Wie kann ich diesen komplexen Plot mit Tikz beenden?

Wie kann ich diesen komplexen Plot mit Tikz beenden?

Ich versuche noch einmal, eine ziemlich komplexe Figur in Tikz zu erstellen, aber es gelingt mir nicht. Dies ist die Ausgabe, die ich mir wünsche:

Bildbeschreibung hier eingeben

Dies ist mein bisher bester Versuch:

Bildbeschreibung hier eingeben

Und dies ist das MWE meines besten (aber schlechten) Versuchs:

\documentclass[dvipsnames]{standalone}
\usepackage{tikz,siunitx}
\usetikzlibrary{fit, calc, matrix, positioning, arrows.meta, intersections, through, backgrounds, patterns}

\begin{document}
\begin{tikzpicture}[node distance = 0pt, every pin/.style = {pin distance=11mm, pin edge={stealth-}}, every node/.style = {color=Blue!60!black}, dot/.style = {circle, fill=black, inner sep=0mm, minimum size=2mm, node contents={}}, line/.style = {-stealth, shorten >=1mm, shorten <= 1mm},]
\coordinate (O) at (0,0);
\coordinate[right=55mm of O] (X);
\coordinate[above=55mm of O] (Y);
\coordinate[above right=1 and 2 of O] (d);
\coordinate[right=2 of X |- Y] (e);
\coordinate (a) at (10,10);
\draw[-latex] ([xshift=-0.1] O) -- (X) node[right] {$h_1$};
\draw[-latex] ([yshift=-0.1] O) -- (Y) node[above] {$h_2$};
\draw[Blue, thick, scale=0.9,name path=B] ($(e)-(5.4,0)$) arc(180:270:5.5 and 4.4);
\path[name path=S] (O) -- (45:6);
\path[name intersections={of=B and S, by={s}}];
\coordinate[left =of s -| O] (s1);
\coordinate[below=of s |- O] (s2);
\draw[red,thick] let \p1 = ($(s)-(O)$), \n1 = {veclen(\x1,\y1)} in ($(O)+(\n1,0)$) arc(0:90:\n1);
\draw[densely dotted]  (s1) -|  (s2) node [pos=0.25,above] {$S^{\prime}$};
\node[dot,at=(s),pin=60:{$F(S^{\prime},d^{\prime})=(1,...,1)$}];
\path[name path=D] (s2) -- (15:8);
\draw[-] (0,0) -- (3.5,3.5);
\node [left] at (s1) {$1$};
\node [below] at (s2) {$1$};
\node [below] at (0,0) {$d^{\prime}=0$};
\node [right, yshift=-2.5pt] at (3.5,3.5) {$45\si{\degree}$};
\node [right] at (7.5,1.55) {$y_1y_2=1$};
\end{tikzpicture}
\end{document}

Kann mir jemand helfen, das gewünschte Ergebnis zu erzielen? Vielen Dank an alle für Ihre Zeit! :)

Antwort1

Eine recht einfache Möglichkeit, dieses Rechteck zu erstellen, besteht darin, ein gedrehtes Rechteck hinzuzufügen, nodeindem

\node[draw,minimum width=10cm,minimum height=6cm,anchor=north,rotate=-45] (rec) at (s) {};

Der Pfeil mit Text am Ende kann dann hinzugefügt werden mit

\draw [latex-] (rec.40) -- +(1cm,0) node[right] {$T = \{ y \in \mathbb{R}^{n} \mid \sum\limits_{i=1}^{n}y_{i} = n\}$};

Bildbeschreibung hier eingeben

\documentclass[dvipsnames,border=4mm]{standalone}
\usepackage{tikz,siunitx}
\usepackage{amsmath,amssymb}

\usetikzlibrary{fit, calc, matrix, positioning, arrows.meta, intersections, through, backgrounds, patterns}

\begin{document}
\begin{tikzpicture}[node distance = 0pt, every pin/.style = {pin distance=11mm, pin edge={stealth-}}, every node/.style = {color=Blue!60!black}, dot/.style = {circle, fill=black, inner sep=0mm, minimum size=2mm, node contents={}}, line/.style = {-stealth, shorten >=1mm, shorten <= 1mm},]
\coordinate (O) at (0,0);
\coordinate[right=55mm of O] (X);
\coordinate[above=55mm of O] (Y);
\coordinate[above right=1 and 2 of O] (d);
\coordinate[right=2 of X |- Y] (e);
\coordinate (a) at (10,10);
\draw[-latex] ([xshift=-0.1] O) -- (X) node[right] {$h_1$};
\draw[-latex] ([yshift=-0.1] O) -- (Y) node[above] {$h_2$};
\draw[Blue, thick, scale=0.9,name path=B] ($(e)-(5.4,0)$) arc(180:270:5.5 and 4.4);
\path[name path=S] (O) -- (45:6);
\path[name intersections={of=B and S, by={s}}];
\coordinate[left =of s -| O] (s1);
\coordinate[below=of s |- O] (s2);
\draw[red,thick] let \p1 = ($(s)-(O)$), \n1 = {veclen(\x1,\y1)} in ($(O)+(\n1,0)$) arc(0:90:\n1);
\draw[densely dotted]  (s1) -|  (s2) node [pos=0.25,above] {$S^{\prime}$};
\node[dot,at=(s),pin=60:{$F(S^{\prime},d^{\prime})=(1,...,1)$}];
\path[name path=D] (s2) -- (15:8);
\draw[-] (0,0) -- (3.5,3.5);
\node [left] at (s1) {$1$};
\node [below] at (s2) {$1$};
\node [below] at (0,0) {$d^{\prime}=0$};
\node [right, yshift=-2.5pt] at (3.5,3.5) {\SI{45}{\degree}};
\node [right] at (7.5,1.55) {$y_1y_2=1$};

\node[draw,minimum width=10cm,minimum height=6cm,anchor=north,rotate=-45] (rec) at (s) {};
\draw [latex-] (rec.40) -- +(1cm,0) node[right] {$T = \{ y \in \mathbb{R}^{n} \mid \sum\limits_{i=1}^{n}y_{i} = n\}$};
\end{tikzpicture}
\end{document}
