Ich habe Probleme, mein Titelblatt richtig aussehen zu lassen. Ein paar Fragen:
- Wie kann ich den Text so verschieben, dass er sich nicht verschiebt?
- Ich möchte keine absoluten Koordinaten verwenden (d. h. ich hatte vorher yshift=-15cm, aber es wurde wirklich kompliziert, die ganze Seite auf einmal zu formatieren).
- Ist mein Ansatz der beste? Vielleicht gibt es einen besseren Weg.
So soll es für mich aussehen (natürlich ohne die beiden oberen Zeilen):
aber hier ist, was ich bekommen habe:
Mein Code lautet wie folgt:
% Title Page Variables
\title{Mining Partially Ordered Sequential Rules on Unbounded Data}
\author{Andriy Drozdyuk}
\def\previousDegrees{Bachelor of Computer Science, University of Toronto, 2001}
\def\subtitleTemplate{A Thesis Submitted in Partial Fulfillment
of the Requirements for the Degree of}
\def\degree{Masters of Computer Science}
\def\gau{Computer Science}
\def\supervisorMain{Michael W. Fleming, Ph.D., Professor, Faculty of Computer Science}
\def\supervisor{Scott Buffett, Ph.D., Adjunct Professor, Faculty of Computer Science}
\def\board{Name, Degree, Department, Chair}
\def\examiner{Name, Degree, Department/Field, Institution PhD Only}
\def\submissionDate{January, 2017}
\def\gradYear{2017}
\def\unb{\MakeUppercase{The University of New Brunswick}}
% Title Page Sizes
\def\mytitlewidth{12cm}
% Title Page Layout
\makeatletter
\begin{titlepage}
% Remember where the picture is relative to the page
% Overlay keeps the bounding box under control - prevents growing
% to encompass the referenced points (e.g. current page)
\begin{tikzpicture}[remember picture, overlay]
\node[yshift=-6cm] at (current page.north) (title) [text width=\mytitlewidth, align=center]{\LARGE\MakeUppercase{\@title}};
\node[yshift=-1cm] at (title) (by) [text width=\mytitlewidth, align=center]{by};
\node[yshift=-1cm] at (by) (author) {\Large\@author};
\node[yshift=-1cm] at (author) (previousDegrees) {\previousDegrees};
\node[yshift=-1cm] at (previousDegrees) (subtitle) {\subtitleTemplate};
\node[yshift=-1cm] at (subtitle) (degree) {\degree};
\node[yshift=-1cm] at (degree) (gau) {in the Graduate Academic Unit of \gau};
\node[right,yshift=-1cm] at (gau) (supervisors) {Supervisors:};
\node[right, xshift=4cm, align=left] at (supervisors) {\supervisorMain};
\node[right, xshift=4cm, yshift=-1cm,align=left] at (supervisors) {\supervisor};
\node[right,yshift=-2cm] at (supervisors) (examBoard) {Examining Board:};
\node[right,xshift=4cm] at (examBoard) {\board};
\node[right,yshift=-2cm] at (examBoard) (externalExaminer) {External Examiner:};
\node[right,xshift=4cm] at (examBoard) {\examiner};
\node[yshift=-3cm] at (externalExaminer) (acceptedBy) {This thesis is accepted by the};
\node[yshift=-1cm] at (acceptedBy) (dean) {Dean of Graduate Studies};
\node[yshift=-2cm] at (dean) (unb) {\unb};
\node[yshift=-2cm] at (unb) (submissionDate) {\submissionDate};
\copyright\node[yshift=-2cm] at (submissionDate) (authorYear) {\@author, \gradYear};
\end{tikzpicture}
\end{titlepage}
\makeatother
Antwort1
So einfach kann es schon losgehen (achten Sie dabei auf die tatsächlichen Voraussetzungen Ihrer Einrichtung):
\documentclass[12pt]{report}
\usepackage{newtxtext}
\usepackage[margin=1in]{geometry}
\begin{document}
\begin{titlepage}
\centering
\setlength{\parindent}{0in}
{\fontsize{16}{19}\selectfont%
MINING PARTIALLY ORDERED SEQUENTIAL RULES\\ ON UNBOUNDED DATA\par
}
\vskip2\baselineskip
by
\vskip2\baselineskip
Andriy Drozdyuk\par
Bachelor of Computer Science, University of Toronto, 2001
\vskip2\baselineskip
A Thesis Submitted in Partial Fulfillment of\\ the Requirements for the Degree of
\vskip2\baselineskip
Masters of Computer Science
\vskip2\baselineskip
in the Graduate Academic Unit of Computer Science
\vfill
\begin{tabular}{ll}
Supervisors: & Michael W. Fleming, Ph.D., Professor, Faculty of Computer Science\\
& Scott Buffett, Ph.D., Adjunct Professor, Faculty of Computer Science\\
& \\
Examining Board: & Name, Degree, Department, Chair\\
& \\
External Examiner: & Department/Field, Institution PhD Only
\end{tabular}
\vfill
This thesis is accepted by the\\
Dean of Graduate Studies
\vskip2\baselineskip
THE UNIVERSITY OF NEW BRUNSWICK\par
January, 2017
\vskip2\baselineskip
\copyright\ Andriy Drozdyuk, 2017
\end{titlepage}
\end{document}
Du bekommst das:
