Wie zeichnet man ein schematisches Industriediagramm in LaTeX?

Question

Ist es möglich, das folgende Diagramm in LaTeX zu erstellen? Mich interessiert der Hauptteil, jede Farbe innerhalb des Kastens ist in Ordnung.

Answer 1

\documentclass{standalone}
\usepackage{tikz}

\usetikzlibrary{positioning}
\usetikzlibrary{decorations.pathreplacing}

\begin{document}


\begin{tikzpicture} [align=left]
    \node [draw] (home) {Home\\(capital-abundant)};
    \draw (home.east) -- ++(2,0) node [above] (cloth) {Cloth}
        -- ++(2,0) node [above] (food) {Food} -- ++(1,0) node [coordinate] (topend) {};
    \node[below=of home] (mid) {};
    \draw[dashed] (cloth |- mid) -- (topend |- mid);
    \node [draw, below=of mid] (foreign) {Foreign\\(labor-abundant)};
    \draw (foreign.east) -- (topend |- foreign);
    \draw[->] (cloth) -- (cloth |- foreign);
    \draw[->] (food |- mid) -- (food);
    \node [coordinate,right=0.1cm of cloth] (c1) {};
    \draw[->] (c1 |- foreign) -- (c1 |- mid);
    \draw[decorate,decoration={brace, amplitude=4pt}]
            (topend) -- (topend |- mid) node[midway, right=3pt]{Interindustry};
    \draw[decorate,decoration={brace, amplitude=4pt}]
            (topend |- mid) -- (topend |- foreign) node[midway, right=3pt]{Intraindustry};
\end{tikzpicture}

\end{document}
