Tabelle mit verbundenen Zellen, Mehrfachindex und Textumbruch

Question

Ich hätte gerne einen Tisch der so aussieht.Hier istein Link zum Öffnen des Bildes in einem anderen Tab.

Für mich ist die Struktur wichtig. Die Formatierung dient lediglich dazu, zu zeigen, was ich in irgendeiner Weise vom Rest abheben möchte.

Wie mache ich:

1. Stellen Sie sicher, dass der Text umbrochen wird, wenn die Daten eine bestimmte Länge überschreiten.
2. Für die Zellen unten rechts eine Mehrfachspalte verwenden, wie im Bild?

Das habe ich:

\documentclass[11pt]{article}
\usepackage{multirow}
\begin{document}
 % Text data placeholder. May be long enough that it needs to be wrapped.
\begin{table}[ht]
    \begin{center}
        \begin{tabular}{cccc}
            \hline
            \multirow{2}{*}{Outer index 1} & Inner index 1.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & Inner index 1.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \hline
            \multirow{2}{*}{Outer index 2} & Inner index 2.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & Inner index 2.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \hline
            \multirow{6}{*}{Outer index 3} &  Inner index 3.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.3 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.4 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.5 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.5 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            &Inner index 3.6 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \hline
        \end{tabular}
    \end{center}
\end{table}

\end{document}

Eine bessere Formatierung ist willkommen. Fügen Sie gerne Ihre eigene Note hinzu.

Answer 1

Hierzu zählen:

• tabularxfür XTypspalten und eine Tabelle, die zur Textbreite passt
• \multicolumn für die Zellen, die sich über 2 Spalten erstrecken
• angepasste Werte um \multirowden Text in der ersten Spalte vertikal zu zentrieren
• ersetzt centerUmgebung durch \centeringwie die ehemalige fügt zusätzlichen weißen Raum um die Tabelle

• booktabsZur besseren Abstandsregelung wurden horizontale Linien aus der Verpackung verwendet .

  \documentclass[11pt]{article}

  \usepackage{multirow}
  \usepackage{geometry}
  \usepackage{tabularx}
  \usepackage{booktabs}
  \usepackage{ragged2e}
  \begin{document}

  \begin{table}[ht]
      \centering
          \begin{tabularx}{\textwidth}{cc>{\RaggedRight\arraybackslash}X>{\RaggedRight\arraybackslash}X}
              \toprule
              \multirow{6}{*}{Outer index 1} & Inner index 1.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              & Inner index 1.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              \midrule
              \multirow{6}{*}{Outer index 2} & Inner index 2.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              & Inner index 2.2 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              \midrule
              \multirow{9}{*}{Outer index 3} &  Inner index 3.1 & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
              &Inner index 3.2 & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
              &Inner index 3.3 & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{ Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
              \bottomrule
          \end{tabularx}
  \end{table}

  \end{document}


---

Auch hier habe ich multirowfür den Inhalt der zweiten Spalte verwendet:

\documentclass[11pt]{article}

\usepackage{multirow}
\usepackage{geometry}
\usepackage{tabularx}
\usepackage{booktabs}
\usepackage{ragged2e}
\begin{document}

\begin{table}[ht]
    \centering
        \begin{tabularx}{\textwidth}{cc>{\RaggedRight\arraybackslash}X>{\RaggedRight\arraybackslash}X}
            \toprule
            \multirow{6}{*}{Outer index 1} & \multirow{3}{*}{Inner index 1.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \multirow{3}{*}{Inner index 1.2} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \midrule
            \multirow{6}{*}{Outer index 2} & \multirow{3}{*}{Inner index 2.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \multirow{3}{*}{Inner index 2.2} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \midrule
            \multirow{9}{*}{Outer index 3} &  \multirow{3}{*}{Inner index 3.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \multirow{3}{*}{Inner index 3.2} & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
            & \multirow{3}{*}{Inner index 3.3} & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{ Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
            \bottomrule
        \end{tabularx}
\end{table}

\end{document}

---

Um den Text in der zweiten Spalte vertikal zu zentrieren, können Sie das makecellPaket auch in Kombination mit vertikal zentrierten XTypspalten verwenden, wie im folgenden MWE gezeigt:

\documentclass[11pt]{article}

\usepackage{multirow}
\usepackage{geometry}
\usepackage{tabularx}
\usepackage{booktabs}
\usepackage{ragged2e}
\usepackage{makecell}
\renewcommand{\tabularxcolumn}[1]{m{#1}}
\begin{document}

\begin{table}[ht]
    \centering
        \begin{tabularx}{\textwidth}{cc>{\RaggedRight\arraybackslash}X>{\RaggedRight\arraybackslash}X}
            \toprule
            \multirow{6}{*}{Outer index 1} & \makecell[cc]{Inner index 1.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \makecell[cc]{Inner index 1.2} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \midrule
            \multirow{6}{*}{Outer index 2} & \makecell[cc]{Inner index 2.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \makecell[cc]{Inner index 2.2} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            \midrule
            \multirow{9}{*}{Outer index 3} &  \makecell[cc]{Inner index 3.1} & Text data placeholder. May be long enough that it needs to be wrapped. & Text data placeholder. May be long enough that it needs to be wrapped.\\
            & \makecell[cc]{Inner index 3.2} & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
            & \makecell[cc]{Inner index 3.3} & \multicolumn{2}{>{\hsize=\dimexpr2\hsize+2\tabcolsep+\arrayrulewidth\relax\RaggedRight\arraybackslash}X}{ Text data placeholder. May be long enough that it needs to be wrapped.  Text data placeholder. May be long enough that it needs to be wrapped.}\\
            \bottomrule
        \end{tabularx}
\end{table}

\end{document}
