Tikz: Wie werden einige verknüpfte Knoten richtig angezeigt?

tag-icon • tag-icon tikz-pgf diagrams nodes
Tikz: Wie werden einige verknüpfte Knoten richtig angezeigt?

Ich habe das folgende Diagramm mit Tikz erstellt. Gibt es eine Möglichkeit, es richtig anzuzeigen? (So wie es ist, wird es mit allen Knoten unterhalb des letzten angezeigt, es ist also ein Durcheinander.)

\documentclass{article}

\usepackage[spanish]{babel}

\usepackage{tikz}
\usetikzlibrary{shapes.geometric, arrows}

\tikzstyle{io} = [ellipse, minimum width=3cm, minimum height=1cm, text centered, draw=black, fill=blue!30]
\tikzstyle{arrow} = [thick,->,>=stealth]

\begin{document}
\begin{tikzpicture}[node distance=2cm]
\node (1) [io] {1 1 1 1};
\node (2) [io, below of=1] {2 1 0 1};
\node (3) [io, below of=2] {1 0 1 2};
\node (4) [io, below of=3] {2 0 0 2};
\node (5) [io, below of=4] {0 0 2 2};
\node (6) [io, below of=5] {0 1 2 1};
\node (7) [io, below of=6] {0 2 2 0};
\node (8) [io, below of=7] {1 2 1 0};
\node (9) [io, below of=8] {2 2 0 0};

\draw [arrow] (1) -- node {t1} (2);
\draw [arrow] (2) -- node {t2} (3);
\draw [arrow] (3) -- node {t1} (4);
\draw [arrow] (4) -- node {t3} (2);
\draw [arrow] (3) -- node {t3} (1);
\draw [arrow] (2) -- node {t3} (9);
\draw [arrow] (9) -- node {t2} (1);
\draw [arrow] (1) -- node {t3} (8);
\draw [arrow] (1) -- node {t2} (5);
\draw [arrow] (5) -- node {t1} (3);
\draw [arrow] (5) -- node {t3} (6);
\draw [arrow] (6) -- node {t1} (1);
\draw [arrow] (6) -- node {t3} (7);
\draw [arrow] (7) -- node {t1} (8);
\draw [arrow] (8) -- node {t2} (6);
\draw [arrow] (8) -- node {t1} (9);

\end{tikzpicture}
\end{document}

Wie könnte ich beispielsweise die Knoten in einem Kreislayout anzeigen?

Antwort1

Sie sagten „in einem Kreislayout“. Hier ist ein Beispiel. Sie können die Knoten mithilfe eines at (<angle:distance>)Makros um Knoten (1) herum platzieren.

\documentclass{article}

\usepackage[spanish]{babel}

\usepackage{tikz}
\usetikzlibrary{shapes.geometric, arrows}

\tikzstyle{io} = [ellipse, minimum width=3cm, minimum height=1cm, text centered, draw=black, fill=blue!30]
\tikzstyle{arrow} = [thick,->,>=stealth]

\begin{document}
\begin{tikzpicture}%[node distance=2cm]
\node (1) [io] {1 1 1 1};
\node (2) [io] at (45:2in) {2 1 0 1};
\node (4) [io] at (90:2in) {2 0 0 2};
\node (3) [io] at (135:2in) {1 0 1 2};
\node (5) [io] at (180:2in) {0 0 2 2};
\node (6) [io] at (225:2in) {0 1 2 1};
\node (7) [io] at (270:2in) {0 2 2 0};
\node (8) [io] at (315:2in) {1 2 1 0};
\node (9) [io] at (360:2in) {2 2 0 0};

\draw [arrow] (1) -- node[auto] {t1} (2);    %% note auto option here onwards
                                             %%        for proper placement.
\draw [arrow] (2) -- node[auto] {t2} (3);
\draw [arrow] (3) -- node[auto] {t1} (4);
\draw [arrow] (4) -- node[auto,xshift=1cm] {t3} (2);
\draw [arrow] (3) -- node[auto] {t3} (1);
\draw [arrow] (2) -- node[auto] {t3} (9);
\draw [arrow] (9) -- node[auto] {t2} (1);
\draw [arrow] (1) -- node[auto] {t3} (8);
\draw [arrow] (1) -- node[auto] {t2} (5);
\draw [arrow] (5) -- node[auto] {t1} (3);
\draw [arrow] (5) -- node[auto] {t3} (6);
\draw [arrow] (6) -- node[auto] {t1} (1);
\draw [arrow] (6) -- node[auto] {t3} (7);
\draw [arrow] (7) -- node[auto] {t1} (8);
\draw [arrow] (8) -- node[auto] {t2} (6);
\draw [arrow] (8) -- node[auto] {t1} (9);

\end{tikzpicture}
\end{document}

Bildbeschreibung hier eingeben

Sie können die Topologie selbst an Ihre Bedürfnisse anpassen.

Antwort2

Hier ist etwas, das Ihnen den Einstieg in die Syntax erleichtern tound Ihnen dabei hilft, die Anker und in=Winkel out=für die Pfeile festzulegen.

Bildbeschreibung hier eingeben

Code:

\documentclass{article}

\usepackage[spanish]{babel}

\usepackage{tikz}
\usetikzlibrary{shapes.geometric, arrows}

\tikzstyle{io} = [ellipse, minimum width=3cm, minimum height=1cm, text centered, draw=black, fill=blue!30]
\tikzstyle{arrow} = [thick,->,>=stealth]

\begin{document}
\begin{tikzpicture}[node distance=2cm]
\node (1) [io] {1 1 1 1};
\node (2) [io, below of=1] {2 1 0 1};
\node (3) [io, below of=2] {1 0 1 2};
\node (4) [io, below of=3] {2 0 0 2};
%\node (5) [io, below of=4] {0 0 2 2};
%\node (6) [io, below of=5] {0 1 2 1};
%\node (7) [io, below of=6] {0 2 2 0};
%\node (8) [io, below of=7] {1 2 1 0};
%\node (9) [io, below of=8] {2 2 0 0};

\draw [arrow] (1.south) -- node[right] {t1} (2.north);
\draw [arrow] (2.south) -- node[right] {t2} (3.north);
\draw [arrow] (3.south) -- node[right] {t1} (4.north);
\draw [arrow,out=70,in=-70] (4.east) to node[right] {t3} (2.east);
\draw [arrow,out=170,in=-170] (3.west) to node[left] {t3} (1.west);
%\draw [arrow] (2.south) -- node[right] {t3} (9.north);
%\draw [arrow] (9.south) -- node[right] {t2} (1.north);
%\draw [arrow] (1.south) -- node[right] {t3} (8.north);
%\draw [arrow] (1.south) -- node[right] {t2} (5.north);
%\draw [arrow] (5.south) -- node[right] {t1} (3.north);
%\draw [arrow] (5.south) -- node[right] {t3} (6.north);
%\draw [arrow] (6.south) -- node[right] {t1} (1.north);
%\draw [arrow] (6.south) -- node[right] {t3} (7.north);
%\draw [arrow] (7.south) -- node[right] {t1} (8.north);
%\draw [arrow] (8.south) -- node[right] {t2} (6.north);
%\draw [arrow] (8.south) -- node[right] {t1} (9.north);

\end{tikzpicture}
\end{document}
