Ich habe das folgende Bild mit Inkspace erstellt und nach Tikz exportiert. Das Problem ist, dass der Text nicht in die Kästchen passt. Und die Pfeile sollten mit einem Farbverlauf gefärbt sein, aber das ist nicht so wichtig. Ich habe es parboxmit tabulareiner Umgebung versucht. Das Ergebnis ist dem untenstehenden Ergebnis ähnlich. Gibt es andere Möglichkeiten, das Problem zu beheben? Entschuldigen Sie den hässlichen Code )) Vielen Dank im Voraus!
\documentclass[12pt,a4paper,oneside, ngerman]{scrreprt}
\usepackage[ansinew]{inputenc}
\usepackage{tikz}
\begin{document}
\begin{figure}
\definecolor{ccccccc}{RGB}{204,204,204}
\definecolor{cffffff}{RGB}{255,255,255}
\definecolor{c999999}{RGB}{153,153,153}
\definecolor{mygray}{RGB}{240,240,240}
\begin{tikzpicture}[ y=0.80pt, x=0.8pt,yscale=-1, scale=0.9]
\begin{scope}[opacity=0.540,transparency group]
\path[cm={{1.1134,0.0,0.0,1.1134,(-102.46687,-81.77008)}},fill=ccccccc]
(557.1429,311.6479)arc(-0.015:180.015:138.571)arc(-180.015:0.015:138.571) --
cycle;
\path[cm={{1.02577,0.0,0.0,1.02577,(-65.21652,-55.31787)}},fill=cffffff]
(557.1429,311.6479)arc(-0.015:180.015:138.571)arc(-180.015:0.015:138.571) --
cycle;
\path[fill=black] (180,242.36218) node[above right] (text4246) {};
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=0.000pt] (265.0000,152.3622) -- (310.0000,127.3622);
\end{scope}
\path[fill=ccccccc,nonzero rule] (170.4042,189.8211) -- (259.5958,152.7604);
\path[draw=ccccccc,fill=ccccccc,line join=miter,line cap=butt,miter
limit=4.00,line width=9.982pt] (165.0322,167.4265) .. controls
(205.0000,167.3622) and (240.0000,167.3622) .. (264.5510,156.9455);
\path[draw=ccccccc,fill=ccccccc,line join=miter,line cap=butt,miter
limit=4.00,line width=9.840pt] (548.1593,287.4135) -- (598.5310,326.3043);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=9.840pt] (267.8571,151.6479) .. controls (285.0000,137.3622) and
(295.0000,132.3622) .. (312.8571,125.2193);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=11.126pt] (416.7852,123.3070) .. controls (465.0000,147.3622) and
(485.0000,177.3622) .. (504.0658,210.8975);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=9.840pt] (511.4464,278.0983) .. controls (506.4286,312.3622) and
(505.0000,317.3622) .. (491.5232,339.1471);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=11.558pt] (302.5861,399.3372) .. controls (360.0000,417.3622) and
(390.0000,422.3622) .. (452.4374,382.1258);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=11.126pt] (217.6500,281.8994) .. controls (225.0000,322.3622) and
(230.0000,327.3622) .. (245.1144,355.2866);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=11.126pt] (265.9079,154.0784) .. controls (241.4286,181.2908) and
(233.2143,192.7193) .. (215.7025,237.4581);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=9.840pt] (597.9835,325.9815) .. controls (624.8229,346.1229) and
(624.8229,346.1229) .. (624.8229,346.1229);
\path[draw=black,fill=mygray,line join=miter,line cap=butt,even odd rule,line
width=0.987pt,rounded corners=0.0000cm] (133.2388,212.6087) rectangle
(264.7613,274.0543);
\path[cm={{0.91468,0.0,0.0,0.90175,(-100.95407,-80.85112)}},fill=cffffff,opacity=0.000]
(644.4773,389.7021)arc(-0.000:180.000:148.492)arc(-180.000:0.000:148.492) --
cycle;
\path[fill=black] (150,262.36218) node[above right] (text4251) {};
\path[draw=black,fill=mygray,line width=0.742pt] (595.7193,265.8981) --
(509.7908,314.9300) -- (423.8622,265.8981) -- (509.7908,216.8661) -- cycle;
\path[fill=black] (443.01562,266.86725) node[above right] (text4362)
{\begin{minipage}[c]{10em}Abbruchkriterium \\ erfüllt?\end{minipage}};
\path[cm={{0.79307,-0.34521,0.66812,2.0141,(127.42176,109.33876)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[cm={{0.73268,0.45968,-1.28519,1.68858,(505.694,162.81655)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[draw=black,fill=mygray,line join=miter,line cap=butt,even odd rule,line
width=0.987pt,rounded corners=0.0000cm] (210.0560,328.7001) rectangle
(341.5786,390.1457);
\path[draw=black,fill=mygray,line join=miter,line cap=butt,even odd rule,line
width=1.068pt,rounded corners=0.0000cm] (394.0991,348.4690) rectangle
(548.3774,409.8133);
\path[draw=black,fill=mygray,line join=miter,line cap=butt,even odd rule,line
width=0.987pt,rounded corners=0.0000cm] (322.4799,94.0224) rectangle
(454.0024,155.4680);
\path[draw=black,fill=mygray,line join=miter,line cap=butt,even odd rule,line
width=1.043pt,rounded corners=0.0000cm] (22.5064,134.1592) rectangle
(169.6727,195.5343);
\path[draw=black,fill=mygray,line join=miter,line cap=butt,even odd rule,line
width=0.987pt,rounded corners=0.0000cm] (606.0053,302.4869) rectangle
(737.5278,363.9325);
\path[fill=black] (164.28571,247.93361) node[above right] (text4255) {Mutation};
\path[fill=black] (217.85713,363.07645) node[above right] (text4255-0)
{Rekombination};
\path[fill=black] (405,373.79074) node[above right] (text4331) {\begin{minipage}[c]{10em}Selektion der\\ besten Individuen\end{minipage}};
\path[fill=black] (340.14285,120.21932) node[above right] (text4335) {\begin{minipage}[c]{10em}Berechnung\\ der Fitness \end{minipage}};
\path[fill=black] (26.270847,159.8571) node[above right] (text4341)
{\begin{minipage}[c]{10em}Initialisierung \\der ersten\\ Population\end{minipage}};
\path[fill=black] (612.86725,328.42966) node[above right] (text4349) {\begin{minipage}[c]{10em}Ergebnis: \\ beste Individuen \end{minipage}};
\path[cm={{0.60459,-0.61854,1.37766,1.61401,(84.78393,210.78691)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[cm={{0.3593,0.78678,-2.00187,0.70393,(516.30858,26.20105)}},fill=c999999,miter
limit=4.00,line width=7.278pt] (210.0000,42.3622) -- (195.0000,51.0224) --
(195.0000,33.7019) -- cycle;
\path[cm={{-0.28036,0.81824,-1.93729,-0.86596,(627.99541,212.57875)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[cm={{-0.61294,-0.61027,1.62665,-1.36272,(357.04714,578.75742)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[cm={{-0.22342,-0.83865,2.21259,-0.33168,(167.67156,464.36418)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[fill=black] (582.5,298.07648) node[above right] (text5333) {Ja};
\path[fill=black] (446.07141,322.36218) node[above right] (text5337) {Nein};
\end{tikzpicture}
\end{figure}
\end{document}
Antwort1
Nach dem Vorschlag von Cjorssen und Skalierung zur Vermeidung von Überboxen habe ich Folgendes erhalten:
\documentclass[12pt,a4paper,oneside, ngerman]{scrreprt}
\usepackage[ansinew]{inputenc}
\usepackage{tikz}
\usetikzlibrary{shapes.geometric}
\usetikzlibrary{shapes.arrows}
\begin{document}
\begin{figure}
\definecolor{ccccccc}{RGB}{204,204,204}
\definecolor{cffffff}{RGB}{255,255,255}
\definecolor{c999999}{RGB}{153,153,153}
\definecolor{mygray}{RGB}{240,240,240}
\definecolor{mygray1}{RGB}{226,226,226}
\begin{tikzpicture}[ y=0.80pt, x=0.8pt,yscale=-1, scale=0.7]
\begin{scope}[opacity=0.540,transparency group]
\path[cm={{1.1134,0.0,0.0,1.1134,(-102.46687,-81.77008)}},fill=ccccccc]
(557.1429,311.6479)arc(-0.015:180.015:138.571)arc(-180.015:0.015:138.571) --
cycle;
\path[cm={{1.02577,0.0,0.0,1.02577,(-65.21652,-55.31787)}},fill=cffffff]
(557.1429,311.6479)arc(-0.015:180.015:138.571)arc(-180.015:0.015:138.571) --
cycle;
\path[fill=black] (180,242.36218) node[above right] (text4246) {};
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=0.000pt] (265.0000,152.3622) -- (310.0000,127.3622);
\end{scope}
