Beispiel für animiertes Mergesort

Question

Ich möchte ein Mergesort-Beispiel wie dieses hier erstellen aufWikipedia:Mergesort. Kann mir jemand helfen?

---

hier ist, was ich bisher gemacht habe, aber es funktioniert nicht richtig und die Effekte sind nicht wie in diesem Wikipedia-Beispiel. Irgendwelche Verbesserungen? Danke

\documentclass{beamer}
\usepackage{pgfpages}
\usepackage[ngerman]{babel}
\usepackage{animate}
\usepackage{tikz}
\usetikzlibrary{arrows,decorations.pathmorphing,through,backgrounds,positioning,fit,petri}
\usetikzlibrary{shapes,shadows}
\usetikzlibrary{shapes.multipart}
\usetikzlibrary{calc}
\usetikzlibrary{decorations.pathreplacing}
\newcounter{angle}
\setcounter{angle}{0}
\begin{document}

\begin{frame}
\begin{animateinline}[
  begin={%
\begin{tikzpicture}
\node[shape=rectangle, draw=black, minimum size=0.5cm](1) at (1,1) {6};
\node[shape=rectangle, draw=black, minimum size=0.5cm](2) at (1.5,1) {5};
\node[shape=rectangle, draw=black, minimum size=0.5cm](3) at (2,1) {3};
\node[shape=rectangle, draw=black, minimum size=0.5cm](4) at (2.5,1) {1};
\node[shape=rectangle, draw=black, minimum size=0.5cm](5) at (3,1) {8};
\node[shape=rectangle, draw=black, minimum size=0.5cm](6) at (3.5,1) {7};
\node[shape=rectangle, draw=black, minimum size=0.5cm](7) at (4,1) {2};
\node[shape=rectangle, draw=black, minimum size=0.5cm](8) at (4.5,1) {4};
\node(9) at (5.0,1) {};
\useasboundingbox (-0.5,-0.5) rectangle (10,9.5);},
  end={\end{tikzpicture}}
]{10}

\newframe*
\multiframe{2}{iCount=1+1}{
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (1) at (1,\iCount) {6};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (2) at (1.5,\iCount) {5};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (3) at (2,\iCount) {3};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (4) at (2.5,\iCount) {1};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (5) at (3.2,\iCount) {8};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (6) at (3.7,\iCount) {7};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (7) at (4.2,\iCount) {2};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (8) at (4.7,\iCount) {4};
}

\newframe*
\multiframe{2}{iCount=2+1}{
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (1) at (1,\iCount) {6};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (2) at (1.5,\iCount) {5};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (3) at (2.1,\iCount) {3};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (4) at (2.6,\iCount) {1};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (5) at (3.2,\iCount) {8};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (6) at (3.7,\iCount) {7};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (7) at (4.3,\iCount) {2};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (8) at (4.8,\iCount) {4};
}

\newframe*
\multiframe{2}{iCount=3+1}{
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (1) at (1,\iCount) {5};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (2) at (1.5,\iCount) {6};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (3) at (2.1,\iCount) {1};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (4) at (2.6,\iCount) {3};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (5) at (3.2,\iCount) {7};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (6) at (3.7,\iCount) {8};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (7) at (4.3,\iCount) {2};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (8) at (4.8,\iCount) {4};
}

\newframe*
\multiframe{2}{iCount=4+1}{
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (1) at (1,\iCount) {1};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (2) at (1.5,\iCount) {3};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (3) at (2.0,\iCount) {5};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (4) at (2.5,\iCount) {6};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (5) at (3.2,\iCount) {2};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (6) at (3.7,\iCount) {4};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (7) at (4.2,\iCount) {7};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (8) at (4.7,\iCount) {8};
}

\newframe*
\multiframe{2}{iCount=5+1}{
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (1) at (1,\iCount) {1};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (2) at (1.5,\iCount) {2};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (3) at (2.0,\iCount) {3};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (4) at (2.5,\iCount) {4};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (5) at (3.0,\iCount) {5};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (6) at (3.5,\iCount) {6};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (7) at (4.0,\iCount) {7};
    \node[shape=rectangle, draw=black, minimum size=0.5cm] (8) at (4.5,\iCount) {8};
}
\end{animateinline}
\end{frame}

\end{document}

Answer 1

Hier ist eine Idee, bei der blaue Kreise anzeigen, was als Nächstes getan wird. Es ist nur ein Konzept, die eigentliche Sache fest zu codieren wäre eine echte Qual (deshalb werde ich es nicht tun). Sie können dies gerne bearbeiten oder löschen.

Code

\documentclass{beamer}
\usepackage{tikz}
\usetikzlibrary{arrows}

% scaling factor of the picture
\pgfmathsetmacro{\scalefactor}{0.40}

% styles for boxes, arrows, and the circles
\tikzset%
{   mybox/.style={thick, minimum width=2cm*\scalefactor, minimum height=2cm*\scalefactor, text=black, inner sep=0},
    myarrow/.style={thick,-latex,blue},
    myhighbox/.style={circle,draw=blue,thick, minimum width=3.3cm*\scalefactor}
}

\begin{document}

\begin{frame}

\begin{tikzpicture}[scale=\scalefactor]

% help grid
    \draw[gray] (0,0) grid (23,11);
%   help labels
    \foreach \x in {0,2,...,22} \draw (\x,0) -- (\x,-0.5) node[below] at (\x,0) {\x};
    \foreach \x in {0,2,...,10} \draw (0,\x) -- (-0.5,\x) node[left] at (0,\x) {\x};

% cycle over all states of boxone; state=[x-pos, y-pos, color, statestart(frame), stateend(frame)]
    \foreach \x/\y/\col/\startframe/\endframe in {1/3/red/1/3, 12/4/black/4/5, 19/1/red/6/6}
    {   \node<\startframe-\endframe>[mybox,draw=\col] at (\x,\y) {1};
    }

% cycle over all states of boxtwo; state=[x-pos, y-pos, color, statestart(frame), stateend(frame)]
    \foreach \x/\y/\col/\startframe/\endframe in {10/7/black/1/2, 20/1/black/3/4, 4/2/red/5/6}
    {   \node<\startframe-\endframe>[mybox,draw=\col] at (\x,\y) {2};
    }

% ... and so on for all boxes

% cycle over all states of arrows; state=[x1, y1, x2, y2, frame]
    \foreach \xa/\ya/\xb/\yb/\fra in {1/3/12/4/3, 12/4/19/1/5, 10/7/20/1/2, 20/1/4/2/4}
    {   \node<\fra>[myhighbox] (startbox) at (\xa,\ya) {};
        \node<\fra>[myhighbox] (endbox) at (\xb,\yb) {};
        \draw<\fra>[myarrow] (startbox) -- (endbox);
    }

% just a help to show how the boxes could be positioned in certain steps
    \foreach \x [count=\c] in {1,4,...,22} \node<7>[mybox,fill=green!20,draw=black] at (\x,1) {\c};
    \foreach \x [count=\c] in {3,5,8,10,13,15,18,20} \node<7>[mybox,fill=green!20,draw=black] at (\x,4) {\c};
    \foreach \x [count=\c] in {4,6,8,10,13,15,17,19} \node<7>[mybox,fill=green!20,draw=black] at (\x,7) {\c};
    \foreach \x [count=\c] in {4.5,6.5,...,18.5} \node<7>[mybox,fill=green!20,draw=black] at (\x,10) {\c};

\end{tikzpicture}

\end{frame}

\end{document}

Ergebnis
