Der Ordner figbefindet sich im selben Verzeichnis wie die .texDatei und die Abbildung Q_a_x.epsbefindet sich im Ordner fig. Dieses Problem tritt auf, wenn ich es unter Linux kompiliere pdflatex. Gibt es eine Möglichkeit, dieses Problem zu lösen, aber weiterhin mit pdflatexstatt zu kompilieren latex? Vielen Dank im Voraus!
Die Positionen der Dateien sind wie hier gezeigt:
Und die Abbildung ist wie folgt in der Tex-Datei enthalten:
\begin{figure}[h]
\centering
\includegraphics[width=3.4in]{./fig/Q_a_x.eps}
\caption{$Q^{GW}(a_*,x)$ as a function of x for different $a_*$'s.}
\label{figQ-a-x}
\end{figure}
Hier ist die Ausgabe der PDFLatex-Kompilierung:
This is pdfTeX, Version 3.1415926-2.5-1.40.14 (TeX Live 2013/Debian)
restricted \write18 enabled.
entering extended mode
(./kerr.tex
LaTeX2e <2011/06/27>
Babel <3.9h> and hyphenation patterns for 78 languages loaded.
(/usr/share/texlive/texmf-dist/tex/latex/revtex4/revtex4.cls
Document Class: revtex4 2001/08/02 v4.0 (http://publish.aps.org/revtex4/
for documentation)
ltxutil: portions licensed from W. E. Baxter ([email protected])
ltxgrid: portions licensed from W. E. Baxter ([email protected])
(/usr/share/texlive/texmf-dist/tex/latex/url/url.sty)
(/usr/share/texlive/texmf-dist/tex/latex/natbib/natbib.sty)
(/usr/share/texlive/texmf-dist/tex/latex/revtex4/revsymb.sty))
(/usr/share/texlive/texmf-dist/tex/latex/amsfonts/amsfonts.sty)
(/usr/share/texlive/texmf-dist/tex/latex/revtex4/aps.rtx)
(/usr/share/texlive/texmf-dist/tex/latex/revtex4/10pt.rtx)
(/usr/share/texlive/texmf-dist/tex/latex/graphics/graphicx.sty
(/usr/share/texlive/texmf-dist/tex/latex/graphics/keyval.sty)
(/usr/share/texlive/texmf-dist/tex/latex/graphics/graphics.sty
(/usr/share/texlive/texmf-dist/tex/latex/graphics/trig.sty)
(/etc/texmf/tex/latex/config/graphics.cfg)
(/usr/share/texlive/texmf-dist/tex/latex/pdftex-def/pdftex.def
(/usr/share/texlive/texmf-dist/tex/generic/oberdiek/infwarerr.sty)
(/usr/share/texlive/texmf-dist/tex/generic/oberdiek/ltxcmds.sty))))
(/usr/share/texlive/texmf-dist/tex/latex/graphics/epsfig.sty)
(/usr/share/texlive/texmf-dist/tex/latex/graphics/color.sty
(/etc/texmf/tex/latex/config/color.cfg))
(/usr/share/texlive/texmf-dist/tex/latex/amsmath/amsmath.sty
For additional information on amsmath, use the `?' option.
(/usr/share/texlive/texmf-dist/tex/latex/amsmath/amstext.sty
(/usr/share/texlive/texmf-dist/tex/latex/amsmath/amsgen.sty))
(/usr/share/texlive/texmf-dist/tex/latex/amsmath/amsbsy.sty)
(/usr/share/texlive/texmf-dist/tex/latex/amsmath/amsopn.sty))
(/usr/share/texlive/texmf-dist/tex/latex/hyperref/hyperref.sty
(/usr/share/texlive/texmf-dist/tex/generic/oberdiek/hobsub-hyperref.sty
(/usr/share/texlive/texmf-dist/tex/generic/oberdiek/hobsub-generic.sty))
(/usr/share/texlive/texmf-dist/tex/generic/ifxetex/ifxetex.sty)
(/usr/share/texlive/texmf-dist/tex/latex/oberdiek/auxhook.sty)
(/usr/share/texlive/texmf-dist/tex/latex/oberdiek/kvoptions.sty)
(/usr/share/texlive/texmf-dist/tex/latex/hyperref/pd1enc.def)
(/usr/share/texlive/texmf-dist/tex/latex/latexconfig/hyperref.cfg))
Package hyperref Message: Driver (autodetected): hpdftex.
(/usr/share/texlive/texmf-dist/tex/latex/hyperref/hpdftex.def
(/usr/share/texlive/texmf-dist/tex/latex/oberdiek/rerunfilecheck.sty))
(/usr/share/texlive/texmf-dist/tex/generic/ulem/ulem.sty)
(/usr/share/texmf/tex/latex/xcolor/xcolor.sty
(/etc/texmf/tex/latex/config/color.cfg)
(/usr/share/texlive/texmf-dist/tex/latex/graphics/dvipsnam.def))
(/usr/share/texlive/texmf-dist/tex/latex/subfig/subfig.sty
(/usr/share/texlive/texmf-dist/tex/latex/caption/caption.sty
(/usr/share/texlive/texmf-dist/tex/latex/caption/caption3.sty)
Package caption Warning: Unsupported document class (or package) detected,
(caption) usage of the caption package is not recommended.
See the caption package documentation for explanation.
)) (/usr/share/texlive/texmf-dist/tex/latex/tools/tabularx.sty
(/usr/share/texlive/texmf-dist/tex/latex/tools/array.sty)) (./kerr.aux)
(/usr/share/texlive/texmf-dist/tex/context/base/supp-pdf.mkii
[Loading MPS to PDF converter (version 2006.09.02).]
)
Package hyperref Warning: Height of page (\paperheight) is invalid (0.0pt),
(hyperref) using 11in.
(/usr/share/texlive/texmf-dist/tex/latex/hyperref/nameref.sty
(/usr/share/texlive/texmf-dist/tex/generic/oberdiek/gettitlestring.sty))
(./kerr.out) (./kerr.out)
Package caption Warning: \caption will not be redefined since it's already
(caption) redefined by a document class or package which is
(caption) unknown to the caption package.
See the caption package documentation for explanation.
(/usr/share/texlive/texmf-dist/tex/latex/amsfonts/umsa.fd)
(/usr/share/texlive/texmf-dist/tex/latex/amsfonts/umsb.fd)
LaTeX Warning: Reference `conclusions' on page 1 undefined on input line 74.
[1{/var/lib/texmf/fonts/map/pdftex/updmap/pdftex.map}]
Overfull \hbox (5.00699pt too wide) in alignment at lines 86--89
[][][] []
LaTeX Warning: Reference `appendix:spin' on page 2 undefined on input
line 93.
Underfull \hbox (badness 4013) in paragraph at lines 93--95
[]\OT1/cmr/m/n/10 The above an-gu-lar equa-tion is the well-known
LaTeX Warning: Reference `appendix:spin' on page 2 undefined on input
line 112.
Package hyperref Warning: Ignoring empty anchor on input line 114.
LaTeX Warning: Reference `appendix:setup' on page 2 undefined on input
line 120
.
[2]
Underfull \hbox (badness 10000) in paragraph at lines 126--128
[]\OT1/cmr/m/n/10 We first de-fine a di-men-sion-less quan-tity
Underfull \hbox (badness 1142) in paragraph at lines 126--128
\OML/cmm/m/it/10 Q[]\OT1/cmr/m/n/10 (\OML/cmm/m/it/10 a[];
M!\OT1/cmr/m/n/10 )$
, which rep-re-sents the ex-pected emis-
Overfull \hbox (8.801pt too wide) in alignment at lines 128--132
[][][] []
! LaTeX Error: File `./fig/Q_a_x' not found.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
Die Präambel meiner Tex-Datei ist hier:
\documentclass[prd, amsfonts, twocolumn, nofootinbib, showpacs]{revtex4}
\usepackage{graphicx, epsfig}
\usepackage{color}
\usepackage{amsmath}
\usepackage{hyperref}
\lower0.6ex\hbox{$\sim$}}}
\newcommand{\lapp}{\mathrel{\raise.3ex\hbox{$<$}\mkern-14mu \lower0.6ex\hbox{$\sim$}}}
\def\bbox{{\,\lower0.9pt\vbox{\hrule \hbox{\vrule height 0.2 cm
\hskip 0.2 cm \vrule height 0.2 cm}\hrule}\,}}
\makeatletter
\makeatother
%%%%%%%%%%%%%%%%%%%%% EDITING MARKUP %%%%%%%%%%%%%%%%%%
\usepackage{color}
\usepackage{ulem}
\usepackage[usenames,dvipsnames]{xcolor}
\usepackage{subfig}
\usepackage{tabularx}
Antwort1
pdflatexakzeptiert (fast) alle Bilddateien außer . Versuchen Sie , .epssie in oder eine andere geeignete Datei zu konvertieren..pdf.png
Andernfalls können Sie epstopdfein Paket verwenden, das die Arbeit automatisch für Sie erledigt. In diesem Fall sollten Sie hinzufügen \epstopdfsetup{outdir=./fig/}, um anzugeben, wo die erstellte .pdfDatei abgelegt werden soll.
