Tikz: Ist es möglich, diese Form mit Pfeilen zu zeichnen?

Question

Ist es möglich, diese Form mit Tikz (im Grunde drei abgewinkelte Pfeile mit einer scharfen Spitze) mithilfe von Pfeilen zu zeichnen?

Answer 1

Etwas wie das?

\documentclass[tikz,border=3mm]{standalone}
\usetikzlibrary{arrows.meta}
\makeatletter
\pgfdeclarearrow{
  name = trident,
  parameters = {\the\pgfarrowlength,%
    \the\pgfarrowwidth,%
    \the\pgfarrowlinewidth,%
    \ifpgfarrowopen o\fi},
  setup code = {
    % The different end values:
    \pgfarrowssettipend{\pgfarrowlength}%
    \pgfarrowssetlineend{.01\pgfarrowlength}%
    \pgfarrowssetvisualbackend{-.1\pgfarrowlength}%
    \pgfarrowssetbackend{-.25\pgfarrowlength}%
% The hull
    \pgfarrowshullpoint{\pgfarrowlength}{0pt}%
    \pgfarrowshullpoint{0pt}{\pgfarrowwidth/2}%
    \pgfarrowshullpoint{0pt}{-\pgfarrowwidth/2}%
    \pgfarrowssavethe\pgfarrowlength%
  },
  drawing code = {%
    %\edef\pgf@orig@linewidth{\the\pgflinewidth}%
    \pgfutil@tempdima=-\pgfarrowlinewidth
    \advance\pgfutil@tempdima by 0.5\pgflinewidth
    \pgfpathmoveto{\pgfqpoint{0pt}{\pgfutil@tempdima}}%
    \pgfpathlineto{\pgfpoint{0pt}{0.5\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.9\pgfarrowlength}{0.5\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{\pgfarrowlength}{0.4\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.9\pgfarrowlength}{0.3\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.2\pgfarrowlength}{0.3\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.2\pgfarrowlength}{0.1\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.9\pgfarrowlength}{0.1\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{\pgfarrowlength}{0pt}}%
    \pgfpathlineto{\pgfpoint{0.9\pgfarrowlength}{-0.1\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.2\pgfarrowlength}{-0.1\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.2\pgfarrowlength}{-0.3\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.9\pgfarrowlength}{-0.3\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{\pgfarrowlength}{-0.4\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0.9\pgfarrowlength}{-0.5\pgfarrowwidth}}%
    \pgfpathlineto{\pgfpoint{0pt}{-0.5\pgfarrowwidth}}%
    \iftikz@mode@double
        \pgflineto{\pgfqpoint{0pt}{-\pgfutil@tempdima}}%
    \else
        \pgfpathclose
    \fi
    \tikz@mode@doublefalse
    \pgfsetlinewidth{+\pgfarrowlinewidth}%
    \ifpgfarrowopen\pgfusepathqstroke\else\ifdim\pgfarrowlinewidth>0pt\pgfusepathqfillstroke\else\pgfusepathqfill\fi\fi
},
  defaults = { length = 12pt,width=8pt,line width=0.4pt,open}
}
\makeatother
\begin{document}
\begin{tikzpicture}
    \draw [double distance=2pt,-{trident[open,line width=0.4pt]}]
    (0,0) -- (70:2);
    \draw [-{trident[width=10pt,length=14pt]}] (2,0) -- ++(70:2);
\end{tikzpicture}
\end{document}

Man könnte noch mehr Parameter einführen. Ich weiß nur nicht, was du vorhast.