\path[fill=ccccccc,nonzero rule] (170.4042,189.8211) -- (259.5958,152.7604);
\path[draw=ccccccc,fill=ccccccc,line join=miter,line cap=butt,miter
limit=4.00,line width=9.982pt] (165.0322,167.4265) .. controls
(205.0000,167.3622) and (240.0000,167.3622) .. (264.5510,156.9455);
\path[draw=ccccccc,fill=ccccccc,line join=miter,line cap=butt,miter
limit=4.00,line width=9.840pt] (548.1593,287.4135) -- (598.5310,326.3043);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=9.840pt] (267.8571,151.6479) .. controls (285.0000,137.3622) and
(295.0000,132.3622) .. (312.8571,125.2193);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=11.126pt] (416.7852,123.3070) .. controls (465.0000,147.3622) and
(485.0000,177.3622) .. (504.0658,210.8975);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=9.840pt] (511.4464,278.0983) .. controls (506.4286,312.3622) and
(505.0000,317.3622) .. (491.5232,339.1471);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=11.558pt] (302.5861,399.3372) .. controls (360.0000,417.3622) and
(390.0000,422.3622) .. (452.4374,382.1258);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=11.126pt] (217.6500,281.8994) .. controls (225.0000,322.3622) and
(230.0000,327.3622) .. (245.1144,355.2866);
\path[draw=ccccccc,line join=miter,line cap=butt,miter limit=4.00,line
width=11.126pt] (265.9079,154.0784) .. controls (241.4286,181.2908) and
(233.2143,192.7193) .. (215.7025,237.4581);
\path[draw=mygray1,line join=miter,line cap=butt,miter limit=4.00,line
width=9.840pt] (597.9835,325.9815) .. controls (624.8229,346.1229) and
(624.8229,346.1229) .. (624.8229,346.1229);
\node[diamond,aspect=3, draw = black, fill = mygray, align = center, ] at (525.01562,260.86725) {Abbruchkr. \\ erf\"{u}llt?};
\path[cm={{0.79307,-0.34521,0.66812,2.0141,(127.42176,109.33876)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[cm={{0.73268,0.45968,-1.28519,1.68858,(505.694,162.81655)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\node[rectangle, draw = black, fill = mygray, align = center, text width = 7em, minimum height = 2.5em] at (270.85713,362.07645) {Rekombination};
\node[rectangle, draw = black, fill = mygray, align = center, text width = 7em, minimum height = 2.5em] at (220.28571,245.93361) {Mutation};
\node[rectangle, draw = black, fill = mygray, align = center, text width = 8em] at (477,375.79074) {Selektion der\\ besten Individuen};
\node[rectangle, draw = black, fill = mygray, align = center, text width = 6em] at (393.14285,120.21932) {Berechnung \\ der Fitness};
\node[rectangle, draw = black, fill = mygray, align = center, text width = 8em] at (75.270847,159.8571) {Initialisierung \\der ersten\\ Population};
\node[rectangle, draw = black, fill = mygray, align = center, text width = 8em] at (698.86725,330.42966) {Ergebnis: \\ beste Individuen};
\path[cm={{0.60459,-0.61854,1.37766,1.61401,(84.78393,210.78691)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[cm={{0.3593,0.78678,-2.00187,0.70393,(516.30858,26.20105)}},fill=c999999,miter
limit=4.00,line width=7.278pt] (210.0000,42.3622) -- (195.0000,51.0224) --
(195.0000,33.7019) -- cycle;
\path[cm={{-0.28036,0.81824,-1.93729,-0.86596,(627.99541,212.57875)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[cm={{-0.61294,-0.61027,1.62665,-1.36272,(357.04714,578.75742)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[cm={{-0.22342,-0.83865,2.21259,-0.33168,(167.67156,464.36418)}},fill=c999999]
(210.0000,42.3622) -- (195.0000,51.0224) -- (195.0000,33.7019) -- cycle;
\path[fill=black] (535.5,330.07648) node[above right] (text5333) {Ja};
\path[fill=black] (440.07141,330.36218) node[above right] (text5337) {Nein};
\end{tikzpicture}
\end{figure}
\end{document}
