Verwenden Sie animateinline in tikzpicture

Verwenden Sie animateinline in tikzpicture

Ich erstelle eine beamerPräsentation mit animierten tikzpictureUmgebungen. Im MWE besteht die obere Abbildung aus einem sich nie ändernden Diagramm und einem Punkt, der sich darauf bewegt. Da das Kompilieren des Diagramms lange dauert, habe ich es in einer Datei gespeichert, image.pdfdie ich in ein lade node. Leider habe ich keine Möglichkeit gefunden, das Bild ein für alle Mal zu laden: Meine aktuelle Lösung besteht darin, es bei jedem Schritt zu laden (also ungefähr 600 Mal ...).

Das untere Diagramm besteht aus einer Kurve, die \pgfplotsaus einer Datendatei gezeichnet wurde data.dat. Ich habe 5 verschiedene Datendateien (ich verwende dieselbe im MWE), die nacheinander mit geladen werden only. Für eine Datendatei zeichne ich einen animierten Punkt auf der Kurve. Auch hier habe ich keine andere Lösung gefunden, als die Kurve bei jeder Iteration (also etwa 600 Mal ...) zu zeichnen.

Insgesamt dauert die Kompilierung mehrere Minuten. Ich habe die Anzahl der Iterationen so reduziert, dass der bereitgestellte Code etwa 20 Sekunden dauern sollte.

Das sind also meine Fragen:

  1. Wie kann ich das Bild ein für alle Mal in den oberen Plot laden?

  2. Wie kann ich jede der fünf Kurven ein für alle Mal in das untere Diagramm eintragen?

  3. Gibt es Unschönheiten im Code, die mir nicht aufgefallen wären?

animateinlineIch habe versucht, und multiframeinnerhalb von zu verschieben tikzpicture, was den Fehler verursacht hat:

Beim Scannen der Verwendung von \beamer@collect@@body wurde die Datei beendet.

Code:

\documentclass{beamer}
\usepackage{tikz}
\usepackage{pgfplots,pgfplotstable}
\usepackage{animate}

\pgfplotstableread[header=false]{
1.733   1.770   1.807   1.843   1.880   1.918
}\mytable

\begin{document}
\begin{frame}{Title}
    % Data to read [a single file "data.dat" is used here for simplification purposes]
    \only<1>{\pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable\def\indice{5}}
    \only<2>{\pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable\def\indice{4}}
    \only<3>{\pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable\def\indice{3}}
    \only<4>{\pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable\def\indice{2}}
    \only<5>{\pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable\def\indice{1}}
    % Get number of rows
    \pgfplotstablegetrowsof{\datatable}
    \pgfmathsetmacro{\rows}{int(\pgfplotsretval-1)}

    \begin{center}
        \begin{animateinline}[loop,poster=first]{10}
            \multiframe{201}{i=0+1}{%
                % Get last value of first column of data.dat
                \pgfplotstablegetelem{\rows}{[index]0}\of\datatable%
                \pgfmathsetmacro{\tmax}{\pgfplotsretval}%
                % Get x-coordinate of moving point
                \pgfplotstablegetelem{0}{[index]\indice}\of\mytable%
                \pgfmathsetmacro{\tfirst}{\pgfplotsretval}%
                \begin{tikzpicture}
                    % top plot
                    \begin{axis}[%
                        scale only axis,
                        axis on top,
                        width=4cm, height=2.25cm,
                        xmin=1.5, xmax=2.2,
                        ymin=0.3, ymax=1.5,
                        ]

                        % LOADS IMAGE AT EVERY STEP!
                        \node[anchor=south west,inner sep=0pt] at (axis cs:1.5,0.3) {\includegraphics[width=4cm, height=2.25cm]{./image}};
                        \addplot[mark=*,red] coordinates {(\tfirst,\tmax-\tfirst)};
                    \end{axis}

                    % bottom plot
                    \begin{scope}[shift={(0,-4.3)}]
                        \begin{axis}[every axis legend/.append style={nodes={right}},
                            scale only axis,
                            width=5.025cm,height=3.15cm,
                            enlarge x limits={value=0.02,upper},
                            enlarge y limits=false,
                            xlabel={$x$}, ylabel={$y$}
                        ]
                        \pgfplotstablegetelem{\i}{[index]0}\of{\datatable}\let\time\pgfplotsretval
                        \pgfplotstablegetelem{\i}{[index]\indice}\of{\datatable}\let\position\pgfplotsretval
                        \addplot[mark=*,blue] coordinates {(\time,\position)};

