Ich füge meinem Dokument den folgenden Code hinzu, um einen Baum zu zeichnen. Alles war in Ordnung, aber der Baum überlappt die zweite Spalte des Dokuments. Wie kann ich ihn so einfügen, dass er eine Spalte einnimmt oder sogar zwei Spalten hat, ohne dass er sich mit dem Text überlappt?
\documentclass[letterpaper, 10 pt, conference]{ieeeconf} \IEEEoverridecommandlockouts
\usepackage{tikz}
\newtheorem{definition}{\textbf{Definition}}
\overrideIEEEmargins
\usepackage{booktabs,lipsum,makecell}
\usetikzlibrary{arrows,shapes,positioning,shadows,trees}
\tikzset{
basic/.style = {draw, text width=2cm, drop shadow, font=\sffamily, rectangle},
root/.style = {basic, rounded corners=2pt, thin, align=center,
fill=green!30},
level 2/.style = {basic, rounded corners=6pt, thin,align=center, fill=green!60,
text width=8em},
level 3/.style = {basic, thin, align=left, fill=pink!60, text width=6.5em}
}
\title{\LARGE \bf
Test
}
\begin{document}
\maketitle
\thispagestyle{empty}
\pagestyle{empty}
\section{test}
bvkxvkxk lsjlfdjl ljsfjlsj lsjljl jljljl ljljl ljl jlj ljljl jljlj ljljlj lj ljl ljljlj l bvkxvkxk lsjlfdjl ljsfjlsj lsjljl jljljl ljljl ljl jlj ljljl jljlj ljljlj lj ljl ljljlj l
\begin{tikzpicture}[
level 1/.style={sibling distance=40mm},
edge from parent/.style={->,draw},
>=latex]
% root of the the initial tree, level 1
\node[root] {Drawing diagrams}
% The first level, as children of the initial tree
child {node[level 2] (c1) {Defining node and arrow styles}}
child {node[level 2] (c2) {Positioning the nodes}}
child {node[level 2] (c3) {Drawing arrows between nodes}};
% The second level, relatively positioned nodes
\begin{scope}[every node/.style={level 3}]
\node [below of = c1, xshift=15pt] (c11) {Setting shape};
\node [below of = c11] (c12) {Choosing color};
\node [below of = c12] (c13) {Adding shading};
\node [below of = c2, xshift=15pt] (c21) {Using a Matrix};
\node [below of = c21] (c22) {Relatively};
\node [below of = c22] (c23) {Absolutely};
\node [below of = c23] (c24) {Using overlays};
\node [below of = c3, xshift=15pt] (c31) {Default arrows};
\node [below of = c31] (c32) {Arrow library};
\node [below of = c32] (c33) {Resizing tips};
\node [below of = c33] (c34) {Shortening};
\node [below of = c34] (c35) {Bending};
\end{scope}
\foreach \value in {1,2,3}
\draw[->] (c1.195) |- (c1\value.west);
\foreach \value in {1,...,4}
\draw[->] (c2.195) |- (c2\value.west);
\foreach \value in {1,...,5}
\draw[->] (c3.195) |- (c3\value.west);
\end{tikzpicture}
\end{document}
Antwort1
nach dem Optimieren Ihres MWE (Änderungen werden im Code durch gekennzeichnet % <--- ...):
\documentclass[conference]{ieeeconf}
%\IEEEoverridecommandlockouts
%\overrideIEEEmargins
\usepackage{tikz}
\usetikzlibrary{arrows, positioning, shadows}
\usepackage{lipsum}
\title{Test}
\begin{document}
\maketitle
\thispagestyle{empty}
\section{test}
\lipsum*[11]% <--- added for dummy text
\begin{table}[ht]
\centering
\begin{tikzpicture}[
node distance = 3mm and 0mm, % <--- added
basic/.style = {draw, drop shadow, text width=18mm, inner xsep=2pt,
font=\sffamily\footnotesize}, % <-- changed
root/.style = {basic, rounded corners=2pt, align=center, fill=green!30},
level 2/.style = {basic, rounded corners=6pt, align=center, fill=green!60,
text width=22mm}, <-- changed
level 3/.style = {basic, align=left, fill=pink!60, text width=20mm}, <-- changed
sibling distance=27mm, <-- changed
edge from parent/.style={-latex,draw},
]
% root of the initial tree, level 1
\node[root] {Drawing diagrams}
% The first level, as children of the initial tree
child {node[level 2] (c1) {Defining node and arrow styles}}
child {node[level 2] (c2) {Positioning the nodes}}
child {node[level 2] (c3) {Drawing arrows between nodes}};
% The second level, relatively positioned nodes
\begin{scope}[every node/.style={level 3}] % <--- corrected positioning syntax
\node [below=of c1, xshift=5pt] (c11) {Setting shape};
\node [below=of c11] (c12) {Choosing color};
\node [below=of c12] (c13) {Adding shading};
\node [below=of c2, xshift=5pt] (c21) {Using a Matrix};
\node [below=of c21] (c22) {Relatively};
\node [below=of c22] (c23) {Absolutely};
\node [below=of c23] (c24) {Using overlays};
\node [below=of c3, xshift=5pt] (c31) {Default arrows};
\node [below=of c31] (c32) {Arrow library};
\node [below=of c32] (c33) {Resizing tips};
\node [below=of c33] (c34) {Shortening};
\node [below=of c34] (c35) {Bending};
\end{scope}
% lines from each level 1 node to every one of its "children"
\foreach \value in {1,2,3}
\draw[->] (c1.195) |- (c1\value.west);
\foreach \value in {1,...,4}
\draw[->] (c2.195) |- (c2\value.west);
\foreach \value in {1,...,5}
\draw[->] (c3.195) |- (c3\value.west);
\end{tikzpicture}
\caption{diagram}
\end{table}
\lipsum[1-23] % <--- added for dummy text
\end{document}
erhalte ich folgendes Ergebnis:
