Ich verwende PSTricks und einige Tikz-Funktionen zum Vorbereiten einiger Skizzen.
Dieser Ausschnitt funktionierte einwandfrei MikTeX unter Windows 7
\documentclass[]{scrartcl}
\usepackage{amstext}
\usepackage{amsmath}
\usepackage{amsfonts}
\usepackage{color}
\usepackage{tikz}
\usepackage{pstricks}
\newrgbcolor{colRM}{.7 .05 .2}
\begin{document}
\begin{center}
\begin{pspicture}(0,0)(17.0,10)
\def \xO {4.0}
\def \yO {1.7}
\rput[c](+{\xO+1.7,\yO-0.8}){ \textcolor{colRM}{ \small{ $\vec M$ } } }
%\psgrid(0,0)(0,-5)(17,10)
\end{pspicture}
\end{center}
\end{document}
funktioniert aber nicht in Kile 2.1.0 auf Ubuntu 12.04, also TeXLive. Die +Ergebnisse in missing number treated as zero.Ich habe versucht, mit der Klammerposition wie {\xO+1.7},{\yO-0.8}oder zu spielen {\xO+1.7} {\yO-0.8}, aber das funktioniert nicht. Meine bisherige Problemumgehung besteht darin, \pgfmathsetmacroin den vorherigen Zeilen zu verwenden und das Ergebnis zu verwenden. Obwohl diese Inkompatibilität etwas frustrierend ist, da ich bei der Arbeit einen Win7-Computer habe und zu Hause nur Linux verwende, würde ich gerne wissen, wie das in Kile geht.
BearbeitenDateiliste gemäß Anfrage von David Carlisle
Dies ist die Windows-Ausgabe von MikTexPortable:
*File List*
scrartcl.cls 2015/02/07 v3.16 KOMA-Script document class (article)
scrkbase.sty 2015/02/07 v3.16 KOMA-Script package (KOMA-Script-dependent basics and keyval usage)
scrbase.sty 2015/02/07 v3.16 KOMA-Script package (KOMA-Script-independent basics and keyval usage)
keyval.sty 2014/10/28 v1.15 key=value parser (DPC)
scrlfile.sty 2015/02/07 v3.16 KOMA-Script package (loading files)
tocbasic.sty 2015/02/07 v3.16 KOMA-Script package (handling toc-files)
scrsize12pt.clo 2015/02/07 v3.16 KOMA-Script font size class option (12pt)
typearea.sty 2015/02/07 v3.16 KOMA-Script package (type area)
german.sty 1998/07/08 v2.5e Support for writing german texts (br)
amstext.sty 2000/06/29 v2.01
amsgen.sty 1999/11/30 v2.0
amsmath.sty 2013/01/14 v2.14 AMS math features
amsbsy.sty 1999/11/29 v1.2d
amsopn.sty 1999/12/14 v2.01 operator names
amsfonts.sty 2013/01/14 v3.01 Basic AMSFonts support
graphics.sty 2014/10/28 v1.0p Standard LaTeX Graphics (DPC,SPQR)
trig.sty 1999/03/16 v1.09 sin cos tan (DPC)
graphics.cfg 2007/01/18 v1.5 graphics configuration of teTeX/TeXLive
dvips.def 2014/10/14 v3.0j Driver-dependent file (DPC,SPQR)
float.sty 2001/11/08 v1.3d Float enhancements (AL)
epic.sty
eepic.sty
color.sty 1999/02/16
color.cfg 2007/01/18 v1.5 color configuration of teTeX/TeXLive
dvipsnam.def 2014/10/14 v3.0j Driver-dependent file (DPC,SPQR)
tikz.sty 2013/12/13 v3.0.0 (rcs-revision 1.142)
pgf.sty 2013/12/18 v3.0.0 (rcs-revision 1.14)
pgfrcs.sty 2013/12/20 v3.0.0 (rcs-revision 1.28)
everyshi.sty 2001/05/15 v3.00 EveryShipout Package (MS)
pgfrcs.code.tex
pgfcore.sty 2010/04/11 v3.0.0 (rcs-revision 1.7)
graphicx.sty 2014/10/28 v1.0g Enhanced LaTeX Graphics (DPC,SPQR)
pgfsys.sty 2013/11/30 v3.0.0 (rcs-revision 1.47)
pgfsys.code.tex
pgfsyssoftpath.code.tex 2013/09/09 (rcs-revision 1.9)
pgfsysprotocol.code.tex 2006/10/16 (rcs-revision 1.4)
xcolor.sty 2007/01/21 v2.11 LaTeX color extensions (UK)
color.cfg 2007/01/18 v1.5 color configuration of teTeX/TeXLive
pgfcore.code.tex
pgfcomp-version-0-65.sty 2007/07/03 v3.0.0 (rcs-revision 1.7)
pgfcomp-version-1-18.sty 2007/07/23 v3.0.0 (rcs-revision 1.1)
pgffor.sty 2013/12/13 v3.0.0 (rcs-revision 1.25)
pgfkeys.sty
pgfkeys.code.tex
pgfmath.sty
pgfmath.code.tex
pgffor.code.tex
tikz.code.tex
pstricks.sty 2013/12/12 v0.60 LaTeX wrapper for `PSTricks' (RN,HV)
ifpdf.sty 2011/01/30 v2.3 Provides the ifpdf switch (HO)
pstricks.tex 2014/10/25 v2.60 `PSTricks' (tvz,hv)
pst-xkey.tex 2005/11/25 v1.6 PSTricks specialization of xkeyval (HA)