                         % PLOTS HOLE CURVE AT EVERY STEP!!
                        \addplot [thick,blue] table [x index=0, y index=\indice] {\datatable};
                    \end{axis}
                \end{scope}
          \end{tikzpicture}%
        }
        \end{animateinline}
    \end{center}
\end{frame}

\end{document}

Link zu data.dat:gehostet auf Filedropper

Link zu image.pdf:gehostet auf Filedropperoder zuOriginal auf der Rückseite

Link zum gesamten Projekt (kann als Zip heruntergeladen werden):gehostet auf overleaf

Antwort1

Der statische Teil des Ganzen tikzpicture, also das obere Bild mit den Achsen und die unten dargestellte Kurve samt Achsen und Achsenbeschriftungen, kann in ein PDF XObject gespeichert werden mit demxsaveboxPaket.

Das tikzpictureso gespeicherte Bild kann als Hintergrundbild beim Plotten auf der Oberseite eingefügt werden.isoliertrote und bewegliche blaue Punkte zum Erstellen der Animationsrahmen.

Anders als beim Einfügen von Standard-Saveboxen wird beim Referenzieren von PDF-XObject-basierten Saveboxen der gespeicherte Code nicht in der PDF-Ausgabedatei repliziert.

Zum Originalcode der Frage waren einige Ergänzungen notwendig:

Die axisOption

scale only axis

für den Hintergrund und beim Plotten der isolierten Punkte, und

hide axis

beim Plotten der isolierten Punkte.

Die Achsenbereiche müssen aus den Eingangsdaten ermittelt werden, da diese beim Plotten der einzelnen Punkte als Achsenoptionen eingestellt werden müssen.

Darüber hinaus muss die untere linke Koordinate des Begrenzungsrahmens des Hintergrunddiagramms in TeX-Makros gespeichert werden, um die korrekte Platzierung des Hintergrundknotens in den Animationsrahmen zu gewährleisten.

Kompilierungszeiten und PDF-Dateigrößen mit den Originaldatensätzen (5 x 201 Datenpunkte) und den Original--> image.jpg<--

  • Original-LaTeX-Quelle: 2:17 min ; 4.235.154 B
  • LaTeX-Code unten: 0:37 min ; 1,083,389 B

\documentclass{beamer}
\usepackage{tikz}
\usepackage{pgfplots,pgfplotstable}
\usepackage{animate}

%saveboxes without code replication, based on PDF XObjects
\usepackage{xsavebox}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% command for saving node anchor coords into  TeX macros
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\makeatletter
\newcommand\saveCoordsOfNodeAnchor[4]{{%
  % #1: macro taking x coordinate
  % #2: macro taking y coordinate
  % #3: <Node id>
  % #4: <anchor>
  \pgfpointanchor{#3}{#4}%
  \pgfmathparse{\pgf@x/\pgf@xx}%
  \xdef#1{\pgfmathresult}%
  \pgfmathparse{\pgf@y/\pgf@yy}%
  \xdef#2{\pgfmathresult}%
}}
\makeatother
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% the data file
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{filecontents*}{data.dat}
0 0.7556 -0.4146 -1.729 -0.8786 1.
0.01406 0.6943 -0.4725 -1.721 -0.8583 0.9466
0.02812 0.6239 -0.5308 -1.702 -0.8333 0.8843
0.04218 0.5448 -0.5892 -1.673 -0.8041 0.8136
0.05624 0.4573 -0.6474 -1.635 -0.7713 0.7348
0.0703 0.3621 -0.705 -1.588 -0.7352 0.6486
0.08436 0.2598 -0.7617 -1.532 -0.6966 0.5555
0.09842 0.1513 -0.8171 -1.468 -0.6558 0.4563
0.1125 0.03716 -0.871 -1.397 -0.6136 0.3516
0.1265 -0.08161 -0.923 -1.319 -0.5705 0.2421
0.1406 -0.2041 -0.9727 -1.236 -0.5271 0.1286
0.1547 -0.3294 -1.02 -1.148 -0.4839 0.01185
0.1687 -0.4565 -1.065 -1.056 -0.4416 -0.1073
0.1828 -0.5844 -1.106 -0.9608 -0.4007 -0.2282
0.1968 -0.7119 -1.144 -0.8638 -0.3616 -0.3499
0.2109 -0.838 -1.179 -0.7657 -0.325 -0.4717
0.225 -0.9617 -1.21 -0.6674 -0.2913 -0.5927
0.239 -1.082 -1.237 -0.57 -0.2609 -0.7122
0.2531 -1.197 -1.26 -0.4743 -0.2343 -0.8296
0.2672 -1.307 -1.278 -0.3814 -0.2118 -0.9439
0.2812 -1.411 -1.293 -0.292 -0.1938 -1.055
0.2953 -1.507 -1.303 -0.2071 -0.1805 -1.161
0.3093 -1.594 -1.309 -0.1275 -0.1721 -1.263
0.3234 -1.672 -1.31 -0.0539 -0.169 -1.359
0.3375 -1.74 -1.307 0.0129 -0.1711 -1.45
0.3515 -1.797 -1.299 0.07228 -0.1787 -1.534
0.3656 -1.843 -1.288 0.1236 -0.1917 -1.611
0.3796 -1.878 -1.271 0.1665 -0.2102 -1.681
0.3937 -1.899 -1.251 0.2004 -0.234 -1.745
0.4078 -1.909 -1.227 0.2249 -0.2632 -1.8
0.4218 -1.905 -1.199 0.2399 -0.2976 -1.848
0.4359 -1.889 -1.168 0.2451 -0.3369 -1.889
0.4499 -1.859 -1.133 0.2405 -0.3811 -1.921
0.464 -1.817 -1.095 0.226 -0.4298 -1.947
0.4781 -1.763 -1.053 0.2017 -0.4827 -1.964
0.4921 -1.696 -1.01 0.1679 -0.5396 -1.975
0.5062 -1.617 -0.9633 0.1248 -0.6001 -1.978
0.5202 -1.527 -0.9149 0.0727 -0.6638 -1.974
0.5343 -1.427 -0.8647 0.01209 -0.7303 -1.964
0.5484 -1.317 -0.8129 -0.05651 -0.7993 -1.948
0.5624 -1.198 -0.7598 -0.1325 -0.8703 -1.926
0.5765 -1.07 -0.7058 -0.2153 -0.9428 -1.899
0.5905 -0.936 -0.6512 -0.304 -1.017 -1.868
0.6046 -0.7956 -0.5963 -0.398 -1.091 -1.832
0.6187 -0.6503 -0.5414 -0.4964 -1.165 -1.792
0.6327 -0.5012 -0.4868 -0.5983 -1.24 -1.749
0.6468 -0.3496 -0.4328 -0.7029 -1.314 -1.704
0.6608 -0.1967 -0.3798 -0.8091 -1.386 -1.657
0.6749 -0.04371 -0.3279 -0.9161 -1.457 -1.608
0.689 0.1081 -0.2776 -1.023 -1.527 -1.559
0.703 0.2574 -0.2291 -1.128 -1.593 -1.51
0.7171 0.4031 -0.1825 -1.232 -1.658 -1.461
0.7312 0.5439 -0.1383 -1.332 -1.719 -1.413
0.7452 0.6787 -0.0966 -1.428 -1.776 -1.366
0.7593 0.8062 -0.05764 -1.52 -1.83 -1.322
0.7733 0.9255 -0.02164 -1.606 -1.88 -1.28
0.7874 1.036 0.01121 -1.685 -1.926 -1.241
0.8015 1.135 0.04075 -1.757 -1.967 -1.205
0.8155 1.224 0.06681 -1.821 -2.003 -1.173
0.8296 1.301 0.08926 -1.877 -2.034 -1.146
0.8436 1.366 0.108 -1.924 -2.06 -1.122
0.8577 1.418 0.1229 -1.962 -2.081 -1.103
0.8718 1.456 0.1339 -1.989 -2.096 -1.089
0.8858 1.481 0.1409 -2.007 -2.106 -1.081
0.8999 1.492 0.144 -2.015 -2.11 -1.077
0.9139 1.488 0.143 -2.013 -2.109 -1.078
0.928 1.471 0.1381 -2. -2.102 -1.084
0.9421 1.44 0.1291 -1.977 -2.089 -1.095
0.9561 1.395 0.1163 -1.945 -2.072 -1.112
0.9702 1.337 0.09953 -1.903 -2.048 -1.133
0.9842 1.266 0.07902 -1.852 -2.02 -1.158
0.9983 1.183 0.05483 -1.792 -1.986 -1.188
1.012 1.089 0.02709 -1.724 -1.948 -1.222
1.026 0.9843 -0.004049 -1.648 -1.905 -1.259
1.04 0.8697 -0.03843 -1.565 -1.857 -1.299
1.055 0.7464 -0.07586 -1.477 -1.805 -1.343
1.069 0.6152 -0.1162 -1.383 -1.749 -1.388
1.083 0.4775 -0.1591 -1.285 -1.69 -1.435
1.097 0.3342 -0.2044 -1.183 -1.627 -1.484
1.111 0.1866 -0.252 -1.078 -1.562 -1.533
1.125 0.03594 -0.3014 -0.972 -1.494 -1.583
1.139 -0.1166 -0.3525 -0.865 -1.424 -1.632
1.153 -0.2697 -0.4049 -0.7583 -1.352 -1.68
1.167 -0.4221 -0.4585 -0.6528 -1.279 -1.726
1.181 -0.5727 -0.5128 -0.5494 -1.204 -1.77
1.195 -0.7201 -0.5676 -0.449 -1.13 -1.811
1.209 -0.8632 -0.6225 -0.3526 -1.055 -1.849
1.223 -1.001 -0.6773 -0.261 -0.9813 -1.883
1.237 -1.132 -0.7317 -0.175 -0.9081 -1.913
1.251 -1.256 -0.7853 -0.09539 -0.8362 -1.937
1.265 -1.371 -0.8378 -0.02284 -0.7662 -1.957
1.28 -1.476 -0.8889 0.04202 -0.6983 -1.97
