So legen Sie in TColorBox Schattenumgebungsfelder in den linken, rechten und unteren Rändern fest. Ich habe in TColorBox viele Optionen mit Rahmenlinien, linken Linien usw. ausprobiert, die bei mir nicht funktioniert haben. Bitte helfen Sie uns, die Einstellungen gemäß den angehängten Bildern vorzunehmen. (Ignorieren Sie die schwarze Hervorhebung am unteren Rand des angehängten Bildes.)
Entschuldigung, hier ist der Code:
\documentclass{book}
\RequirePackage{amsmath,amssymb,lipsum,textcase,multicol}
\RequirePackage[breakable,hooks]{tcolorbox}
\tcbuselibrary{breakable,skins}
\makeatletter
\def\boxthreelabelfont{\noindent\fontsize{17bp}{14bp}\selectfont\bfseries\color{white}}
\def\boxthreetitlefont{\noindent\fontsize{11bp}{14bp}\selectfont\color{white}}
\def\boxthreetextfont{\noindent\fontsize{8.5bp}{11bp}\selectfont\parindent0pt\parskip9pt}
\newenvironment{Boxthree}[2][]{\begingroup\begin{tcolorbox}
[enhanced,breakable,%
arc=0pt,outer arc=0pt,boxrule=1pt,boxsep=0pt,top=22.7pt,left=14.5pt,right=15pt,bottom=5.5pt,middle=0pt,
bottomsep at break=0pt,topsep at break=2pt,
titlerule=0pt,titlerule style={gray,line width=0pt,},toptitle=9.9pt,bottomtitle=9.0pt,lefttitle=22pt,
righttitle=22pt,
title={{\boxthreelabelfont\MakeTextUppercase{#1}}\par\vskip4.5pt{\boxthreetitlefont\MakeTextUppercase{#2}}},
colbacktitle=black,colframe=gray,colback=white,rounded corners=southeast,
fontupper={\boxthreetextfont},
before skip=15pt,after skip=15pt,
toggle enlargement,
grow to left by=15pt,grow to right by=46pt, bottomrule at break=-8pt, toprule at break=-20pt,
arc=15pt,%leftrule=60pt,rightrule=60pt,
overlay={\draw[gray,line width=63pt]
(frame.south west) -- (frame.north west);}
%borderline={60pt}{20pt}{15black},
%leftrule=60pt
%overlay first={
%\fill[black!15,sharp corners] ([xshift=0pt]65pt,20pt) rectangle ([xshift=-0mm]frame.north west);
%\fill[black!15] (-35mm,-2.5mm) rectangle (145mm,6mm);}
%overlay last={
%\fill[black!15,sharp corners] ([xshift=0pt]65pt,20pt) rectangle ([xshift=-0mm]frame.north west);
%\fill[black!15] (-35mm,-2.5mm) rectangle (145mm,6mm);}
]\null\ignorespaces\removelastskip\vspace{-16.8\p@}\begin{multicols}{2}}{\end{multicols}\end{tcolorbox}\endgroup}
\def\boxtwobreak{\end{multicols}\pagebreak\begin{multicols}{2}}
\begin{document}
\begin{Boxthree}{Example 1.4}
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
\boxtwobreak
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
\end{Boxthree}
\end{document}
Antwort1
Ich bin mir nicht sicher, aber vielleicht möchten Sie einedrop midday shadow(Seite 185 in v4.20)
\documentclass{book}
\RequirePackage{amsmath,amssymb,lipsum,textcase,multicol}
\RequirePackage[breakable,hooks]{tcolorbox}
\tcbuselibrary{breakable,skins}
\makeatletter
\def\boxthreelabelfont{\noindent\fontsize{17bp}{14bp}\selectfont\bfseries\color{white}}
\def\boxthreetitlefont{\noindent\fontsize{11bp}{14bp}\selectfont\color{white}}
\def\boxthreetextfont{\noindent\fontsize{8.5bp}{11bp}\selectfont\parindent0pt\parskip9pt}
\newenvironment{Boxthree}[2][]{%
\begingroup\begin{tcolorbox}[%
enhanced,breakable,%
%arc=0pt, outer arc=0pt,
boxrule=1pt, boxsep=0pt, top=22.7pt, left=14.5pt, right=15pt, bottom=5.5pt, middle=0pt, bottomsep at break=0pt, topsep at break=2pt, titlerule=0pt,
titlerule style={gray, line width=0pt,},
toptitle=9.9pt, bottomtitle=9.0pt, lefttitle=22pt, righttitle=22pt,title={{\boxthreelabelfont\MakeTextUppercase{#1}}%
\par\vskip4.5pt{\boxthreetitlefont\MakeTextUppercase{#2}}},
colbacktitle=black,
colframe=gray,
colback=white, rounded corners=southeast,
fontupper={\boxthreetextfont}, before skip=15pt, after skip=15pt,
toggle enlargement, grow to left by=15pt, grow to right by=46pt, bottomrule at break=-8pt, toprule at break=-20pt,
arc=15pt,
drop midday shadow,
%
%
%leftrule=60pt,rightrule=60pt,
%overlay={\draw[gray,line width=63pt]
% (frame.south west) -- (frame.north west);}
%borderline={60pt}{20pt}{15black},
%leftrule=60pt
%overlay first={
%\fill[black!15,sharp corners] ([xshift=0pt]65pt,20pt) rectangle ([xshift=-0mm]frame.north west);
%\fill[black!15] (-35mm,-2.5mm) rectangle (145mm,6mm);}
%overlay last={
%\fill[black!15,sharp corners] ([xshift=0pt]65pt,20pt) rectangle ([xshift=-0mm]frame.north west);
%\fill[black!15] (-35mm,-2.5mm) rectangle (145mm,6mm);}
]\null\ignorespaces\removelastskip\vspace{-16.8\p@}\begin{multicols}{2}}{\end{multicols}\end{tcolorbox}\endgroup}
\makeatother
\def\boxtwobreak{\end{multicols}\pagebreak\begin{multicols}{2}}
\begin{document}
\begin{Boxthree}{Example 1.4}
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
\boxtwobreak
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
What made you decide to be a lawyer? Perhaps someone in your family introduced you to the idea, or you were inspired by a lawyer you had read about in a book or seen on TV or in a movie. Perhaps you had the opportunity to speak to a practising lawyer at some point in your life, or you attended a legal trial. Perhaps you have arrived at law school knowing that you have wanted to be a lawyer your entire~life.
By enrolling in your law degree, you have taken the first step in your journey towards becoming a member of a long-standing and honourable profession the legal profession.
\end{Boxthree}
\end{document}