xkeyval.sty 2014/12/03 v2.7a package option processing (HA)
xkeyval.tex 2014/12/03 v2.7a key=value parser (HA)
pst-fp.tex 2014/10/25 v2.60 `PST-fp' (hv)
pst-3dplot.sty 2010/01/01 package wrapper for pst-3dplot.tex (hv)
pst-3d.sty 2009/07/28 package wrapper for pst-3d.tex (hv)
pst-3d.tex 2010/02/14 v1.11 `PST-3d' (hv)
pst-plot.sty 2011/04/13 package wrapper for pst-plot.tex (hv)
pst-xkey.sty 2005/11/25 v1.6 package wrapper for pst-xkey.tex (HA)
multido.sty 2004/05/17 package wrapper for PSTricks `multido.tex', (HV/RN)
multido.tex 2010/05/14 v1.42 `multido' (tvz,hv)
pst-plot.tex 2014/08/23 1.70 `pst-plot' (tvz,hv)
pst-node.sty 2010/04/22 package wrapper for pst-node.tex
pst-node.tex 2014/08/04 1.35 `pst-node' (tvz,hv)
pst-3dplot.tex 2014/08/25 v2.01 `PST-3dplot' (hv)
fig2_base.eps Graphic file (type eps)
umsa.fd 2013/01/14 v3.01 AMS symbols A
umsb.fd 2013/01/14 v3.01 AMS symbols B
***********
Dies ist die TeX Live Ubuntu-Ausgabe:
*File List*
scrartcl.cls 2009/07/24 v3.04a KOMA-Script document class (article)
scrkbase.sty 2009/07/24 v3.04a KOMA-Script package (KOMA-Script-dependent basics and keyval usage)
scrbase.sty 2009/07/24 v3.04a KOMA-Script package (KOMA-Script-independent basics and keyval usage)
keyval.sty 1999/03/16 v1.13 key=value parser (DPC)
scrlfile.sty 2009/03/25 v3.03 KOMA-Script package (loading files)
tocbasic.sty 2009/06/08 v3.03b KOMA-Script package (handling toc-files)
scrsize12pt.clo 2009/07/24 v3.04a KOMA-Script font size class option (12pt)
typearea.sty 2009/07/24 v3.04a KOMA-Script package (type area)
german.sty 1998/07/08 v2.5e Support for writing german texts (br)
amstext.sty 2000/06/29 v2.01
amsgen.sty 1999/11/30 v2.0
amsmath.sty 2000/07/18 v2.13 AMS math features
amsbsy.sty 1999/11/29 v1.2d
amsopn.sty 1999/12/14 v2.01 operator names
amsfonts.sty 2009/06/22 v3.00 Basic AMSFonts support
graphics.sty 2009/02/05 v1.0o Standard LaTeX Graphics (DPC,SPQR)
trig.sty 1999/03/16 v1.09 sin cos tan (DPC)
graphics.cfg 2009/08/28 v1.8 graphics configuration of TeX Live
dvips.def 1999/02/16 v3.0i Driver-dependant file (DPC,SPQR)
float.sty 2001/11/08 v1.3d Float enhancements (AL)
epic.sty
eepic.sty
color.sty 1999/02/16
color.cfg 2007/01/18 v1.5 color configuration of teTeX/TeXLive
dvipsnam.def 1999/02/16 v3.0i Driver-dependant file (DPC,SPQR)
tikz.sty 2010/10/13 v2.10 (rcs-revision 1.76)
pgf.sty 2008/01/15 v2.10 (rcs-revision 1.12)
pgfrcs.sty 2010/10/25 v2.10 (rcs-revision 1.24)
everyshi.sty 2001/05/15 v3.00 EveryShipout Package (MS)
pgfrcs.code.tex
pgfcore.sty 2010/04/11 v2.10 (rcs-revision 1.7)
graphicx.sty 1999/02/16 v1.0f Enhanced LaTeX Graphics (DPC,SPQR)
pgfsys.sty 2010/06/30 v2.10 (rcs-revision 1.37)
pgfsys.code.tex
pgfsyssoftpath.code.tex 2008/07/18 (rcs-revision 1.7)
pgfsysprotocol.code.tex 2006/10/16 (rcs-revision 1.4)
xcolor.sty 2007/01/21 v2.11 LaTeX color extensions (UK)
color.cfg 2007/01/18 v1.5 color configuration of teTeX/TeXLive
pgfcore.code.tex
pgfcomp-version-0-65.sty 2007/07/03 v2.10 (rcs-revision 1.7)
pgfcomp-version-1-18.sty 2007/07/23 v2.10 (rcs-revision 1.1)
pgffor.sty 2010/03/23 v2.10 (rcs-revision 1.18)
pgfkeys.sty
pgfkeys.code.tex
pgffor.code.tex
tikz.code.tex
pstricks.sty 2008/11/26 v0.40 LaTeX wrapper for `PSTricks' (RN,HV)
pstricks.tex 2009/05/19 v1.29 `PSTricks' (tvz,hv)
pst-3dplot.sty 2009/07/28 package wrapper for pst-3dplot.tex (hv)
pst-3dplot.tex 2009/10/06 v1.86 `PST-3dplot' (hv)
pst-xkey.tex 2005/11/25 v1.6 PSTricks specialization of xkeyval (HA)
xkeyval.sty 2008/08/13 v2.6a package option processing (HA)
xkeyval.tex 2008/08/13 v2.6a key=value parser (HA)
fig2_base.eps Graphic file (type eps)
umsa.fd 2009/06/22 v3.00 AMS symbols A
umsb.fd 2009/06/22 v3.00 AMS symbols B
***********