1.294 -1.572 -0.9383 0.09862 -0.6331 -1.977
1.308 -1.656 -0.9857 0.1465 -0.5708 -1.977
1.322 -1.729 -1.031 0.1852 -0.512 -1.971
1.336 -1.79 -1.073 0.2145 -0.457 -1.957
1.35 -1.839 -1.113 0.2341 -0.406 -1.936
1.364 -1.875 -1.15 0.2439 -0.3595 -1.907
1.378 -1.898 -1.183 0.2439 -0.3176 -1.87
1.392 -1.908 -1.213 0.234 -0.2806 -1.826
1.406 -1.906 -1.239 0.2144 -0.2486 -1.775
1.42 -1.89 -1.261 0.1854 -0.222 -1.715
1.434 -1.863 -1.28 0.1472 -0.2007 -1.649
1.448 -1.823 -1.294 0.1002 -0.1848 -1.575
1.462 -1.771 -1.303 0.04494 -0.1744 -1.494
1.476 -1.709 -1.309 -0.01806 -0.1694 -1.407
1.49 -1.636 -1.31 -0.08818 -0.1698 -1.314
1.504 -1.553 -1.307 -0.1647 -0.1755 -1.215
1.519 -1.462 -1.299 -0.247 -0.1862 -1.111
1.533 -1.362 -1.287 -0.3341 -0.2018 -1.002
1.547 -1.256 -1.27 -0.4253 -0.222 -0.8898
1.561 -1.143 -1.249 -0.5197 -0.2465 -0.7739
1.575 -1.025 -1.224 -0.6163 -0.275 -0.6555
1.589 -0.9031 -1.195 -0.7142 -0.307 -0.5351
1.603 -0.7781 -1.163 -0.8125 -0.3421 -0.4136
1.617 -0.6512 -1.126 -0.9102 -0.38 -0.2918
1.631 -0.5234 -1.087 -1.006 -0.42 -0.1704
1.645 -0.3958 -1.044 -1.1 -0.4617 -0.05026
1.659 -0.2694 -0.9978 -1.19 -0.5045 0.06786
1.673 -0.1453 -0.9493 -1.276 -0.5478 0.1832
1.687 -0.02446 -0.8984 -1.357 -0.5912 0.2948
1.701 0.0922 -0.8455 -1.431 -0.6339 0.4022
1.715 0.2038 -0.7909 -1.499 -0.6755 0.5043
1.729 0.3094 -0.7348 -1.559 -0.7153 0.6007
1.744 0.4084 -0.6776 -1.611 -0.7528 0.6906
1.758 0.5 -0.6197 -1.655 -0.7874 0.7733
1.772 0.5836 -0.5614 -1.688 -0.8185 0.8483
1.786 0.6586 -0.503 -1.712 -0.8458 0.9151
1.8 0.7247 -0.4448 -1.726 -0.8686 0.9732
1.814 0.7814 -0.3872 -1.729 -0.8865 0.9757
1.828 0.8285 -0.3304 -1.721 -0.8994 0.9179
1.842 0.8658 -0.2748 -1.702 -0.9075 0.8512
1.856 0.8931 -0.2205 -1.673 -0.9107 0.7757
1.87 0.9106 -0.168 -1.632 -0.9094 0.692
1.884 0.9182 -0.1174 -1.581 -0.9037 0.6003
1.898 0.9162 -0.06883 -1.519 -0.894 0.5012
1.912 0.9047 -0.0226 -1.447 -0.8805 0.3952
1.926 0.8843 0.02118 -1.365 -0.8634 0.2829
1.94 0.8552 0.06238 -1.273 -0.8432 0.165
1.954 0.818 0.1009 -1.173 -0.8201 0.04202
1.968 0.7731 0.1367 -1.065 -0.7945 -0.08518
1.983 0.7214 0.1696 -0.9498 -0.7667 -0.2159
1.997 0.6633 0.1998 -0.828 -0.7371 -0.3493
2.011 0.5997 0.2272 -0.7007 -0.7061 -0.4846
2.025 0.5312 0.2518 -0.5688 -0.6739 -0.6211
2.039 0.4588 0.2738 -0.4334 -0.6409 -0.7577
2.053 0.3832 0.2932 -0.2955 -0.6075 -0.8938
2.067 0.3052 0.3101 -0.1563 -0.574 -1.029
2.081 0.2258 0.3247 -0.01679 -0.5406 -1.161
2.095 0.1457 0.3371 0.1218 -0.5077 -1.29
2.109 0.06586 0.3475 0.2583 -0.4756 -1.416
2.123 -0.01292 0.3561 0.3917 -0.4445 -1.537
2.137 -0.08981 0.363 0.5207 -0.4146 -1.652
2.151 -0.164 0.3685 0.6444 -0.3863 -1.762
2.165 -0.2348 0.3727 0.7616 -0.3596 -1.864
2.179 -0.3014 0.3758 0.8713 -0.3349 -1.959
2.193 -0.3632 0.3781 0.9726 -0.3122 -2.046
2.208 -0.4195 0.3796 1.065 -0.2917 -2.125
2.222 -0.4698 0.3805 1.147 -0.2736 -2.194
2.236 -0.5136 0.381 1.218 -0.258 -2.254
2.25 -0.5505 0.3812 1.278 -0.2449 -2.305
2.264 -0.58 0.3813 1.325 -0.2345 -2.345
2.278 -0.6019 0.3812 1.361 -0.2268 -2.374
2.292 -0.616 0.3812 1.384 -0.2219 -2.393
2.306 -0.6221 0.3812 1.393 -0.2197 -2.401
2.32 -0.6202 0.3812 1.39 -0.2204 -2.399
2.334 -0.6102 0.3812 1.374 -0.2239 -2.385
2.348 -0.5924 0.3813 1.345 -0.2301 -2.361
2.362 -0.5668 0.3813 1.304 -0.2391 -2.327
2.376 -0.5338 0.3812 1.251 -0.2508 -2.282
2.39 -0.4936 0.3808 1.185 -0.2651 -2.227
2.404 -0.4466 0.3801 1.109 -0.2819 -2.162
2.418 -0.3934 0.3789 1.022 -0.3012 -2.089
2.432 -0.3344 0.3771 0.9254 -0.3228 -2.006
2.447 -0.2702 0.3745 0.82 -0.3464 -1.915
2.461 -0.2015 0.3709 0.7066 -0.3721 -1.816
2.475 -0.129 0.3661 0.5862 -0.3996 -1.71
2.489 -0.05344 0.3599 0.4598 -0.4287 -1.598
2.503 0.02445 0.3522 0.3286 -0.4592 -1.48
2.517 0.1038 0.3428 0.1936 -0.4908 -1.357
2.531 0.1839 0.3315 0.0559 -0.5233 -1.229
2.545 0.2638 0.318 -0.08325 -0.5565 -1.098
2.559 0.3426 0.3023 -0.2228 -0.5899 -0.9646
2.573 0.4196 0.2843 -0.3615 -0.6235 -0.8291
2.587 0.4938 0.2636 -0.4983 -0.6567 -0.6926
2.601 0.5644 0.2404 -0.6322 -0.6893 -0.5559
2.615 0.6306 0.2145 -0.762 -0.721 -0.4199
2.629 0.6917 0.1858 -0.8868 -0.7514 -0.2854
2.643 0.7469 0.1543 -1.006 -0.7802 -0.1532
2.657 0.7954 0.12 -1.118 -0.807 -0.02405
2.672 0.8367 0.08287 -1.222 -0.8314 0.1012
2.686 0.8701 0.04307 -1.318 -0.8532 0.2219
2.7 0.8951 0.0006246 -1.405 -0.872 0.3372
2.714 0.9113 -0.04434 -1.482 -0.8874 0.4466
2.728 0.9183 -0.09169 -1.55 -0.8991 0.5493
2.742 0.9158 -0.1412 -1.607 -0.907 0.645
2.756 0.9035 -0.1928 -1.653 -0.9106 0.7329
2.77 0.8813 -0.2462 -1.688 -0.9097 0.8128
2.784 0.8492 -0.3011 -1.713 -0.9042 0.8841
2.798 0.8073 -0.3573 -1.726 -0.8939 0.9466
2.812 0.7556 -0.4146 -1.729 -0.8786 1.
\end{filecontents*}

