten
User ----------- write ------------ read
Root ---------- 21.3MB/s -------- 21.8MB/s
Domain -------- 19.7MB/s -------- 19.4MB/s
Guest----------105.1MB/s ------- 101.2MB/s
(Root via AFP 109.7MB/s ------- 108.9MB/s)
Getestet mit 1 GB Junk-Sequential-Reading und -Schreibing.
SMB4.conf
[global]
server max protocol = SMB3_11
encrypt passwords = yes
dns proxy = no
strict locking = no
oplocks = yes
deadtime = 1
max log size = 51200
max open files = 588197
logging = file
load printers = no
printing = bsd
printcap name = /dev/null
disable spoolss = yes
getwd cache = yes
guest account = nobody
map to guest = Bad User
obey pam restrictions = yes
directory name cache size = 0
kernel change notify = no
panic action = /usr/local/libexec/samba/samba-backtrace
nsupdate command = /usr/local/bin/samba-nsupdate -g
server string = FreeNAS File Server
ea support = yes
store dos attributes = yes
lm announce = yes
acl allow execute always = true
dos filemode = yes
multicast dns register = yes
domain logons = no
idmap config *: backend = tdb
idmap config *: range = 90000001-100000000
server role = member server
workgroup = MYDOMAIN
realm = MYDOMAIN.LAN
security = ADS
client use spnego = yes
cache directory = /var/tmp/.cache/.samba
local master = no
domain master = no
preferred master = no
ads dns update = yes
winbind cache time = 7200
winbind offline logon = yes
winbind enum users = yes
winbind enum groups = yes
winbind nested groups = yes
winbind use default domain = no
winbind refresh tickets = yes
idmap config MYDOMAIN: backend = rid
idmap config MYDOMAIN: range = 20000-90000000
allow trusted domains = no
client ldap sasl wrapping = plain
template shell = /bin/sh
template homedir = /home/%D/%U
netbios name = S-FREENAS
pid directory = /var/run/samba
create mask = 0666
directory mask = 0777
client ntlmv2 auth = yes
dos charset = CP437
unix charset = UTF-8
log level = 1
[temp]
path = /mnt/zfs03/temp
printable = no
veto files = /.snapshot/.windows/.mac/.zfs/
writeable = yes
browseable = yes
vfs objects = zfs_space zfsacl aio_pthread streams_xattr catia fruit
hide dot files = yes
guest ok = yes
nfs4:mode = special
nfs4:acedup = merge
nfs4:chown = true
zfsacl:acesort = dontcare
TOP beim Übertragen als Root:
last pid: 46255; load averages: 0.81, 0.49, 0.39 up 2+01:33:28 10:49:23
45 processes: 3 running, 42 sleeping
CPU: 11.7% user, 0.0% nice, 0.9% system, 0.0% interrupt, 87.4% idle
Mem: 273M Active, 3125M Inact, 15G Wired, 230M Cache, 734M Free
ARC: 14G Total, 985M MFU, 12G MRU, 290K Anon, 63M Header, 202M Other
Swap: 8192M Total, 148K Used, 8191M Free
PID USERNAME THR PRI NICE SIZE RES STATE C TIME WCPU COMMAND
46144 root 1 102 0 337M 29744K CPU4 4 1:46 100.00% smbd
2443 root 1 -52 r0 6304K 2272K CPU1 1 13:39 0.10% watchdogd
11480 root 12 21 0 241M 20348K nanslp 1 18:20 0.00% collectd
4655 root 6 21 0 409M 183M select 7 7:11 0.00% python2.7
19466 root 1 52 0 237M 64044K select 7 2:46 0.00% python2.7
2779 root 1 20 0 36500K 18216K select 5 0:56 0.00% ntpd
1919 root 1 20 0 79388K 5024K kqread 3 0:16 0.00% syslog-ng
TOP beim Transfer als Gast
last pid: 46439; load averages: 0.91, 0.68, 0.49 up 2+01:37:13 10:53:08
45 processes: 1 running, 44 sleeping
CPU: 0.8% user, 0.0% nice, 3.6% system, 1.9% interrupt, 93.7% idle
Mem: 273M Active, 3125M Inact, 15G Wired, 230M Cache, 734M Free
ARC: 14G Total, 1332M MFU, 13G MRU, 8994K Anon, 64M Header, 203M Other
Swap: 8192M Total, 148K Used, 8191M Free
PID USERNAME THR PRI NICE SIZE RES STATE C TIME WCPU COMMAND
46407 root 1 46 0 337M 29760K select 4 0:14 38.09% smbd
11480 root 12 21 0 241M 20380K nanslp 3 18:22 0.20% collectd
19466 root 1 52 0 237M 64044K select 6 2:46 0.20% python2.7
2443 root 1 -52 r0 6304K 2272K nanslp 2 13:40 0.10% watchdogd
4655 root 6 20 0 409M 183M select 6 7:15 0.00% python2.7
2779 root 1 20 0 36500K 18216K select 3 0:56 0.00% ntpd
Hardware
- AsRock C2750D4I
- Intel Octa-Core Avoton C2750
- 16 GB DDR3 1600 ECC Ram 4
- WD Red Pro 4 TB (2 entspiegelte Spiegel)
- 1 GB/s LAN
- FreeNAS OS 9.10.1
- 32 GB USB2.0-Stick
