Betrachten Sie das folgende Diagramm:
\documentclass{article}
\usepackage[T1]{fontenc}
\usepackage[margin = 2cm]{geometry}
\usepackage{pstricks}
\usepackage{rotating}
\usepackage{microtype}
\DisableLigatures[f]{encoding = T1}
\pagestyle{empty}
\begin{document}
\begin{center}
\textbf{\Huge Venn Diagram of Irrational Nonsense}
\end{center}
\vspace{5ex}
\begin{center}
\psset{unit = 2.4}
\begin{pspicture}(-3.5,-1.75)(3.5,4.25)
\psellipse[rot = -50](1.5,0.5)(1.5,3)
\psellipse[rot = 50](-1.5,0.5)(1.5,3)
\psellipse[rot = -50](0,1.8)(1.5,3)
\psellipse[rot = 50](0,1.8)(1.5,3)
\rput(-3.57,1.93){
\begin{rotate}{45}
\shortstack[c]{%
Religious\strut\\[-0.75ex]
Bollocks\strut}
\end{rotate}
}
\rput(-2.1,3.2){
\begin{rotate}{45}
\shortstack[c]{%
Quackery\strut\\[-0.75ex]
Bollocks\strut}
\end{rotate}
}
\rput(3.07,2.33){
\begin{rotate}{315}
\shortstack[c]{%
Paranormal\strut\\[-0.75ex]
Bollocks\strut}
\end{rotate}
}
\rput(1.52,3.78){
\begin{rotate}{315}
\shortstack[c]{%
Pseudoscientific\strut\\[-0.75ex]
Bollocks\strut}
\end{rotate}
}
\rput(0,0.5){Scientology}
{\footnotesize
\rput(0.5,0){\shortstack[c]{%
Psychic\strut\\[-0.75ex]
Surgery\strut}}
\rput(1.5,0.1){Aura Therapy}
\rput(1.7,0.5){Reiki}
\rput(1.9,0.9){Chakra}
\rput(0.6,1){Qi}
\rput(0.9,1.3){Feng Shui}
\rput(1.2,1.6){Past Life Regression}
{\tiny
\rput(2.1,2.43){Ley Lines}
\rput(1.95,2.32){Orgone Energy}
\rput(1.97,2.21){Palmistry}
\rput(1.98,2.1){Orbs}}
\rput(2.9,1.8){Crop Circles}
\rput(3.1,1.5){Ectoplasm}
\rput(3.1,1.2){Telepathy}
\rput(3,0.9){Tarot}
\rput(3,0.6){\shortstack[c]{%
Crystal\strut\\[-0.75ex]
Power\strut}}
\rput(2.9,0.3){\shortstack[c]{%
Automaric\strut\\[-0.75ex]
Writing\strut}}
\rput(2.75,0){Geomancy}
\rput(2.55,-0.25){Levitation}
\rput(2.1,-0.5){Remote Writing}
\rput(2,-0.7){Ghosts}
\rput(1.4,-0.7){Psychics}
\rput(1.5,-1){Poltergeist}
\rput(1.2,-1.2){Seances}
\rput(-0.5,-0.5){Exorcism}
\rput(-0.5,-0.8){Ouija Boards}
\rput(-0.5,-1.1){Spiritualism}
\rput(0,-1.4){Stigmata}
\rput(0.5,-0.5){Akashic Record}
\rput(0.5,-0.8){Occult}
\rput(0.5,-1.1){Voodoo}
\rput(-0.5,0){\shortstack[c]{%
Bible\strut\\[-0.75ex]
Code\strut}}
\rput(-1.9,0.95){\shortstack[c]{%
Apocalyptic\strut\\[-0.75ex]
Prophecies\strut}}
\rput(-1.7,0.6){Intelligent Design}
\rput(-1.6,0.3){Out of Body Experience}
\rput(-1.5,0){Turin Shroud}
\rput(-1.2,1.6){Antrophosophy}
\rput(-0.8,1.1){Alphabiotics}
\rput(0,3.2){Anti Vaccination}
\rput(-0.4,2.9){Cupping}
\rput(0.4,2.9){Chiropratic}
\rput(0,2.6){Bioharmonics}
\rput(-0.4,2.3){Reflexology}
\rput(0.4,2.3){Rolfing}
\rput(0,2){Applied Kinesiology}
\rput(0,1.75){Ear Candles}
\rput(0,1.5){Detox}
{\scriptsize
\rput(0.7,3.7){Chemtrails}
\rput(1,3.525){Astrology}
\rput(1.3,3.35){Numerology}
\rput(1.6,3.175){Hollow Earth}
\rput(1.8,3){Moon Landing Denial}
\rput(1.8,2.825){Dowsing}
\rput(1.8,2.65){Bigfoot}}
\rput(-0.7,3.6){Shiatsu}
\rput(-1,3.4){Acupuncture}
\rput(-1.3,3.2){Homeopathy}
\rput(-1.6,3){Aromatherapy}
\rput(-1.8,2.8){Ayurvedic Medicine}
{\tiny
\rput(-2.1,2.4){\shortstack[c]{%
Angel\strut\\[-0.75ex]
Therapy\strut}}
\rput(-1.98,2.15){\shortstack[c]{%
Faith\strut\\[-0.75ex]
Healing\strut}}}
\rput(-2.8,1.9){Miracles}
\rput(-3,1.6){\shortstack[c]{%
Religious\strut\\[-0.75ex]
Fundamentalism\strut}}
\rput(-3.1,1.3){Reincarnation}
\rput(-3.1,1.05){Creationism}
\rput(-3,0.8){Prayer}
\rput(-2.97,0.5){\shortstack[c]{%
Trans-\strut\\[-0.75ex]
substantiation\strut}}
\rput(-2.85,0.2){Holy Relics}
\rput(-2.65,-0.1){Angels}
\rput(-2.35,-0.4){The Trinity}
\rput(-1.9,-0.7){Karma}}
\end{pspicture}
\end{center}
\end{document}
Wie färbe ich das Diagramm, um folgende Ausgabe zu erhalten?
Beachten Sie, dass die spezifischen Farben nicht wichtig sind. Es kommt darauf an, wie ich die überlappenden Farben erhalte.
Antwort1
Das ist eine einfache feste Füllung mit einem kleinen Wert für opacity:
[...]
\psset{unit = 2.4,opacity=0.2,fillstyle=solid}
\begin{pspicture}(-3.5,-1.75)(3.5,4.25)
\psellipse[rot=-50,fillcolor=blue](1.5,0.5)(1.5,3)
\psellipse[rot = 50,fillcolor=red](-1.5,0.5)(1.5,3)
\psellipse[rot = -50,fillcolor=green](0,1.8)(1.5,3)
\psellipse[rot = 50,fillcolor=yellow](0,1.8)(1.5,3)
[...]