\pgfplotstableread[header=false]{
1.733   1.770   1.807   1.843   1.880   1.918
}\mytable

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% command for saving static plot content (the top image and the bottom curve
% with axes and labels) into xsavebox
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\newcommand\saveStaticPlot{%
  \xsbox{staticPlotContent}{%
    \begin{tikzpicture}
      % top plot
      \begin{axis}[%
        scale only axis,
        axis on top,
        width=4cm,
        height=2.25cm,
        xmin=1.5, xmax=2.2,
        ymin=0.3, ymax=1.5,
      ]
        \node[anchor=south west,inner sep=0pt] at (axis cs:1.5,0.3) {%
          %resize image to fit within the axis box
          \resizebox{\pgfkeysvalueof{/pgfplots/width}}{\pgfkeysvalueof{/pgfplots/height}}{\thefrog}
        };
      \end{axis}
      % bottom plot
      \begin{scope}[shift={(0,-4.3)}]
        \begin{axis}[every axis legend/.append style={nodes={right}},
          scale only axis,
          width=5.025cm,height=3.15cm,
          xmin=\xMin, xmax=\xMax,
          ymin=\yMin, ymax=\yMax,
          enlarge x limits={value=0.02,upper},
          xlabel={$x$}, ylabel={$y$}
        ]
        \addplot [thick,blue] table [x index=0, y index=\indice] {\datatable};
        \end{axis}
      \end{scope}
      %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
      %save BBox coordinates
      %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
      \saveCoordsOfNodeAnchor{\llx}{\lly}{current bounding box}{south west}
      %\saveCoordsOfNodeAnchor{\urx}{\ury}{current bounding box}{north east}
      %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
    \end{tikzpicture}%
  }%
}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% save bitmap image once for all
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\xsbox{frog}{\includegraphics{./image}}

