Anzeige ungerader Zahlen

Wie kann ich die ungeraden Zahlen auf dem anzeigen xticklabels? Bildbeschreibung hier eingeben

CODE:

\documentclass[margin=3mm]{standalone}
\usepackage[english,spanish]{babel}         % multilenguaje
\usepackage{pgfplots}
\usetikzlibrary{babel,
    positioning}
\pgfplotsset{compat=1.16,width=0.98\linewidth}



\usepackage{filecontents}
\begin{filecontents}{performance.data}
    x    A       B         C        D        E         F
    0.01 0.9126  0.9126   0.9313   0.9494   0.9524   0.9462
    0.02 0.8872  0.8872   0.8980   0.9044   0.9014   0.8966
    0.03 0.8713  0.8713   0.8747   0.8767   0.8737   0.8722
    0.05 0.8549  0.8549   0.8552   0.8541   0.8538   0.8532
    0.09 0.8710  0.8710   0.8700   0.8687   0.8676   0.8667
    0.10 0.8782  0.8782   0.8771   0.8751   0.8740   0.8738
    0.20 0.9301  0.9301   0.9281   0.9275   0.9269   0.9271
\end{filecontents}
\decimalpoint


\begin{document}
    \begin{tikzpicture}
    \begin{axis}[
    grid = none,
    legend style={at={(0.97,0.03)}, anchor=south east, draw=black},
%   legend cell align=left,
%   legend pos=north east,
    xmin=0.000499999999999999, xmax=0.2095,
    ylabel={RMSE},
    xlabel={$\lambda$},
    %
    xticklabel style={font=\small,
        /pgf/number format/fixed},
    yticklabel style={font=\small},
    %
    every axis plot post/.append style={line width=1.2pt},
    %
    mark size=1.3pt,
    cycle list={
        {blue,mark=*},
        {black,mark=*},
        {red,mark=*},
        {green,mark=*},
        {orange,mark=*},
        {cyan,mark=*},% <-- don't add a comma here
    },
    ]
    \addplot    table [y=A] {performance.data};
    \addlegendentry{20 f}
    \addplot    table [y=B] {performance.data};
    \addlegendentry{40 f}
    \addplot    table [y=C] {performance.data};
    \addlegendentry{60 f}
    \addplot    table [y=D] {performance.data};
    \addlegendentry{100 f}
    \addplot    table [y=E] {performance.data};
    \addlegendentry{150 f}
    \addplot    table [y=F] {performance.data};
    \addlegendentry{200 f}
    \end{axis}
    \end{tikzpicture}
\end{document}

Antwort1

Kommentar in Antwort umwandeln.

Sie können das xticksmanuell wie folgt angeben:

xtick={0.01,0.03,...,0.20},

sodass nur ungerade Häkchen angezeigt werden.

Ergebnis:

Bildbeschreibung hier eingeben

\documentclass[margin=3mm]{standalone}
\usepackage[english,spanish]{babel}         % multilenguaje
\usepackage{pgfplots}
\usetikzlibrary{babel,positioning}
\pgfplotsset{compat=1.16,width=0.98\linewidth}
\usepackage{filecontents}
\begin{filecontents}{performance.data}
    x    A       B         C        D        E         F
    0.01 0.9126  0.9126   0.9313   0.9494   0.9524   0.9462
    0.02 0.8872  0.8872   0.8980   0.9044   0.9014   0.8966
    0.03 0.8713  0.8713   0.8747   0.8767   0.8737   0.8722
    0.05 0.8549  0.8549   0.8552   0.8541   0.8538   0.8532
    0.09 0.8710  0.8710   0.8700   0.8687   0.8676   0.8667
    0.10 0.8782  0.8782   0.8771   0.8751   0.8740   0.8738
    0.20 0.9301  0.9301   0.9281   0.9275   0.9269   0.9271
\end{filecontents}
\decimalpoint


\begin{document}
    \begin{tikzpicture}
    \begin{axis}[
    grid = none,
    legend style={at={(0.97,0.03)}, anchor=south east, draw=black},
%   legend cell align=left,
%   legend pos=north east,
    xmin=0.000499999999999999, xmax=0.2095,
    ylabel={RMSE},
    xlabel={$\lambda$},
    %
    xtick={0.01,0.03,...,0.20},
    xticklabel style={font=\small,
        /pgf/number format/fixed},
    yticklabel style={font=\small},
    %
    every axis plot post/.append style={line width=1.2pt},
    %
    mark size=1.3pt,
    cycle list={
        {blue,mark=*},
        {black,mark=*},
        {red,mark=*},
        {green,mark=*},
        {orange,mark=*},
        {cyan,mark=*},% <-- don't add a comma here
    },
    ]
    \addplot    table [y=A] {performance.data};
    \addlegendentry{20 f}
    \addplot    table [y=B] {performance.data};
    \addlegendentry{40 f}
    \addplot    table [y=C] {performance.data};
    \addlegendentry{60 f}
    \addplot    table [y=D] {performance.data};
    \addlegendentry{100 f}
    \addplot    table [y=E] {performance.data};
    \addlegendentry{150 f}
    \addplot    table [y=F] {performance.data};
    \addlegendentry{200 f}
    \end{axis}
    \end{tikzpicture}
\end{document}
