Angenommen, ich muss in einem Algorithmus innerhalb eines nummerierten Schritts Schritte hinzufügen und möchte, dass diese automatisch durch Buchstaben des Alphabets markiert werden.
Ich versuche es \begin{description} \end{description}, aber an einem bestimmten Punkt muss ich meinen Algorithmus aufteilen (langer Algorithmus), und die Verwendung einer Beschreibungsumgebung verursacht Probleme, wenn ich den Algorithmus aufteilen möchte. Kann mir jemand helfen?
\documentclass[a4paper,english,12pt,oneside]{book}
%\documentclass[11pt,draft]{article}
%\usepackage{fullpage}
%\usepackage[top=1in, bottom=1in, left=1in, %right=1in]{geometry}
%\usepackage[margin=1in, paperwidth=8.5in, paperheight=11in]{geometry}
\usepackage[left=2cm, right=2cm, top=2.5cm, bottom=2.5cm]{geometry}
%\usepackage[left=20mm]{geometry}
\usepackage[T1]{fontenc}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{graphicx}
\usepackage{refstyle}
\usepackage{subcaption}
\usepackage{amsmath}
\usepackage{amssymb}
\usepackage{enumerate}
\usepackage{epstopdf}
\usepackage{breqn}
\usepackage{mathtools}
%--------------------------------------------------------------------------------------------------
%\usepackage{a4wide}
\usepackage{amsfonts}
\usepackage{amstext}
\usepackage{amsthm}
\usepackage{newlfont}
\usepackage{graphics}
\usepackage{tabularx}
\usepackage{geometry}
\usepackage{lscape}
\usepackage{multirow}
\usepackage{epsfig}
%----------------------------------------------------------------------------------------------------
\usepackage{algorithm}
\usepackage{algcompatible}
\usepackage{algorithmicx}
\usepackage{algpseudocode}
\usepackage{pifont}
%\usepackage[lite]{mtpro2}
%----------------------------------------------------------------------------------------------------
%------------------------------------------------------------------------------------------------------------------------------
\usepackage{color}
\definecolor{violet}{rgb}{0.7,0.2,0.8}
\definecolor{bluevert}{rgb}{0,0.9,1}
\definecolor{trustcolor}{rgb}{0.71,0.14,0.07}
\definecolor{PinkTriton}{rgb}{.708 ,.055 ,.275}
\definecolor{RedTriton}{rgb}{.491 ,.097 ,.066} % couleur rouge du triton
\definecolor{OrangeTriton}{rgb}{.953 ,.502 ,.04}
%------------------------------------------------------------------------------------------------------------------------------
\usepackage[colorlinks=true,linkcolor=blue, citecolor=blue]{hyperref}
% define new commandes-------------------------------------------------------------------
\def\blank{\medskip\hrule\medskip}
%-----------------------------------------------------------------------------------------
\begin{document}
%\algstore{myalg}
% \end{algorithmic}
% \end{algorithm}
% \begin{algorithm}
% \begin{algorithmic} [1]
% \algrestore{myalg}
%-------------------------------------------------------------------------------------------------------
\begin{algorithm}
\caption{Square Root Cubature Kalman Filter SRCKF}
\textbf{Time update}
\begin{algorithmic}[1]
\State Factorize the state error covariance matrix
\begin{equation}
P_{k-1|k-1} = S_{k-1|k-1}S_{k-1|k-1}^T
\label{eq:Ref_3}
\end{equation}
\State Evaluate the cubature points (i=1,2,...,$m = 2n_x$)
\begin{equation}
X_{i,k-1|k-1} = \hat{x}_{k-1|k-1} + S_{i,k-1|k-1}\zeta_i
\label{eq:Ref_3}
\end{equation}
\State Evaluate the propagated cubature points through the process equation (i=1,2,...,$m = 2n_x$)
\begin{equation}
X_{i,k|k-1}^*=f(X_{i,k-1|k-1},u_{k-1})
\label{eq:Ref_3}
\end{equation}
\State Estimate the predicted state
\begin{equation}
\hat{x}_{k|k-1} = \frac{1}{m}\sum_{i=1}^m{X_{i,k|k-1}^*}Y
\label{eq:Ref_3}
\end{equation}
\State Estimate the predicted error covariance
\begin{equation}
P_{k|k-1}=\frac{1}{m}\sum_{i=1}^m{X_{i,k|k-1}^*X_{i,k|k-1}^{*T}}-\hat{x}_{k|k-1}\hat{x}_{k|k-1}^T+Q_{k-1}
\label{eq:Ref_3}
\end{equation}
\end{algorithmic}
\textbf{Measurement update}\\
\begin{algorithmic}[1]
\State Factorize the state error covariance matrix:
\begin{equation}
P_{k|k-1} = S_{k|k-1}S_{k|k-1}^T
\label{eq:Ref_3}
\end{equation}
\State Evaluate the cubature point (i=1,2,...,m)
\begin{equation}
X_{i,k|k-1} = \hat{x}_{k|k-1} + S_{k|k-1}\zeta_i
\label{eq:Ref_3}
\end{equation}
\State Evaluate the propagated cubature point through the measurement equation
\begin{equation}
Y_{i,k|k-1} = h(X_{i,k|k-1})
\label{eq:Ref_3}
\end{equation}
\begin{description}
\item[a.] Estimate the predicted measurement
\begin{equation}
\hat{y}_{k|k-1} = \frac{1}{m}\sum_{i=1}^m{Y_{i,k|k-1}}
\label{eq:Ref_3}
\end{equation}
\item[b.] Estimate the innovation covariance matrix
\begin{equation}
P_{yy,k|k-1} = \frac{1}{m}\sum_{i=1}^m{Y_{i,k|k-1}Y_{i,k|k-1}^T}-\hat{y}_{k|k-1}\hat{y}_{k|k-1}^T+R_k
\label{eq:Ref_3}
\end{equation}
\item[c.] Estimate the cross-covariance matrix
\begin{equation}
P_{xy,k|k-1}=\frac{1}{m}\sum_{i=1}^m{X_{i,k|k-1}Y_{i,k|k-1}^T}-\hat{x}_{k|k-1}\hat{y}_{k|k-1}^T
\label{eq:Ref_3}
\end{equation}
% split long alg-----------------------------------------------------------------------------------
\algstore{myalg}
\end{algorithmic}
\end{algorithm}
\clearpage
\begin{algorithm}
\ContinuedFloat
% \caption{Square Root Cubature Kalman Filter SRCKF (continued)}
\begin{algorithmic}
\algrestore{myalg}
%--------------------------------------------------------------------------------------------------
\item[d.] Estimate the Kalman gain
\begin{equation}
K_k=P_{xy,k|k-1}(P_{yy,k|k-1})^{-1}
\label{eq:Ref_4}
\end{equation}
\end{description}
\State Estimate the Updated state
\begin{equation}
\hat{x}_{k|k}=\hat{x}_{k|k-1}+K_k(y_k-\hat{y}_{k|k-1})
\label{eq:Ref_2}
\end{equation}
\State Estimate the corresponding error covariance
\begin{equation}
P_{k|k}=P_{k|k-1}-K_kP_{yy,k|k-1}K^T_k
\label{eq:Ref_3}
\end{equation}
\end{algorithmic}
\end{algorithm}
\end{document}