\begin{document}
\begin{frame}{Title}
    % Data to read [a single file "data.dat" is used here for simplification purposes]
    \only<1>{%
      \pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable%
      \def\indice{5}%
      %get min and max values
      %time
      \pgfplotstablesort[sort key={[index]0}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]0},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMax}{\pgfplotsretval}%
      %data
      \pgfplotstablesort[sort key={[index]\indice}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]\indice},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMax}{\pgfplotsretval}%
    }
    \only<2>{%
      \pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable%
      \def\indice{4}%
      %get min and max values
      %time
      \pgfplotstablesort[sort key={[index]0}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]0},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMax}{\pgfplotsretval}%
      %data
      \pgfplotstablesort[sort key={[index]\indice}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]\indice},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMax}{\pgfplotsretval}%
    }
    \only<3>{%
      \pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable%
      \def\indice{3}%
      %get min and max values
      %time
      \pgfplotstablesort[sort key={[index]0}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]0},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMax}{\pgfplotsretval}%
      %data
      \pgfplotstablesort[sort key={[index]\indice}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]\indice},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMax}{\pgfplotsretval}%
    }
    \only<4>{%
      \pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable%
      \def\indice{2}%
      %get min and max values
      %time
      \pgfplotstablesort[sort key={[index]0}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]0},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMax}{\pgfplotsretval}%
      %data
      \pgfplotstablesort[sort key={[index]\indice}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]\indice},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMax}{\pgfplotsretval}%
    }
    \only<5>{%
      \pgfplotstableread[col sep=space,row sep=newline,header=true]{./data.dat}\datatable%
      \def\indice{1}%
      %get min and max values
      %time
      \pgfplotstablesort[sort key={[index]0}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]0},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]0}\of\tmptble%
      \pgfmathsetmacro{\xMax}{\pgfplotsretval}%
      %data
      \pgfplotstablesort[sort key={[index]\indice}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMin}{\pgfplotsretval}%
      \pgfplotstablesort[sort key={[index]\indice},sort cmp={float >}]\tmptble\datatable%
      \pgfplotstablegetelem{0}{[index]\indice}\of\tmptble%
      \pgfmathsetmacro{\yMax}{\pgfplotsretval}%
    }
    % Get number of rows
    \pgfplotstablegetrowsof{\datatable}
    \pgfmathsetmacro{\rows}{int(\pgfplotsretval-1)}

    \begin{center}
      \saveStaticPlot%  save the satic plot with the current data
      \begin{animateinline}[loop,poster=first]{10}
        \multiframe{201}{i=0+1}{%
          % Get last value of first column of data.dat
          \pgfplotstablegetelem{\rows}{[index]0}\of\datatable%
          \pgfmathsetmacro{\tmax}{\pgfplotsretval}%
          % Get x-coordinate of moving point
          \pgfplotstablegetelem{0}{[index]\indice}\of\mytable%
          \pgfmathsetmacro{\tfirst}{\pgfplotsretval}%
          \begin{tikzpicture}
            %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
            % insert static plot as a node at (\llx,\lly)
            %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
            \node[inner sep=0pt, anchor=south west] at (\llx,\lly) {\thestaticPlotContent};
            %\useasboundingbox (\llx,\lly) rectangle (\urx,\ury);

            %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
            % overlay the red and blue dots
            %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
            % top plot (red point only!!!)
            %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
            \begin{axis}[%
              scale only axis,
              % note: axes hidden, no axis labels
              hide axis,
              width=4cm, height=2.25cm,
              xmin=1.5, xmax=2.2,
              ymin=0.3, ymax=1.5,
            ]
              \addplot[mark=*,red] coordinates {(\tfirst,\tmax-\tfirst)};
            \end{axis}
            %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
            % bottom plot, blue point only, axes hidden, no axis labels
            %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
            \begin{scope}[shift={(0,-4.3)}]
              \begin{axis}[every axis legend/.append style={nodes={right}},
                  scale only axis,
                  hide axis,
                  xmin=\xMin, xmax=\xMax,
                  enlarge x limits={value=0.02,upper},
                  ymin=\yMin, ymax=\yMax,
                  width=5.025cm,height=3.15cm,
              ]
                \pgfplotstablegetelem{\i}{[index]0}\of{\datatable}\let\time\pgfplotsretval
                \pgfplotstablegetelem{\i}{[index]\indice}\of{\datatable}\let\position\pgfplotsretval
                \addplot[mark=*,blue] coordinates {(\time,\position)};
              \end{axis}
            \end{scope}
          \end{tikzpicture}%
        }%
      \end{animateinline}
    \end{center}
\end{frame}

\end{document}

Um die isolierten Punkte zu sehen, aktivieren Sie

\saveCoordsOfNodeAnchor{\urx}{\ury}{current bounding box}{north east}

und ändern

\node[inner sep=0pt, anchor=south west] at (\llx,\lly){\thestaticPlotContent};
%\useasboundingbox (\llx,\lly) rectangle (\urx,\ury);

Zu

%\node[inner sep=0pt, anchor=south west] at (\llx,\lly){\thestaticPlotContent};
\useasboundingbox (\llx,\lly) rectangle (\urx,\ury);

verwandte Informationen
